Kreg Adaptive Cutting System Project Table Kit User manual

ADAPTIVE
SYSTEM
01/2019 NK9396
V1
Owner’s
Manual
Guide d’utilisation / Manual del propietario
PROJECT TABLE REPLACEMENT TOP IS COVERED IN THIS MANUAL

PARTS
BEFORE YOU BEGIN
Check the contents of the carton to ensure you have all parts in the quantities listed. Should any part be missing, contact Kreg Customer
Service. Refer to your original Adaptive Cutting System Project Table owner’s manual for part identication and reassembly instructions.
CONTENTS: ACS745
ITEM DESCRIPTION QUANTITY
Project Table Top 1
Table-Top Screws 16
Star-Drive Bit 1
WARNING:
!
This product can expose you to chemicals including Formaldehyde, which is known to the State of California to cause cancer.
For more information go to www.P65Warnings.ca.gov.

SETUP
(1) Remove the guide track, hinges,
hinge-mounting plates, and all
corresponding hardware. Retain all
components for reassembly.
(2) Place the Project Table upside down
on a at surface that will support the
table tracks when the nuts securing
them to the table top are removed.
ATTENTION:
!
Two people are required to lift
the Project Table.
(3) Remove all nuts, bar brackets,
and U-bolts fastening leg assemblies
1 and 2; the wheel assembly; and the
four nuts attaching the table tracks to the Project Table top. Retain all nuts, bar brackets, and U-bolts for reassembly.
Remove the old Project Table Top
1
1
2
3
3

(4) Turn the table top right side up,
making sure the table tracks do not fall
out and get damaged.
(5) Lift the table tracks out of the table-
top slots. Leave the table-track bolts
and plastic retaining plates in place.
(6) Mark the table frame member
adjacent to the side of the table with
the saw kerf (cutting side).
(7) Remove the 16 screws securing
the table top to the aluminum frame
using the included star-drive bit and
remove the top. Discard the screws.
(1) Position the new table top in the
aluminum frame with the cutting side
of the top on the side opposite the
mark on the frame.
ATTENTION:
!
Rotating the new table top 180°
from the position of the old top avoids driving the new
table-top bolts into the aluminum frame at the same
locations where the old bolts were removed,
ensuring secure anchorage.
(2) Drive the 16 new table-top screws
to attach the new table top to the
aluminum frame.
(3) Position the table tracks in the slots.
ATTENTION:
!
Different bolt spacing allows the
table tracks to be installed only in one orientation.
SETUP
Remove the old Project Table Top
Installing the Project Table Top
7
6
5
4
Retaining Plates
Mark Saw Kerf
3
2
1
Saw Kerf
Mark

(1) Turn the project table upside down
on a at surface, making sure the
table tracks do not fall out.
(2) Thread nuts onto the two
protruding bolts closest to the
aluminum frame that fasten each of
the table tracks.
ATTENTION:
!
Before tightening the bolts, ensure
the table-track ends are ush with the table-top edge.
(3) Install leg assemblies 1 and 2 and
the wheel assembly as instructed in
your original Adaptive Cutting System
Project Table owner’s manual.
(1) Turn the Project Table right side
up and install the hinge-mounting
plates, hinges, and guide track, and
recalibrate your system as instructed
in your original Adaptive Cutting
System Project Table owner’s manual.
ATTENTION:
!
Two people are required to lift
the Project Table.
SETUP
Install the Leg and Wheel Assemblies
Install the Guide Track
3
3
12
1
1

For assistance with any Kreg product, contact us through our Web site or call Customer Service.
Si vous avez besoin d’aide concernant les produits Kreg, communiquez avec nous
sur notre site Web ou appelez notre service à la clientèle.
Si requiere asistencia con cualquier producto Kreg, póngase en contacto
con nosotros a través del sitio web o llame al Servicio al Cliente.
www.kregtool.com • 800.447.8638
201 Campus Dr, Huxley, IA 50124
Kreg Enterprises Inc.
