Leica Zeno 10 User manual

Leica Zeno 10/Zeno 15
User Manual
Version 4.1
English

2
Zeno 10/Zeno 15, Introduction
Introduction
Purchase Congratulations on the purchase of a Leica Zeno 10/Zeno 15.
This manual contains important safety directions as well as instructions for setting
up the product and operating it. Refer to "5 Safety Directions" for further informa-
tion.
Read carefully through the User Manual before you switch on the product.
Product identifica-
tion
The type and serial number of your product are indicated on the type plate.
Enter the type and serial number in your manual and always refer to this information
when you need to contact your agency or Leica Geosystems authorised service work-
shop.
Type: _______________
Serial No.: _______________

Zeno 10/Zeno 15, Introduction 3
Symbols The symbols used in this manual have the following meanings:
Type Description
DANGER Indicates an imminently hazardous situation which, if not
avoided, will result in death or serious injury.
WARNING Indicates a potentially hazardous situation or an unintended
use which, if not avoided, could result in death or serious
injury.
CAUTION Indicates a potentially hazardous situation or an unintended
use which, if not avoided, may result in minor or moderate
injury.
NOTICE Indicates a potentially hazardous situation or an unintended
use which, if not avoided, may result in appreciable material,
financial and environmental damage.
Important paragraphs which must be adhered to in practice as
they enable the product to be used in a technically correct and
efficient manner.

4
Zeno 10/Zeno 15, Introduction
Trademarks • Windows is a registered trademark of Microsoft Corporation in the United States
and other countries
• CompactFlash and CF are trademarks of SanDisk Corporation
• Bluetooth®is a registered trademark of Bluetooth SIG, Inc.
• SD Logo is a trademark of SD-3C, LLC.
All other trademarks are the property of their respective owners.
Validity of this
manual
This manual applies to the Zeno 10 and Zeno 15 GNSS/GIS handhelds. Differences
between the various models are marked and described.
Available
documentation Name Description/Format
Zeno 10/Zeno
15 User
Manual
All instructions required in order to operate the product
to a basic level are contained in the User Manual.
Provides an overview of the product together with tech-
nical data and safety directions.

Name Description/Format
Zeno GIS
Getting
Started Guide
Describes the general working of the product in
standard use. Intended as a quick reference field guide.


Zeno 10/Zeno 15, Introduction 5
* only available as Online Help
Refer to the following resources for all Zeno 10/Zeno 15 documentation/soft-
ware:
• the Leica Zeno GIS DVD
• https://myworld.leica-geosystems.com
myWorld@Leica Geosystems (https://myworld.leica-geosystems.com) offers a
wide range of services, information and training material.
With direct access to myWorld, you are able to access all relevant services whenever
it is convenient for you, 24 hours a day, 7 days per week. This increases your effi-
ciency and keeps you and your equipment instantly updated with the latest informa-
tion from Leica Geosystems.
Zeno GIS Help
*
Overall comprehensive help to the product and applica-
tion functions. Included are detailed descriptions of
special software/hardware settings and software/hard-
ware functions.
Name Description/Format

6
Zeno 10/Zeno 15, Introduction
Service Description
myProducts Simply add all Leica Geosystems products that you and your
company own. View detailed information on your products, buy
additional options or Customer Care Packages (CCPs), update your
products with the latest software and keep up-to-date with the
latest documentation.
myService View the service history of your products in Leica Geosystems
Service Centers and detailed information on the services performed
on your products. For your products that are currently in Leica
Geosystems Service Centers view the current service status and the
expected end date of service.
mySupport Create new support requests for your products that will be
answered by your local Leica Geosystems Support Team. View the
complete history of your Support and view detailed information on
each request in case you want to refer to previous support
requests.
myTraining Enhance your product knowledge with the Leica Geosystems
Campus - Information, Knowledge, Training. Study the latest online
training material or download training material on your products.
Keep up-to-date with the latest News on your products and
register for Seminars or Courses in your country.

Zeno 10/Zeno 15, Table of Contents 7
Table of Contents
In this manual Chapter Page
1 Description of the System 11
1.1 Overview 11
1.2 Terminology 12
1.3 System Concept 14
1.3.1 Software Concept 14
1.3.2 Power Concept 18
1.3.3 Data Storage Concept 19
1.4 CS Components 21
1.4.1 CS10 21
1.4.2 CS15 23
1.5 Docking Station Components 25
2 User Interface 26
2.1 Keyboard 26
2.2 Operating Principles 32
3 Operation 33
3.1 Equipment Setup 33

8
Zeno 10/Zeno 15, Table of Contents
3.1.1 Fixing the Display Foil to the CS 33
3.1.2 Fixing a Hand Strap to the CS 35
3.1.3 Fixing the Slot Cover to the CS 36
3.1.4 Inserting and Removing a SIM Card 37
3.1.5 Setting up as Handheld GNSS 39
3.1.6 Setting up the Docking Station 41
3.1.7 Connecting to a Personal Computer 42
3.2 Power Functions 48
3.3 Batteries 50
3.3.1 Operating Principles 50
3.3.2 Changing the Battery 51
3.3.3 Charging the Battery 54
3.4 Working with the Memory Device 56
3.5 LED Indicators on CS10/CS15 60
3.6 LED Indicators on GG03 62
3.7 Using the Digital Camera 64
4 Care and Transport 66
4.1 Transport 66
4.2 Storage 67
4.3 Cleaning and Drying 68

Zeno 10/Zeno 15, Table of Contents 9
5 Safety Directions 70
5.1 General Introduction 70
5.2 Definition of Use 71
5.3 Limits of Use 72
5.4 Responsibilities 73
5.5 Hazards of Use 75
5.6 Electromagnetic Compatibility EMC 80
5.7 FCC Statement, Applicable in U.S. 83
6 Technical Data 88
6.1 CS10/CS15 Technical Data 88
6.2 GS05/GS06 Technical Data 93
6.2.1 Tracking Characteristics 93
6.2.2 Accuracy 95
6.2.3 Technical Data 96
6.3 GG03 Technical Data 99
6.3.1 Tracking Characteristics 99
6.3.2 Accuracy 101
6.3.3 Technical Data 103
6.4 Antennas Technical Data 107
6.5 Conformity to National Regulations 110

10
Zeno 10/Zeno 15, Table of Contents
6.5.1 CS10 110
6.5.2 CS15 113
6.5.3 GG03 116
7 Software Licence Agreement 118
Appendix A Pin Assignments and Sockets 120
A.1 CS10/CS15 120
A.2 GG03 123
Index 125

Zeno 10/Zeno 15, Description of the System 11
1 Description of the System
1.1 Overview
System compo-
nents
003039_002
CS10
GG03
CS15
GS05
GS06

12
Zeno 10/Zeno 15, Description of the System
1.2 Terminology
CS general descrip-
tion
CS is a collective term describing the various models (CS10/CS15) of the multi-
purpose field controller.
Zeno general
description
Zeno is a collective term describing the various models (Zeno 10/Zeno 15) of the
Leica Zeno GNSS/GIS handhelds:
• Leica Zeno 10: GNSS/GIS handheld consisting of CS10 field controller and GS05
GNSS cap.
• Leica Zeno 15: GNSS/GIS handheld consisting of CS15 field controller and GS06
GNSS cap.
• Leica Zeno Rover: GNSS/GIS rover consisting of CS10/CS15 field controller and
GG03 antenna.

Zeno 10/Zeno 15, Description of the System 13
CS available
models
*1 removable
Model Touch screen Colour display Internal 3.5 GSM/ UMTS modem Internal battery*1 SD card CompactFlash card Bluetooth Wireless LAN 802.11b/g Windows CE
CS10 GIS --
CS10 3.5G GIS   
CS15 GIS --
CS15 3.5G GIS   
Use the supplied stylus on the screens of the touch screen.

14
Zeno 10/Zeno 15, Description of the System
1.3 System Concept
1.3.1 Software Concept
Software for all CS
models
Software for the
GS05/GS06
Software for the
GG03
Software type Description
CS firmware This software includes:
(CS_xx.fw) - The language-specific version of Windows CE.
- The basic functionality of the CS.
Software type Description
GS firmware This software includes:
(GS_xx.fw) - The firmware for the measurement engine.
Software type Description
GG firmware This software includes:
(GG_xx.fw) - The firmware for the measurement engine.

Zeno 10/Zeno 15, Description of the System 15
Software upload Uploading firmware can take some time. Ensure that the battery is at least
75% full before beginning the upload, and do not remove the battery during
the upload process.
Software for Description
All CS models The software is stored in the flash RAM of the CS field
controller.
CS firmware update instructions
• Download the most recent CS firmware file from
https://myworld.leica-geosystems.com. Refer to "Intro-
duction".
• Connect the CS field controller to your PC. Refer to
"3.1.7 Connecting to a Personal Computer".
• Copy CS firmware file onto a folder on the Leica SD card,
Leica CompactFlash card or USB stick.
• Tap the Loader icon from the desktop, to run the Loader
application.
• Browse to the directory into which you copied CS firm-
ware file, select it and start the upload.
• A message will appear when the upload is complete.
Ensure that a Leica SD card or a Leica CF card is
inserted into the CS field controller before starting
the upload.

16
Zeno 10/Zeno 15, Description of the System
GS05/GS06 The software is stored in the flash RAM of the GS05/GS06.
GS firmware update instructions
• Download the most recent GS firmware file from
https://myworld.leica-geosystems.com. Refer to "Intro-
duction".
• Connect the CS field controller to your PC. Refer to
"3.1.7 Connecting to a Personal Computer".
• Copy GS firmware file onto a folder on the Leica SD card,
Leica CompactFlash card or USB stick.
• Click on Start > Programs > Zeno Tools > Firmware, to
run the Firmware loader application.
• Browse to the directory into which you copied GS firm-
ware file, select it and start the upload.
Software for Description

Zeno 10/Zeno 15, Description of the System 17
GG03 The software is stored in the flash RAM of the GG03.
ME firmware update instructions
• Download the most recent GG firmware file from
https://myworld.leica-geosystems.com. Refer to "Intro-
duction".
• Connect the CS field controller to your PC. Refer to
"3.1.7 Connecting to a Personal Computer".
• Copy GG firmware file into the /SYSTEM directory of the
Leica SD card or Leica CompactFlash card.
• Connect the GG with the GEV234/GEV237 cable to the
CS field controller and establish a connection between
the GG and the CS field controller. Refer to the Leica Viva
Technical Reference Manual (Connections.. - Connec-
tions..).
• Start the upload. Refer to the Leica Viva GNSS Getting
Started Guide (Appendix B Uploading System Files).
• A message will appear when the upload is complete.
Software for Description

18
Zeno 10/Zeno 15, Description of the System
1.3.2 Power Concept
General Use the Leica Geosystems batteries, chargers and accessories or accessories recom-
mended by Leica Geosystems to ensure the correct functionality of the instrument.
Power options Model Power supply
all CS models Internally by GEB211/GEB212 battery, OR
Externally by docking station, OR
Externally by GEV235 cable, OR
Externally by GEV219 cable (only CS models with LEMO CBC01
connector module), OR
Externally by GDC221 car adapter
If an external power supply is connected and the internal battery
is inserted, then the external power is used.
GS05/GS06 Externally by CS field controller
GG03 Internally by GEB211/GEB212 battery, OR
Externally by GEV219 cable
If an external power supply is connected and the internal battery
is inserted, then the external power is used.

Zeno 10/Zeno 15, Description of the System 19
1.3.3 Data Storage Concept
Description Data is stored on a memory device. The memory device can be an SD card, Compact-
Flash card, USB stick or internal memory.
Memory device
While other SD cards or CompactFlash cards can be used, Leica Geosystems
recommends to only use Leica SD cards or Leica CompactFlash cards and is
not responsible for data loss or any other error that can occur while using a
non-Leica card.
Removing the SD card, CompactFlash card or USB stick while the CS field controller is
turned on can cause loss of data. Only remove the SD card, CompactFlash card or USB
stick or unplug connecting cables when the CS field controller is switched off.
SD card: All CS field controllers have an SD card slot fitted as
standard. An SD card can be inserted and removed. Avail-
able capacity: 1 GB.
CompactFlash card: All CS field controllers have a CF card slot fitted as
standard. A CompactFlash card can be inserted and
removed. Available capacity: 256 MB, 1 GB.
USB stick: All CS field controllers have a USB port fitted as standard.
Internal memory: All CS field controllers have an internal memory fitted as
standard. Available capacity: 1 GB.

20
Zeno 10/Zeno 15, Description of the System
Transfer data Data can be transferred in various ways. Refer to "3.1.7 Connecting to a Personal
Computer".
CompactFlash cards and SD cards can directly be used in an OMNI drive as supplied
by Leica Geosystems. Other PC card drives can require an adaptor.
