Liko Viking L User manual

Prod. No. 2040014
S/N 7 800 001- 7 900 000
Prod. No. 2040004
S/N 7 200 201- 7 300 300
DISCONTINUED 2013
Prod. No. 2040034
S/N 9 300 001- 9 400 000
Viking™ L
Mobile Li
Service Manual
3EN36401 Rev. 10
ENGLISH

Spare part statement
Liko AB will as a manufacturer of staonary & mobile lis keep spare parts available
for 10 years aer the last manufacturing date of the product.
Spare parts are available in the spare parts list or in the Service Manual for each model of li.
Components (manufacturing parts) are not available aer last manufacturing date.
Repairs and maintenance may only be performed by personnel authorized by Hill-Rom
and using original Liko™ spare parts.
For informaon regarding Service and Maintenance educaon, contact your Hill-Rom representave.
For contact informaon please visit our website: www.hill-rom.com lwww.liko.com

Table of Contents 1.0
Service Manual Viking™L mobile lift • 3EN360401 Rev. 10 3 www.hill-rom.com lwww.liko.com
Page
1.0 Table of contents....................................................................................................................... 3
2.0 Spare Parts Posion .................................................................................................................. 4
3.0 Technical Data
3.1 Viking L 2040004............................................................................................... 5
3.2 Viking L 2040014............................................................................................... 6
3.3 Viking L 2040034............................................................................................... 7
4.0 Troubleshoong
4.1 Viking L 2040004............................................................................................... 8
4.2 Viking L 2040014............................................................................................... 9
4.3 Viking L 2040034.............................................................................................. 10
4.4 Control Unit CBL20 .......................................................................................... 11
5.0 Spare Parts List......................................................................................................................... 12
5.19 Aachment for Control Box ........................................................... 17
5.20 Handcontrol 6-Buon ................................................................... 18
5.22-24, 248 Cable for Charging.......................................................................... 19
5.55 HandControl EE 4-buon............................................................... 20
5.139 Extra Baery Box, incl. Baeries.................................................... 21
5.159 Front Fork Cover ............................................................................ 22
5.160 Extension Cable.............................................................................. 23
5.192 Front Wheel 100 mm..................................................................... 24
5.193 Rear Wheel 125 mm ...................................................................... 25
5.194 Rear Fork Cover.............................................................................. 26
5.196 Li Arm Plasc Cover..................................................................... 27
5.197 Overhead Beam Restoraon set .................................................... 28
5.198 Control Box Viking L/XL.................................................................. 29
5.199 Locking Handle XL ......................................................................... 30
5.263 Extension Cable US ........................................................................ 31
5.264 Latch Universal Slingbar................................................................. 32
5.266 Base Motor Viking M,L complete................................................... 33
5.292 Hook for HandControl 2,4,6 .......................................................... 35
5.293 End Cover Handle/Arm Support grey............................................. 36
5.307 Li Arm Plasc Cover .................................................................... 37
5.308 Overhead Beam Restoraon set .................................................... 38
5.309 Actuator Viking L, XL ...................................................................... 39
5.311 Latch, composite............................................................................ 40
5.331 Outer Tube ..................................................................................... 41
5.333 Wireless hand control HBL20......................................................... 43
5.336 Control Unit CBL, by S/N................................................................ 44
5.336C Control Unit CBL, by S/N cable....................................................... 46
5.348-349 Extension cable CBL20 ................................................................... 48
5.350 Extra baery box............................................................................ 49
5.351 Beltclip HBL20................................................................................ 50
5.352 Clips with hook HBL20 ................................................................... 51
5.353 Charge cable hook.......................................................................... 52
5.354 Hand control hanger ...................................................................... 53
5.413 Rear Wheel fork ............................................................................. 54
5.422 Locking device CBL20..................................................................... 55
5.439 Bracket Cover ................................................................................. 56
5.451 Bracket Cover ll .............................................................................. 57
5.452 Restoraon set motor aachment................................................. 58
5.453 Control Unit CBL, Viking L ............................................................. 60
5.453C Control Unil CBL, Vi L Cable............................................................ 62
5.455 Actuator LA44-400 ......................................................................... 64
5.459 Leg Cover L&XL .............................................................................. 65
5.461 Flexlink........................................................................................... 67
5.485 Fork locking aachment ................................................................ 68
5.486 Wheel Fork..................................................................................... 69
5.490 SlingBar Assembly set .................................................................... 70
5.511 Locking ring hand control CBL........................................................ 71
6.0 Service,Control Unit CB
6.1 Parameter Code Key........................................................................................................... 72
6.2 Reset Service Interval Parameters...................................................................................... 73
7.0 Liko Service System, LSS........................................................................................................... 74
8.0 Liko Diagnosc System - Service, LDS....................................................................................... 75
9.0 Periodic Inspecon................................................................................................................... 77
10.0 Preventave Maintenance....................................................................................................... 83
11.0 Product Changes ...................................................................................................................... 89

Spare Parts Posions
2.0
Service Manual Viking™L mobile lift • 3EN360401 Rev. 10 4 www.hill-rom.com lwww.liko.com
PROD. NO. PRODUCT
Spare Parts List 61 www.hill-rom.com l www.liko.com
PROD. NO. POS. NO. NAME UNIT 2040003 2040013 2040033
2040004 Viking L (Disconnued 2013)
2040014 Viking L (with intelligent control box)
2040034 Viking L (with intelligent control box and cable hand control)
139
19
266
192
193
413
159
196 197
198 199
55
160 263
264
292
311
307 308
331
309
194
439
Product No. 2040014 (S/N: 7 800 001- 7 900 000)
2040034 (S/N: 9 300 001- 9 400 000)
Fits Viking L, all models:
Product No. 2040004 (S/N: 7 200 201 - 7 300 300)
22 23 24 248
485
192
193
194
307
199
266
308
311
333
293
453
348 349
350
351 352
353
354
413
451
452
455
459
459
461
461
485
159
486
490
490
511
453C
422
Service Tools, see page 83
Liko Service System Liko Diagnosc System
20
Spare Parts Posions Viking™ L mobile li
293

Technical Data
Service Manual Viking™L mobile lift • 3EN360401 Rev. 10 5 www.hill-rom.com lwww.liko.com
Prod. No. 2040004
4www.liko.com
Viking L • 7EN136102-03
Measurements
Lifting
speed:
3.5 cm/s (0.8 inch./s) without load
Batteries: Two 12 V, 2.9 Ah, valve-regulated
lead-acid gel-type batteries. New bat-
teries are provided by the supplier.
Battery Built-in charger, 100-240 V AC,
max 400 mA
Motor (mast): 24 V, 10.8 A, permanent magnetic
motor with mechanical safety mecha-
nism, safety nut and outer tube.
Motor (base): 24 V, 5.5 A, permanent magnetic
motor.
Material: Aluminium
Emergency
lowering:
Mechanical and electrical
Technical Data
Wheels: Standard front: 100 mm dual.
Standard rear: 125 mm dual w. brake.
Alt. front: 75 mm dual.
Alt. rear: 100 mm single w. brake.
Intermittent
operation:
Int. Op 10/90, active operation max 2
min. Out of a time of 100, active must
be less than 10, though not more than
2 min.
Degree of
protection:
IP 43
Built for indoor operation.
Type B according to the degree of protection
against electric chock.
Class ll equipment.
* Standard for Viking L.
Model Wheel
diameter
Max.
load
L
Max
L
Min
A
Max
A
Min
B B1C D E F F1GWeight
tot
Weight
part
Turning
diameter
Viking L 100/125 * 250 1790 450 2000 1360 1350 900 660-960 550-950 1060 140 45 900 40 22 1420
Viking L 75/100 250 1780 440 1990 1350 1350 900 660-960 550-950 1050 120 35 900 40 22 1420
Maximum load and weight in kg. Measures in mm.
Maximum load and weight in lbs. Measures in inches.
Model Wheel
diameter
Max.
load
L
Max
L
Min
A
Max
A
Min
B B1C D E F F1GWeight
tot
Weight
part
Turning
diameter
Viking L 3.9/ 4.9* 550 70 18 79 54 53 35 26-38 22-37 42 5.5 1.8 35 88 48 60
Viking L 3.0/3.9 550 70 18 79 54 53 35 26-38 22-37 42 4.7 1.4 35 88 48 60
* Standard for Viking L.
L
G
B
FF1B1
A
E
D
C
3.1

Technical Data
Service Manual Viking™L mobile lift • 3EN360401 Rev. 10 6 www.hill-rom.com lwww.liko.com
Prod. No. 2040014
Maximum load: 250 kg (550 lbs)
Material: Aluminium
Weight: Total weight: 36.5 kg (80 lbs)
Heaviest part: 20.5 kg (45 lbs)
Wheels: Front: 100 mm (4 in) twin wheels.
(Or 75 mm* (3 in) twin wheels).
Rear: 125 mm (5 in) twin wheels.
(Or 100 mm (4 in) single castors with brakes).
Turning
diameter: 1460 mm (57.4 in)
Emergency Low-
ering: Mechanical and electrical
Liing interval: 1330 mm (52.4 in)
Liing Speed (no
load):
21 mm/s and 13 mm/s, respecvely
0.8 in/s and 0.5 in/s,
Sound Level: 51 dB(A)
Protecon
Class: IP X4
Operang Forces
of Controls: HandControl: 4 N
Operaon Panel: 4 N
HandControl
IR
Baeries: 2 AAA LR03 1.5 V.
Reach: 2 m (80 in)
Electrical Data: 24 V
Intermient
operaon:
Int. Op 10/90, acve operaon max 2 min. Only
10% of a given length of me may
be acve, yet no more than 2 min.
Baeries: NiMH cells, 2.2 Ah. New baeries provided by
the supplier.
Baery
Charger:
CBL20001, built-in, 100-240 V AC,
50-60 Hz, max 600 mA.
Li Motor: Permanent magnet motor with mechanical
safety mechanism
24 V, 6.4 A
Motor for
base-width
adjustment:
Permanent magnet motor
24 V, 6 A
The device is intended for use indoors
Type B, in accordance with the electrical shock protecon class.
Class II equipment.
Top view
Lateral view
B
B1
F F1
Amax.
B2
Amin.
**600 mm (24 in)
E
M
N
O
Max. reach posion of li arm
B3
Lmin
Lmax
C
D2
D
Max. reach posion of li arm
D1
**700 mm (28 in)
Note: The measurements are based on the li being equipped with standard sling bar and standard wheels. When changing to other liing accessories,or
other wheels, check that the li sll achieves desired liing height.
** Reference measurement according to Standard EN ISO 10535:2006.
Measures in mm
Measures in inch.
Amax Amin B B1 B2 B3** C D D2** E F F1 Lmax Lmin M N O
max min max min
2030 1390 1360 900 630 560 1070 695 950 625 230 1060 165 43 1790 460 500 280 550
A max A min B B1 B2 B3** C D D2** E F F1 Lmax Lmin M N O
max min max min
80.0 54.7 53.5 35.4 24.8 22.0 42.1 27.4 37.4 24.6 9.1 41.7 6.5 1.7 70.5 18.1 19.7 11.0 21.7
3.2

Maximum load: Viking L: 250 kg (550 lbs)
Material: Aluminium
Weight: Total weight: 37,4 kg (82.5 Ibs)
Heaviest part: 21,6 kg (47.6 Ibs)
Wheels: Front: 100 mm (4 in) twin wheels.
Rear: 125 mm (5 in) twin wheels.
Turning diameter 1460 mm (57.4 in)
Emergency
lowering device:
Mechanical and electrical
Liing interval: 1330 mm (52.4 in)
Liing speed
(no load)
21 mm/s and 13 mm/s, respecvely
( 0.8 in/s and 0.5 in/s, respecvely)
Sound level: 51 dB(A)
Protecon class: IP X4
Operang Forces of
Controls:
HandControl: 2.4 N
Operaon Panel: 4 N
Electrical data: 24 V
Intermient
power:
Int. Op 10/90, acve operaon
max 2 min. Only 10% of a given
length of me may be acve, but no
more than 2 min.
Baeries: NiMH cells, 2.2 Ah. New baeries
provided by the supplier.
Baery charger: CBL20002, built-in, 100-240 V AC,
50-60 Hz, max 600 mA.
Li motor: Permanent magnet motor with
mechanical safety mechanism
24 V, 6.4 A
Motor for base-width
adjustment:
Permanent magnet motor
24 V, 6 A
The device is intended for use indoors
Type B, in accordance with the electrical shock protecon class.
Class II equipment.
Top view
Lateral view
B
B1
F F1
Amax.
B2
Amin.
**600 mm (24 in)
E
M
N
O
Max. reach posion of li arm
B3
Lmin
Lmax
C
D2
D
Max. reach posion of li arm
D1
**700 mm (28 in)
Technical Data
Service Manual Viking™L mobile lift • 3EN360401 Rev. 10 7 www.hill-rom.com lwww.liko.com
Prod. No. 2040034
Note: The measurements are based on the li being equipped with standard sling bar and standard wheels. When changing to other liing accessories,or
other wheels, check that the li sll achieves desired liing height.
** Reference measurement according to Standard EN ISO 10535:2006.
Measures in mm
Measures in inch.
Amax Amin B B1 B2 B3** C D D2** E F F1 Lmax Lmin M N O
max min max min
2030 1390 1360 900 630 560 1070 695 950 625 230 1060 165 43 1790 460 500 280 550
A max A min B B1 B2 B3** C D D2** E F F1 Lmax Lmin M N O
max min max min
80.0 54.7 53.5 35.4 24.8 22.0 42.1 27.4 37.4 24.6 9.1 41.7 6.5 1.7 70.5 18.1 19.7 11.0 21.7
3.3

Service Manual Viking™L mobile lift • 3EN360401 Rev. 10 8 www.hill-rom.com lwww.liko.com
11 www.liko.com
Viking L • 7EN136102-03
Simple Troubleshooting
The lift does not work up/down.
Width adjustment does not
work in/out.
Battery charging does not
work.
The lift stops in the elevated
position.
If you hear unusual sounds.
1. Check that the emergency stop button is not
pushed in (p. 7).
2. Check that the cables are correctly connected
(p. 5).
3. Check that the charger cable is not connected
to the wall socket.
4. Check that the battery is charged (p. 8).
5. Check that the contact plates of the battery are
not defective or broken off.
6. If the lift still does not work satisfactorily, contact
Liko/Hill-Rom.
1. Check that the emergency stop button is not
pushed in (p. 7).
2. Check to ensure that the wall socket is power-
supplied.
3. Check to ensure that the charger cable is
correctly connected (p. 6 & 8).
4. Check that the contact plates of the battery box
are not defective or broken off.
5. If the lift still does not work satisfactorily, contact
Liko/Hill-Rom.
1. Check that the emergency stop button is not
pushed in (p. 7).
2. Use the electrical emergency lowering (marked)
to safely lower the patient (p. 7).
3. Use the mechanical emergency lowering
(marked) to safely lower the patient (p. 7).
4. Check that the battery is charged.
5. If the lift still does not work satisfactorily, contact
Liko/Hill-Rom.
Contact Liko/Hill-Rom.
.
.
.
.
.
.
.
.
Prod. No. 2040004
Trouble shoong
4.1

Service Manual Viking™L mobile lift • 3EN360401 Rev. 10 9 www.hill-rom.com lwww.liko.com
Prod. No. 2040014
Trouble shoong
The li does not work up/down with the
operaon panel.
The base-width adjustment doesn’t work
(in/out) with
the operaon panel.
The charger doesn’t work.
The li is stuck in the high posion.
If you hear unusual sounds.
1. Make sure that the emergency stop is not engaged.
2. Check that the charging cable is correctly connected.
3. Make sure that the baery is properly aached.
4. Check that the baery’s contact plates are not defecve or broken.
5. If the problem persists, please contact Liko/Hill-Rom.
1. Make sure that the emergency stop is not engaged.
2. Check the baery capacity.
3. HandControl IR indicates baery change.
4. Use the electrical emergency lowering device to lower
the paent onto a rm surface.
5. Use the manual emergency lowering device to lower
the paent onto a rm surface.
6. If the problem persists, please contact Liko/Hill-Rom.
Contact Liko/Hill-Rom.
The li does not work up/down with
the HandControl IR.
The base-width adjustment doesn’t
work (in/out) with
the HandControl IR.
1. Make sure that the emergency stop is not engaged.
2. Make sure that the cables to the control box are connected
correctly.
3. Check that the charger cable is not connected to an electric outlet.
4. Check the baery capacity.
5. Check that the baery’s contact plates are not defecve or broken.
6. If the problem persists, please contact Liko/Hill-Rom.
1. Make sure that the emergency stop is not engaged.
2. If the li has not been used for 24 hours, enable the system.
3. Check that the HandControl IR is enabled.
4. Check that the charger cable is not connected to an electric outlet.
5. HandControl IR indicates baery change.
6. If the li works via the operaon panel, change the HandControl IR.
7. If the li moon is stopped during raising maximum load, and
then won’t raise, try to lower the li and then raise again.
8. If the problem persists, please contact Liko/Hill-Rom.
4.2

Service Manual Viking™L mobile lift • 3EN360401 Rev. 10 10 www.hill-rom.com lwww.liko.com
Prod. No. 2040034
4.3
Trouble shoong
1. Check that the emergency stop buon has not been pressed.
2. Check that the charger cables are connected correctly.
3. Make sure that the baery is properly aached.
4. If the problem persists, please contact Liko/Hill-Rom.
1. Check that the emergency stop buon has not been pressed.
2. Check the baery capacity.
3. Check that the hand control cable is connected correctly.
4. Electrical emergency lowering, use the operaon panel to lower the
paent onto a rm surface.
5. Use the mechanical emergency lowering device to lower the paent
onto a rm surface.
6. If the problem persists, please contact Liko/Hill-Rom.
1. Check that the emergency stop buon has not been pressed.
2. Check that the cables to the control box are connected correctly.
3. Check that the charger cable is not connected to an electric outlet.
4. Check the baery capacity.
5. If the problem persists, please contact Liko/Hill-Rom.
1. Check that the emergency stop buon has not been pressed.
2. Check the baery capacity.
3. Check that the charger cable is not connected to an electric outlet.
4. Check that the hand control cable is correctly connected.
5. If the li works via the operaon panel, change the Hand Control.
6. If the problem persists, please contact Liko/Hill-Rom.
The li does not work up/down
with the operaon panel.
The base-width adjustment doesn’t
work (in/out) with
the operaon panel.
The charger doesn’t work.
The li is stuck in the high posion.
If you hear unusual sounds. Contact Liko/Hill-Rom.
The li doesn’t work up/down with
Hand Control.
The base-width adjustment doesn’t
work (in/out) with the Hand Control.

Service Manual Viking™L mobile lift • 3EN360401 Rev. 10 11 www.hill-rom.com lwww.liko.com
Trouble Shooting for CBL20
3EN902101-01
Customers FAQ:
- The liftarms up/down function or base width in/out function doesn´t work?
a) Change position on actuator and base motor cables.
b) Perform step 2 and see if fault is on output channel or motors.
- The control panel function´s on controlbox is ok, but the hand control has no function?
a) Check to ensure that battery contact plates in the hand control are not defective or broken.
- There´s no charging function?
a) Verify contact between control box and battery. Perform step 4.
b) Check charging function. Perform step 5.
Note! Begin with Simple trouble shooting from Service manual for the
actual product. If problem remains continue as described below.
Tools Required
Multimeter
123
Instructions regarding the check points for
Lift type: Serial No: Prod. Year: Contract No:
Name:
Address:
(Zip Code)
Viking M
www.liko.com
14
Tools required
Ah 140 280 420 560 700
Check:
8 Battery
Battery capacity
Check battery capacity by pressing the i button (1).
The following information is displayed:
2 – Green light: More than 50% of battery capacity remaining.
3 – Yellow light: 25% -50% of battery capacity remaining.
4 – Yellow light: 0% -25% of battery capacity remaining.
The indicator lamps light for about 30 seconds before switching off.
Battery capacity is also displayed during lift operation.
Maximum charge is reached after about 5 hours. When the batteries are fully charged, the charger switches
automatically to maintenance charging.
The lamps blink alternately (yellow/yellow/green) during charging. A blinking green lamp indicates that charging
is complete. When operating time is noticeably shorter than normal, the batteries should probably be replaced.
Discontinue charging and replace the batteries with 2006107 Extra battery box.
1
4
3
2
Prod. No.
2006107 Extra battery box
Replace:
2
123
1
Instructions regarding the check points for
Lift type: Serial No: Prod. Year: Contract No:
Name:
Address:
(Zip Code)
Viking M
www.liko.com
14
Tools required
Ah 140 280 420 560 700
Check:
8 Battery
Battery capacity
Check battery capacity by pressing the i button (1).
The following information is displayed:
2 – Green light: More than 50% of battery capacity remaining.
3 – Yellow light: 25% -50% of battery capacity remaining.
4 – Yellow light: 0% -25% of battery capacity remaining.
The indicator lamps light for about 30 seconds before switching off.
Battery capacity is also displayed during lift operation.
Maximum charge is reached after about 5 hours. When the batteries are fully charged, the charger switches
automatically to maintenance charging.
The lamps blink alternately (yellow/yellow/green) during charging. A blinking green lamp indicates that charging
is complete. When operating time is noticeably shorter than normal, the batteries should probably be replaced.
Discontinue charging and replace the batteries with 2006107 Extra battery box.
1
4
3
2
Prod. No.
2006107 Extra battery box
Replace:
3
green, LED
yellow, LED
5
4
1. Make sure that:
- the emergency stop 1 is not activated.
- the battery is assembled correctly.
- the charging cable is not connected to mains.
2. Check operation panel function´s for actuator and base motor
Push control buttons on operation panel 2 at control box
- If both actuator and base motor functions response, continue to step 5.
- If no function, continue to step 3.
- If only one of either the actuator or base motor function response:
change position on actuator and base motor cables then check control
function of operation panel, to see if fault is on output channels or the
motors. If control box function is ok! Continue to step 5.
If control box is faulty. Replace the control box.
3. Check battery capacity
3a) Push in the battery capacity button 3 :
- If any of the three LED´s on the battery start´s the battery is OK, continue
to step 4.
- If not, continue to step 3b.
3b) Measure battery voltage: release battery, 4 measure on contact 1 and 3:
- If voltage over 0V the battery is ok! Continue to step 4.
4. Verify contact between control box and battery.
4a) Remove the battery and wait for green LED to turn off.
4b) Put back the battery and see if green LED start automatically.
- If green LED starts, battery contact is ok!
- If not, try to ensure that the battery´s contact plates are not defective
or broken and try to bend them out carefully, then repeat step 4.
- If still no contact, continue to step 5.
5. Check charging function
5a) Connect the charging cable to mains
- If charging starts within 1 minute, charge and then continue to step 6.
- If charging doesn´t start, continue to step 5b.
5b) Measure output voltage on the control box 5 on contact 1 and 3.
- If voltage is 3-4V charging is OK! Replace the battery, continue to step 6.
- If voltage is 0V when the charging cable is connected to mains the control
box needs to be replaced! Replace the control box.
6. Charge the battery until green LED is ashing, on the battery.
- Check that all function´s on the control box is ok!
If not , Replace control box.
Check point:
4.4
Trouble shoong
Control Unit CBL

Spare Parts List
5.0
Service Manual Viking™L mobile lift • 3EN360401 Rev. 10 12 www.hill-rom.com lwww.liko.com
Spare Parts List 62 www.hill-rom.com l www.liko.com
PROD. NO. POS. NO. NAME UNIT 2040004 2040014 2040034
Spare Parts
Viking™ L mobile li
There are three models of Viking L; Prod. No. 2040004, 2040014 and 2040034. Which spare part that ts
to each model, can be read in the columns to the right. (x=ts with this model)
Viking L Control Units
20490009
20490009US
198
198
Control Box Viking L/XL
Control Box Viking L/XL, US
only for the US-market
pce
pce
x
x
20490039 336 Control Unit CBL, by S/N
Can only be ordered if S/N
(serial number) can be provided to
Liko Customer Service.
Will be programmed at Liko before
delivery.
2 weeks delivery me from
Hill-Rom/Liko Alvik, Sweden
pce x
20490054 336C Control Unit CBL by S/N, Cable
Can only be ordered if S/N
(serial number) can be provided to
Liko Customer Service.
Will be programmed at Liko before
delivery.
2 weeks delivery me from
Hill-Rom/Liko Alvik, Sweden
pce x
20490043 453 Control Unit CBL, Viking L
Before use; requires Soware and,
needs to be programmed with Liko
Service System,
Prod. No. 21090024
pce x
20490055 453C
Control Unit CBL Viking L, Cable
Before use; requires Soware and,
needs to be programmed with Liko
Service System,
Prod. No. 21090024
pce
x
Viking L Spare Parts
20090023 19 Aachment for Control Box pce x
20090089 20 Hand control 6-Buon pce x
PROD. NO. POS. NO. NAME UNIT 2040004 2040014 2040034

Spare Parts List
5.0
Service Manual Viking™L mobile lift • 3EN360401 Rev. 10 13 www.hill-rom.com lwww.liko.com
Spare Parts List 63 www.hill-rom.com l www.liko.com
PROD. NO. POS. NO. NAME UNIT 2040004 2040014 2040034
Spare Parts
Viking™ L mobile li
20090026 22 Cable for Charging, EU pce x x x
20090027 23 Cable for Charging, UK pce x x x
20090028 24 Cable for Charging, US pce x x x
20190017 55 Hand Control EE 4-Buon pce x
2006106 139 Extra Baery box, incl. Baeries pce x
20390006 159 Fork Cover pair x x x
21090001 160 Extension Cable pce x
20490003 192 Front Wheel 100 mm
We recommend replacing both
wheels, as there are two dierent
versions that can vary in
appearance. (dimension is the same)
pce x x x
20490004 193 Rear Wheel 125 mm
We recommend replacing both
wheels, as there are two dierent
versions that can vary in
appearance. (dimension is the same)
pce x x x
20490005 194 Rear Fork Cover pair x x x
20490007 196 Li Arm Plasc Cover Vi
To S/N 7200488.
set x
20490008 197 Overhead Beam Restoraon set
To S/N 7200488
set x
20490010 199 Locking Handle Viking XL
from S/N 7200431
pair x x x
20090050 248 Cable for Charging, AU/NZ pce x x x

Spare Parts List
5.0
Service Manual Viking™L mobile lift • 3EN360401 Rev. 10 14 www.hill-rom.com lwww.liko.com
Spare Parts List 64 www.hill-rom.com l www.liko.com
PROD. NO. POS. NO. NAME UNIT 2040004 2040014 2040034
Spare Parts
Viking™ L mobile li
21090011 263 Extension Cable US pce x
31590011 264 Latch Universal SlingBar pair x
20490011 266 Base Motor Viking M, L pce x x x
20090058 292 Hook for Hand control 2, 4, 6 pce x x
20090066 293 End Cover Handle/Arm Support
grey, 4 pce
set x x x
20490023 307 Li arm plasc cover
Prod. No. 2040004, from S/N
7200795
set x x x
20490024 308 Overhead beam restoraon set
Prod. No. 2040004, from S/N
7200795
set x2
x6
x3
x6
x2
x x x
20490025 309 Actuator Viking L, XL pce
X
Y
Z
x
31590014 311 Latch, composite
Fits Universal SlingBar
from S/N 1299511
pair x x x

Spare Parts List
5.0
Service Manual Viking™L mobile lift • 3EN360401 Rev. 10 15 www.hill-rom.com lwww.liko.com
Spare Parts List 65 www.hill-rom.com l www.liko.com
PROD. NO. POS. NO. NAME UNIT 2040004 2040014 2040034
Spare Parts
Viking™ L mobile li
20490030 331 Outer Tube pce x
20490031 333 Wireless hand control HBL20 set x
21090018 348 Extension cable CBL20 pce x x
21090019 349 Extension cable CBL 20 US, pce x x
2006107 350 Extra baery box pce x x
21090020 351 Beltclip HBL20 pair x
21090021 352 Clips with hook HBL20 pair x
21090022 353 Charge cable hook , 10 pce set x x
21090023 354 Hand control hanger, 10 pce set x
20490037 413 Rear Wheel fork pair x x x
20090077 422 Locking device CBL20, 10 pce set x x
20490040 439 Bracket Cover set x

Spare Parts List
5.0
Service Manual Viking™L mobile lift • 3EN360401 Rev. 10 16 www.hill-rom.com lwww.liko.com
Spare Parts List 66 www.hill-rom.com l www.liko.com
PROD. NO. POS. NO. NAME UNIT 2040004 2040014 2040034
Spare Parts
Viking™ L mobile li
20490041 451 Bracket Cover ll set x x
20490042 452 Restoraon set motor aachment set
X
Y
Z
x2
x x
20490045 455 Actuator LA44 - 400 set x x
20490047 459 Leg Cover L&XL set x x x
20490049 461 Flexlink set x x x
20090080 485 Fork locking aachment, 4 pair set x x x
20090081 486 Wheel Fork pair x x x
20490052 490 SlingBar Assembly set set x x x
20490057 511 Locking Ring CBL
10 pce
x

Service Manual Viking™L mobile lift • 3EN360401 Rev. 10 17 www.hill-rom.com lwww.liko.com
Attachment for Control Box
Monteringsbeslag kontrollbox
Assembly Instruction
Monteringsanvisning
Prod. No. 20090023
3SE630238-05
2011-02-08
© Copyright Liko AB www.liko.com
Tools required:
3 mm
T25
Contains: Qty:
Screw MRT-GF M5x16 3
Screw MCL6S M5x8 4
Control box attachment 1
Fits:
Golvo 7000ES/7007ES, 7007 LowBase
Uno 100 EM/EE
Uno 102 EM/EE/ES
Sabina EM/EE
Sabina II EM/EE
Viking XL (Prod. No. 2040003)
Viking L (Prod. No. 2040004)
Viking M (Prod. No. 2040005)
Liko M220 / M230
2.
3.
x 1
1.
x 3 (Viking M, L, XL, Golvo 7000ES/7007ES)
x 3 (Sabina, Uno, Liko M220/M230)
4. 5.
NOTE
- Make sure the spare part is mounted according to the assembly instruction.
- Check all functions related to the changed spare part.
- Repairs and maintenance may only be performed by personnel authorized by Liko/Hill-Rom and using original Liko spare parts.
(Holder for the charging cable, is
not standard on every lift model)
5.19
5.19

Service Manual Viking™L mobile lift • 3EN360401 Rev. 10 18 www.hill-rom.com lwww.liko.com
Hand Control ES 6-Button
Handkontroll ES 6-knappar
Assembly Instruction
Monteringsanvisning
Prod. No. 20090089
3SE690232-02
2013-01-17
© Copyright Liko AB www.liko.com
NOTE
- Make sure the spare part is mounted according to the assembly instruction.
- Check all functions related to the changed spare part.
- Repairs and maintenance may only be performed by personnel authorized by Hill-Rom/Liko and using original Liko spare parts.
Product: Prod. No.
Viking XL 2040033
Viking L 2040034
Viking M 2040035
Golvo 8000 2000034
Golvo 8008 2000035
Golvo 8008 LowBase 2000039
Contains: Qty:
Hand control ES 1
Locking Ring 1
Tools required
Product:
Golvo 7000ES/7007ES
Golvo 7007 LowBase
Uno 102 ES
Sabina EE
Sabina II EE
Connect cable
1. Release the locking ring
by pressing the triangular
tab.
2. Remove the
locking ring.
3. Remove the
hand control.
Assemble in
reverse order.
4. Make sure the
rectangular
tabs at the
locking ring
 arexed.
Use no locking
ring on these
products.
Triangular tab
facing out.
5.20

Service Manual Viking™L mobile lift • 3EN360401 Rev. 10 19 www.hill-rom.com lwww.liko.com
5.22-24, 248
Cable for Charging
Laddningskabel
Assembly Instruction
Monteringsanvisning
3SE630237-06
2012-09-11
© Copyright Liko AB www.liko.com
NOTE
- Never charge batteries in a wet area.
- The lift cannot be charged with the emergency stop engaged.
- When charging, a yellow indicator light on the control box will illuminate. The yellow light turns off when the battery is fully
charged. If the light has not turned off after 8 hours of charging, the battery may need to be replaced. Stop charging and
replace the battery.
- Make sure the spare part is mounted according to the assembly instruction.
- Check all functions related to the changed spare part.
-
Repairs and maintenance may only be performed by personnel authorized by Liko/Hill-Rom and using original Liko spare parts.
Prod. No. 20090026 EU
20090027 UK
20090028 US
20090050 AU/NZ
Contains: Qty:
Charging cable 1
Fits:
Golvo 7000ES / 7007ES / 7007 LowBase
Golvo 8000 / 8008 / 8008 LowBase
Uno 100 EM/EE
Uno 102 EM/EE/ES
Sabina EM/EE
Sabina II EM/EE
Viking XL
Viking L
Viking M
The lift cannot be used when the charger cable is plugged into an electrical outlet.
Lift equipped with Liko Diagnostic System™

Service Manual Viking™L mobile lift • 3EN360401 Rev. 10 20 www.hill-rom.com lwww.liko.com
Hand Control 2, 4-button
Handkontroll 2, 4-knapp
Assembly Instruction
Monteringsanvisning
Prod. No. 20190016, 20190017
3SE630204-11
2012-09-11
© Copyright Liko AB www.liko.com
Connect cable
Connect cable
20190016 Contains: Qty:
Hand control EM 2-Button 1
20190017 Contains: Qty:
Hand Control EE 4-Button 1
20190016 Hand control EM 2-Button, Fits:
LikoLight
Sabina EM
Sabina II EM
Uno 100 EM
Uno 102 EM
Viking S
Viking XS
20190017 Hand control EE 4-Button, Fits:
Uno 100 EE
Uno 102 EE
Viking XL Prod. No. 2040003
Viking L Prod. No. 2040004
Viking M Prod. No. 2040005
NOTE
- Make sure the spare part is mounted according to the assembly instruction.
- Check all functions related to the changed spare part.
- Repairs and maintenance may only be performed by personnel authorized by Hill-Rom/Liko and using original Liko spare parts.
5.55
