Lighting Technologies SKYLINE LED/M User manual

SKYLINE LED /M
Manual

SKYLINE LED
Name
Code
Rated
power,
W
Luminou
s
efficienc
y, lm/W
Luminous
flux, lm
Weight, kg
CRI, Ra
Size, mm,
AxBxC
SKYLINE LED 30 DK 4000K /M/
1707000420
35
124
4350
12,7
>80
730x490x130
SKYLINE LED 60 DW 4000K /M/
1707000430
52
148
7700
14,7
>70
SKYLINE LED 90 DW 4000K /M/
1997031940
90
133
12000
>70
SKYLINE LED 120 DW 4000K /M/
1997031950
104
137
14200
>70
Notes:
-**CCT –correlated color temperature.
- Rated power consumption tolerance ±10%.
- Nominal values of luminous flux, weight tolerance is ±10%.
- Rated CCT tolerance ±300К.
- The supply mains must be protected from communication and electric impulse noise.
- The main characteristics of line voltages at a network user’s supply terminals in public AC electricity networks
should comply EN 50160-2010.
- Luminaire corresponds to the protection classification IP by IEC 60529.
- Diffuser type: Silicate protective glass.
- Further information about luminaire's dimensions shown in the table, please see "Overall and installation
dimensions" section.

DELIVERY SET
- Luminaire, pcs. 1
- Package, pcs. 1
- Manual, pcs. 1
FUNCTION
- Console luminaire with LED light source is designed for lighting of streets and roads with low and
medium traffic capacity. The luminaire light source cannot be exchanged or replaced by the user.
- Replacement of the luminaire light source is available in the factory or in a specialized service.
- Luminaire corresponds to the safety requirements IEC 60598-2-2, EN 55015.
- The lighting fixture is intended for installation at the vertical or bracket type support with diameter of 48-
60 mm.
- Wind stress area –0.2 m2.
SAFETY NOTICE
- Never work on the luminaire when voltage is switched on.
- Do not operate the luminaire without protective grounding (for class I luminaires).
- Position the luminaire to avoid long viewing into the luminaire at a
distance of less than 0.5 m.
- Only operate the luminaire if the diffuser is undamaged.
- Unauthorized disassembling, modification and repair is prohibited. In
case of malfunction, the luminaire should be immediately switched off
and report to manufacturer or specialized luminaire service.
- The luminaire has passed a high voltage test for insulation and electric strength according to IEC
60598-1.
- The LED luminaries are considered as low-hazard solid domestic waste and should be disposed
according to Directive 2002/96/EC WEEE.
- Do not cover the luminaire with insulating material.

INSTALLATION AND OPERATION RULES
The luminaire should be used according to «Standard code of customer electrical installations».
Installation, cleaning and replacing of the components should be done only with the main power
off. The diffuser should be cleaned with soft cloth and mild detergent.
1. Switch mains power off. Unpack the luminaire.
2. Strip mains cable according to dimensions shown.
3. Release cable connector's nut (when available) on luminaire side, remove bushing on the
other side and pull out terminals block. Connect mains cable having put it through bushing
and observing polarity shown. Tighten bushing and cable lock nuts, tightening torque 2.5 Nm.
4. Installation on pole support.
4.1 Tools needed

4.2 Mount the luminaire on support or vertical pole with diameter 48-60 mm. Adjust luminaire's
position using the bubble level (1) on the bracket. Fix the luminaire by tightening lock screws
(2) with at least 18 Nm of torque. Lock the screw with hexagonal nuts (3).
4.3 Release screw (4) if needed. Set luminaire tilt angle needed using marks on the bracket
(marks intervals - 10°, turn intervals - 5°). Tighten the screw (4) with at least 18 Nm of torque.
ATTENTION! Luminaire lifting and carrying by mains cable is not allowed, it may cause moist protection
failure, cable and luminaire’s internal circuits damage.
Dimensions

CONNECTION SCHEME
CONNECTION SCHEME FOR DALI DIMMING LUMINAIRES
WARRANTY
- The manufacturer shall repair or replace a luminaire that has been found to be defective under
normal use through no fault of the customer provided that it was delivered, stocked,
mounted/installed and operated in conditions and according to the requirements specified in a
product data sheet, engineering specifications, mounting and service instructions, delivery
terms, rules for technical maintenance of electrical installations and other conditions agreed by
the manufacturer and the customer during the warranty period or expanded warranty period
specified below.
- The luminaire is a serviceable device. When installing the luminaire, free access should be
provided for service or repair. The manufacturer is not responsible and will not compensate any
expenses related to construction work, rental vehicles etc. in case the repair site is not readily
accessible. The statutory warranty period is determined by the applicable law, and may vary
from country to country. The manufacturer undertakes statutory warranty obligations in the
amount and within the time frame stipulated by the applicable law.
- Warranty period - 60 months from date of delivery subject to terms and conditions specified
herein and on the manufacturer’s website at https://www.ltcompany.com/en/terms/
- Warranty does not apply to color change of painted surfaces and plastic parts during luminaire
operation.
Luminous flux level is at least 70% of the nominal value during the warranty period.
- Warranty will cover the entire period, given that assembly, installation and operation of
luminaires are handled by specialized technical personnel and according to the luminaire's
manual.
- The service life of the luminaires under normal climatic conditions subject to installation and
usage instructions is:
· 8 years – for luminaires with body and/or optical parts (diffuser) made of polymeric materials.
· 10 years - all other luminaries.

- The manufacturer reserves the right to make modifications to the product that improve its end-
user performance.
The manufacturer is not liable for typographical and other errors that may have occurred in
printing.
- The warranty period of emergency power supply units (supplied with rechargeable battery) and
illumination control system components (supplied without luminaires) is limited to 12 (twelve)
months from date of delivery.
Storage.
- The luminaire should be stored in heated and ventilated warehouses, storages with conditioned
air which situated at any climatic region and with temperature from +5 to +40°С and relative
humidity not more than 80%.
- NiCd, NiMh batteries: Temperature range +5 to +40°C.
- When storing for more than 6 months it is recommended to refresh batteries - 5 cycles of
charging-discharging.
- Transportation in manufacturer's package could be done by any mode of transport as long as
protection from mechanical damage and precipitation is provided.
ACCEPTANCE CERTIFICATE
The luminaire meets the requirements of applicable EC directives
Manufacture date ___________________________________________________________________
Inspected by _______________________________________________________________________
Packaged by _______________________________________________________________________
Manufacturer: company LLC "IGC "Lighting Technologies'
Date of sale________________________________________________________________________
Company stamp
Hotline
www.LTcompany.com
0049 89 550 59 8611
