KStrong AFA930050 Operator's manual

THESE INSTRUCTIONS APPLY TO THE FOLLOWING MODEL:
EDGE D-RING ANCHOR PLATE
USER INSTRUCTION MANUAL
AFA930050
EN 795: 2012 Type A
* The bolt image on cover is for reference purpose only & it would not be provided with the anchor.
*

Please read and understand the manufacturer's instructions for each component or part of the complete system. Manufacturer's instructions
must be followed for proper use, care, and maintenance of this product. These instructions must be retained and be kept available for the user's
reference at all times. Alterations or misuse of this product, or failure to follow instructions, may result in serious injury or death.
Note: The user is advised to keep this user instructions document for the life of the product.
1. INTRODUCTION: This Anchor is classed as a Personal Protective Equipment (PPE) by the European PPE Regulation (EU) 2016/425 and
have been shown to comply with this Regulation through the Harmonized European Standard EN 795: 2012 type A.
This Anchor is designed to minimize the risk of/provide protection against the danger of falling from heights. However, always remember that
no item of PPE can provide full protection and care must always be taken while carrying out the risk related activity.
2. PERFORMANCE AND LIMITATIONS OF USE:
The Anchor has been tested in accordance with EN 795: 2012 type A and has achieved the following performance levels:
Static Strength
(Clause 4.4.1.3)
Dynamic Strength &
Integrity Test
(Clause 4.4.1.2)
Corrosion Resistance
(Clause 4.7)
EN 795:2012 Type A test
Anchor Holds an increased load of 300kg for 3 min following dynamic test.
General Requirements
for Anchor Devics
(Clause 4.2)
Sustained a force of 12 kN for 3 minutes (PASS).
No sharp edges (PASS).
(PASS)
When tested with rigid steel mass of 100 kg, the test mass held after test with the
device remaining stable throughout. (PASS)
No Corrosion evident after 48 hours of salt spray testing. (PASS)
Result/Comment
3. APPLICATION : The Egde D-Ring Anchor Plates have been
designed for temporary or permanent applications, It can be
used on concrete and Steel. D-ring anchor bolts can be used for
vertical wall, floor mount, or overhead ceiling installation. It
incorporates a reuseable D-ring assembly; just install a new bolt
assembly and it's ready to go.
4. INSPECTION: Visually inspect the system before each use to
ensure that it is in a serviceable condition and is operating
correctly. If during inspection, doubts are raised about the safety
of the system or a component, these should be replaced either by
the manufacturer or a competent person.
5. PRECAUTIONS:
ŸEnsure the Medical condition of the user does not affect his
safety in normal and emergency use.
ŸThe equipment shall only be used by a person trained and
competent in its safe use.
ŸA rescue plan shall be in place to deal with any
emergencies that could arise during the work.
ŸEnsure that the anchor is installed directly above the user's head.
ŸIt is essential to verify free space required beneath the user at work place before each occasion of use so that in case of a fall there will be
no collision with ground or other obstacle in the fall path.
02
ANCHOR PLATE
D-RING

Stud
Washer
Nut
Anchor
6. INSTRUCTIONS FOR USAGE :
ŸAll mechanical attachments shall be determined by an
engineer on sight or a qualified person.
ŸUse rotary hammer and drill bit (bit size: 12mm). Hole
MUST be 95mm deep.
ŸClean hole using compressed air. Ensure hole is fully
clean of all debris.
ŸDismantle bolt by removing nut & washer.
ŸReassemble bolt with Anchor D-ring and Bracket
Assembly. In order, pass Inner Bolt through Washer,
Dring and Bracket Assembly, and Outer Bolt
Components (see image on right). Ensure bolt end cap
(#6) is handtight and fully secure.
ŸUse a hammer to drive Anchor and bolt into hole. D-ring
bracket must be flush against work surface. DO NOT
expand bolt before fully installing Anchor in hole.
ŸAttach complete and compatible personal fall arrest
system to Anchor D-ring.
7. ANCHORAGE STRENGTH: Ensure that the structure on to
which the anchor is fitted is strong enough to withstand a load
of 12kN. Please refer to an Engineer to verify the concrete
structure is suitable for the installation.
8. LIMITATIONS:
ŸAnchors should be the personal property of its user.
ŸIt should not be used in highly acid or basic
environments.
ŸThe anchor has been tested to EN 795:2012 type A
and is appropriate only for single person use with an
energy absorber as per EN 355:2002.
ŸEnsure that the Anchor is installed directly above the
user's head.
9. COMPATIBILITY: To optimize protection, in some instance it
may be necessary to use the anchor with suitable PPE such
as boots/ gloves/ helmet/ ear defenders. In this case, before
carrying out the risk-related activity, consult your supplier to
ensure that all your protective products are compatible and
suitable for your application.
10 REPAIR: If the product becomes damaged, it will NOT
provide the optimum level of protection, and therefore should
be immediately removed from service. Never use the
damaged product. Repair is permitted, provided that it is
either done by the manufacturer or a competent repair centre
or individual approved by the manufacturer.
11 WITHDRAWAL FROM USE: If the system has been used to
arrest a fall, it should be removed from service and returned
to the manufacturer or a competent repair centre for servicing
and re-test.
12 CLEANING: In case of minor soiling, wipe the anchor with
cotton cloth or a soft brush. Do not use any abrasive material.
For intensive cleaning wash the anchor in water at a
0 0
temperature between 30 C to 60 C by using a neutral
detergent (pH 7). The washing temperature should not
0
exceed 60 C. Do not use acid or basic detergents.
03
DIRECTION OF LOAD APPLICATION
INSTALLATION

04
13 STORAGE AND TRANSPORT: When not in use, store the anchor away from heavily acidic or basic environment. Never place heavy items on
top of it. Also ensure that it is stored away from chemically hazardous environment preferable storage should be in dry environment.
14. WARNING:
ŸDo not make any alteration or additions to the equipment without the manufacturer's prior written consent and repair shall only be carried
out by personnel trained by the manufacture & duly authorized by him.
ŸThe equipment shall not be used outside its limitation, or for any purpose other than that for which it is intended.
The Anchor is marked with :
(i) For Single user only.
(ii) Identification of the manufacturer
(iii) Type or product code
(iv) Product description
(v) Norm Reference.
(vi) UID of traceability
MARKING
MAX
1
ANCHOR : AFA930050
UID : XXXXXXXXXXXXX
EN795:2012-TYPE A
MBS.: 23kN
Read the user
instructions carefully
before each use.
i
ii
iii
v
iv
vi

LIFESPAN: The estimated product Lifespan is 10 years from the date of manufacture. The following factors can reduce the Lifespan of the product:
intense use, contact with chemical substances, specially aggressive environments, extreme temperature exposure, UV exposure, abrasions, cuts,
violent impacts, bad use or maintenance.
DISCLAIMER: Prior to use, the end user must read and understand the manufacturer's instructions supplied with this product at the time of shipment
and seek training from their employer's trained personnel on the proper usage of the product. Manufacturer is not liable or responsible for any loss,
damage or injury caused or incurred by any person on grounds of improper usage or installation of this product.
Periodic examination
next due date
Product
Model & type/Identification
Trade Name
Address
Identification number
Manufacturer
Tel, email into use
Year of manufacture
Purchase Date
Date first put into use
Other relevant information (eg. document number)
PERIODIC EXAMINATION AND REPAIR HISTORY
Date Name and signature
of competent person
Reason for entry
(periodic examination
or repair)
Defects noted, repairs
relevant information
carried out and other
EQUIPMENT RECORD
05

06

07

Certification Body :
SATRA Technology Europe Ltd, Bracetown Business Park, Clonee, Dublin D15 YN2P Ireland (Notified Body 2777)
Ongoing Assessment Body:
SGS Fimko Oy, Takomotie 8, FI-00380 Helsinki, Finland (Notified Body 0598)
For EU Declaration, visit https://kstrong.com/asia/eu-declaration-form/
www.kstrong.com
USA South America ASIA
KStrong Inc.
150 N. Radnor Chester Road Suite F200
Radnor, Pennsylvania 19087 United States
Contact number : 1-833-KSTRONG
AKS/AFA930050/010221/V2
