KYLAND Technology SICOM3010G Assembly instructions

SICOM3010G Industrial Ethernet Switch
Hardware Installation Manual
Kyland Technology Co., LTD.
Publication Date: Oct. 2011
Version: V1.0
Customer Service Hotline: [phone]
FAX: [phone]
Website: http://www.kyland.cn
E-mail: [e-mail]

SICOM3010G User’s Manual-v1.0
1
SICOM3010G Industrial Ethernet Switch
Hardware Installation Manual
Disclaimer: Kyland Technology Co., Ltd. tries to keep the content of this
manual as accurate and as updated as possible. This document is not
guaranteed to be error-free, and we reserve the right to amend it without notice
to users.
Copyright © 2011 KYLAND Technology CO., LTD.
All rights reserved.
No part of this documentation may be excerpted, reproduced, translated,
annotated or duplicated, in any form or by any means without the prior written
permission of KYLAND Corporation.

SICOM3010G User’s Manual-v1.0
2
.
Notice for Safety Operation
This product performs reliably as long as it is used according to the
guidance. Artificial damage or destruction of the equipment should be
avoided.
Read this manual carefully and keep it for future reference;
Do not place the equipment near water sources or damp areas;
Do not place anything on power cable or put the cable in unreachable
places;
Do not tie or wrap the cable, which may cause a fire risk;
Power connectors and other equipment connectors should be firmly
interconnected and checked frequently;
Do not repair the equipment by yourself, unless it is clearly specified in
the manual;
Please keep the equipment clean; if necessary, wipe the equipment
with soft cotton cloth.
In the following cases, please immediately shut down your power supply
and contact your Kyland representative:
Water gets into the equipment;
Equipment damage or shell damage;
Equipment operation or performance has abnormally changed;
The equipment emits odor, smoke or abnormal noise.

SICOM3010G User’s Manual-v1.0
3
Contents
1Packing List..........................................................................................................4
2Product Overview................................................................................................. 4
3Structure and Interface......................................................................................... 5
3.1 Front Panel....................................................................................................5
3.2 Top Panel ......................................................................................................7
4Mounting............................................................................................................... 8
4.1 Dimension Drawing........................................................................................8
4.2 Mounting Steps..............................................................................................9
5Cable Connection............................................................................................... 12
5.1 10/100/1000Base-T(X) Ethernet Port........................................................... 12
5.2 1000Base-X, 10/100/1000Base-T(X) SFP Port............................................ 14
5.2.1 Gigabit SFP Optical Module .................................................................... 14
5.2.2 Gigabit SFP Electrical Module................................................................. 16
5.3 1000Base-X, 10/100/1000Base-T(X) Combo Port........................................ 17
5.4 Console Interface......................................................................................... 18
5.5 Power .......................................................................................................... 19
5.6 Grounding.................................................................................................... 20
5.7 Relay Contact.............................................................................................. 22
6LED Indicators.................................................................................................... 23
7Reset Button....................................................................................................... 25
8Management Access.......................................................................................... 25
8.1 Connected through Console Port................................................................. 25
8.2 Connected through Ethernet Cable.............................................................. 28
8.3 Web Access................................................................................................. 28
9Product Configuration Information ...................................................................... 29
10Basic Features and Specifications...................................................................... 31

SICOM3010G User’s Manual-v1.0
4
1 Packing List
SICOM3010G Industrial Ethernet Switch 1
CD 1
Screwdriver 1
18#AWG yellow-green line 1
Certificate of Quality (including Certificate of Compliance)1
Note
: After unpacking, please check the accessories and the appearance of the
equipment. If anything is missing or damaged, please contact us.
2 Product Overview
SICOM3010G is a series of green low power consumption and full Gigabit
ports industrial Ethernet switch that can be applied extensively in wind
power, distribution network automation, subway PIS、AFC, power SACDA,
wastewater treatment, highway, metallurgy, hydroelectric power,
photovoltaic power, railway CBTC, factory automation, intelligent
transportation and many other industries.
SICOM3010G has a Mini USB Console port, and supports Web, Telnet and
Console network management; supports VCT (Virtual Cable Test); supports
one-key recovery.
SICOM3010G industrial Ethernet switch supports DIN-Rail and panel
mounting. It provides 1000Base-X, 10/100/1000Base-T(X) Combo ports,
1000Base-X, 10/100/1000bBase-T(X) SFP ports, and
10/100/1000Base-T(X) ports.

SICOM3010G User’s Manual-v1.0
5
3 Structure and Interface
3.1 Front Panel
SICOM3010G-2GX/GE-6GE
Figure 1 Front Panel 1
Table 1 SICOM3010G-2GX/GE-6GE Front Panel
Number Diagram Label Description
1 PWR1 Power 1 LED
2 PWR2 Power 2 LED
3 Run Running LED
4 Ring Ring LED
5 Reset Reset button

SICOM3010G User’s Manual-v1.0
6
6 Console Console interface
7 Alarm Alarm LED
8 GX7/GE7, GX8/GE8 1000Base-X, 10/100/1000Base-T(X) Combo port
9 GE1~GE6 10/100/1000Base-T(X) RJ45 port
10 -- RJ45 port Speed LED
11 -- RJ45 port Link/ACT LED
SICOM3010G-2GX/GE-2GX-6GE
Figure 2 Front Panel 2
Table 2 SICOM3010G-2GX/GE-2GX-6GE Front Panel
Number Diagram Label Description
1 PWR1 Power 1 LED

SICOM3010G User’s Manual-v1.0
7
2 PWR2 Power 2 LED
3 Run Running LED
4 Ring Ring LED
5 Reset Reset button
6 Console Console interface
7 Alarm Alarm LED
8 GX9, GX10 1000Base-X, 10/100/1000Base-T(X) SFP port
9 GX7/GE7, GX8/GE8 1000Base-X, 10/100/1000Base-T(X) Combo port
10 GE1~GE6 10/100/1000Base-T(X) RJ45 port
11 -- RJ45 port Speed LED
12 -- RJ45 port Link/ACT LED
3.2 Top Panel

SICOM3010G User’s Manual-v1.0
8
Figure 3 Top Panel
Table 3 SICOM3010G Top Panel
Number Description
1 Power supply terminal block
2 Grounding Screw
3 Relay contact
4 Mounting
4.1 Dimension Drawing
Dimension Drawing for DIN-Rail Mounting (Unit: mm)
Figure 4 DIN-Rail Mounting Dimension
Dimension Drawing for Panel Mounting (Unit: mm)

SICOM3010G User’s Manual-v1.0
9
Figure 5 Panel Mounting Dimension
4.2 Mounting Steps
SICOM3010G DIN-Rail Mounting
The specific steps are as follows:
Step 1: Select the mounting position for SICOM3010G and ensure that
there is adequate space.
Step 2: Insert the top of the DIN-Rail into the slot of the DIN-Rail connecting
seat in the rear panel of SICOM3010G as shown below; move the switch in
the direction of arrow 2 to put the whole Din-Rail into the seat; check
whether SICOM3010G is firmly mounted on the DIN-Rail, as shown below.
Figure 6 DIN-Rail Mounting

SICOM3010G User’s Manual-v1.0
10
Remove SICOM3010G from DIN-Rail
The specific steps are as follows:
Step 1: Insert the screwdriver into the hole at the bottom of spring locking
plate; press the plate down to loosen the connection of DIN-Rail and switch,
as shown in arrow 1.
Step 2: Pull the SICOM3010G up in the direction of arrow 2; meanwhile
remove the switch from the DIN-Rail along the direction of arrow 3.
Figure 7 Dismounting
SICOM3010G Panel Mounting
The specific steps are as follows:
Step 1: Select the mounting position for SICOM3010G on the wall or in
cabinet; ensure that there is adequate space for the switch.
Step 2: Drill 4 holes on the selected position according to the panel
mounting dimension drawing; use a cross-screwdriver to screw 4 cross-slot
screws (M3×10) into holes. Don’t tighten the screws completely; leave
about 5mm of space between.
Step 3: Aim 4 mounting holes on SICOM3010G mounting plate at 4 fixed
screws; pass the screws through 4 holes with the diameter of 6.5mm (Ф6.5);

SICOM3010G User’s Manual-v1.0
11
then slide down SICOM3010G as seen below; finally screw 4 screws tightly.
Now the SICOM3010G should be firmly fixed to the wall or cabinet.
Figure 8 Panel Mounting
Remove SICOM3010G from wall or cabinet
The specific steps are as follows:
Step 1: Use a screwdriver to loosen 4 screws; move the switch up to let
screws into 4 holes with the diameter of 6.5mm (Ф6.5).
Step 2: Unscrew the screws from wall or cabinet; remove the switch from
wall or cabinet.
Figure 9 Dismounting

SICOM3010G User’s Manual-v1.0
12
5 Cable Connection
5.1 10/100/1000Base-T(X) Ethernet Port
10/100/1000Base-T(X) Ethernet RJ45 port can be connected to terminal
equipment and network devices with straight-through cables or crossover
cables. RJ45 connectors must be equipped at both ends of cable.
Pin definition of 10/100/1000Base-T(X) RJ45 port
Pin number of 10/100/1000Base-T(X) RJ45 port is shown in Figure 10.
Figure 10 RJ45 Port
Pin definition of 10/100/1000Base-T(X) RJ45 port is shown in Table 4.
Table 4 Pin Definition of 10/100/1000Base-T(X) RJ45 Port
Pin MDI MDI-X
1 Transmit/Receive Data(TRD0+) Transmit/Receive Data(TRD1+）
2 Transmit/Receive Data(TRD0-) Transmit/Receive Data(TRD1-)
3 Transmit/Receive Data(TRD1+) Transmit/Receive Data(TRD0+)
4 Transmit/Receive Data(TRD2+) Transmit/Receive Data(TRD3+)
5 Transmit/Receive Data(TRD2-) Transmit/Receive Data(TRD3-)
6 Transmit/Receive Data(TRD1-) Transmit/Receive Data(TRD0-)
7 Transmit/Receive Data(TRD3+) Transmit/Receive Data(TRD2+)

SICOM3010G User’s Manual-v1.0
13
8 Transmit/Receive Data(TRD3-) Transmit/Receive Data(TRD2-)
Note: “+”“-”means level polarity.
Wiring Sequence
Figure 11 10/100/1000M Straight-through Cable Wiring
Figure 12 10/100/1000M Cross-over Cable Wiring
Note: The correlation between the pin of RJ45 connector and the color of twisted pair is:
1-orange and white, 2-orange, 3-green and white, 4-blue, 5-blue and white, 6-green,
7-brown and white, 8-white.

SICOM3010G User’s Manual-v1.0
14
5.2 1000Base-X, 10/100/1000Base-T(X) SFP Port
1000Base-X, 10/100/1000Base-T(X) SFP port namely is 1000Base SFP
slot. Insert SFP module to SFP slot, and then plug the twisted pair or the
optical fiber into SFP module to transmit data. Choose the model of SFP
module to meet your requirements, as shown in Table 11.
5.2.1 Gigabit SFP Optical Module
Figure 13 shows an example of a Gigabit SFP optical module;
Figure 13 Gigabit SFP Optical Module
Gigabit SFP optical module is equipped with LC connector, and each
port consists of TX (transmit) port and RX (receive) port, as shown in
Figure 14.
Connect the TX (transmit) port of switchA to the RX (receive) port of
switch B, and the RX (receive) port of switch A to the TX (transmit) port
of switch B in order to transmit data between switchAand switch B, as
shown in Figure 14.

SICOM3010G User’s Manual-v1.0
15
Figure 14 Gigabit SFP Optical Module Wiring
Confirm Gigabit SFP optical module RX port and TX port
1. Insert the two connectors in one end of optical fiber into SFP optical
module, and then insert the two connectors in the other end of the
optical fiber into SFP optical module of another switch to
communicate.
2. Check the corresponding port Link/ACT indicator in the front panel:
Indicator flashing means link connectivity;
Indicator off means no link connectivity and it may be because of the
incorrect link between RX port and TX port in SFP optical modules.
Try to swapping connectors in any one end of optical fiber.
The use of SFP optical module
While wiring, first insert the SFP optical module into the SFP slot in the
switch, and then plug the optical fiber into the SFP optical module. See
Figure 15.

SICOM3010G User’s Manual-v1.0
16
Figure 15 SFP Optical Module
5.2.2 Gigabit SFP Electrical Module
Figure 16 shows an example of a Gigabit SFP electrical module;
Figure 16 Gigabit SFP Electrical Module
The use of SFP electrical module
While wiring, first insert the SFP electrical module into the SFP slot in
the switch, and then plug the twisted pair into the SFP electrical module.
See Figure 17.

SICOM3010G User’s Manual-v1.0
17
Figure 17 SFP Electrical Module
5.3 1000Base-X, 10/100/1000Base-T(X) Combo Port
As shown in Figure 18, The 1000Base-X, 10/100/1000Base-T(X) Combo
port consists of one 1000 Base-X port (GX7) and one 10/100/1000Base-T(X)
Ethernet port (GE7), and only one of the two ports can be used at one time.
Besides, the 1000 Base-X port has priority over 10/100/1000Base-T(X) port.
Plug the optical fiber and the twisted pair into GX7 and GE7 respectively;
GX7 can communicate normally and the GE7 will be disabled automatically.

SICOM3010G User’s Manual-v1.0
18
Figure 18 Combo Port
10/100/1000Base-T(X) Ethernet port
The instructions of 10/100/1000Base-T(X) Ethernet port can refer to
section 5.1.
1000Base-X port
Insert Gigabit SFP optical module into 1000Base-X port, and then plug
the optical fiber into SFP module to transmit data. Choose the model of
SFP module that will meet your requirements, as shown in Table 11.
The instructions of Gigabit SFP optical module can refer to section 5.2.1.
5.4 Console Interface
Install the driver for Mini USB onto your PC. The driver “Mini USB
driver.exe” is in the software download folder, which is on the supplied CD.
Connect the USB port on the PC to the Console interface on the switch
with cable equipped with Mini USB connector and USB connector at both
ends. Run Hyper Terminal software in WINDOWS operating system to
connect to console software of the switch, which will allow you to configure,
maintain and manage the switch.
Mini USB connector
Mini USB connector pin number is shown in Figure 19.
Figure 19 Mini USB Connector
Mini USB connector pin definition is shown in Table 5.

SICOM3010G User’s Manual-v1.0
19
Table 5 Mini USB Pin Definition
Mini USB Pin Definition
1 VBUS
2 D-
3 D+
4 ID
5 GND
USB connector
USB connector pin number is shown in Figure 20.
Figure 20 USB Connector
USB pin definition is shown in Table 6.
Table 6 USB Pin Definition
USB Pin Definition
1 VBUS
2 D-
3 D+
4 GND
5.5 Power
According to the power input requirements, use a 5.08mm-spacing terminal
block to connect power cable.
Note: The cross section area of power cable is required to be greater than 0.75mm2
