Kohler VERDERA K-29853T User manual

1461645-T01-A
-1- © Copyright Kohler China Investment Co., Ltd. 2020
© 版权为科勒（中国）投资有限公司所有 2020
ZHONGSHAN KOHLER SHOWER CO., LTD. NO13-1, XINGYE ROAD, ZHONGSHAN TORCH
DEVELOPMENT ZONE, ZHONGSHAN, GUANGDONG, CHINA POST CODE: 528437
中山科勒卫浴有限公司 广东省中山市中山火炬开发区兴业路 13-1 号邮编：528437
TOOLS REQUIRED 所需工具
φ6
ACCESSORIS LIST 附件清单
VERDERA DISPLAY 新维乐智讯
INSTALLATION INSTRUCTIONS
安装说明书
MIRRORED CABINET
镜柜
K-29853T/K-29854T/K-29855T/K-29856T
-1-
BEFORE YOU BEGIN 安装之前
© Copyright Kohler China Investment Co., Ltd. 2020
© 版权为科勒（中国）投资有限公司所有 2020
ZHONGSHAN KOHLER SHOWER CO., LTD. NO13-1, XINGYE ROAD, ZHONGSHAN TORCH
DEVELOPMENT ZONE, ZHONGSHAN, GUANGDONG, CHINA POST CODE: 528437
中山科勒卫浴有限公司 广东省中山市中山火炬开发区兴业路 13-1 号邮编：528437
• 请仔细阅读本指引，以便熟悉所需工具、物料及安装程序。请遵照
适用的章节来安装本产品，以免安装失当导致不必要的损失。除了
有关正确的安装方法之外，还务请详阅所有操作及安全指引。
• 本指引所载之一切资料，均以印刷时所有之最新产品情况为基础，
科勒中国保留权利随时更改产品特性、包装或供应情况，恕不另行
通知。
• 说明书包括重要的安装、清洁及保养方面的内容，请把这些资料交
给用户阅读，保管。
• 安装之前，仔细检查产品是否有损伤。
• 本产品符合 GB/T10357.4-2013, GB/T10357.5-2013，
GB24977-2010 和GB9254-2008。
• Please read these instructions carefully to familiarize yourself
with the required tools, materials, and installation sequences.
Follow the sections that pertain to your particular installation.
This will help you avoid costly mistakes. In addition to proper
installation, read all operating and safety instructions.
• All information in these instructions is based upon the latest
product information available at the time of publication. Kohler
China. reserves the right to make changes in product
characteristics, packaging, or availability at any time without notice.
• These instructions contain important care, cleaning, and warranty
information-please leave instructions for the consumer.
• Before installation carefully inspect the new fixture for any signs
of damage.
• The product complies with GB/T10357.4-2013,
GB/T10357.5-2013, GB24977-2010 and GB9254-2008.
WARNING: Risk of electrical shock. A licensed
electrician should make all electrical connections.
WARNING: Risk of electrical shock. Connect only to a
circuit protected by a typical two-pole circuit breaker.
WARNING: Risk of electrical shock. Disconnect power
before servicing.
警告：有触电的危险。
请找合格的电工来进行所有的线路连接。
警告：有触电的危险。
仅能和双极型断路器保护的电路连接。
警告：有触电的危险。
工作之前先切断电源。
ROUGHING-IN 尺寸图
UNIT: mm
单位 :毫米
Reference Value
参考值
K-29855T K-29856T
900
499 399 600
840
40
125
3PCS 2PCS 1PCS 14PCS 5PCS 5PCS 5PCS1PCS

Cabinet Installation 柜体安装
INSTALLATION 安装
-2-
1461645-T01-A
STEP1: Drill holes
安装步骤一：钻安装孔
ELECTRICAL PARTS LIST 电器部件清单
Item
序号
1
2
3
4
5
Electrical Function
电器功能
Power
电源
Defogger
防雾膜
Side Lighting
竖灯
Top Lighting
顶灯
Touch Screen
触摸屏
Type Description
规格描述
Input: 220V 50Hz, Pmax=60W
Input: DC24V, Pmax=15W
Input: DC24V, Pmax=16W, LED 4000K
Input: DC24V, Pmax=12W
Input: DC24V, Pmax=10W
Fixate Place
安装位置
Top of Cabinet
柜体顶部
On the back of the mirror
贴外镜背面
Two side of mirrored cabinet
镜柜两侧
Top of Cabinet
镜柜顶部
Attach the back of the mirror
贴外镜背面
Fix the mounting bar
to the wall, level the
mounting bar.
托承条固定到墙上，
保持水平。
Mirror cabinet plus holes width
800mm and above
镜柜宽度800mm及以上加此孔
≥40 mm from top part of the countertop
(such as faucet)
距台面最高点（如水龙头把手）≥40
L1
L 2
(1150mm) To Floor
(1150mm) 至地面
Drill holes - Ø 6mm
钻孔 - Ø 6mm
Model
型号
K-29853T
K-29854T
K-29855T
K-29856T
L1
760
460
760
460
L2
760
460
760
460
L3
781
781
814
814
L1
L2
L3
Kohler reserves the right to change marked dimensions without prior notice.
科勒公司保留随时变更图中标示尺寸的权利，无需另行通知。
K-29853T K-29854T
980
399499 125600
680
800

Installation and Adjustment of Accessories 配件安装及调节
STEP2: If needed, align the door.
安装步骤二：若有需要，可对柜门进行调整。
-3-
STEP2: Install the mounting bar. Place it level and fix it.
The number of screw holes is based on the actual product.
安装步骤二：安装托条，水平放置并固定。 螺钉孔数量以实物
为准。
1461645-T01-A
STEP3: Fix the cabinet
安装步骤三：固定柜体
1. Put the cabinet on the mounting bar.
1. 将柜体放在托条上。
2.
Slide the clips to align with the drilled holes. Fix with screws.
2. 滑动顶扣，对准上一步骤的钻孔后，用螺钉固定。
Installation of Side Mirror 侧镜安装
STEP1: Align the brackets with the mounting holes.
安装步骤一：将支架与安装孔对齐。
STEP2: Secure the brackets with the round-headed short screws.
安装步骤二：用圆头短螺钉将支架固定。
Note: When installed by cabinet splicing, side mirrors need
not be installed on the cabinet side.
注意：拼柜安装时，拼柜侧不用安装侧镜。
STEP1: Install the clips. Insert the shelves between the clips.
Insert the glass shelf into the snap-in pins, insert the glass
shelf vertically upwards and then rotate to horizontal position.
安装步骤一：安装夹子，将层板玻璃垂直插入层板夹，再旋转水
平后推入另一排层板夹中。
3
2
1
Top Clip
顶扣
Cabinet
柜体
Mounting Bar
托条

Installed Cabinet / 拼柜安装 Adjust magnifying glass / 调整放大镜
-4-
The bathroom shall be kept in good ventilation. Clean the
cabinet with water and soft cloth. Do not use detergent
containing abrasive and chemical substance.
卫生间尽量保持空气畅通，镜柜只能使用蘸有清水的湿布擦拭，
勿使用含研磨剂及化学物质的清洁剂。
警告！ 小心产品受损。
Warning! Risk of product damage.
USER MAINTENANCE 日常维护
1461645-T01-A
Power line connection 电源线接入
Wire Input
外部电源线输入
220V/50Hz
STEP1: Wiring.
安装步骤一：接线。
K-30552T can be installed by cabinet splicing. Add additional
connectors on the basis of the mounting bar and the top
clips. (86mm for models with light, 46mm for models without
light)
K-30552T 可拼柜安装，在托条与顶扣基础上增加连接件 （带灯
款用 86mm，不带灯款用 46mm）
STEP2: Fix top cover.
安装步骤二：固定顶盖 。
Wiring Terminal
Pull the orange handle until it is locked.
Insert the wire and restore the handle.
接线端子
扳动橙色操作手柄，直至其处于竖直锁
定位置，将导线插入，随后将手柄扳回
原位，接线完成。
Note: When installing the top cover of the top lighting version, you need to
first connect the U-shaped connector of the top cover to the top cover. Then,
tear off the double-sided adhesive on the connector, and glue the top cover
to the top of the mirror cabinet.
备注：顶灯版的顶盖安装时，需先将顶盖的 U 型连接件和顶盖连接后，再将
连接件上的双面胶撕下，将顶盖粘结在镜柜顶部。
Connectors
连接件 The mirror can be removed.
放大镜可以拆卸。
Direction
方向
Press the button to easily
move mirror up or down
按住此按钮可轻松上下移动
放大镜组件
To adjust mirror height, slide up or down.
IMPORTANT! Rotate mirror in before closing the door.
上下滑动，以调节镜子高度。
重要：必须在柜门关闭前旋入镜子。
