KYLAND Technology SICOM6028GPT Assembly instructions

SICOM6028GPT/6424PT/6028GP/6424P
Series Industrial Ethernet Switch
Hardware Installation Manual
Kyland Technology Co., LTD.
Publication Date: Mar. 2012
Version: V1.1
Customer Service Hotline: [phone]
FAX: [phone]
Website: http://www.kyland.cn
E-mail: [e-mail]

SICOM6028GPT/6424PT/6028GP/6424P User’s Manual-v1.1
1
SICOM6028GPT/6424PT/6028GP/6424P Series Industrial Ethernet Switch
Hardware Installation Manual
Disclaimer: Kyland Technology Co., Ltd. tries to keep the content of this manual as
accurate and as updated as possible. This document is not guaranteed to be
error-free, and we reserve the right to amend it without notice to users.
Copyright © 2012 KYLAND Technology CO., LTD.
All rights reserved.
No part of this documentation may be excerpted, reproduced, translated, annotated or
duplicated, in any form or by any means without the prior written permission of
KYLAND Corporation.

SICOM6028GPT/6424PT/6028GP/6424P User’s Manual-v1.1
2
Notice for Safety Operation
This product performs reliably as long as it is used according to the guidance.
Artificial damage or destruction of the equipment should be avoided.
Read this manual carefully and keep it for future reference;
Do not place the equipment near water sources or damp areas;
Do not place anything on power cable or put the cable in unreachable places;
Do not tie or wrap the cable, which may cause a fire risk;
Power connectors and other equipment connectors should be firmly
interconnected and checked frequently;
Do not repair the equipment by yourself, unless it is clearly specified in the
manual;
Please keep the equipment clean; if necessary, wipe the equipment with soft
cotton cloth.
In the following cases, please immediately shut down your power supply and
contact your Kyland representative:
Water gets into the equipment;
Equipment damage or shell damage;
Equipment operation or performance has abnormally changed;
The equipment emits odor, smoke or abnormal noise.

SICOM6028GPT/6424PT/6028GP/6424P User’s Manual-v1.1
3
Contents
1Packing List.........................................................................................................5
2Product Overview ...............................................................................................5
3Structure and Interface.......................................................................................6
3.1 Front Panel..................................................................................................6
3.2 Rear Panel ..................................................................................................6
3.2.1 Rear Panel 1U Slot ............................................................................7
3.2.2 Rear Panel 0.5U Slot.........................................................................8
4Interface Modules Mounting ..............................................................................9
4.1 Interface Modules Mounting......................................................................10
4.2 Interface Modules Removal.......................................................................12
5Switch Chassis Mounting ................................................................................16
5.1 Dimension Drawing ...................................................................................16
5.2 Mounting Steps .........................................................................................17
6Cable Connection .............................................................................................19
6.1 10/100Base-T(X) Ethernet Port.................................................................19
6.2 100Base-FX Ethernet Port ........................................................................21
6.3 10/100/1000Base-T(X) Ethernet Port........................................................22
6.4 1000Base-X, 10/100/1000Base-T(X) SFP Port.........................................23
6.4.1 Gigabit SFP Optical Module.............................................................23
6.4.2 Gigabit SFP Electrical Module .........................................................25
6.5 Console Interface......................................................................................26
6.6 Power........................................................................................................27
6.7 Grounding..................................................................................................28
6.8 Relay Contact............................................................................................29

SICOM6028GPT/6424PT/6028GP/6424P User’s Manual-v1.1
4
7LED Indicators ..................................................................................................29
8Power-on Self-inspection.................................................................................31
9Management Access......................................................................................32
9.1 Connected through Console Port..............................................................32
9.2 Connected through Ethernet Cable...........................................................34
9.3 Web Access...............................................................................................35
10 Product Configuration Information.................................................................36
11 Basic Features and Specifications..................................................................38

SICOM6028GPT/6424PT/6028GP/6424P User’s Manual-v1.1
5
1 Packing List
Industrial Ethernet Switch 1
CD (including Hardware Installation Manual, Web Operation Manual and
Windows utility) 1
Screwdriver 1
Mounting Bracket 2
Puller 1
Certificate of Quality (including Certificate of Compliance)1
Note: After unpacking, please check the accessories and the appearance of the equipment. If
anything is missing or damaged, please contact us.
2 Product Overview
The series switches include SICOM6028GPT/6424PT/6028GP/6424P layer 3
switch as shown in Table 1.They all adopt flexible modular design for easy
expansion.
Table 1 Product Model
Model
Interface Description
PTP
SICOM6028GPT
Supports max 28 Gigabit ports
Supported
SICOM6424PT
Supports max 4 Gigabit ports and 24 fast
Ethernet ports Supported
SICOM6028GP
Supports max 28 Gigabit ports
Unsupported
SICOM6424P
Supports max 4 Gigabit ports and 24 fast
Ethernet ports Unsupported
The series switches support 19 inch 1U Rack mounting by their front/rear panel.
They provide one 1U slot and six 0.5U slots in the rear panel, applied extensively
in power, rail transit, coal mining and many other industries. They are compliant
with IEC61850-3 and IEEE1613; provide Mini USB Console port; support
IEC62439-6; support VCT (Virtual Cable Test).

SICOM6028GPT/6424PT/6028GP/6424P User’s Manual-v1.1
6
3 Structure and Interface
3.1 Front Panel
Figure 1 Front Panel
1: Alarm-Alarm LED
2: Run-Running LED
3: Ring-Ring LED
4: Lock-Synchronization Finish LED
5: PWR2-Power 2 LED
6: PWR1-Power 1 LED
7: Slot (1-7) Speed (1-4)-4 port Speed LEDs (Slot (1-7))
8: Slot (1-7) Link/ACT (1-4)-4 port Link/ACTLEDs ((Slot (1-7))
9: Console-Console interface (Mini USB)
10: USB interface (for future release)
11: Front mounting bracket
3.2 Rear Panel
Figure 2 Rear Panel
1: 1U Slot1 for 4-port Gigabit interface module
2: 0.5U Slot2 for 4-port Ethernet interface module
3: 0.5U Slot3 for 4-port Ethernet interface module
4: 0.5U Slot4 for 4-port Ethernet interface module

SICOM6028GPT/6424PT/6028GP/6424P User’s Manual-v1.1
7
5: 0.5U Slot5 for 4-port Ethernet interface module
6: 0.5U Slot6 for 4-port Ethernet interface module
7: 0.5U Slot7 for 4-port Ethernet interface module
8: Alarm contact
9: Grounding screw
10: Terminal block for power input
11: Rear mounting bracket
3.2.1 Rear Panel 1U Slot
SM6.6-4GX-1U
SM6.6-4GX-1U：
4 1000Base-X, 10/100/1000Base-T(X) SFP ports
Figure 3SM6.6-4GX-1U
SM6.6-2GX-2GE-1U
SM6.6-2GX-2GE-1U：
2 1000Base-X, 10/100/1000Base-T(X) SFP ports
2 10/100/1000Base-T(X) RJ45 ports
Figure 4SM6.6-2GX-2GE-1U
SM6.6-4GE-1U
SM6.6-4GE-1U:
4 10/100/1000Base-T(X) RJ45 ports
Figure 5SM6.6-4GE-1U

SICOM6028GPT/6424PT/6028GP/6424P User’s Manual-v1.1
8
3.2.2 Rear Panel 0.5U Slot
SM6.6-4GX-0.5U
Figure 6SM6.6-4GX-0.5U
SM6.6-4GX-0.5U: 4 1000Base-X, 10/100/1000Base-T(X) SFP ports
SM6.6-2GX-2S/M-0.5U
Figure 7SM6.6-2GX-2S/M-0.5U
SM6.6-2GX-2S/M-0.5U:
2 1000Base-X, 10/100/1000Base-T(X) SFP ports
2 100Base-FX, SM/MM ports, FC/SC/ST connector
SM6.6-4GE-0.5U
Figure 8SM6.6-4GE-0.5U
SM6.6-4GE-0.5U: 4 10/100/1000Base-T(X) RJ45 ports
SM6.6-2GX-2GE-0.5U
Figure 9SM6.6-2GX-2GE-0.5U
SM6.6-2GX-2GE-0.5U:

SICOM6028GPT/6424PT/6028GP/6424P User’s Manual-v1.1
9
2 1000Base-X, 10/100/1000Base-T(X) SFP ports
2 10/100/1000Base-T(X) RJ45 ports
SM6.6-4S/M-0.5U
Figure 10 SM6.6-4S/M-0.5U
SM6.6-4S/M-0.5U:
4 100Base-FX, SM/MM ports, FC/SC/ST connector
SM6.6-2S/M-2T-0.5U
Figure 11 SM6.6-2S/M-2T-0.5U
SM6.6-2S/M -2T-0.5U:
2 100Base-FX, SM/MM ports, FC/SC/ST connector
2 10/100Base-T(X) RJ45 ports
SM6.6-4T-0.5U
Figure 12 SM6.6-4T-0.5U
SM6.6-4T-0.5U: 4 10/100Base-T(X) RJ45 ports
4 Interface Modules Mounting
Note: We recommend that the interface modules be installed and removed while the power is
disconnected.

SICOM6028GPT/6424PT/6028GP/6424P User’s Manual-v1.1
10
4.1 Interface Modules Mounting
The series switches provide one 1U Slot (Slot1) and six 0.5U Slots (Slot2-Slot7) in
the rear panel as shown in Figure 2. Interface modules can be installed into slots
as needed. The models of the interface modules are shown in Table 11.
Note: Not all the slots need to be installed with the interface modules; you can choose the
appropriate slots according to specific requirements.
0.5U interface modules installation in upper slots(Slot2,Slot4 and Slot6)
Step 1: Choose the appropriate 0.5U interface module. Insert the interface
module with the port numbers (1, 2, 3, 4) facing up. Insert the guide rail of
interface module into the guide rail slot, as shown in Figure 13 , and then
push the interface module into the slot completely along the guide rail slot.
Figure 13 0.5U Interface Module Mounting 1
Step 2: Secure the interface module into the switch chassis with two screws
(M2.5×5), as shown in Figure 14.

SICOM6028GPT/6424PT/6028GP/6424P User’s Manual-v1.1
11
Figure 14 0.5U Interface Module Mounting 2
0.5U interface modules installation in lower slots(Slot3,Slot5 and Slot7)
Step 1: Choose the appropriate 0.5U interface module. Insert the interface
module with the port numbers (1, 2, 3, 4) upside down. Insert the guide rail of
interface module into the guide rail slot, as shown in Figure 15, and then push
the interface module into the slot completely along the guide rail slot.
Figure 15 0.5U Interface Module Mounting 3
Step 2: Secure the interface module into the switch chassis with two screws

SICOM6028GPT/6424PT/6028GP/6424P User’s Manual-v1.1
12
(M2.5×5), as shown in Figure 16 .
Figure 16 0.5U Interface Module Mounting 4
1U interface modules mounting in Slot1
The installation instructions for 1U interface modules in Slot1 are the same as
in upper slots(Slot2,Slot4 and Slot6). Please refer to the instructions above.
4.2 Interface Modules Removal
0.5U interface modules removal
When removing the 0.5U interface modules, a puller as shown in Figure 17 is
needed.
Figure 17 Puller
The specific mounting steps are as follows: (removal for upper and lower slots
is the same)

SICOM6028GPT/6424PT/6028GP/6424P User’s Manual-v1.1
13
Step 1: Remove the two fastening screws of the interface modules and switch
chassis.
Step 2: Insert the long tab into the handle of the interface module, as shown in
Figure 18; then move the puller left to ensure adequate space for inserting the
short tab.
Figure 18 Interface Modules Removal 1
Step 3: Insert the short tab of the puller into the other handle of the interface
module as shown in Figure 19; move the puller to the right to keep both of the
tabs inserted into the two handles of the interface module, as shown in Figure
20.

SICOM6028GPT/6424PT/6028GP/6424P User’s Manual-v1.1
14
Figure 19 Interface Modules Removal 2
Figure 20 Interface Modules Removal 3
Step 4: Grip the handle of puller; push the handle in the direction of arrow 1
with your thumb, and at the same time pull the handle outwards with your
fingers in the direction of arrow 2. The interface module will pop-up. Pull the
interface module outwards along the guide rail slot, until it completely comes
out of the switch chassis.

SICOM6028GPT/6424PT/6028GP/6424P User’s Manual-v1.1
15
Figure 21 Interface Modules Removal 4
Note: When using the puller, ensure to insert the long tab into the handle of the interface module
first and then insert the short tab; otherwise the long and short tabs will not be inserted into the
handles because of the specific design of the puller.
1U interface modules removal
Step 1: Remove the three fastening screws of the interface modules and
switch chassis.
Step 2: Pull the handle of the interface module outwards along the guide rail
slot, until it completely comes out of the switch chassis, as shown in Figure
22.

SICOM6028GPT/6424PT/6028GP/6424P User’s Manual-v1.1
16
Figure 22 Interface Modules Removal 5
5 Switch Chassis Mounting
5.1 Dimension Drawing

SICOM6028GPT/6424PT/6028GP/6424P User’s Manual-v1.1
17
Figure 23 Mounting Dimension Drawing
Note: The switch housing is part of the heat dissipation system, which becomes hot during
operation. Please use caution when coming in contact and avoid covering the ventilation
holes of the switch housing when the switch is operating.
5.2 Mounting Steps
The series switches support rack mounting by its front/rear panel.
The steps of mounting by the front panel

SICOM6028GPT/6424PT/6028GP/6424P User’s Manual-v1.1
18
Step 1: Select the mounting position for the switch in the rack and ensure that
there is adequate space for it.
Step 2: As shown in Figure 24, move the switch in the direction of arrow 1 and
align the holes in the switch mounting brackets and the corresponding holes
in the rack; use 4 screws (M5×14) to fix the switch in the rack.
Figure 24 Mounting by Front Panel
Removal steps
Step 1: Unscrew 4 screws fastening the switch and the rack as shown in
Figure 25.
Step 2: Remove the switch from the rack along the direction of arrow 1.
Figure 25 Removal
The steps of mounting by the rear panel
Step 1: Select the mounting position for the switch in the rack and ensure that

SICOM6028GPT/6424PT/6028GP/6424P User’s Manual-v1.1
19
there is adequate space for it.
Step 2: As shown in Figure 26, move the switch in the direction of arrow 1 and
align the holes in the mounting brackets and the corresponding holes in the
rack; use 4 screws (M5×14) to fix the switch in the rack.
Figure 26 Mounting by Rear Panel
Removal steps
Step 1: Unscrew 4 screws fastening the switch and the rack as shown in
Figure 27.
Step 2: Remove the switch from the rack along the direction of arrow 1.
Figure 27 Removal
6 Cable Connection
6.1 10/100Base-T(X) Ethernet Port
10/100Base-T(X) Ethernet RJ45 port can be connected to terminal equipment and
network devices with straight-through cables or crossover cables. RJ45
connectors must be equipped at both ends of cable.
