KPS DMM3000 User manual

User Manual / MANUAL DEL USUARIO /
Manuel d'utilisation /
Benutzerhandbuch / Manuale Utente
DMM3000
LIMITED
WARRANTY
YEARS
IT
EN All New True RMS Multimeter
Multímetro de valor eficaz verdadero totalmente rediseñado
Multimètre RMS (« valeurs efficaces vraies ») avec tout
nouveau design
Ganz neu gestaltetes True RMS Vielfachmessgerät
Multimetro a vero valore efficace di progettazione
assolutamente nuova

EN
DMM3000
Safety Information
!
Read First
!
Understand and follow operating instructions carefully.
WARNING
!
Identifies hazardous conditions and actions that could cause
BODILY HARM or DEATH.
WARNING
!
•When using test leads or probes, keep your fingers behind the
finger guards.
•Remove test lead from Meter before opening the battery door or
meter case.
•Use the Meter only as specified in this manual or the protection
by the Meter might be impaired.
•Always use proper terminals, switch position, and range for
measurements.
•Verify the Meter’s operation by measuring a known voltage.
If in doubt, have the Meter serviced.
•Do not apply more than the rated voltage, as marked on Meter,
between terminals or between any terminal and earth ground.
•Only replace the blown fuse with the proper rating as specified
in this manual.
•Use caution with voltages above 30 Vac rms, 42 Vac peak,or 60
Vdc. These voltages pose a shock hazard.
•To avoid false readings that can lead to electric shock and
injury, replace battery as soon as low battery indicator.
•Disconnect circuit power and discharge all high-voltage
capaci-tors before testing resistance, continuity, diodes, or
capacitance.
•Do not use Meter around explosive gas or vapor.
•To reduce the risk of fire or electric shock do not expose this
product to rain or moisture.
CAUTION
!
Identifies conditions and actions that could DAMAGE the meter or
equipment under test.
1

EN
DMM3000
CAUTION
!
•Disconnect the test leads from the test points before changing
the position of the function rotary switch.
•
Do not expose Meter to extremes in temperature or high humidity.
•1HYHUVHWWKHPHWHULQȍ$IXQFWLRQWRPHDVXUHWKH
voltage of a power supply circuit in equipment that could result
in damage the meter and the equipment under test.
Symbols as marked on the meter and
Instruction manual
~
Risk of electric shock
See instruction manual
DC measurement
Equipment protected by double or reinforced insulation
Battery
Fuse
Earth
AC measurement
Conforms to EU directives
Do not discard this product or throw away
Attention! Magnets might affect the correct functioning
of cardiac pacemakers and implanted defibrillators.
As a user of such medical devices, keep a sufficient
distance to the magnet.
!
To alert you to the presence of a potentially hazardous voltage,
when the Tester detects a voltage ≧30 V or a voltage overload
(OL) in V, mV, AutoV . The symbol is displayed.
Unsafe Voltage
Do not attempt to repair this Meter.
It contains no user-serviceable parts. Repair or servicing should
only be performed by qualified personnel.
Maintenance
Periodically wipe the case with a dry cloth and detergent.
Do not use abrasives or solvents.
Cleaning
2

EN
DMM3000
1VoltSeek Light
2LCD Display
3Button
4Rotary Switch
6Common lnput
7A lnput
5V , , , lnput(or ”+”)
The Meter Description
Front Panel Illustration
1. VoltSeek Light
2. 6,000 counts digital and 60 segments analog display
3. Push-buttons.
4. Rotary switch for turn the Power On / Off and select the
function.
5. Input Terminal for Multi-function.
6. Input Terminal for A.
7. Common (Ground reference) Input Terminal.
Introduction
3

EN
DMM3000
•6,000 count digital and 60 segments analog display
•Large white LED backlight display
•True RMS measurements on ACV
•LoZ for prevent false reading from ghost voltage
•AutoVolt automatic AC/DC voltage selection
•Auto Ranging
•0.5% DCV accuracy
•Smart Hold
•Peak Hold for capture peak readings
•Relative Function
•Auto Power Off (can be disabled)
•Capacitance measurements
•Frequency Counter on ACV
•Diode Test
•Frequency Counter on ACA
•10Amp ACA/DCA
•11A/1000V High Energy Fuse
•VoltSeekTM for non-contact voltage detection
•EasyStickTM holster with built in magnetic sticker
•ContiVisionTM for visible continuity beeper
•Battery Capacity indication in segments
•Included Holster with Probe Holder, Tilt Stand and Magnetic
sticker
•CAT IV 600V/ CATIII 1000V standard
Features :
Making Basic Measurements
Preparation and Caution Before Measurement
Observe the rules of Warnings and Cautions.
! !!
CAUTION
!
When connecting the test leads to the DUT (Device Under Test)
connect the common test leads before connecting the live test
leads ; when removing the test leads, remove the live test leads
before removing the common test leads.
4

EN
DMM3000
Measuring ACV/DCV/AutoV Voltage
Dial the switch to select the measuring function.
Disconnect
Measuring AC/DC Current
Dial the switch to select the measuring function.
5

EN
DMM3000
Measuring Capacitance / Diode
Dial the switch and press the Function button to select the
measuring function
Measuring Continuity / Resistance
Red Black
Dial the switch and press the Function button to select the
measuring function.
6

EN
DMM3000
WARNING
!
The VoltSeek LED indicates the electric field. If the VoltSeek LED
is not on, voltage could still be present.
VoltSeek
Dial the switch and press the RANGE button to select the
measuring function and sensitivity.
Switch
Position Function
Using the Function
Press the Function button to change the function on the same
switch position.
7

EN
DMM3000
Press Ragen Button >2 Sec to Auto Mode
1
123
Range Button
Press
Leave the peak hold mode
Button > 2 sec
Peak Hold (for AC only)
In the Peak Hold function ,the meter records the peak min. value
and the peak max. value when the inputs goes below the recorded
peak min. value or above the recorded peak max. value ,the meter
records the new value . Press Hold button to pause the recording.
8

EN
DMM3000
Smart Hold
The meter will beep continuously and the display will flash if the
measured signal is larger than the display reading by 50 counts.
(However ,it can not detect across the AC and DC Voltage /
Current).
5HODWLYHǻ
Press the Relative button to enable/disenable this function.
Backlight
Press the Backlight button to turn the backlight on/off.
9

EN
DMM3000
Auto Power Off
Wake-up the meter by dialing the switch or pressing any button.
Disable Auto Power Off
Dial the switch to off position ,then keep the Function button down
and turn the meter on.
10

EN
DMM3000
Testing LCD Monitor
Dial the switch to off position ,then keep the HOLD button down
and turn the meter on.
Fuse Replacement
Fuse:11A/1000V
11

EN
DMM3000
CAUTION
!
Remove test leads from meter before opening the battery cover or
meter case.
Low Battery and Battery Replacement
Replace the battery as soon as the low battery indicator
appears, to avoid false reading.
Refer to the following figure to replace the batteries
12

EN
DMM3000
Specifications
General Specifications
Maximum voltage applied to any terminal :
1000 Vac rms or 1000 Vdc. rms
Display : 6000 counts.
Polarity Indication : Automatic, positive implied, negative
indicated.
Overrange Indication : OL
Batteries Life : 200 hours ALKALINE Battery
Low Batteries Indication :
Voltage drops below operating voltage will flash.
Power Requirement : 9V battery
Auto Power Off : 20 minutes.
Operating Temperature : -10 ~10°C
10°C ~ 30°C (≦80% RH),
30°C ~ 40°C (≦75% RH),
40°C ~ 50°C (≦45%RH)
Storage Temperature :
-40°C to 60°C , 0 to 80% R.H. (batteries not fitted)
Measure : Samples 3 times per second .
Altitude : 6561.7 ft (2000m)
ⅠThe circuits not connected to mains.
Ⅱ
The circuits directly connected to Low-voltage installation.
ⅢThe building installation.
ⅣThe source of the Low-voltage installation.
CAT Application field
Weight : 250g (including battery)
Dimensions (W x H x D) : 74mm x 156mm x 44mm.
Pollution degree : 2
Safety : Complies with EN61010-1,CAT.IV. 600V, CAT.Ⅲ. 1000V
EMC : EN 61326-1
Shock vibration : Sinusoidal vibration per MIL-PRF- 28800F
(5 ~ 55 Hz, 3g max.)
Drop Protection : 4 feet drop to hardwood on concrete floor.
Indoor Use.
13

EN
DMM3000
Accuracy is given as ±(% of reading + counts of least significant
digit) at 23°C ± 5°C, with relative humidity Less than 80% R.H.
1. Temperature coefficient
0.1 x (Specified accuracy) / °C, < 18°C, > 28°C
2. AC Function
ACV and ACA specifications are ac coupled, true R.M.S. The
crest factor may be up to 3.0 as 4000 counts.
For square wave, Accuracy is unspecified.
For non-sinusoidal waveforms, Additional Accuracy by Crest
Factor (C.F.) : Add 3.0% for C.F. 1.0 ~ 2.0.
Add 5.0% for C.F. 2.0 ~ 2.5.
Add 7.0% for C.F. 2.5 ~ 3.0.
Range OL Reading Resolution Accuracy
600.0mV 660.0mV 0.1mV ±(0.5% + 5D)
Input Impedance :0ȍ
Overload Protection : AC/DC1000V
3. DC mV
Electrical Specifications
Range OL Reading Resolution Accuracy
6.000V 6.600V 0.001V
±(0.5% + 2D)
60.00V 66.00V 0.01V
600.0V 660.0V 0.1V
1000V 1100V 1V
Input Impedance : 0ȍ
Overload Protection : AC/DC 1000V
4. DC Voltage
14

EN
DMM3000
Range OL Reading Resolution Accuracy
600.0mV 660.0mV 0.1mV ±(1.0% + 5D)
6.000V 6.600V 0.001V
±(1.0% + 3D)
60.00V 66.00V 0.01V
600.0V 660.0V 0.1V
1000V 1100V 1V
LCD displays 0 counts when the reading < 10 counts.
Input Impedance: 0ȍOHVVWKDQS)
Frequency Response: 45~500Hz(Sine Wave)
Overload Protection: AC/DC 1000V
5. AC Voltage
Range OL Reading Resolution Accuracy
600.0V 660.0V 0.1V ±(2.0% + 3D)
1000V 1100V 1V
LCD displays 0 counts when the reading < 10 counts.
Input Impedance : OHVVWKDQNȍ
Frequency Response : 45 ~ 500Hz (Sine Wave)
Overload Protection : AC/DC 1000V
6. Auto Voltage
Range OL Reading Resolution Accuracy
6.000A 6.600A 0.001A ±(1.0% + 3D)
10.00A 20.00A 0.01A
Maximum measurement time :
>5A for max.3 minutes with at least 20 minutes rest time.
>10A for max.30 seconds with at least 10 minutes rest time.
Overload Protection : AC/DC 11A
7. DC Current
15

EN
DMM3000
Range OL Reading Resolution Accuracy
6.000A 6.600A 0.001A
±(1.5% + 3D)
10.00A 20.00A 0.01A
In 6A Range,LCD displays 0 counts when the reading < 20 counts.
In10A Range,LCD displays 0 counts when the reading < 10 counts.
Maximum measurement time :
>5A for max.3 minutes with at least 20 minutes rest time.
>10A for max.30 seconds with at least 10 minutes rest time.
Frequency Response : 45 ~ 500Hz (Sine Wave)
Overload Protection : AC/DC 11A
8. AC Current
Range OL Reading Resolution Accuracy
ȍ ȍ ȍ ±(0.9% + 5D)
Nȍ Nȍ Nȍ ±(0.9% + 2D)
Nȍ Nȍ Nȍ ±(0.9% + 2D)
Nȍ Nȍ Nȍ ±(0.9% + 2D)
0ȍ 0ȍ 0ȍ ±(0.9% + 2D)
0ȍ 0ȍ 0ȍ ±(1.5% + 5D)
7KHUHLVDOLWWOHUROOLQJOHVVWKDQGLJLWVZKHQPHDVXULQJ!
0ȍ
Overload Protection : AC/DC 1000V
9. Resistance
Range OL Reading Resolution Accuracy
ȍ ȍ ȍ ±(0.9% + 5D)
Continuity : Built-in buzzer sounds when measured resistance is
OHVVWKDQȍDQGVRXQGVRIIZKHQPHDVXUHGUHVLVWDQFHLVPRUH
WKDQȍ%HWZHHQȍWRȍWKHEX]]HUPD\EHVRXQGRURII
either.
Continuity Indicator : 2KHz Tone Buzzer
Response Time of Buzzer : ȝVHF
Overload Protection : AC/DC 1000V
10. Continuity
16

EN
DMM3000
Range OL Reading Resolution Accuracy
1.500V 1.550V 0.001V ±(0.9% + 2D)
Open Circuit Voltage : Approx. 1.8V
Overload Protection : AC/DC 1000V.
11. Diode
Range OL Reading Resolution Accuracy
1.000μF 1.100μF 0.001μF±(1.9% + 5D)
10.00μF 11.00μF0.01μF
±(1.9% + 2D)
100.0μF 110.0μF0.1μF
1.000mF 1.100mF 0.001mF
10.00mF 11.00mF 0.01mF
Overload Protection : AC/DC 1000V.
12. Capacitance
Range OL Reading Resolution Accuracy
100.00Hz 100.00Hz 0.01Hz
±(0.1% + 2D)
1000.0Hz 1000.0Hz 0.1Hz
10.000kHz 10.000kHz 0.001kHz
100.00kHz 100.00kHz 0.01kHz
Minimum Sensitivity : > 5V (for ACV 1Hz ~ 10kHz)
> 20.0V (for ACV 10kHz ~ 50kHz)
unspecified (for ACV 50kHz ~ 100kHz)
>0.6A (for ACA)
Minimum Frequency : 1Hz
Overload Protection : AC/DC 1000V or 11A
14. Peak Hold
Specified accuracy ± 150 digits.
Accuracy of Square Wave is unspecified.
15. VoltSeek
Voltage Range of High Sensitivity :
80V ~ 1000V (At the top edge of the meter)
Voltage Range of Low Sensitivity :
160V ~ 1000V (At the top edge of the meter)
13. Frequency
17

EN
DMM3000
This meter is warranted to the original purchaser against defects
in material and workmanship for 2 years from the date of
purchase. During this warranty period, Manufacturer will, at its
option, replace or repair the defective unit, subject to verification
of the defect or malfunction.
This warranty does not cover fuses, disposable batteries, or
damage from abuse, neglect, accident, unauthorized repair,
alteration, contamination, or abnormal conditions of operation or
handling.
Any implied warranties arising out of the sale of this product,
including but not limited to implied warranties of merchantability
and fitness for a particular purpose, are limited to the above. The
manufacturer shall not be liable for loss of use of the instrument
or other incidental or consequential damages, expenses, or
economic loss, or for any claim or claims for such damage,
expense or economic loss. Some states or countries laws vary,
so the above limitations or exclusions may not apply to you.
Limited Warranty
18

ES
DMM3000
Información de seguridad
!
Lea primero
!
Comprenda y siga cuidadosamente las instrucciones de
funcionamiento.
ADVERTENCIA
!
Esto identifica situaciones de peligro que pudieran causar DAÑO
CORPORAL o MUERTE.
ADVERTENCIA
!
• Cuando utilice puntas de prueba o sondas, mantenga los dedos
detrás de los protectores de mano.
• Retire la punta de prueba del amperímetro antes de abrir la tapa
de las pilas o la carcasa.
• Utilice el amperímetro solo según lo especificado en este
manual, de lo contrario la protección podría verse mermada.
• Utilice siempre los bornes adecuados, así como la posición del
Conmutador y rango para mediciones correctos.
• Verifique el funcionamiento del amperímetro midiendo un tensión
conocida. En caso de duda, mande el amperímetro a reparar.
• No aplique más de la tensión nominal, según marque el
amperímetro, entre bornes o entre cualquier borne y tierra.
• Sólo reemplace un fusible quemado con otro del valor adecuado
según lo especificado en este manual.
• Tenga cuidado con las tensiones por encima de 30VCA RMS,
42VCA pico o ±30VCC. Estas tensiones representan un peligro
de electrocución.
• Para evitar lecturas erróneas que pueden provocar descargas
eléctricas y lesiones, reemplace la pila según salga el indicador
de pila baja.
• Desconecte la alimentación del circuito y descargue todos los
condensadores de alta tensión antes de la prueba de
resistencia, continuidad y diodos o capacitancia.
• No opere el amperímetro alrededor de gases explosivos, vapor o
polvo.
• Para reducir el riesgo de incendio o descarga eléctrica no
exponga este producto a la lluvia o la humedad.
PRECAUCÍON
!
Esta señal indica que se da una situación de peligro que podría
DAÑAR el amperímetro o el equipo que se está probando.
19
