Lenze SDSGA User manual

BA 13.0008 − EN
.5ôE
Ä.5ôEä
Operating Instructions
l
SDSGA
Inverter−optimised asynchronous motors
Buy: www.ValinOnline.com | Phone [phone] | Email: [email protected]

l
2 BA 13.0008 − EN 2.1
,Please read these instructions before you start working!
Follow the enclosed safety instructions.
Document history
Material No. Version Description
409413 1.0 03/1999 TD09 First edition for pilot series
409413 1.1 04/2001 TD09 Chapter 3.2: Extension of application conditions
All chapters: Revised
452930 1.2 04/2002 TD09 Extended by chapter 5.2.1, type and quantity of lubricant
13209536 2.0 04/2007 TD09 Complete revision extended by gearbox type SPL 120
.5ôE 2.1 05/2009 TD09 Change of address
0Fig. 0Tab. 0
0Fig. 0Tab. 0
Buy: www.ValinOnline.com | Phone [phone] | Email: [email protected]

l3
BA 13.0008 − EN 2.1
Nameplates
product series SDSLL
Field Contents Example
1 Manufacturer CE identification
2Type of current Motor type
3Date of manufacture Commission No.
4Rated power (W) Rated speed (1/min)
5Rated voltage (V) Rated frequency (Hz)
6Rated current (A) Rated torque (mF) Type of protection (IP)
7Operating mode Thermal class Material No.
Gearboxes
Field Contents Example
1 Manufacturer CE identification
2Gearbox type
3Commission No. Ratio
4Torque M2in Nm
5
Brakes
Reference to installed brake
Field Contents Example
1 Brake type/size Voltage
2Electric power Torque ID No.
Buy: www.ValinOnline.com | Phone [phone] | Email: [email protected]

l
4 BA 13.0008 − EN 2.1
Type code
Inverter−optimised three−phase AC motors S D S LALL LLL −L L
0
1
2
3
4
5
6
7
8
Legend for SDLGLtype code
0Product group SSmall drives
1Current type DThree−phase AC
2Ventilation S Self ventilation (cooling by convection and radiation)
3Design/housing G
R
Smooth housing and round
Ribbed housing, round
4Machine type AAsynchronous machine
5Built−on accessories AG
BA
BG
BI
BR
BS
BW
B
G
XX
IG
RS
Absolute value encoder
Brake and sin/cos absolute value encoder or SSI absolute value encoder
Brake, resolver and incremental encoder
Brake and incremental encoder (pulse encoder)
Brake
Brake and resolver
Brake, resolver and absolute value encoder
Brake, encoder prepared
No brake, encoder prepared
No brake, no encoder
Incremental encoder (pulse encoder)
Resolver
6Frame size
7Overall length
8Number of pole pairs
Buy: www.ValinOnline.com | Phone [phone] | Email: [email protected]

Contents i
l5
BA 13.0008 − EN 2.1
1 Preface and general information 6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.1 About these Operating Instructions 6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.1.1 Terminology used 6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.1.2 Scope of supply 6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.2 Legal regulations 7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2 Safety instructions 8. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.1 Personnel responsible for safety 8. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.2 Residual hazards 9. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.3 Safety instructions for low−voltage machinery 9. . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.4 Definition of notes used 12. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3 Technical data 13. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.1 Rated data 13. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.1.1 Shaft loads 14. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.2 General data and operating conditions 15. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.2.1 Other application conditions 16. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4 Mechanical installation 18. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4.1 Transport, storage and installation 18. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4.2 Site 19. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5 Electrical installation 20. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5.1 Attachments 21. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5.2 Gearbox mounting 21. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5.2.1 Table of lubricants 22. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5.2.2 Connection plan for SDSGALL inverter motor 24. . . . . . . . . . . . . . . . . . . . . .
6 Commissioning 26. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
6.1 Before switching on 26. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
6.2 During operation 27. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
7 Maintenance/repair 28. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
7.1 Temperature monitoring 28. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
7.2 Repair 29. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
8 Troubleshooting and fault elimination 30. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Buy: www.ValinOnline.com | Phone [phone] | Email: [email protected]

Preface and general information
About these Operating Instructions
Terminology used
1
l
6 BA 13.0008 − EN 2.1
1 Preface and general information
1.1 About these Operating Instructions
ƒThese Operating Instructions inform about safety−relevant working on and with
inverter−optimised motors of type SDS. They contain safety instructions which must
be observed to enable trouble−free operation.
ƒAll persons working on and with the inverter−optimised motors of type SDS must
have the Operating Instructions available and observe the information and notes
relevant for them.
ƒThe Operating Instructions must always be complete and perfectly readable.
1.1.1 Terminology used
Term In the following text used for
Motor Inverter−optimised motor of type SDS
Drive system Drive system with inverter−optimised motor of type SDS or other Lenze
drive components
1.1.2 Scope of supply
ƒShort description
After receipt of the delivery, check immediately whether the items delivered match the
accompanying papers. Lenze does not accept any liability for deficiencies claimed
subsequently.
Claim
ƒvisible transport damage immediately to the forwarder.
ƒvisible deficiencies/incompleteness immediately to your Lenze representative.
Buy: www.ValinOnline.com | Phone [phone] | Email: [email protected]

Preface and general information
Legal regulations
Scope of supply
1
l7
BA 13.0008 − EN 2.1
1.2 Legal regulations
Labelling Nameplate Manufacturer
Lenze products are clearly labelled and defined by the
indications on the nameplates.
Lenze GmbH & Co KG
Kleinantriebe
Postfach 10 13 52
D−31763 Hameln
Application as
directed
Drive products
lmust only be operated under the conditions prescribed in these Instructions.
lmust only be used for the ordered and acknowledged application conditions.
lmeet the protection requirements of the EC "Low−Voltage Directive".
lare not machines in the sense of the EC Machine Directive.
lmust not be used at powers higher or lower than indicated in these Instructions.
Drive systems with SDS motors
lmeet the EC Directive "Electromagnetic compatibility" if they are installed according to the specifications
of the CE−typical drive system.
lare applicable:
– on public and non−public mains,
– in industrial as well as residential and commercial premises.
lThe end user is responsible for adhering to the EC directives in the machine application.
Any other use shall be deemed inappropriate!
Liability lThe information, data, and notes in these instructions were up to date at the time of printing. Claims
referring to motors which have already been supplied cannot be derived from the information, illustrations
and descriptions.
lThe process−related notes and circuit sections used in these instructions are suggestions whose suitability
for the respective application must be checked. Lenze assumes no guarantee for the suitability of the listed
procedures and circuit samples.
lThese operating instructions describe the product features without guaranteeing them.
lNo liability shall be accepted for damage and downtimes resulting from:
– non−observance of the operating instructions
– unauthorised changes or modifications to the motors
– operating errors
– improper work on and with the motors.
Warranty lTerms of warranty: see terms of sales and delivery of Lenze GmbH & Co KG Kleinantriebe.
lWarranty claims must be made to Lenze immediately after detecting the deficiency or fault.
lThe warranty is void in all cases in which liability claims cannot be made.
Disposal Material Recycle Dispose
Metal D−
Plastic D−
Assembled PCBs −D
In−house
transport
lTransport the motors free of vibration.
lAvoid heavy shocks.
lIf possible, use manufacturer’s packaging for transport.
Cushioned bag ensures:
– dust protection
– moisture protection
– mechanical protection
Storage
conditions
lStorage:
– free of vibration
if a certain risk of vibration exists, we recommend to rotate the rotor once per week
– dry, in a non−aggressive environment
– free of dust
– free of extreme temperature changes
lCorrosion:
– Steel parts are corrosion−protected when being delivered. Do not remove the protection! Check it every
three months and, if necessary, renew it.
Buy: www.ValinOnline.com | Phone [phone] | Email: [email protected]

Safety instructions
Personnel responsible for safety
2
l
8 BA 13.0008 − EN 2.1
2 Safety instructions
2.1 Personnel responsible for safety
Operator
ƒAn operator is any natural or legal person who uses the drive system or on behalf of
whom the drive system is used.
ƒThe operator or his safety officer must ensure
– that all relevant regulations, instructions and legislation are observed.
– that only qualified personnel work with and on the drive system.
– that the personnel have the Operating Instructions available for all corresponding
operations.
– that non−qualified personnel are prohibited from working with and on the drive
system.
Skilled personnel
Skilled personnel are persons who − because of their education, experience, instructions,
and knowledge about corresponding standards and regulations, rules for the prevention
of accidents, and operating conditions − are authorised by the person responsible for the
safety of the plant to perform the required actions and who are able to recognise potential
hazards.
(See IEC 364, definition of skilled personnel)
Buy: www.ValinOnline.com | Phone [phone] | Email: [email protected]

Safety instructions
Residual hazards
2
l9
BA 13.0008 − EN 2.1
2.2 Residual hazards
Protection of persons The motor surfaces can become very hot. Danger of burns when touching!
lInstall a guard, if necessary.
High−frequency voltages can be capacitively transferred to the motor housing
through the inverter supply.
lCarefully earth the motor housing.
Danger of unintentional starting or electrical shocks
lPerform connection work only in the de−energised state, only with motor
in standstill.
lBuilt−in brakes are not fail−safe brakes.
Device protection Built−in thermal detectors are not a full protection for the machine.
lIf necessary, limit the maximum current, perform a function block
interconnection with disconnection after a few seconds of operation with I
> IN, particularly if a danger of blocking exists.
lThe integrated overload protection does not prevent overload under all
conditions!
Built−in brakes are not fail−safe brakes .
lSpeed reduction is possible.
Fuses are not a motor protection.
lUse current−dependent motor protection switches for average operating
frequency
lUse built−in thermal detectors at high operating frequency.
Excessive torques lead to a break of the motor shaft or demagnetisation
lDo not exceed the maximum torques according to the catalogue.
Lateral forces from the motor shaft are possible.
lPerfectly align shafts of motor and driving machine to each other.
lSpeeds >3000 min−1 destroy the motor.
Fire protection Fire hazard
lPrevent contact with combustible substances.
2.3 Safety instructions for low−voltage machinery
in conformity with the Low−Voltage Directive 73/23/EEC
1. General
Low−voltage machines have dangerous, live and rotating parts as well as possibly hot
surfaces. All operations serving transport, connection, commissioning and maintenance
are to be carried out by skilled, responsible technical personnel (observe prEN 50110−1/
VDE 0105; IEC 364). Improper handling can cause severe injuries or material damage.
2. Application as directed
These low−voltage machines are intended for industrial and commercial installations.
They comply with the harmonised standards of the series EN60034 (VDE 0530). Their use
in hazardous areas is prohibited unless they are expressly intended for such use (follow
additional instructions).
The enclosures £IP 23 are by no means intended for outdoor use. Air cooled designs are rated
for ambient temperatures between −20°C and +40°C and altitudes of£1000 m amsl. Check
indications on the nameplate and, if other observe them. The conditions on site must
correspond to all nameplate data.
Low−voltage machines are components for installation in machinery as defined in the
Machinery Directive 89/392/EEC. Commissioning is prohibited until conformity of the end
product with this Directive has been established (observe i.a. EN 60204−1).
Buy: www.ValinOnline.com | Phone [phone] | Email: [email protected]

Safety instructions
Safety instructions for low−voltage machinery
2
l
10 BA 13.0008 − EN 2.1
3. Transport, storage
The forwarder must be informed directly after receipt of the goods about all damage or
deficiencies; if necessary, commissioning must be stopped. Tighten screwed−in ring bolts
before transport. They are designed for the weight of the low−voltage machine, do not
apply extra loads. If necessary, use suitable and adequately dimensioned means of
transport (e.g. rope guides).
Remove the shipping brace before commissioning. Reuse it for further transports. For
storage of low−voltage machines ensure a dry, dust−free and low−vibration (v rms
£O.2mm/s) environment (damage while being stored). Measure the insulation resistance
before commissioning. If the values are £1k per volt of rated voltage, dry the winding.
4. Installation
Ensure an even surface, solid foot or flange mounting and exact alignment if a direct clutch
is connected. Avoid resonances with a rotational frequency and double mains frequency
which may be caused during installation. Turn rotor by hand, listen for unusual slipping
noises. Check the direction of rotation when the clutch is not active (observe section 5).
Use appropriate tools to mount or remove belt pulleys and clutches (heat generation!) and
cover them with a touch guard. Avoid excessive belt tensions (technical list).
If required, provide pipe connections. Mounting positions with shaft end at top must be
protected with a cover which avoids the ingression of foreign particles into the fan. Free
circulation of the cooling air must be ensured. The exhaust air − also of other machines next
to the drive system− must not be intaken again immediately.
5. Electrical connection
All operations must only be carried out by qualified and skilled personnel when the
low−voltage machine is at standstill and when the machine is de−energised and protected
against unintentional restart. This also applies to auxiliary circuits (e.g. anti−condensation
heating).
Check safe isolation from the supply!
Exceeding of the tolerances specified in EN 60034−1 (VDE 0530, part 1) − voltage + 5%,
frequency + 2%, wave form, symmetry − leads to excessive temperatures and affects the
electromagnetic compatibility. Observe the indications on the nameplate and the diagram
in the terminal box.
The connection must ensure a continuous and safe electrical supply (no loose wire ends);
use appropriate cable terminals. The connection to the PE conductor must be safe.
The clearance between shining, live parts and earth must not fall below: 8mm at Vr £550V,
10mm at Vr £725V, 14mm at Vr £1000V.
No foreign objects, dirt or moisture in the terminal box. All unused cable entries and the
box itself must be sealed against dust and water. For the trial run without output
elements, lock the key. Check brake operation before commissioning of low−voltage
machines with brakes.
Buy: www.ValinOnline.com | Phone [phone] | Email: [email protected]

Safety instructions
Safety instructions for low−voltage machinery
2
l11
BA 13.0008 − EN 2.1
6. Operation
Vibration severities vrms £3.5 mm/s (Pr £15 kW) or 4.5mm/s (Pr > 15 kW) are acceptable in
coupled mode operation. In case of deviations from normal operation, e.g. increased
temperatures, noises, vibration, find the cause and, if necessary, contact the
manufacturer. Do not switch off the protection devices, not even for trial runs. Switch off
the machine in problematic situations.
If the drive is exposed to dirt, clean it regularly.
Regrease the bearings using the relubrication facility while the low−voltage machine is
running. Observe the saponification number. If the grease drain hole is sealed with a plug,
(IP54 drive end; IP23 drive and non−drive end), remove the plug before commissioning. Seal
the bore holes with grease. Replace the prelubricated bearings (2Z−bearings) after approx.
10,000 h (2pole) or 20,000 h (multi−pole), but no later than after three to four years or
according to the manufacturer’s instructions.
Buy: www.ValinOnline.com | Phone [phone] | Email: [email protected]

Safety instructions
Definition of notes used
2
l
12 BA 13.0008 − EN 2.1
7. Inverter−driven operation for asynchronous motors
The indications in the terminal box inform about the limit values for the voltage that may
be permanently applied to the insulation system of the motor. Example: SDSGA series.
Permissible voltage:
û v1.5 kV
dv / dt v5 kV / ms
2.4 Definition of notes used
The following pictographs and signal words are used in this documentation to indicate
dangers and important information:
Safety instructions
Structure of safety instructions:
}Danger!
(characterises the type and severity of danger)
Note
(describes the danger and gives information about how to prevent dangerous
situations)
Pictograph and signal word Meaning
{Danger!
Danger of personal injury through dangerous electrical voltage.
Reference to an imminent danger that may result in death or
serious personal injury if the corresponding measures are not
taken.
}Danger!
Danger of personal injury through a general source of danger.
Reference to an imminent danger that may result in death or
serious personal injury if the corresponding measures are not
taken.
(Stop!
Danger of property damage.
Reference to a possible danger that may result in property
damage if the corresponding measures are not taken.
Application notes
Pictograph and signal word Meaning
)Note! Important note to ensure troublefree operation
ITip! Useful tip for simple handling
,Reference to another documentation
Buy: www.ValinOnline.com | Phone [phone] | Email: [email protected]

Technical data
Rated data
3
l13
BA 13.0008 − EN 2.1
3 Technical data
3.1 Rated data
ƒThe most important rated data of the motor are indicated on the nameplate.
– Further technical data can be obtained from the catalogs.
ƒThe torques and weights indicated in Tab. 2 are guide values for the selection of the
transmission elements and base.
ƒThe rated data indicated on the nameplate refer to operation with Lenze servo
inverters of the 9300 series with an inverter input voltage (mains voltage) of 400 V
and an inverter frequency of 8 kHz.
)Note!
ƒThe motors can also be connected to inverters others than inverters of the
9300 series:
– Observe the minimum frequencies (Tab. 1).
– Depending on the modulation and control performance of the inverter it
might be necessary to derate the power if excessive temperatures are
detected (see chap. 3.2.1).
Motor type Min. cycle frequency [kHz]
SDLLA 047...063 8
Tab. 1 Minimum permissible inverter cycle frequencies
Buy: www.ValinOnline.com | Phone [phone] | Email: [email protected]

Technical data
Rated data
Shaft loads
3
l
14 BA 13.0008 − EN 2.1
3.1.1 Shaft loads
The permissible loads listed in the table (Tab. 2) are either radial forces or axial forces.
KL−SDS−001
Fig. 1 Points of action of radial and axial loads
FaPermissible axial load Ref. to the nominal bearing
service life of 10,000 h
Fr1 Permissible radial load, acts on the middle of the shaft
Fr2 Permissible radial load, acts on the end of the shaft
Motor type Pr
shaft
nr
1/min
n
1/min
Mr
Nm
M
Nm
J
kg cm2U V
Ir
A
Fr1 /Fr2
N
Fa
N
l
cosj
f
HZ
mmotor
appro
x. kg
SDSGARSLL
047−22 75
6000
2700 0.27 1.0 0.41
230/400
0.90/0.52 350/300 250 0.5
100
3.0
056−22 240 2790 0.81 3.2 1.404 1.49/0.86 560/530 430 0.714 4.0
063−22 400 2800 1.35 5.0 2.796 2.12/1.23 650/605 510 0.7 5.3
063−32 600 2825 1.9 8.0 4.21 3.00/1.74 6.8
Tab. 2 Rated data for standard design
Formula designations
PrRated power Fr1/Fr2 Permissible radial load
MrRated torque FaPermissible axial load
IrRated current nrRated speed
URated voltage mmotor Motor weight (mass)
FRated frequency Nmax. speed
JMoment of inertia Mmax. torque
LPower factor
Buy: www.ValinOnline.com | Phone [phone] | Email: [email protected]

Technical data
General data and operating conditions
3
l15
BA 13.0008 − EN 2.1
3.2 General data and operating conditions
Field Values
Conformity CE Low−Voltage Directive (73/23/EEC)
Climatic conditions Average relative humidity 85 %, without condensation
Permissible
temperature range
Non−ventilated or with integral
fan without brake or with
spring−operated brake
−20 °C ... +40 °C Without power derating, above
+40 °C with power derating see
catalog
Protection type See nameplate Protection types only apply for
horizontal installation
Thermal class F (155 °C) to DIN−IEC 34 / VDE 0530 The insulation will be weakened or
destroyed when the limit
temperature is exceeded
Tropical insulation Not guaranteed
Permissible voltage 1.5 kV peak value 5 kV/ms rate of rise
Vibration Up to 2.0g / 20m/s2without resonance excitation, e.g. of the fan.
Mounting positions Can be used in all mounting positions Vertical arrangements to DIN−IEC
34 part 7 are possible if they meet
the designs
Motors with directly mounted
gearbox must not be mounted in
mounting position with motor at
the bottom
Permissible installation
height h
h £1000 m amsl
1000 m amsl <h £4000 m amsl
Without power derating
With power derating, see catalog
Buy: www.ValinOnline.com | Phone [phone] | Email: [email protected]

Technical data
General data and operating conditions
Other application conditions
3
l
16 BA 13.0008 − EN 2.1
3.2.1 Other application conditions
ƒOther application conditions require a power derating or torque reduction using the
factors listed in table 2 and 3 (see below).
1
2
0
0Installation height
1Permissible continuous torque Mperm/Mcont 40 °C 1000 m
2Cooling air / ambient temperature [°C]
(Stop!
ƒThe motor will be destroyed when the maximum motor speed is exceeded
ƒDo not exceed the maximum torques specified in Tab. 2!
– Torques as high as indicated can be reached through appropriate
motor−controller combinations.
– Excessive torques might result in a break of the motor shaft!
)Note!
ƒExcessive axial and radial forces reduce the bearing service life.
– Observe the permissible forces to Tab. 2!
– Calculation basis:
Bearing service life Lh10 = 10000 h
Torque M = 2.5 Mr
The permissible continuous power is calculated as follows:
P’= kυ@kh@Pc
with Pcbeing the permissible continuous power under normal conditions. A
corresponding relation applies to the torque:
M’ = kυ@kh@Mc
with Mcbeing the permissible continuous torque under normal conditions.
Buy: www.ValinOnline.com | Phone [phone] | Email: [email protected]

Technical data
General data and operating conditions
Other application conditions
3
l17
BA 13.0008 − EN 2.1
3.2.1.1 Power derating
Power derating for other application conditions
Cooling air temperature °C1) 40 45 50 55 60
Power derating kυ1) 1.00 0.95 0.90 0.83 0.77
Installation height amsl in m 2) 1000 2000 3000 4000 5000
Power derating kh2) 1.00 0.92 0.83 0.77 0.67
1) Derating for other ambient and cooling air temperatures
2) Derating for other installation heights
Buy: www.ValinOnline.com | Phone [phone] | Email: [email protected]

Mechanical installation
Transport, storage and installation
4
l
18 BA 13.0008 − EN 2.1
4 Mechanical installation
4.1 Transport, storage and installation
}Danger!
ƒUse appropriate means of transport or hoists:
– Ensure safe fixing.
ƒTransport the motors free of vibrations.
ƒAvoid heavy shocks.
Storage
ƒfree of vibration
if a certain risk of vibration exists, we recommend to rotate the rotor once per week
ƒdry, in a non−aggressive environment
ƒfree of dust
ƒfree of extreme temperature changes
Corrosion
ƒSteel parts are corrosion−protected when being delivered. Do not remove the
protection! Check it every three months and, if necessary, renew it.
Installation
The motors are tested for operation and are ready for use.
Preparations
ƒRemove the corrosion protection from the steel parts.
ƒCheck for transport damage and fix key, if necessary.
ƒThe mounting depends on the motor design, the weight and the motor torque.
ƒBefore mounting the motor, foot and flange surfaces must contact the mounting
surfaces evenly. Insufficient motor alignment reduces the service life of the bearings
and the transmission elements!
ƒClutches and other transmission elements must be mounted according to the
corresponding instructions. Avoid shocks onto the shafts and do not exceed the
permissible radial and axial forces to avoid damage to the bearings!
ƒProvide sufficient space for unimpeded ventilation.
Buy: www.ValinOnline.com | Phone [phone] | Email: [email protected]

Mechanical installation
Site
4
l19
BA 13.0008 − EN 2.1
4.2 Site
}Danger!
Do not use in hazardous areas!
The motors are designed for the following rated conditions:
ƒAmbient and cooling air temperatures up to +40 °C (in case of other temperatures
see chapter 3.2.1).
ƒInstallation height up to 1000 m amsl (in case of other installation heights see
chapter 3.2.1).
ƒEnsure unimpeded ventilation!
ƒThe exhaust air must not be intaken again!
ƒOperation within the permissible control range for self−ventilated motors.
Buy: www.ValinOnline.com | Phone [phone] | Email: [email protected]

Electrical installation5
l
20 BA 13.0008 − EN 2.1
5 Electrical installation
{Danger!
ƒElectrical connection must only be carried out by qualified personnel!
ƒConnections must only be made when the equipment is de−energised!
Danger through unintended starts or electric shocks.
(Stop!
It must be ensured that the supply voltage corresponds to the voltage
indicated on the nameplate.
Voltage supply
ƒInverter−optimised motors
– must be supplied by inverters.
– connect the encoders mounted to the motor with the corresponding connections
of the inverter.
ƒHolding brake (as option)
ƒFollow the Operating Instructions for the inverter used to connect it.
Cable cross−sections
ƒSelect appropriate connection cables to avoid impermissible heating (DIN
57100/VDE 0100 T523).
ƒWhen extremely long cables are used, we recommend to use the next cable cross
section up to reduce the power losses. Observe the minimum cross sections to DIN
VDE 0298−4.
ƒEstablish the electrical connection as shown in the circuit diagram attached to each
motor. The circuit diagrams for the standard designs can be found in chapter 5.2.2.
Motor protection
ƒThe motor cable cannot be protected by temperature monitorings or PTC thermistors
in the motor winding:
– Take measures to DIN 57100 / VDE 0530.
ƒThe inverter changes current and voltage such that the output current can be
considerably higher than the input current. The motor cable cannot be protected via
the mains input fuses of the inverter:
– Take measures to DIN 57100 / VDE 0530.
ƒEnsure careful earthing of the motor housing!
– If the motor is inverter driven, high−frequency voltages may be capacitively
transferred to the motor housing.
Buy: www.ValinOnline.com | Phone [phone] | Email: [email protected]
