THESE INSTRUCTIONS APPLY TO THE FOLLOWING MODEL:
EDGE STRAIGHT BAR STEEL ANCHOR
USER INSTRUCTION MANUAL
AFA930552
EN 795:2012 Type A

Please read and understand the manufacturer's instructions for each component or part of the complete system.
Manufacturer's instructions must be followed for proper use, care, and maintenance of this product. These instructions must
be retained and be kept available for the user's reference at all times. Alterations or misuse of this product, or failure to follow
instructions, may result in serious injury or death.
Note: The user is advised to keep this user instructions document for the life of the product.
1. INTRODUCTION:
2. PERFORMANCE AND LIMITATIONS OF USE:
This Anchor is compliance with European Standard EN 795:2012 Type A for one user.
Quick and Easy to install, this Anchor is designed to be installed on Trapezoidal roof top.
These post deploys in the event of fall to absorb the energy hence leaves the roof panel intact to maintain architectural
integrity.
This Anchor has been tested in accordance with EN 795:2012 Type A and has achieved the following performance levels-
3. APPLICATION:
The EDGE Straight Bar Anchor is designed to be fixed on trapezoidal roof with help of screws directly on the purlins of
the structure. Eye having Ø25.0mm to be used as anchor point.
4. INSPECTION:
Visually inspect the system before each use to ensure that it is in a serviceable condition and is operating
correctly. If during inspection, doubts are raised about the safety of the system or a component, these should be
replaced either by the manufacturer or a competent person.
A formal inspection of fall protection products/components must be performed preferably every six months or at
least annually by a competent person other than the user. The frequency of formal inspections should be based
on conditions of use or exposure. Record the inspection results in the inspection and maintenance log at the end
of this manual. The component should be checked for cut, frayed, heavily soiled, welding burns etc. Metal parts
like D-rings should be duly check for the crack, bent, deformities, corrosion etc.
Ÿ
Ÿ
General Requirements (PASS)
for Anchor devices
(Clause 4.1)
No sharp edges (PASS).
Static Strength Sustained a force of 12 kN for 3 minutes (PASS).
(Clause 4.4.2.3)
Dynamic Strength & Integrity Test When tested with rigid steel mass of 100 kg, the test mass held after test with the
(Clause 4.4.1.2) device remaining stable throughout. (PASS).
Anchor Holds an increased load of 300kg for 3 min following dynamic test.
Corrosion Resistence No corrosion evident after 48 hours of salt spray testing. (PASS)
(Clause 4.2.2.1)
EN 795:2012 Type A Result/Comment
01

5. ROOF INSPECTION
ŸAs per EN 795:2012 Type A, ensure that the anchor plate to which the Roof Sheeting would be attached is able
to sustain a load of minimum 12 kN for a single person.
ŸDO NOT use such area for installation where any signs of excessive rust, missing or loose roof nails or screws,
tears or splits in the metal or damaged purlins is being found.
ŸConsult an Engineer if the height safety supervisor inspecting the roof is doubtful whether the anchorage is
structurally adequate or not, as per EN 795:2012 Type A.
6. PRECAUTIONS:
Ensure the Medical condition of the user does not affect his safety in normal and emergency use.
The equipment shall only be used by a person trained and competent in its safe use.
A rescue plan shall be in place to deal with any emergencies that could arise during the work.
Ensure that the anchor is installed directly above the user's head.
Ensure that the equipment is compatible with other items when assembled into a system.
It is essential to verify free space required beneath the user at work place before each occasion of use so that in
case of a fall there will be no collision with ground or other obstacle in the fall path.
7. PRE-USE CHECK:
It is important to check before use, any dangers that may arise by the use of combinations of items of the
equipment in which the safe function of any one item is affected by or interferes with the safe function of another.
Carry out a pre-use check of the system, to ensure that it is in a serviceable condition and operates correctly
before it is used.
Ensure the compatibility of items of equipment when assembled into a system.
Ÿ
Ÿ
Ÿ
Ÿ
Ÿ
Ÿ
Ÿ
Ÿ
Ÿ
8. INSTALLATION OF STRAIGHT BAR STEEL ANCHOR
ŸThe anchor and the roof is to be inspected as per the
instructions above and as EN 795:2012 Type A.
ŸA minimum of 3 heavy duty screws with a head radius of 25
mm is required to penetrate at least 35 mm into the purlin.
ŸLocate the appropriated fixing point on the roof.
ŸThe anchor is to be placed perpendicularly to the trapezoidal
roof onto the roofing structure. The slots of the anchor (used
to fix the screws) must be aligned with the purlin.
ŸTo achieve 12 kN strength, the anchor must be fixed with
minimum of 3 suitable heavy duty roof screws.
ŸFit karabiner to loading eye with locking device facing
upward.
ŸPut rope through karabiner and ensure karabiner has fitted
correctly.
ŸTo ensure safety, work from a minimum of 2M distance from
an unprotected edge. Reverse the installation process to
remove the anchor plate.
STRAIGHT BAR STEEL ANCHOR
AFA930552
Anchor Min. 3 heavy duty roof screws
Min. 35mm
screws
penetration
Purlin
02

9. ANCHORAGE STRENGTH:
Ensure that the structure on to which the anchor is fitted is strong enough to withstand a load of 12kN.
10. COMPATIBILITY:
To optimise protection, in some instance it may be necessary to use the anchorage sling
boots/gloves/helmet and ear protection. In this case, before carrying out the risk-related activity, consult your supplier
to ensure that all your protective products are compatible and suitable for your application.
ŸIt should be the personal property of the user.
ŸIt should not be used in highly acidic or basic environment.
ŸThe anchor has been tested to is appropriate only for single person use with an energy
absorber as per EN 355:2002.
ŸIt is essential for the safety of the user that if the product is resold outside the original country of destination, the
reseller shall provided instruction for use, for maintenance, periodic examination and for repair in the language of
the country in which product in to be used.
ŸAnchor device should only be used for personal fall protection equipment and not for lifting equipment.
12. REPAIR:
If the product becomes damaged, it will NOT provide the optimum level of protection, and therefore should be
immediately removed from service. It needs to be inspected to see if it is replaced or repaired. Never use the damaged
product. Repair is only permitted by the manufacturer or a nominated repair centre or individual approved by the
manufacturer.
13. CLEANING & MAINTENANCE:
In case of minor soiling, wipe the anchor with cotton cloth or a soft brush. Do not use any abrasive material. For
0 0
intensive cleaning wash the anchor in water at a temperature between 30 C to 60 C by using a neutral detergent (pH
0
7). The washing temperature should not exceed 60 C. Do not use acid or basic detergents.
14. STORAGE AND TRANSPORT:
When not in use, store the anchor away from heavily acidic or basic environment. Never place heavy items on top of it.
Also ensure that it is stored away from chemically hazardous environment preferebly storage should be in dry
environment.
15. WITHDRAWAL FROM USE:
If the system has been used to arrest a fall, it should be removed from service and returned to the manufacturer or a
competent repair centre for servicing and re test.
16. WARNING
ŸDo not make any alterations or additions to the equipment without the manufacturer’s prior written consent and
that any repair shall only be carried out by personnel trained by the manufacturer & duly authorized by him.
ŸThe equipment shall not be used out side its limitation, or for any purpose other than that for which it is intended.
with suitable PPE such as:
11. LIMITATION:
EN 795:2012 Type B
03

MARKING
The Anchor is marked with:
(i) Identification of the manufacturer
(ii) Type or product code marking
(iii) Mfg. Date
(iv) . for traceability
(v) Norm Reference.
(vi) Minimum Breaking Strength
UID
EN 795
QRCODE
UID: XXXXXXXXXXXX
Date of mfg.: MM/YYYY
MBS: 15kN
EN795:2012 Type A
Fall not to exceed 2 meters.
Only competent users
should use this equipment.
KStrong Inc.
150 N. Radnor Chester Road
Suite F200 Radnor,
Pennsylvania 19087 United States KStrong.com Made In India
flat bar anchor
AFA930552
(i)
(ii)
(iii) (v)
(vi)
(iv)
04

LIFESPAN:
DISCLAIMER: Prior to use, the end user must read and understand the manufacturer's instructions supplied with this product at the time of
shipment and seek training from their employer's trained personnel on the proper usage of the product. Manufacturer is not liable or responsible
for any loss, damage or injury caused or incurred by any person on grounds of improper usage or installation of this product.
The estimated product Lifespan is 10 years from the date of manufacture. The following factors can reduce the Lifespan of the
product: intense use, contact with chemical substances, specially aggressive environments, extreme temperature exposure, UV exposure,
abrasions, cuts, violent impacts, bad use or maintenance.
Periodic examination
next due date
Product
Model & type/Identification
Trade Name
Address
Identification number
Manufacturer
Tel, email into use
Year of manufacture
Purchase Date
Date first put into use
Other relevant information (eg. document number)
PERIODIC EXAMINATION AND REPAIR HISTORY
Date Name and signature
of competent person
Reason for entry
(periodic examination
or repair)
Defects noted, repairs
relevant information
carried out and other
EQUIPMENT RECORD
05

Certification Body:
SATRA Technology Europe Ltd, Bracetown Business Park, Clonee, Dublin D15 YN2P Ireland (Notified Body 2777)
Ongoing Assessment Body:
SGS Fimko Oy, Takomotie 8, FI-00380 Helsinki, Finland (Notified Body 0598)
www.kstrong.com
USA South America ASIA
KStrong Inc.
150 N. Radnor Chester Road Suite F200
Radnor, Pennsylvania 19087 United States
Contact number : 1-833-KSTRONG
AKS- -110121-v2AFA930552
For EU Declaration, please visit https://kstrong.com/asia/eu-declaration-form/
