Leica MojoMINI Installation and operating manual

Leica
V 1.0

Leica
Safety Guide
English
Version 1.0
EN

2
Leica mojoMINI, Introduction
EN
Introduction
Symbols used in
this manual
The symbols used in this manual have the following meanings.
Type Description
Danger Indicates an imminently hazardous situation which, if not
avoided, will result in death or serious personal injury.
Warning Indicates a potentially hazardous situation or an unintended
use which, if not avoided, could result in death or serious
personal injury.
Caution Indicates a potentially hazardous situation or an unintended
use which, if not avoided, may result in minor or moderate
personal injury, appreciable material, financial and environ-
mental damage, or all of these.
Important paragraphs which must be adhered to in practice as
they enable the product to be used in a technically correct and
efficient manner.

Leica mojoMINI, Safety Directions 3
EN
1 Safety Directions
1.1 General Introduction
Description • The following directions should enable the person responsible for the product,
and the person who actually uses the equipment, to anticipate and avoid opera-
tional hazards.
• The person responsible for the product must ensure that all users understand
these directions and adhere to them.

4
Leica mojoMINI, Safety Directions
EN
1.2 Intended Use
Permitted use • Street navigation and field guidance.
• Data communication with external appliances.
• Measuring raw data and computing coordinates using satellite signals.
Adverse use • Use of the product without instruction.
• Use outside of the intended limits.
• Disabling safety systems.
• Removal of hazard notices.
• Opening the product using tools.
• Modification or conversion of the product.
• Use after misappropriation.
• Use of products with obviously recognizable damages or defects.
• Use with accessories from other manufacturers without the prior explicit
approval of Leica Geosystems.
• Inadequate safeguards at a work site.
Warning Adverse use can lead to injury, malfunction and damage.
It is the task of the person responsible for the equipment to inform the user about
hazards and how to counteract them. The product is not to be operated until the user
has been instructed on how to work with it.

Leica mojoMINI, Safety Directions 5
EN
Warning Unauthorised modification of agricultural machinery by mounting or installing the
product may alter the function and safety of that agricultural machinery.
Precautions:
Follow the instructions of the machinery manufacturer. If no appropriate instruction
is available, ask the machinery manufacturer for instructions before mounting or
installing the product.
1.3 Limits of Use
Environment Suitable for use in an atmosphere appropriate for permanent human habitation: not
suitable for use in aggressive or explosive environments.
Danger Local safety authorities and safety experts must be contacted before working in
hazardous areas, or in close proximity to electrical installations or similar situations
by the person in charge of the product.

6
Leica mojoMINI, Safety Directions
EN
1.4 Responsibilities
Manufacturer of
the product
Leica Geosystems AG, CH-9435 Heerbrugg, hereinafter referred to as Leica Geosys-
tems, is responsible for supplying the product, including the user manual and original
accessories, in a completely safe condition.
Manufacturers of
non
Leica Geosystems
accessories
The manufacturers of non Leica Geosystems accessories for the product are respon-
sible for developing, implementing and communicating safety concepts for their
products, and are also responsible for the effectiveness of those safety concepts in
combination with the Leica Geosystems product.
Person in charge of
the product
The person in charge of the product has the following duties:
• To understand the safety instructions on the product and the instructions in the
user manual.
• To be familiar with local regulations relating to safety and accident prevention.
• To inform Leica Geosystems immediately if the product and the application
becomes unsafe.
• To ensure that the national laws, regulations and conditions for the operation of
radio transmitters are respected.
Warning The person responsible for the product must ensure that it is used in accordance with
the instructions. This person is also accountable for the training and the deployment
of personnel who use the product and for the safety of the equipment in use.

Leica mojoMINI, Safety Directions 7
EN
1.5 Hazards of Use
Warning The absence of instruction, or the inadequate imparting of instruction, can lead to
incorrect or adverse use, and can give rise to accidents with far-reaching human,
material, financial and environmental consequences.
Precautions:
All users must follow the safety directions given by the manufacturer and the direc-
tions of the person responsible for the product.
Caution Watch out for erroneous measurement results if the product has been dropped or
has been misused, modified, stored for long periods or transported.
Precautions:
Periodically carry out test measurements and perform the field adjustments indicated
in the user manual, particularly after the product has been subjected to abnormal use
and before and after important measurements.
Warning If the product is used with accessories, for example masts, staffs, poles, you may
increase the risk of being struck by lightning.
Precautions:
Do not use the product in a thunderstorm.

8
Leica mojoMINI, Safety Directions
EN
Warning Inadequate securing of the working site can lead to dangerous situations, for
example in traffic, on building sites, and at industrial installations.
Precautions:
Always ensure that the working site is adequately secured. Adhere to the regulations
governing safety and accident prevention and road traffic.
Warning Only Leica Geosystems authorised service workshops are entitled to repair these
products.
Caution If the accessories used with the product are not properly secured and the product is
subjected to mechanical shock, for example blows or falling, the product may be
damaged or people may sustain injury.
Precautions:
When setting-up the product, make sure that the accessories are correctly adapted,
fitted, secured, and locked in position.
Avoid subjecting the product to mechanical stress.
Caution The product uses the GPS P-Code signal which by U.S. policy may be switched off
without notice.

Leica mojoMINI, Safety Directions 9
EN
Caution During the transport, shipping or disposal of batteries it is possible for inappropriate
mechanical influences to constitute a fire hazard.
Precautions:
Before shipping the product or disposing of it, discharge the batteries by running the
product until the batteries are flat.
When transporting or shipping batteries, the person in charge of the product must
ensure that the applicable national and international rules and regulations are
observed. Before transportation or shipping contact your local passenger or freight
transport company.
Caution Installing near mechanically moving machine components may damage the product.
Precautions:
Deflect the mechanically moving machine components as far as possible and define
a safe installation zone.
Caution Beware of inadequate steering if machine is defective like after a crash or other
damaging events or alterations to the machine.
Precautions:
Periodically perform control measurements and field adjustments on the machine as
specified in the User Manual.

10
Leica mojoMINI, Safety Directions
EN
Warning While steering or navigating the machine accidents may occur due a) the operator
not paying attention to the surroundings (persons, ditches, traffic, etc), or b)
malfunctions (… of a system component, interference, etc.).
Precautions:
The operator assures that the machine is operated, guided and monitored by a qual-
ified user (e.g., a licensed driver). The user has to be able to take emergency meas-
ures, for example an emergency stop.
Warning Batteries not recommended by Leica Geosystems may be damaged if charged or
discharged. They may burn and explode.
Precautions:
Only charge and discharge batteries recommended by Leica Geosystems.
Warning Using a battery charger not recommended by Leica Geosystems can destroy the
batteries. This can cause fire or explosions.
Precautions:
Only use chargers recommended by Leica Geosystems to charge the batteries.
Warning High mechanical stress, high ambient temperatures or immersion into fluids can
cause leackage, fire or explosions of the batteries.
Precautions:
Protect the batteries from mechanical influences and high ambient temperatures. Do
not drop or immerse batteries into fluids.

Leica mojoMINI, Safety Directions 11
EN
Warning If battery terminals come in contact with jewellery, keys, metallised paper or other
metals, short circuited battery terminals can overheat and cause injury or fire, for
example by storing or transporting in pockets.
Precautions:
Make sure that the battery terminals do not come into contact with metallic objects.
Danger If the product is used with accessories, for example, masts, staffs, or poles, you may
increase the risk of being struck by lightning. Danger from high voltages also exists
near power lines. Lightning, voltage peaks, or the touching of power lines can cause
damage, injury and death.
Precautions:
• Do not use the product in a thunderstorm as you may increase the risk of being
struck by lightning.
• Be sure to remain at a safe distance from electrical installations. Do not use the
product directly under or in close proximity to power lines. If it is essential to
work in such an environment contact the safety authorities responsible for elec-
trical installations and follow their instructions.
• To prevent damages due to indirect lightning strikes (voltage spikes) cables, for
example for antenna, power source or modem should be protected with appro-
priate protection elements, like a lightning arrester. These installations must be
carried out by an authorised specialist.
• If there is a risk of a thunderstorm, or if the equipment is to remain unused and
unattended for a long period, protect your product additionally by unplugging all
systems components and disconnecting all connecting cables and supply cables.

12
Leica mojoMINI, Safety Directions
EN
Warning If the product is improperly disposed of, the following can happen:
• If polymer parts are burnt, poisonous gases are produced, which may impair
health.
• If batteries are damaged or are heated strongly, they can explode and cause
poisoning, burning, corrosion, environmental contamination, or all of these.
• By disposing of the product irresponsibly you may enable unauthorised persons
to use it in contravention of the regulations, exposing themselves and third
parties to the risk of severe injury and rendering the environment liable to
contamination.
Precautions:
Product specific treatment and waste management information can be downloaded
from the Leica Geosystems home page at http://www.leica-geosystems.com/treat-
ment or obtained from your Leica Geosystems dealer.
Warning Excessively loud volume may damage your hearing.
Precautions:
Turn the volume down before connecting earphones, and then turn the volume up to
a comfortable level.
The product must not be disposed with household waste. Dispose of the
product appropriately in accordance with the national regulations in force in
your country. Always prevent access to the product by unauthorised
personnel.

Leica mojoMINI, Safety Directions 13
EN
Warning • The SmartAg receiver must be protected by a 5 A fast blow fuse, or damage to
wiring may result. This damage is not covered by warranty.
• If the power supply voltage is outside the specified range, the SmartAg receiver
will not operate.
• If the power supply voltage exceeds +48 V DC, then the SmartAg receiver may be
permanently damaged. This damage is not covered by warranty.
Warning Do not mount the mojoMINI where it may obscure the driver’s view of the road or
field.
Warning Do not mount the mojoMINI where it may be struck by a deploying airbag.

14
Leica mojoMINI, Safety Directions
EN
1.6 Electromagnetic Compatibility EMC
Description The term Electromagnetic Compatability is taken to mean the capability of the
product to function smoothly in an environment where electromagnetic radiation and
electrostatic discharges are present, and without causing electromagnetic distur-
bances to other equipment.
Warning Electromagnetic radiation can cause disturbances in other equipment.
Although the product meets the strict regulations and standards that are in force in
this respect, Leica Geosystems cannot completely exclude the possibility that other
equipment may be disturbed.
Caution There is a risk that disturbances may be caused in other equipment if the product is
used in conjunction with accessories from other manufacturers, for example field
computers, personal computers, two-way radios, non-standard cables or external
batteries.
Precautions:
Use only the equipment and accessories recommended by Leica Geosystems. When
combined with the product, they meet the strict requirements stipulated by the
guidelines and standards. When using computers and two-way radios, pay attention
to the information about electromagnetic compatibility provided by the manufac-
turer.

Leica mojoMINI, Safety Directions 15
EN
Caution Disturbances caused by electromagnetic radiation can result in erroneous measure-
ments. Although the product meets the strict regulations and standards which are in
force in this respect, Leica Geosystems cannot completely exclude the possibility that
the product may be disturbed by very intense electromagnetic radiation produced by,
for example, nearby radio transmitters, two–way radios, or diesel generators.
Precautions:
Check the plausibility of results obtained under these conditions.
Warning If the product is operated with connecting cables attached at only one of their two
ends, the permitted level of electromagnetic radiation may be exceeded and the
correct functioning of other products may be impaired.
Precautions:
While the product is in use, connecting cables must be connected at both ends.

16
Leica mojoMINI, Safety Directions
EN
Radios or digital
cellular phones
Use of the product with radio or digital cellular phone devices:
Warning Electromagnetic fields can cause disturbances in other equipment, in installations, in
medical devices, for example pacemakers or hearing aids and in aircraft. It can also
affect humans and animals.
Precautions:
Although the product meets the strict regulations and standards which are in force
in this respect, Leica Geosystems cannot completely exclude the possibility that other
equipment may be disturbed or that humans or animals may be affected.
• Do not operate the product with radio or digital cellular phone devices in the
vicinity of filling stations or chemical installations, or in other areas where an
explosion hazard exists.
• Do not operate the product with radio or digital cellular phone devices near to
medical equipment.
• Do not operate the product with radio or digital cellular phone devices in aircraft.

Leica mojoMINI, Safety Directions 17
EN
1.7 FCC Statement, Applicable in U.S.
Warning
Warning Changes or modifications not expressly approved by Leica Geosystems for compli-
ance could void the user's authority to operate the equipment.
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC rules.
These limits are designed to provide reasonable protection against harmful interfer-
ence in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interfer-
ence to radio communications. However, there is no guarantee that interference will
not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encour-
aged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and the receiver.
• Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.

18
Leica mojoMINI, Safety Directions
EN
1.8 ICES-003 Statement, Applicable in Canada
Warning This Class (B) digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe (B) est conforme à la norme NMB-003 du
Canada.
