Kramer VP-300THD User manual

Kramer Electronics, Ltd.
Preliminary
USER MANUAL
Model:
VP-300THD
1:2 XGA/HD DA/CAT 5 Transmitter

Contents
i
Contents
1Introduction 1
2Getting Started 1
2.1Quick Start 2
3Overview 3
3.1About the Power Connect Feature 4
3.2Shielded Twisted Pair (STP) / Unshielded Twisted Pair (UTP) 4
4Your VP-300THD 1:2 XGA/HD DA/CAT 5 Transmitter 5
5Connecting the VP-300THD 6
5.1Wiring the CAT 5 LINE IN / LINE OUT RJ-45 Connectors 8
6Technical Specifications 8
Figures
Figure 1: VP-300THD 1:2 XGA/HD DA/CAT 5 Transmitter 5
Figure 2: VP-300THD 1:2 XGA/HD DA/CAT 5 Transmitter (Underside) 6
Figure 3: Connecting the VP-300THD 7
Figure 4: CAT 5 PINOUT 8
Tables
Table 1: VP-300THD 1:2 XGA/HD DA/CAT 5 Transmitter Features 5
Table 2: VP-300THD 1:2 XGA/HD DA/CAT 5 Transmitter (Underside) Features 6
Table 3: CAT 5 PINOUT 8
Table 4: Technical Specifications of the VP-300THD (with 30m CAT 5 cable) 8

Introduction
1
1 Introduction
Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been
providing a world of unique, creative, and affordable solutions to the vast
range of problems that confront the video, audio, presentation, and
broadcasting professional on a daily basis. In recent years, we have
redesigned and upgraded most of our line, making the best even better! Our
1,000-plus different models now appear in 11 groups1 that are clearly
defined by function.
Thank you for purchasing the Kramer VP-300THD 1:2 XGA/HD DA/CAT
5 Transmitter, which is ideal for:
•Presentation and multimedia applications
•Long range graphics distribution for schools, hospitals, security, and
stores
Each package includes the following items:
•The VP-300THD 1:2 XGA/HD DA/CAT 5 Transmitter
•Power supply (12V DC)
•This user manual2
2 Getting Started
We recommend that you:
•Unpack the equipment carefully and save the original box and
packaging materials for possible future shipment
•Review the contents of this user manual
•Use Kramer high performance high-resolution cables3
1 GROUP 1: Dis tribution Amplifiers; GROUP 2: Switc hers and Matrix Swi tchers; GROUP 3: Co ntrol Systems;
GROUP 4: Format/Standards Converters; GROUP 5: Ra nge Extenders and Repea ters; GROUP 6: S pecialty AV Products;
GROUP 7: Scan C onverters and Scalers; GROUP 8: Cables and Connectors; GROUP 9: Room Connectivity;
GROUP 10: Accessories and Rack Adapters; GROUP 11: Sierra Products
2 Download up-to-date Kramer user manuals from our Web site at http://www.kramerelectronics.com
3 The complete list of Kramer cables is on our Web site at http://www.kramerelectronics.com

KRAMER: SIMPLE CREATIVE TECHNOLOGY
Getting Started
2
2.1 Quick Start
This quick start chart summarizes the basic setup and operation steps.
Step 1: Connect the input and the outputs
m Set the polarity and the ID bit using the underside switches m Set the polarity and the ID bit using the underside switches
Step 2: Connect the power
Step 3: If required:
1
1
2
2
3
3
3
Connect the input
Connect the outputs
Connect the CAT 5 cable between the
transmitter (VP-300THD) and the
receiver (TP-120)
Connect the input
Connect the outputs
Connect the CAT 5 cable between the
transmitter (VP-300THD) and the
receiver (TP-120)
LINE OUT
OUTPUT 2
VP-300THD
1:2 XGA/HD /CAT5 TransmitterDA
OUTPUT 1
TP-120
VP-300THD
Projector
Display
Display
VGA
VGA
Computer
Graphics Source
VGA
VGA
CAT 5

Overview
3
3 Overview
The VP-300THD is a high-performance distribution amplifier for computer
graphics video signals1 with resolutions ranging from VGA through UXGA
and higher as well as HDTV. It takes one input, provides correct buffering
and isolation, and distributes the signal to two computer graphics video or
HDTV outputs and one twisted pair output.
The VP-300THD features:
•HDTV compatibility
•H & V sync polarity switches for improved HDTV compatibility with
the CAT 5 outputs
•ID bit control
•A resolution of up to WUXGA and 1080p
•A transmission range of more than 300 feet (more than 100 meters)
•The Power Connect feature (see section 3.1)
•12V DC power
To achieve the best performance:
•Use only good quality connection cables2 to avoid interference,
deterioration in signal quality due to poor matching, and elevated noise
levels (often associated with low quality cables).
•Avoid interference from neighboring electrical appliances that may
adversely influence signal quality and position your Kramer
VP-300THD away from moisture, excessive sunlight and dust
1 Note that the CAT5 connector excludes audio
2 Available from Kramer Electronics on our Web site at http://www.kramerelectronics.com

KRAMER: SIMPLE CREATIVE TECHNOLOGY
Overview
4
3.1 About the Power Connect Feature
The Power Connect feature applies as long as the cable can carry power.
This feature is available when using STP cable and the distance does not
exceed 50m on standard CAT 5 cable. For longer distances, heavy gauge
cable should be used1. For units which are connected via RJ-45 connectors,
make sure that the shield of the STP cable is connected to the metal casing
of the connectors on both ends of the cable. For units which are connected
via terminal block connectors, the shield of the STP cable must be
connected to a ground terminal on the units at both ends (use the ground
terminal of the power supply connection if necessary).
For a CAT 5 cable exceeding a distance of 50m, separate power supplies
should be connected to the transmitter and to the receiver simultaneously.
3.2 Shielded Twisted Pair (STP) / Unshielded Twisted Pair (UTP)
We recommend that you use Shielded Twisted Pair (STP) cable. There are
different levels of STP cable available, and we advise you to use the best
quality STP cable that you can afford. Our non-skew-free cable, Kramer
BC-STP is intended for analog signals where skewing is not an issue. For
cases where there is skewing, our UTP skew-free cable, Kramer BC-XTP,
may be used. Bear in mind, though, that we advise using STP cables where
possible, since the compliance to electromagnetic interference was tested
using those cables.
Although Unshielded Twisted Pair (UTP) cable might be preferred for long
range applications, the UTP cable should be installed far away from electric
cables, motors and so on, which are prone to create electrical interference.
However, since the use of UTP cable might cause inconformity to
electromagnetic standards, Kramer does not commit to meeting the standard
with UTP cable.
1 CAT 5 cable is still suitable for the video/audio transmission, but not for feeding the power at these distances

Your VP-300THD 1:2 XGA/HD DA/CAT 5 Transmitter
5
4 Your VP-300THD 1:2 XGA/HD DA/CAT 5 Transmitter
Figure 1 and Table 1 define the VP-300THD:
Figure 1: VP-300THD 1:2 XGA/HD DA/CAT 5 Transmitter
Table 1: VP-300THD 1:2 XGA/HD DA/CAT 5 Transmitter Features
# Feature Function
1 OUTPUT 1 15-pin HD
Connector Connect to the XGA acceptor 1
2 OUTPUT 215-pinHDConnector Connect to the XGA acceptor 2
3 LINE OUT RJ-45 Connector Connects to1the LINE IN RJ-45 connector
on the TP-120 XGA Line Receiver2
4 12V DC +12V DC connector for powering the unit
Figure 2 and Table 2 define the underside of the VP-300THD:
1 Using a UTP CAT5 cable with RJ-45 connectors at both ends (the PINOUT is defined in Table 3 and Figure 4)
2 Refer to the separate user manual: PT-110, PT-120, TP-120, WP-110, which can be do wnloaded from the Internet at this
URL: http://www.kramerelectronics.com
1
12
24 43 3
66
55

KRAMER: SIMPLE CREATIVE TECHNOLOGY
Connecting the VP-300THD
6
Figure 2: VP-300THD 1:2 XGA/HD DA/CAT 5 Transmitter (Underside)
Table 2: VP-300THD 1:2 XGA/HD DA/CAT 5 Transmitter (Underside) Features
# Feature Function
1 HS Switch Slide the switch to the right to change the HS polarity to NEG. (NEGATIVE) polarity1;
slide the switch to the left2(to NORMAL) to retain the polarity
2 VS Switch Slide the switch to the right to change the VS polarity to NEG. (NEGATIVE) polarity1;
slide the switch to the left2(to NORMAL) to retain the polarity
3 ID BIT Switch Slide to the right to set to ON3; to the left to set to OFF
5 Connecting the VP-300THD
You can use the VP-300THD and, for example, the TP-120 to configure an
XGA/HD DA/CAT 5 Transmitter and Receiver system.
To connect the VP-300THD with the TP-120, as the example in Figure 3
illustrates, do the following:
1. On the VP-300THD 1:2 XGA/HD DA/CAT 5 Transmitter, connect the:
Computer graphics (XGA / HD) source (for example, a computer)
to the INPUT 15-pin HD connector
OUTPUT 1 and OUTPUT 2 15-pin HD connectors to up to4 two
acceptors (for example, to a display and to a projector,
respectively)
1 Downgoing syncs
2 By default, both switches are set to the left
3 The default. Enabling the notebook or laptop to output a VGA signal to an external VGA monitor
4 When both outputs are not required, connect only the output that is required and leave the other output unconnected

Connecting the VP-300THD
7
2. On the TP-120 XGA Line Receiver, connect the XGA OUT 15-pin HD
connector to the XGA / HD acceptor (for example, a display).
3. Connect the LINE OUT RJ-45 connector on the VP-300THD to the LINE
IN RJ-45 connector on the TP-120, via UTP cabling (with a range of more
than 300ft (more than 100 meters)), see section 3.2.
4. Connect the 12V DC power adapter to the power socket on the
VP-300THD, and plug the adapter into the mains electricity socket.
Similarly, connect the other 12V DC power adapter to the power socket on
the TP-120,and plug that adapter into the mains electricity socket.
5. On the VP-300THD, if required:
Set the ID BIT switch to ON
Set the VS and HS switches1 on the underside
6. On the TP-120, if required:
Adjust2 the video output signal level and/or cable compensation
equalization level
Set the H SYNC and V SYNC switches3, on the underside
Figure 3: Connecting the VP-300THD
1 By default, both switches are set to the left (to NORMAL) to retain the VS and HS polarity
2 Use a screwdriver to carefully rotate the trimmer, adjusting the appropriate level
3 By default, both switches are set down (for normal V SYNC and H SYNC polarity)
LINE OUT
OUTPUT 2
VP-300THD
1:2 XGA/HD /CAT5 TransmitterDA
OUTPUT 1
TP-120
VP-300THD
Projector
Display
Display
VGA
VGA
Computer
Graphics Source
VGA
VGA
CAT 5

KRAMER: SIMPLE CREATIVE TECHNOLOGY
Technical Specifications
8
5.1 Wiring the CAT 5 LINE IN / LINE OUT RJ-45 Connectors
Table 3 and Figure 4 define the UTP CAT 5 PINOUT, using a straight pin
to pin cable with RJ-45 connectors:
Table 3: CAT 5 PINOUT Figure 4: CAT 5 PINOUT
EIA /TIA 568A EIA /TIA 568B
PIN Wire Colo
r
PIN Wire Colo
r
1 Green / White 1 Orange / White
2 Green 2 Orange
3 Orange / White 3 Green / White
4 Blue 4 Blue
5 Blue / White 5 Blue / White
6 Orange 6 Green
7 Brown / White 7 Brown / White
8 Brown 8 Brown
Pair 1 4 and 5 Pair 1 4 and 5
Pair 2 3 and 6 Pair 2 1 and 2
Pair 3 1 and 2 Pair 3 3 and 6
Pair 4 7 and 8 Pair 4 7 and 8
6 Technical Specifications
This section includes the technical specifications1 of the VP-300THD.
Table 4: Technical Specifications of the VP-300THD (with 30m CAT 5 cable)
INPUT: 1 XGA on an 15-pin HD connector
OUTPUTS: 2 XGA on 15-pin HD connectors; 1 RJ-45 connector
MAX. OUTPUT
LEVEL2: 2.3Vpp (XGA), 1.4Vpp (CAT 5)
RESOLUTION: Up to UXGA
DIFF. GAIN2: 0.03% (XGA), 2.6% (CAT 5)
DIFF. PHASE2: 0.05Deg (XGA), 0.28 Deg (CAT 5)
K-FACTOR2: <0.05% (XGA), 0.1% (CAT 5)
S/N RATIO2: 75dB (XGA), 71dB (CAT 5)
CONTROLS2: LEVEL: –9.1dB to 2.3dB (CAT 5)
EQ.: 0 to 35dB (CAT 5)
COUPLING2: DC (XGA), AC (CAT 5)
POWER SOURCE: 12V DC, 280mA
DIMENSIONS: 12cm x 7.5cm x 2.5cm (4.7" x 2.95" x 0.98") W, D, H
WEIGHT: 0.3 kg. (0.67 lbs.) approx.
ACCESSORIES: Power supply
OPTION: RK-3T 19" rack adapter
1 Specifications are subject to change without notice
2 “CAT 5” specifications refer to a VP-300THD to TP-120 configuration
