Liko RepoSheet Short Manual

is a warning triangle used for situations that demand extra care and attention.
In this document, the person being lifted is referred to as the patient and the person helping them is referred to as
the caregiver.
Product Description
Solo RepoSheet accessory has been specially
developed by Liko to facilitate transfers of a patient in
bed. It is an excellent aid for repositioning further up
in bed and during turning in beds using a lift and with
minimal body strain for the caregivers.
Transfers can be carried out with the help of one person
but we recommend that there are two caregivers which
is time-saving and a comfortable way to work.
Solo RepoSheet accessory can be used in combination
with, or instead of ordinary bed sheets.
Solo RepoSheet accessory is intended for short-term
use by one individual patient. It should be disposed
when it becomes soiled or when the patient no longer
needs it.
Two models are available; Short, for lifting up to
200 kg (440 lbs.), and Generous, for lifting up to 300 kg
(660 lbs.). Solo RepoSheet Generous accessory have a
separate Instruction Guide.
There are also RepoSheet accessory models for long-
term use in Liko’s product range.
If it is necessary to transfer a patient between two
horizontal surfaces sufcient lift straps are used to ensure
that the patient has enough support under the body to be
lifted safely during the transfer. Also, make sure that strap
loops do not become stuck anywhere during the transfer.
Solo RepoSheet accessory works best in combination
with overhead lifts. We recommend LikoGuard™
overhead lift, Likorall™overhead lift or Multirall™
overhead lift. See nal page for recommended sling bars.
Solo RepoSheet accessory is not intended for lifting
or transfers from lying to sitting positions. For such needs,
we recommend lifting with one of our many sling models.
IMPORTANT!
Lifting and transferring a patient always involves a certain level of risk. Read the instruction guide for both
the patient lift and lifting accessories before use. It is important to completely understand the contents of the
instruction guide. The equipment should only be used by trained personnel. Ensure that the lifting accessories
are suitable for the lift used. Exercise care and caution during use. As a caregiver, you are always responsible for
the patient’s safety. You must be aware of the patient’s ability to make it through the lifting situation. If something
is unclear, contact the manufacturer or supplier.
7EN161109 Rev. 3
ENGLISH
Solo RepoSheet™ Short
Accessory
Instrucon Guide

2www.hill-rom.com I www.liko.comSolo RepoSheet™Short • 7EN161109 Rev. 3
Before lifting, remember the following!
Denitions
4. Year/month of production
5. Lift strap (with different
colour at the head end)
User Description
Place Solo RepoSheet Short accessory centrally on the bed with the
head end of the sheet approx. 10 cm (3.9 inch.) from the edge of the
mattress. Note that the lift strap at the head end has a different colour.
Solo RepoSheet accessory should be placed like this the rst time it is
used or when it is time to change the bedding.
The rst time Solo RepoSheet accessory is put in place on the bed,
it is easiest to lift the patient from the bed in a sling, for example, Soft
Original High Back Sling, Model 26.
Each new time Solo RepoSheet Short accessory is put in place means
repositioning 2-3 times further up in the bed before it is time to change
the bedding.
Lifting further up in the bed
Connect the strap loops: Connect the strap loops to each side of the sling bar. Use the lift straps that lift the head and all the
lift straps that lift the body down to the hollow of the knees (3-4 pairs of straps is usual). Lifting with the lift straps under the
hollow of the knees can cause over-extension of the knee-joint. When it is also necessary to lift the calves, (for example when
transferring between two beds) particular care must be taken so that over-extension of the knee-joints does not occur.
Lifting: Lift so that the patient is free of the mattress and can be moved up to the desired position in the bed. During
repositioning, the caregivers should hold on to the sling bar and/or support the patient from the underneath. Do not pull the
lift straps! Lower, disconnect and smooth out the Solo RepoSheet accessory.
Alternative: In some cases, particularly if you want to lift the patient in as a straight position as possible, it may be better to
use Side Bars and distribute the strap loops on the Side Bar’s hooks instead, see the small illustration (although not during
the “turning” operation when only one side of the Solo RepoSheet accessory’s lift straps are carrying weight).
1
2
4
5
3
1. Strap loops
2. Product label
3. Caution label:
Do not wash
Positioning of Solo RepoSheet Short accessory
• A responsible person within your organization should decide on a
case-by-case basis whether one or more caregivers are needed.
• Plan the lifting operation before the lift to make it as safe and
convenient as possible.
• Before lifting, check that the lifting accessory hangs vertically and
can move freely.
• Although Liko’s sling bars are equipped with latches, special
caution must be exercised:
Before the patient is lifted from the underlying surface, but after the
straps have been fully extended, make sure the strap loops are
properly connected to the sling bar.
• Never lift a patient higher off the underlying surface than is needed
to complete the lifting and transfer procedure.
• Never leave a patient unattended during a lifting situation.
• The wheels on the bed must be locked during lifting/transfer
operation, the recommendation applies in particular when turning
patients.
• Put the bed rails up during turning, particularly if only one caregiver
carries out the procedure.
• Make sure that the RepoSheet accessory’s unconnected strap
loops do not become stuck, for example, in the bed during use.
• During transfers, the caregivers should hold on to the sling bar and/
or support the patient from underneath. Avoid pulling the lift straps
as that can damage the RepoSheet accessory.
SideBars

23www.hill-rom.com I www.liko.com
Solo RepoSheet™Short • 7EN161109 Rev. 3
Turning in bed
Turning a patient in bed can be done with the assistance of one person but we recommend that there are two caregivers
which is time saving and a comfortable way to work.
Use of bed rails is recommended, particularly in situations where only one caregiver is carrying out the procedure.
1. Before turning can take place
the patient must rst be moved to
one side of the bed. Connect the
necessary number of lift straps
according to the description at the
end of page 2.
Lift the patient high enough to clear
the bed surface.
2. Move the patient to one
side of the bed, lower onto
the mattress.
1. Disconnect the strap loops from the
side of the sling bar which is closest to
the middle of the bed. If Side Bars are
used, these should be removed.
Connect 3-4 strap loops to the hooks on
the sling bar when it is hanging parallel
to the bed.
2. Place the patient in such a way that turning is
made easy: arms over the side, one leg over the
other. Lift carefully so that the patient is turned
to the side with the help of the lift without tipping
forward.
3. Adjust the patient’s body position to one which is
comfortable and place pillows to support (behind the back,
between the knees, under the head). Lower the sling bar and
disconnect the strap loops. Smooth out the sheet.
Changing Solo RepoSheet accessory
The easiest way to change Solo RepoSheet accessory is to lift the patient in a Solo RepoSheet accessory while tting the
bed with a new one. After lowering, the rst sheet can be removed when the patient is turned to the side, preferable with the
assistance of the new RepoSheet accessory and the lift.
If Solo RepoSheet accessory is used for lifting further up in the bed it is practical to have two or more sheets to change
between.
When the patient is to be moved from the side position onto a supine position carry out the procedure in reverse order:
remove pillows, lower lift, connect the strap loops, lift and move the patient to the middle of the bed, etc.
Preparations for turning: Turning:
Alternative Areas of Use
Solo RepoSheet accessory in combination with Liko™FlexoStretch or Liko™
UltraStretch™accessory can be used for lifting and transferring a patient in a
horizontal position.The lift straps on the RepoSheet accessory’s head end is
connected to the hooks on the stretchers head end. The remaining lift straps
is distributed on the other hooks, see illustration.

Recommended combinations of Liko’s sling bars:
Name Model Prod. No. Dimensions Maximum load¹
Solo RepoSheet Short 36871003 180x110 cm (71x43 inch) 200 kg (440 lbs.)
Overview, Solo RepoSheet™Short accessory
Medical Device Class I Product
Material: 50 % cotton and 50 % polyester
Accessories: Universal SideBars, pair. Prod. No. 3156079
DO NOT WASH. The caution label situated on the back of the sheet displays the DO NOT WASH –symbol.
If the sheet is washed this label disintegrates to display the DO NOT USE –symbol. The sheet must then be disposed of.
Liko’s products undergo continuous development, which is why we reserve the right to make product changes without prior notice.
Contact your Hill-Rom representative for advice and information about product upgrades.
Design and Quality by Liko in Sweden
Liko is quality certied according to ISO 9001 and its equivalence for the medical device industry, ISO 13485.
Liko is also certied according to environmental standard ISO 14001.
Inspect the Solo RepoSheet accessory before each use. Pay special attention to wear and damage to seams, material/fabric,
straps and strap loops. During use, pay attention to that the RepoSheet accessory does not get stuck in equipment, which can
damage the sheet. Do not use damaged lifting accessories. If anything is unclear, please contact the manufacturer or supplier.
Care and Maintenance
Solo RepoSheet accessory is a disposable item that is intended for individual use only. Write the patient’s name on the product label
which is on the back side of the sheet.
Solo RepoSheet accessory should no longer be used:
• when it is soiled or if it is suspected of being contaminated
• if it is damaged
• when the patient no longer requires it.
Dispose of the Solo RepoSheet accessory accordance with hospitals or care facility regulations. Solo RepoSheet accessory can be
recycled by incinerating.
Explanation: 1 = Recommended, 2 = May work, 3 = Not advised, 4 = Inappropriate
Other Combinations
Combinations of accessories/products other than those recommended by Liko can result in risk for the safety of the patient.
¹ For retained maximum load, lift/accessories intended for the same load or more are required.
© Copyright Liko R&D AB 2018
Liko AB
Nedre vägen 100
SE-975 92 Luleå, Sweden
[phone]
www.hill-rom.com I www.liko.com
Liing and posioning when
turning in bed: Sling bar 350³ Sling bar 450⁴ Sling bar 600²
,
⁵
Solo RepoSheet Short 1
1
4
Liing and posioning
further up in bed: Universal 350¹ SlingGuard 350 Standard 450¹ Universal 450¹ SlingGuard 450 Universal 600¹ SlingGuard 600
Solo RepoSheet Short 1 1 1 1 1
1
1
¹ The recommendaon apply both with and without SideBars.
² We recommend sling bars with a maximum width of 450 mm (17.7 inch.). A sling bar which is too wide can damage the Solo RepoSheet accessory.
³ Sling bar 350 relates to Universal SlingBar 350 Prod. No. 3156074, 3156084, and 3156094, and also SlingGuard 350 Prod. No. 3308010 and 3308510.
⁴ Sling bar 450 relates to Universal SlingBar 450 Prod. No. 3156075, 3156085, and 3156095, and also SlingGuard 450 Prod. No. 3308020 and 3308520.
⁵ Sling bar 600 relates to Universal SlingBar 600 Prod. No. 3156076 and 3156086, and also SlingGuard 600 Prod. No. 3308030 and 3308530.
