Kohler Natura 15457T User manual

BEFORE YOU BEGIN
BEFORE YOU BEGIN
INSTALLATION INSTRUCTIONS
K-15457T/K-
NATURA
MIRRORS
15458T
·
·
·
·
Please read these instructions carefully to familiarize
yourself with the required tools, materials, and installation
sequences. Follow the sections that pertain to your
particular installation . This will help you avoid costly
mistakes. In addition to proper installation, read all
operating and safety instructions.
All information in these instructions is based upon the
latest product information available at the time of
publication. Kohler China Ltd. reserves the right to make
changes in product characteristics, packaging, or
availability at any time without notice.
These instructions contain important care, cleaning, and
warranty information-
Obey all electrical regulations in force at the time of
installation.
Mirrored cabinets are very heavy and should
not be lifted or installed by just one person.
please leave instructions for the
consumer.
Warning! Risk of personal injury and product
damage.
·
·
·
·
-
SAFETY: WARNINGS
Kohler products are precision engineered and should give
continued superior and safe performance, provided:
1.They are installed, commissioned, operated and maintained
in accordance with the recommendations given in this
Manual.
2.Periodic attention is given, as necessary, to maintain the
product in good functional order. Recommended guidelines
are given in the section.
Carefully inspect the new fixture for any signs of damage.
When installing Kohler Products, manufacturers guidelines for
power tool safety should be followed.
MAINTENANCE
1.
2.
DESCRIPTION
Visible surfaces of natura mirror are white, and oak grain. The
series adopt E1 grade wood-based panel of high quality, and
with further processing, its harmful emissions will be less than
1.5mg/L.
E1
1.5mg/L
ORDERING INFORMATION
This installation covers the following products in the NATURA
range:
NATURA 700mm Mirror ..................15457T-FL/15457T-FH
NATURA 1050mm Mirror ................15458T-FL/15458T-FH
700mm ........................
1050mm ......................
15457T-FL/15457T-FH
15458T-FL/15458T-FH
-1-
, 2007
Copyright Kohler China Ltd., 2007
1
215500
1082404-T01-B

-2-
ROUGHING-IN
INSTALLATION
A. Install Mirror A.
UNIT : mm
Fig.1
1
15457T
Mirror
700mm(width) 15458T
Mirror
1050mm(width)
1915
1930
100
200
X/2
X
220-240V
100
1. X
2. ( )
1. Mark the position of hanged bracket on the wall according
to dimensions as illustrated. X dimension means the width
of mirror you will install.
2. Ensure that the electricity supply cables (three cores) for
illumination are installed.
Caution!
Note:
Avoid the cables and pipes inner set when
drilling in the wall.
Different types of bolts are required for different
decoration boards. Please apply suitable bolts and board nuts.
UNIT : mm
Spirit Level
X=Mirror Width
X=
Wall Bracket
1082404-T01-B

-3-
B. ( )
1. X
Fig.3
3
B. Install Hanged Bracket (Mirror Cabinet)
1. Mark the position of hanged brackets on the wall according
to dimensions as illustrated. X dimension means the width
of mirror cabinet.
3. Drill holes for fixing hanged bracket. Using level to make
sure that the hanged bracket is level.
4. Fix bracket on the wall with bolts and nuts.
5. Adjust bracket clips at the back of mirror to make sure that
the mirror is correctly hanged.
6. Hang the mirror on the wall, and position bracket clips on
hanged bracket.
7. Adjust the bolts in the bracket suspension, and make sure
that the mirror is level.
3.
4.
5.
6.
7.
1
2
Fig.2
2
UNIT : mm
Wall Bracket
X=Mirror Cabinet Width
X=
100
X/2
X
220-240V
734
1867
1930
Bracket Clip
100
Wall Bracket
Wall Bracket
1082404-T01-B

-4-
2. ( )
3.
4.
2. Ensure that the electricity supply cables (three cores) for
illumination are installed.
3.
Caution!
Note:
Avoid the cables and pipes inner set when
drilling in the wall.
Different types of bolts are required for different
decoration boards. Please apply suitable bolts and board nuts.
Drill holes for fixing hanged bracket. Using level to make
sure that the hanged bracket is level.
4. Fix bracket on the wall with bolts and nuts.
Warn! Risk of product damage.
1. Many cleansers contain abrasive and chemical substance
which is not suitable for cleaning stainless steel, enamel,
plating or plastic products. You may use mild cleansers or
soaps to clean the surfaces. Wipe any splashes of cleaner
solutions from the surface with clean soft cloth.
2. Maintain ventilation in the bathroom, and separate the dry
area from the damp one if conditions permit. Try to open
the door and windows of the bathroom and maintain good
ventilation.
3. Kohler bathroom cabinet are dealt with strict procedures
for damp-proof, whose good damp-proof function ensures
good performance even in bathroom of huge humidity. Yet
do not splash and pour water directly on the bathroom
cabinet. Make sure that the bathroom is not over damp
and wipe any splashes from surfaces immediately.
4. Maintenance of door board: Clean and wipe door board
regularly, and wipe the condensation vapor with dry and
soft cloth.
5. Ensure that electrical connections for appliances such as
head lamp is insulated ; wipe mirror surface with chamois
regularly to guarantee the persistent excellent performance.
6. Please do not sit, lean or step on the cabinet.
1.
2.
3.
4.
5.
6.
USER MAINTENANCE
USER MAINTENANCE
1082404-T01-B

K-15457T/K-
NATURA
SERVICE PARTS PAGE
MIRRORS
15458T
-5-
**
** Color code must be specified when ordering.
1081582
Mirror Hanging
Hook; 2 PC
1081578
Screw For Holder;
4PC
1081550
Expanding Dowel;
2PC
sx 8 40
1081577
Mirror Hanging
Holder; 2 PC
