Lenze 12 Series User manual

BA 12.0028−EN
.=A.
Ä.=A.ä
Operating Instructions
Gearbox

Type 12.LLL / 52.LLL


2 BA 12.0028−EN 6.0
Product key
Gearboxes
1 2 . . .
Product group
Product family
Gearbox size
Design
Geared motors
1 2 . . . −
Product group
Product family
Gearbox size
Design
Motor key
Nameplate
Gearboxes / geared motors
Field Contents Example
1 Assembly plant/country EXTERTAL/Germany
12.623.12.1−71S/4−H−TH
i=132 CLP460
227 Nm 10/min (50Hz)
GT/40001234 00566070
4−070−01−1156 0423
2Product key
3 Ratio Lubricant
4Torque M2in Nm Speed n2in 1/min (frequency in Hz)
5Order number ID number
6Customer require-
ments
Year and week of manufacture

3
BA 12.0028−EN 6.0
Document history
Material number Edition Contents
391291 1.0 03/1996 TD09 First edition
450298 2.0 12/2001 TD09 Complete revision, new layout
3.0 04/2003 TD09 Corrections in the lubricant quantity tables
4.0 07/2004 TD09 Change in the lubricant table (lubricant type) in chapter
"Maintenance intervals"
13035296 5.1 08/2004 TD09 Change: title page
Change: nameplate
Addition: list of lubricants (lubricant table)
.=A. 6.0 12/2008 TD09 New edition due to reorganisation of the company
0Fig. 0Tab. 0

Contentsi
4 BA 12.0028−EN 6.0
1 Preface and general information 6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.1 About these Operating Instructions 6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.2 Terminology used 6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.3 Scope of supply 6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.4 Lenze drive systems 7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.4.1 Labelling 7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.5 Legal regulations 7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2 Safety instructions 8. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.1 Personnel responsible for safety 8. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.2 General safety information 8. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.3 Notes used 9. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3 Technical data 10. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.1 Product features 10. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.1.1 Design 10. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.1.2 Mode of operation 10. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.2 Weights 11. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.2.1 Operating conditions 12. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4 Mechanical installation 13. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4.1 Storage 13. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4.2 Mounting 13. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4.2.1 Preparation 13. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4.2.2 General information about the assembly of drive systems 14. . . . . . . . . . .
4.2.3 Assembly of transmission elements on solid shafts 14. . . . . . . . . . . . . . . .
4.2.4 Mounting of motors on gearboxes with mounting flange 15. . . . . . . . . . .
4.2.5 Mounting of gearboxes with hollow shaft with keyway 17. . . . . . . . . . . .
4.2.6 Breather screw 17. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5 Electrical installation 18. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5.1 Motor connection 18. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
6 Commissioning and operation 19. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
6.1 Before switching on 19. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
6.2 During operation 19. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
7 Maintenance 20. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
7.1 Maintenance intervals 20. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Contents i
5
BA 12.0028−EN 6.0
7.2 Maintenance operations 21. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
7.2.1 Replacing the lubricant 21. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
7.2.2 Lubricant quantity 21. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
7.2.3 Repair 26. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
8 Troubleshooting and fault elimination 27. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
9 Disposal 28. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Preface and general information
About these Operating Instructions
1

6 BA 12.0028−EN 6.0
1 Preface and general information
1.1 About these Operating Instructions
ƒThese Operating Instructions are intended for safety−relevant operations on and
with the gearboxes 12. and 52.. They contain safety instructions which
must be observed.
ƒAll persons working on and with the gearboxes 12. and 52. must have the
Operating Instructions available and observe the information and notes relevant for
them.
ƒThe Operating Instructions must always be complete and perfectly readable.
1.2 Terminology used
Term In the following text used for
Gearbox Gearboxes of the product families 12. and 52.
Drive system Drive systems with gearboxes 12. and 52. and other Lenze drive
components
1.3 Scope of supply
ƒThe drive systems are combined individually according to a modular design. The
scope of supply can be obtained from the pertinent papers.
ƒAfter receipt of the supply, check immediately whether it corresponds with the
accompanying papers. Lenze does not grant any warranty for subsequent claims.
Claim for
– visible transport damages immediately to the forwarder.
– visible deficiencies / incompleteness immediately to the responsible Lenze
subsidiary / agency.

Preface and general information
Lenze drive systems
Labelling
1
7
BA 12.0028−EN 6.0
1.4 Lenze drive systems
1.4.1 Labelling
Lenze drive systems are uniquely designated by the content of their nameplates.
Manufacturer
Lenze Drives GmbH
Postfach 10 13 52
D−31763 Hameln
Application as directed
ƒLenze drive systems
– are intended for use in machinery and plant,
– must only be used for the purposes ordered and confirmed,
– must only be operated under the ambient conditions prescribed in these
Operating Instructions,
– must not be operated beyond their corresponding power limits.
Any other use shall be deemed inappropriate!
1.5 Legal regulations
Liability
ƒThe information, data, and notes in the Operating Instructions were state of the art
at the time of printing. Claims referring to drive systems which have already been
supplied cannot be derived from the information, illustrations, and descriptions.
ƒWe do not accept any liability for damage and operating interference caused by:
– inappropriate use,
– unauthorised modifications to the drive system,
– improper working on and with the drive system,
– operating faults,
– disregarding the Operating Instructions.
Warranty
ƒConditions of warranty: see terms of sale and delivery of Lenze Drive Systems
GmbH.
ƒWarranty claims must be made to Lenze immediately after detecting the deficiency
or fault.
ƒThe warranty is void where liability claims cannot be made.

Safety instructions
Personnel responsible for safety
2

8 BA 12.0028−EN 6.0
2 Safety instructions
2.1 Personnel responsible for safety
Operator
ƒAn operator is any natural or legal person who uses the drive system or on behalf of
whom the drive system is used.
ƒThe operator or his safety officer must ensure
– that all relevant regulations, instructions and legislation are observed.
– that only qualified personnel work with and on the drive system.
– that the personnel have the Operating Instructions available for all corresponding
operations.
– that non−qualified personnel are prohibited from working with and on the drive
system.
Skilled personnel
Skilled personnel are persons who − because of their education, experience, instructions,
and knowledge about corresponding standards and regulations, rules for the prevention
of accidents, and operating conditions − are authorised by the person responsible for the
safety of the plant to perform the required actions and who are able to recognise potential
hazards.
(See IEC 364, definition of skilled personnel)
2.2 General safety information
ƒThis safety information does not claimed to be complete. In case of questions and
problems, please contact your Lenze representative.
ƒAt the time of delivery the drive system meets the state of the art and ensures safe
basic operation.
ƒThe drive system is a source of danger for persons, for the drive system itself, and for
other material assets of the operator, if
– unqualified personnel works with and on the drive system,
– the drive system is used inappropriately.
ƒThe drive systems must be designed such that they perform their functions after
proper installation and with application as directed in fault−free operation and that
they do not cause hazards for persons. This also applies for their interaction with the
complete plant.
ƒBe sure to take appropriate measures in the case of drive system failure so that no
material damage occurs.
ƒOperate the drive system only when it is in a proper state.
ƒRetrofittings, modifications, or redesigns of the drive system are basically
prohibited. Lenze must be contacted in all cases.

Safety instructions
Notes used
2
9
BA 12.0028−EN 6.0
2.3 Notes used
The following pictographs and signal words are used in this documentation to indicate
dangers and important information:
Safety instructions
Structure of safety instructions:
Danger!
(characterises the type and severity of danger)
Note
(describes the danger and gives information about how to prevent dangerous
situations)
Pictograph and signal word Meaning
Danger!
Danger of personal injury through dangerous electrical voltage.
Reference to an imminent danger that may result in death or
serious personal injury if the corresponding measures are not
taken.
Danger!
Danger of personal injury through a general source of danger.
Reference to an imminent danger that may result in death or
serious personal injury if the corresponding measures are not
taken.
Stop!
Danger of property damage.
Reference to a possible danger that may result in property damage
if the corresponding measures are not taken.
Application notes
Pictograph and signal word Meaning
Note! Important note to ensure troublefree operation
Tip! Useful tip for simple handling
Reference to another documentation

Technical data
Product features
Design
3

10 BA 12.0028−EN 6.0
3 Technical data
ƒThe most important technical data are indicated on the nameplate (for design and
contents see page 2).
ƒFurther technical data are listed in the product catalogues.
3.1 Product features
3.1.1 Design
Drive systems have a modular design.
They consist of:
ƒReduction gearboxes
– helical gearboxes,
– worm gearboxes,
– helical−worm gearboxes,
– helical−bevel gearboxes,
– shaft−mounted gearboxes
ƒVariable speed drives
ƒMotors
3.1.2 Mode of operation
ƒTorque and speed conversion
Product family Input stage 1st stage 2nd stage 3rd stage
Helical gearbox Helical Helical Helical −−−
Worm gearbox −−− Worm −−− −−−
Helical−worm gearbox Helical Helical Worm −−−
Helical−bevel gearbox Bevel Helical
Shaft−mounted gearbox Helical
Tab. 1 Torque and speed conversion of the gearboxes
ƒThe reaction torque must be supported by foot mounting, flange mounting, or
torque plate.

Technical data
Weights
3
11
BA 12.0028−EN 6.0
3.2 Weights
Weights [kg]: Helical gearboxes / helical−geared motors
Gearbox
type
Geared motors
Motor frame size
Gearbox
071 080 090 100 112 132 160 180 200 225
12.61.08 < 11 < 14 −−− −−− −−− −−− −−− −−− −−− −−− < 4.5
12.62.08 < 12 < 15 −−− −−− −−− −−− −−− −−− −−− −−− < 6
12.61.10 < 13 < 16 < 20 < 25 −−− −−− −−− −−− −−− −−− < 6.5
12.62.10 < 15 < 18 < 25 −−− −−− −−− −−− −−− −−− −−− < 9
12.63.10 < 18 < 20 −−− −−− −−− −−− −−− −−− −−− −−− < 12
12.61.12 < 18 < 20 < 25 < 30 < 35 −−− −−− −−− −−− −−− < 12
12.62.12 < 25 < 25 < 35 < 40 −−− −−− −−− −−− −−− −−− < 17
12.63.12 < 25 < 30 < 35 −−− −−− −−− −−− −−− −−− −−− < 20
12.61.16 −−− < 30 < 40 < 45 < 50 < 90 −−− −−− −−− −−− < 20
12.62.16 −−− < 40 < 50 < 55 < 60 < 100 −−− −−− −−− −−− < 35
12.63.16 < 45 < 50 < 55 < 60 −−− −−− −−− −−− −−− −−− < 40
12.61.20 −−− −−− < 55 < 60 < 70 < 105 < 170 −−− −−− −−− < 40
12.62.20 −−− −−− < 80 < 85 < 90 < 130 < 190 −−− −−− −−− < 60
12.63.20 −−− < 80 < 90 < 95 < 100 < 140 −−− −−− −−− −−− < 75
12.61.25 −−− −−− −−− < 75 < 85 < 120 < 185 < 240 −−− −−− < 65
12.62.25 −−− −−− −−− < 130 < 135 < 175 < 240 < 295 −−− −−− < 115
12.63.25 −−− −−− < 140 < 150 < 155 < 195 < 255 −−− −−− −−− < 130
12.61.32 −−− −−− −−− −−− −−− < 135 < 205 < 260 < 340 < 445 < 85
12.62.32 −−− −−− −−− −−− −−− < 250 < 315 < 370 < 450 < 455 < 200
12.63.32 −−− −−− −−− < 240 < 245 < 285 < 350 < 405 −−− −−− < 225
Weights [kg]: Worm gearboxes / worm−geared motors
Gearbox
type
Geared motors
Motor frame size
Gearbox
063 071 080 090 100 112 132
52..04 < 13 < 15 < 18 −−− −−− −−− −−− < 6.5
52..05 −−− < 20 < 25 −−− −−− −−− −−− < 15
52..06 −−− −−− < 35 < 45 −−− −−− −−− < 20
52..08 −−− −−− < 50 < 60 < 65 < 80 −−− < 35
52..10 −−− −−− −−− < 75 < 80 < 95 −−− < 50
52..12 −−− −−− −−− −−− < 125 < 140 < 170 < 85

Technical data
Weights
Operating conditions
3

12 BA 12.0028−EN 6.0
Weights [kg]: Helical−worm gearboxes / helical−worm geared motors
Gearbox
type
Geared motors
Motor frame size
Gearbox
063 071 080 090 100 112 132 160
52..04 −−− −−− −−− −−− −−− −−− −−− −−−
52..05 < 20 < 25 < 30 −−− −−− −−− −−− −−− < 15
52..06 −−− < 35 < 35 < 45 −−− −−− −−− −−− < 25
52..08 −−− < 55 < 55 < 65 < 70 −−− −−− −−− < 45
52..10 −−− < 80 < 85 < 95 < 95 < 115 < 135 −−− < 70
52..12 −−− −−− < 130 < 140 < 140 < 160 < 190 < 235 < 115
Weights [kg]: Helical−bevel gearboxes / helical−bevel geared motors
Gearbox
type
Geared motors
Motor frame size
Gearbox
071 080 090 100 112 132 160 180
52..04 < 55 < 60 < 70 < 75 −−− −−− −−− −−− < 40
52..05 −−− < 90 < 100 < 105 < 120 < 150 −−− −−− < 70
52..06 −−− −−− < 150 < 155 < 170 < 200 < 270 −−− < 120
52..08 −−− −−− −−− < 265 < 280 < 310 < 385 < 435 < 220
Weights [kg]: Shaft−mounted gearboxes
Type Gearbox size
08 09 10 12 14 17 18 20 24 28 35 42 45
12.410 −−− 20 30 35 55 90 −−− −−− −−− −−− −−− −−− −−−
12.420 15 20 30 50 65 100 −−− −−− −−− −−− −−− −−− −−−
12.425 −−− −−− −−− −−− −−− −−− 25 −−− 55 −−− 190 315 −−−
12.435 −−− −−− −−− −−− −−− −−− −−− −−− −−− 55 −−− −−− −−−
12.460 −−− −−− −−− −−− −−− −−− −−− 10 −−− −−− −−− −−− 15
3.2.1 Operating conditions
Ambient conditions such as temperature range, etc. are determined by the lubricant
specifications (see chapter 6.1) and the drive motor (nameplate and Operating
Instructions for the motor).

Mechanical installation
Storage
Preparation
4
13
BA 12.0028−EN 6.0
4 Mechanical installation
Danger!
Only transport the drive with transport equipment or hoists which are suitable
for this load. Ensure a safe fixing. Avoid shocks!
4.1 Storage
If you do not install the gearbox immediately, ensure appropriate conditions of storage.
ƒUp to one year:
– Without special measures in dry, dust−free rooms which are protected against
sunlight.
– Store the gearbox with ventilation such that the breather screw is located at the
top.
– Shafts and bright surfaces are delivered with protection against corrosion.
ƒMore than one year:
– Please contact Lenze.
4.2 Mounting
4.2.1 Preparation
Thoroughly remove anticorrosion agents from output shafts and flange faces.

Mechanical installation
Mounting
General information about the assembly of drive systems
4

14 BA 12.0028−EN 6.0
4.2.2 General information about the assembly of drive systems
ƒTake safety measures prior to any operation:
– Disconnect the machine from the mains, ensure standstill of the machine and
avoid any machine movement.
– Check the proper state of the drive system. Never install and set up damaged drive
systems.
– Check the combination of drive function and machine functions. Check the
direction of rotation.
ƒThe mounting surfaces must be even, without torsion, and free from vibration.
ƒAlign the drive system on the mounting surfaces exactly with the machine shaft to
be driven.
– Ensure that the assembly is without torsion, to avoid additional load.
– Compensate for minor misalignments by using suitable flexible couplings.
ƒSupport the reaction torque appropriately.
ƒFixings of accessories and attachments must be secured against loosening. We
recommend that screw connections are glued.
Stop!
The lubricant fill quantity of the gearboxes is matched to the mounting
position. The mounting position indicated on the nameplate must be observed
to avoid damage to the gearbox.
4.2.3 Assembly of transmission elements on solid shafts
ƒDraw the transmission elements onto the output shaft only by using the centering
thread.
Stop!
Shocks and blows to the shafts damage the roller bearings.

Mechanical installation
Mounting
Mounting of motors on gearboxes with mounting flange
4
15
BA 12.0028−EN 6.0
4.2.4 Mounting of motors on gearboxes with mounting flange
Helical gearboxes, helical−worm gearboxes, helical−bevel gearboxes
B5 flange
K12.0542/3
Fig. 1 Helical gearboxes, helical−worm gearboxes, helical−bevel gearboxes prepared for mounting on
standard motors
1 Clamping screw
2 Motor key
1. Assemble motor key (2).
2. Push coupling hub onto the motor shaft, observe dimension x.
3. Secure coupling hub against axial movement using the clamping screw (1).
4. Lay spider into the coupling claw at the gearbox side.
5. Align claws of the motor−side coupling hub with its counterpart.
6. Slowly push motor, and bolt onto the gearbox flange.
Helical gearbox
Type / size
Helical−bevel
gearbox
Type / size
Helical−worm
gearbox
Type / size
Motor frame
size
Motor shaft Assembly
dimensions
12.601 12.602 12.603 12.5L3 52.16Ld [mm] l [mm ] x [mm]
08 08 10 −−− 05
063 11 23 0
071 14 30 2.5
080 19 40 7.5
10 10 12 −−− 06
071 14 30 0
080 19 40 5
090 24 50 0
12 12 16 15 08
080 19 40 5
090 24 50 0
100/112 28 60 0
16 16 20 19 10 090 24 50 0
100/112 28 60 0
20 20 25 24 12 100/112 28 60 0
132 38 80 0
25 25 32 30 −−−
132 38 80 0
160 42 110 3.5
180 48 110 0

Mechanical installation
Mounting
Mounting of motors on gearboxes with mounting flange
4

16 BA 12.0028−EN 6.0
Worm gearboxes
B5 flange
B14 flange
K12.0542/2
Fig. 2 Worm gearboxes prepared for mounting on standard motors, type 52.4 and 52.5
1 Clamping screw
2 Motor key
1. Assemble motor key (2).
2. Push coupling hub onto the motor shaft, observe dimension m.
3. Secure coupling hub against axial movement using the clamping screw (1).
4. Lay spider into the coupling claw at the gearbox side.
5. Align claws of the motor−side coupling hub with its counterpart.
6. Slowly push motor, and bolt onto the gearbox flange.
Motor frame size Motor shaft Flange dimensions Assembly dimensions
d [mm] l [mm ] a [mm] m [mm]
063 11 23 90 25
063 11 23 140 30
071 14 30 105/140/160 30
080 19 40 120/160/200 40

Mechanical installation
Mounting
Mounting of gearboxes with hollow shaft with keyway
4
17
BA 12.0028−EN 6.0
4.2.5 Mounting of gearboxes with hollow shaft with keyway
1. Draw the gearbox with hollow shaft onto the machine shaft to be driven:
– Use a suitable assembly paste.
– Take up forces only via the hollow shaft, and not via gearbox housing.
2. Secure the gearbox axially:
– The hollow shaft is equipped with snap ring grooves for axial securing (fig. 3). Parts
required for fixing the shaft are not included in the scope of supply.
K12.0525/1
Fig. 3 Hollow shaft with snap ring
4.2.6 Breather screw
ƒIf your gearbox is equipped with a breather screw, the screw is marked by a label.
Stop!
Before the first set−up, remove the plug from the breather screw. Without
ventilation, the seals may be damaged because of the rising pressure during
operation.

Electrical installation
Motor connection
5

18 BA 12.0028−EN 6.0
5 Electrical installation
Danger!
Electrical connections must only be carried out by skilled personnel!
5.1 Motor connection
To correctly connect the motor, please observe:
ƒthe notes in the terminal box of the motor
ƒthe notes in the Operating Instructions of the motor
ƒthe technical data on the motor nameplate.

Commissioning and operation
Before switching on
6
19
BA 12.0028−EN 6.0
6 Commissioning and operation
Stop!
The drive may only be commissioned by skilled personnel!
6.1 Before switching on
Check:
ƒDoes the drive appear undamaged?
ƒIs the mechanical fixing o.k.?
ƒHas the electrical connection been carried out properly?
ƒAre all rotating parts and surfaces that may become hot protected against contact?
ƒIf the oil level of the drive has been increased due to storage purposes (see
chapter 4.1), it must be reduced again to the height permissible for the intended
mounting position.
ƒFor gearboxes with breathing:
– Has the transport locking device been removed?
6.2 During operation
During operation, check the drive periodically and take special care of:
ƒDeviations from normal operation such as
– abnormal noises, stronger vibrations, or increased temperatures
– leakages,
– loose fixing elements,
– the condition of the electrical cables.
ƒIf any interference should occur, you have to stop the drive and go through the steps
for troubleshooting and fault elimination (chapter 8). If the interference cannot be
eliminated, please contact the Lenze Service.

Maintenance
Maintenance intervals
7

20 BA 12.0028−EN 6.0
7 Maintenance
7.1 Maintenance intervals
ƒThe mechanical power transmission system is free of maintenance.
ƒShaft seals and roller bearings:
– The service life depends on the operating conditions.
– Replace seals in case of leakage to avoid consequential damage.
ƒLubricants are subject to natural aging and must be replaced at regular intervals:
– The type of lubricant is indicated on the nameplate. If not indicated, please see
"List of lubricants" (Tab. 2).
– Only use similar lubricants when changing the lubricant.
– For maintenance intervals: see Tab. 2 "List of lubricants".
Stop!
Also observe the maintenance intervals for the other drive components!
Gearbox type Lubricant Change intervals
Type Specification Ambient
temperature
Note
Helical gearboxes,
helical−bevel gearboxes,
shaft−mounted
gearboxes
CLP 460 Oil on mineral basis
with additives
0 _C ... + 40 _C16,000 operating hours − no
longer than three years (oil
temperature 70...80 _C)
Worm gearboxes,
helical−worm gearboxes
CLP−PG 460
CLP−PG 220
Oil on synthetic basis
(polyglycol)
−20 _C ... + 40 _CDo not mix with
mineral oils
25,000 operating hours − no
longer than three years (oil
temperature 70...100 _C)
All gearbox types CLP−HC 220
(H1)
Food−compatible oil
on synthetic basis
−20 _C ... + 40 _CApproval to
USDA H1
16,000 operating hours − no
longer than three years (oil
temperature 70...80 _C)
All gearbox types CLP−E 320 Biodegradable
diester oil on
synthetic basis
−20 _C ... + 40 _CWater pollution
class 0
16,000 operating hours − no
longer than three years (oil
temperature 70...80 _C)
Tab. 2 List of lubricants
