Kusam-meco KM 8042 User manual

COATING THICKNESS
GAUGE
MODEL - KM 8042
17, Bharat Industrial Estate, T. J. Road, Sewree (W),
Mumbai-400015. INDIA
Sales Direct: 24156638 (022)2412 4540, 2418 1649 2414 9659
E-mail : [email protected], Website : www.kusamelectrical.com,
www.kusam-meco.co.in
Tel.: Fax:
*
*
* AC Clamp Adaptor
* AC/DC Current Adaptor
* Transistorised Electronic Analog & Digital Insulation
Resistance Testers(upto 10 KV)
* Digital Sound Level Meter & Sound Level Calibrator
* Digital contact & Non-contact Type Tachometer
* Digital Non-contact (infrared) Thermometer &
Portable Infrared Calibrator
* Thermo Hygrometer / Anemometer
Digital Absolute pressure meter
* Wood, Paper & Grain Moisture Meter
* Distance Meter & Network Cable Tester
* Digital Hand Held Temperature Indicators
* Digital Lux Meter
* Thermal Imaging Camera
* Power Factor Regulator
* Maximum Demand Controller/Digital Power Meter
* Earth Resistance Tester
* Digital Panel Meters & DC Power Supplies
* Digital Storage / Analog Storage Oscilloscope.
* Coating Thickness Guage
* Process Calibrators & Multifunction Calibrators
* Gas Analysers & Waterproof Pen Testers
* Frequency Counter / Function Generator
* Phasing Sticks & High Voltage Detector
* Transducer & Transmitter
* Digital Milli Ohm Meter
* Solar Power Meter
* EMF/ELF Detector / RF Field Strength Meter
Digital Multimeter
Digital AC & AC/DC Clampmeter
LIST OF PRODUCTS
OPERATION
MANUAL
OPERATION
MANUAL

CONTENTS
1) Preface.........................................
2) Safety information........................
3) Function & Features.....................
4) Specifications...............................
5) Names of parts ............................
6) Operation Instruction....................
7) Calibrating Meter..........................
8) Notices.........................................
9) Maintenance................................
10) Test certificate.............................
11) Warranty......................................
01
01
01
02
03
04
05
08
10
11
12
COATING
THICKNESS GAUGE
MODEL - KM 8042

1. Preface
Please read the following information carefully
before using the meter. The coating thickness guage
is designed to measure the coating thickness on a
magnetic metalic matrix, can be widely used for
manufacturing, metal machining, chemical industry,
commodity inspection and so on. It is according with
JJG 889-1995 standard.
2. Safety information
According to European Union’s CE safety norms.
Please use it according to the following conditions.
Environment conditions :
Operation temperature : 0 ~ +40°C
Storage and transport temperature : -40 ~ +70°C.
Maintenance & save : Do not clear the meter using
alcohol and impregnant. If you do not use it for a long
time, please take out the batteries and place the
instrument in a dry surrounding.
3. Functions & Features :
By electromagnetic method, the meter can measure
the coating thickness non-destructively, including
paint, spray-plastic, rubber, enamel, or chromeplate,
copperizing, aluminium plating on steel, iron, non-
austenitic stainless steel.
Four digitals LCD display, differentiating upto mm.
System calibrating by user-self.
Pocket shell, convenient for engineering locale.
01
Thickness unit “mm” or “mil” optional.
Coupling state display.
Shut down manually or automatically.
Low battery voltage indication.
The meter has been designed according to EC
directive : 89/336/EEC
Digital display : 4 digits
Measurement range : 0 ~ 1200mm.
4. Specifications
Resolution : 1mm
Accuracy : ±(3%H + 2mm)
Measurement rate : 0.8 second.
Display units : mm or mil
Critical thickness of metallic base : 1mm
Minimum thickness of metallic base : 0.2mm
Minimum curvature radius : protruding 1.5mm,
concave 6mm.
Probe diameter :13mm
power Supply : 1.5V AAA * 3 batteries.
Operating Temperature : 0 ~ 40°C;
20%~80% humidity without strong magnetic
environment.
Storage Temperature : -40 ~ +70°C.
Dimensions : 165(L) x 60(W) x 30(H)mm
Weight : about 190g.
Accessories : probe, standard thickness pieces (5),
martensite stainless steel block, operating manual,
batteries.
02

03
5. Name of parts :
Instrument Familiarization
1. Sensor Cover
2. Thickness sensor
3. LCD display
4. Function key
LCD Display
04
The meaning of the symbols represented by the
following：
1. Display zone
2. Thickness units
3. Coupling sign
4. Indication to low voltage of the batteries
5. Number of standard thickness piece
Ⅵ．O peratio n i nstru ction
1. Press button “ON/OFF” , the meter displays 0. Waiting
for five minutes or more to get the meter steady.
2. Put the probe on the coating to be tested, Press it
gently and don’t dither. When a coupling sign appears,
the thickness of the coating displays. If coupling is
not good or the probe dithering, the coupling sign and
thickness don’t display.
3. When taking the probe out from the coating, the
coupling symbol disappears, but thickness keeps
displaying.
4. Press button µm/mil, thickness unit “µm” changes into
“mil” or contrarily.

05
5. To turn off:
When the meter is working, pressing button ON/OFF
will get shutdown immediately.
6. Automatic shutdown
When the meter is working, and stop to press button
or stop to measure for fifteen minutes, shutdown will
occur automatically.
Ⅶ． C alibrating th e m eter
1. The meter is based on the principle of electromagnetic
induction. Before leaving the factory, it had been
calibrated on the martensite stainless steel block that
is as an accessory
.
2. When the base material to be tested is different from
the martensite stainless steel block in the accessories,
user must calibrate the meter on the material to be
tested.
3. When changing a new probe, or the probe is abrased
or the meter is used for a long time, user need to
calibrate it.
06
4. The method of calibrating is following：
a. Press µm/mil then press ON/OFF buttons
simultaneity. The main display section of the meter is
0000, the lower left quarter is sample 0. It indicates
thickness 0 will be calibrated. Waiting for five minutes
or more to get the meter steady. Put the probe directly
on the metallic matrix without coating and press it for
two seconds no dithering. Then press button µm/mil
to perform calibrating of thickness 0 (the probe keeps
to press no dithering when Adjusting) . The main
display section changes into 50µm, the lower left
quarter changes into sample 1. It indicates that the
thickness of sample 1 will be calibrated. The probe
can be taken up.
b. Accoding to the thickness marking on the sample
1,press button ▲ or ▼ to change digitals of the main
display section untill it is equal to the value of the
sample 1. Lay the sample 1 on the metallic matrix,
then put the probe on them and press it for two
senconds gently, then press button ìm/mil to do
calibrating of the thickness of sample 1 (the probe
keeps to press no dithering when Adjusting). The
main display section changes into 125ìm, the lower

08
best dose on a workpiece that don’t smear any
coating.
Ⅷ．Notices
1. When calibrating on a metallic matrix and
measurement on another kind metallic matrix, the
error of measurement might be more than the rating
value. A material dealt with heat treatment or cold
working, its magnetism might change, calibrating had
2. The meter can not measure on the base that is
non-magnetic material, such as copper, aluminum
etc.
3. When power on, waiting for five minutes or more to
get the meter steady, then calibrating or measuring to
insure its accuracy.
4. When measuring on a thin base under 1mm, calibrate
the meter on the material with the same thickness.
When the basal thickness is more than 1mm, a
change of the basal thickness does not affect
measurement.
5. Don’t calibrate or measure on the fringe of a
workpiece.
07
left quarter changes into sample 2 . It indicates
the thickness of sample 2 will be calibrated. The probe
can be taken up.
c. Imitating the step b , perform calibrating of the
thickness of sample 2, sample 3, sample 4, sample 5.
At last, sample 6 displays. The thickness of sample 6
is equal to the sum of sample 3+ sample 5, press
button ▲ or ▼ to change digitals of the main display
section untill it is equal to the sum of sample 3+
sample 5. Lap over the sample 3 and sample 5, place
them on the metallic matrix, than put the probe on
them and press it for two seconds gently, then press
button µm/mil to perform calibrating of the
thickness of sample 6 (the probe keeps to press no
dithering when Adjusting). The meter displays OFF
finally.
d. Press ON/OFF button to end calibrating.

10
2. Mounting battery and probe
Remove the battery cover on the back and put in
three 1.5V AAA batteries according to the mark on
the shell to insure putting batteries in correctly, then
close the battery cover. Insert the plug of the probe
into a socket on the top of the meter.
Ⅸ. M aintenance
1. CLEANING INSTRUCTIONS
The meter may be wiped down with a wet sponge or
cloth using a mild water based detergent or
anti-bacterial soap and rinsed under a gentle stream
of cold water.
NOTE:
This unit is not designed for complete submersion or
washing in water.
09
10. When battery voltage is too low to work, a battery
symbol appears on the screen. It reminds you to
change new batteries.
11. When you do not use the meter for a long time,
please take out batteries to avoid damaging the meter
by electrolyte.
12. Don’t store the meter in a high temperature or wet
place.
13. After power off, to turn power on again, wait for five
seconds.
might be disturbed.
6. When calibrating on a plane, measurement is on a
curved surface, the error might be more than the
rating value.
7. Don’t press the probe with big force to avoid that the
Sample distortion brings an error.
8. The Samples or the coating of a workpiece is not
entirety even, might increase display error.
9. In a strong magnetic environment, measurement

11
This Test Certificate warrantees that
the product has been inspected and
tested in accordance with the published
specifications.
QC
PASS
KUSAM-MECO
TEST CERTIFICATE
COATING THICKNESS GAUGE
MODEL NO. __________
KM 8042
SERIAL NO. ___________
MUMBAI
DATE: ___________
ISO 9001
REGISTERED
12
WARRANTY
Each “KUSAM-MECO” product is warranted to be free from
defects in material and workmanship under normal use &
service. The warranty period is one year (12 months) and
begins from the date of despatch of goods. In case any
defect occurs in functioning of the instrument, under proper
use, within the warranty period, the same will be rectified by
us free of charges, provided the to and fro freight charges are
borne by you.
This warranty extends only to the original buyer or end-user
customer of a “KUSAM-MECO” authorized dealer.
This warranty does not apply for damaged Ic’s, fuses, burnt
PCB's, disposable batteries, carrying case, electrodes,
probes, cables or to any product which in “KUSAM-MECO’s”
opinion, has been misused, altered, neglected,
contaminated or damaged by accident or abnormal
conditions of operation or handling.
“KUSAM-MECO” authorized dealer shall extend this
warranty on new and unused products to end-user
customers only but have no authority to extend a greater or
different warranty on behalf of “KUSAM-MECO”.
“KUSAM-MECO’s” warranty obligation is limited, at option,
free of charge repair, or replacement of a defective product
which is returned to a “KUSAM-MECO” authorized service
center within the warranty period.
THIS WARRANTY IS BUYER’S SOLE AND EXCLUSIVE
REMEDY AND IS IN LIEU OF ALL OTHER WARRANTIES,
EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED
TO ANY IMPLIED WARRANTY OF MERCHANTABILITY
OR FITNESS FOR A PARTICULAR PURPOSE. “KUSAM-
MECO” SHALL NOT BE LIABLE FOR ANY SPECIAL,
INDIREC T, INCIDENTAL OR CONSEQUEN TIAL
DAMAGES OR LOSSES, INCLUDING LOSS OF DATA,
ARISING FROM ANY CAUSE WHATSOEVER.
All transaction are subject to Mumbai Jurisdiction.
