Koso GP style User manual

ODO<ADJUST>TRIP
X1000 rpm
3
1
Please contact the local distributor if the items you open are not the same, with the above-listed one.
Thank you for purchasing KOSO GP style speedometer, led night-back-lighted, multi-function in one. easy-wiring. Clear-controlling and easy-using.
WARNING!
CAUTION!
MARK MEANING:
PRESS THE
BUTTON ONE TIME PRESS THE
BUTTON 3
SECONDS
Tachometer
Display range: 0~15000 RPM.
Display unit: 100 RPM.
Speedometer
display range: 0~160 km/h. 0~100 MPH.
display unit: km/h / MPH.
Odo meter
Display range: 0~99999 km
Display unit: 1 km.
Trip meter
Display range: 0~999.9 km
Display unit: 0.1 km.
,
reset automatically after 99999 km.
,
reset automatically after 999.9 km.
Temperature
Display range:
Display unit:
o
0~120 C.
o
1 C.
Tachometer warning light
Setting range: 5000~15000 RPM.
Adjusting unit: 100 RPM.
>Regarding the setting,
please check 4-2.
500 RPM BEFORE THE SETTING OVER-RPM
The indicator light will differ
from different models.
4-1
4-2
Speeding warning light setting instruction.
Tachometer warning light setting instruction.
Press the button to select the number
you want to set. (Now you are in the speeding
warning light setting screen)
ADJUST
Now 30 & speed is flashing.
Now 60 (The number you want to set) &
speed is flashing.
Press the button to select the number
you want to set.
ADJUST
Setting range: 30~160 km/h.
Adjusting unit: 5 km/h.
Now 5000 (The number you want to set)
& tachometer warning light is flashing.
Setting range:
Adjusting unit:
5000~15000 RPM.
100 RPM.
Press the button 3 times to
main screen.
EX. The setting is changed from 30 km/h to 60
km/h.
SELECT back the
Main screen.
Now in setting screen. Press the
button 1 time to enter the
warning light setting screen.
SELECT
tachometer
Now 30 (The number you want to set) &
speed is flashing.
Hold down the button to
increase the setting number fast.
ADJUST
The setting screen is a circle in order
as the following, the speeding
warning setting> the tachometer
warning setting> the temperature
warning setting> main screen.
CAUTION! Please start the setting
when the motorcycle is
stopped (0 km/h).
In main screen, press down the
& button for 3 seconds to enter the
speeding warning light setting screen.
SELECT
ADJUST
In main screen, press down the &
button for 3 seconds to enter the
speeding warning light setting screen.
SELECT
ADJUST
1.The lcd meter is apply for DC 12V.
2.for installation, please follow the steps described in manual. any damage caused by wrong installation shall be imputed to the users.
3.don't break or modify the wire terminal. to avoid the short circuit, please don't pull the wire when installing.
4.do not disassemble or change any parts excluding the manual description.
5.the interior examination or maintenance should be executed by our professionals.
6.if you find the needle is auto-reset by itself, please check your battery situation. if the battery can't provide enough voltage, it will
cause the meter auto-reset.
INsTRUCTION
Notice
Accessory
You could get the installation details from the information behind the mark.
Some processes must be followed to avoid the affection caused by wrong installation.
Some processes must be followed to avoid damages to yourself or the public.
Some processes must be followed to avoid the damage to the vehicle.
1Meter X 1 2RPM wire set X 1
Function instruction
Speeding warning light
Setting range: 30~160 km/h.
Adjusting unit: 5 km/h.
>Regarding the setting, please check 4-1.
Temperature warning light
Setting range: 6
Adjusting unit:
>Regarding the setting, please check 4-3.
o
0~120 C.
o
1 C.
Fuel symbol
Display range:
he fuel reserve symbol begins
to flash if only 3 grids left.
16levels.
T
ODO<ADJUST>TRIP
X1000rpm
3
ODO<ADJUST>TRIP
X1000 rpm
ODO<ADJUST>TRIP
X1000 rpm
ODO<ADJUST>TRIP
X1000 rpm
ODO<ADJUST>TRIP
X1000 rpm
ODO<ADJUST>TRIP
X1000 rpm
ODO<ADJUST>TRIP
X1000 rpm
ODO<ADJUST>TRIP
X1000 rpm
2Wiring installation instructions
CAUTION! Just wind the rpm wire onto the spark plug wire, do not connect them! Also we suggest you to replace the spark "R" in the
meantime.
Meter (Accessory 1)
1.Please remove the original meter and install the KOSO radar series speedometer, then fix the cable
wire and meter.
2.Use the washer (Accessory 3) and screw (Accessory 4) to fix the meter on handle-bar cover.
3.Wind the rpm sensor onto the spark plug cap. RPM sensor wire (Accessory 2)
Manual
4
5
M3 washer X 4 M3 screw X 4
wh802ba001
speedometer
KOSO GP style

4-3 Temperature warning light setting instruction.
Now 30 & speed is flashing.
Now 60 (The number you want to set) &
warning light is flashing.temperature
Now 8000 (The number you want to set)
& tachometer warning light is flashing.
o
Setting range: 0~150 C.
o
Adjusting unit: 1 C
6
.
Press the button 2 times to
main screen.
EX. The setting is changed from 5000 RPM
to 8000 RPM.
SELECT back
the
5Trip reset instruction
In main screen, press the button to
switch the odometer to trip meter.
ADJUST Press down the button for 3 seconds,
and then the trip meter will be reset.
ADJUST Now the trip meter is reset.
Now 90 (The number you want to set) &
warning light is flashing.temperature
press the button to back the main
screen. oo
EX. The setting is changed from 60 C to 90 C.
SELECT
Now in setting screen. press the
button 2 times to enter the
warning light setting screen.
SELECT
temperature
Press the button to select the number
you want to set.
ADJUST
In main screen, press down the &
button for 3 seconds to enter the
speeding warning light setting screen.
SELECT
ADJUST
ODO<ADJUST>TRIP
X1000 rpm
ODO<ADJUST>TRIP
X1000 rpm
ODO<ADJUST>TRIP
X1000 rpm
ODO<ADJUST>TRIP
X1000 rpm
ODO<ADJUST>TRIP
X1000 rpm
ODO<ADJUST>TRIP
X1000 rpm
ODO<ADJUST>TRIP
X1000 rpm
ODO<ADJUST>TRIP ODO<ADJUST>TRIP
X1000 rpm X1000 rpm
ODO<ADJUST>TRIP
X1000 rpm
Main screen.
Main screen.
wh802ba001
