In this document, the person being lied is referred to as the paent, and the person helping is referred to as the caregiver.
Product Descripon
Likorall™ 242/243/250
Overhead lis
Instrucons for Use
Likorall 242 S Prod. no. 3122009-3122010
Likorall 242 ES Prod. no. 3122005-3122006
Likorall 242 S R2R Prod. no. 3122011-3122012
Likorall 242 ES R2R Prod. no. 3122007-3122008
Likorall 243 ES Prod. no.3123001-3123002
Likorall 250 ES Prod. no. 3122501-3122502
Likorall 250 S, IRC Prod. no. 3124050
7EN120115 Rev. 11
ENGLISH 2020
Likorall overhead li is a general-purpose LikoTM li with the
intended use in: health care, intensive care and rehabilitaon.
Likorall overhead li is designed and developed for the complete
range of LikoTM xed installed and free-standing li systems. A
LikoTM li system is always close at hand and easy to use.
All common lis and transfers can be performed using Likorall
overhead li, for instance between bed/wheelchair, to/from oor,
toilet visits, gait training, and together with stretchers. Likorall R2R
(room to room) overhead li enables the paent to be moved
between two rail systems in separate rooms, without connecng
rails and without making holes over doors.
Likorall overhead li with the ES designaon is prepared for
operaon with the wireless HandControl Remote (IR) and in
addion, a Transfer Motor can be connected for motor driven
movement of Likorall ES overhead li along the rail. Likorall S,
IRC overhead li is prepared for connuous charging through
the railsystem by the LikoTM In-Rail charging system (IRC)
Accessories
A large and complete range of accessories are available for
Likorall overhead li, including many dierent sling models
in several sizes and designs.
IMPORTANT!
Liing and transferring a paent always involves a certain level of risk. Read the instrucons for use for both the paent
li and liing accessories before use. It is important to completely understand the contents of the instrucons for use.
The equipment should only be used by trained personnel. Ensure that the liing accessories are suitable for the li used.
Exercise care and cauon during use. As a caregiver, you are always responsible for the paent’s safety. You must be aware
of the paent’s ability to make it through the liing situaon. If something is unclear, contact the manufacturer or supplier.
Likorall 242
Likorall 242 R2R
Likorall 243, 250
All models

2
7EN120115 Rev. 11 • 2020 www.hillrom.com
Table of Contents
Symbol Descripon .......................................................................................................................... 3
Safety Instrucons ........................................................................................................................... 4
Denions ....................................................................................................................................... 5
Technical Data ................................................................................................................................. 5
Measurements ................................................................................................................................. 6
EMC Table ......................................................................................................................................... 6
Operaon ......................................................................................................................................... 9
Charging the Baeries .................................................................................................................. 12
Transferring from Room to Room ................................................................................................... 13
Maximum Load ............................................................................................................................... 14
Recommended Liing Accessories ................................................................................................. 14
Simple Troubleshoong .................................................................................................................. 16
Recycling Instrucons ..................................................................................................................... 17
Cleaning and Disinfecon .............................................................................................................. 18
Inspecon and Maintenance ......................................................................................................... 22

3www.hillrom.com
7EN120115 Rev. 11 • 2020
Symbol Descripon
These symbols can be found in this document and/or on the product.
Symbol Descripon
For indoor use only.
The product has extra protecon against electric shock (Insulaon Class II).
Protecon level against electric shock Type B.
Warning. Used were extra care and aenon is needed.
Read instrucons for use before use.
This product complies with EC direcves.
IP N1 N 2 Protecon level against: ingress of solid objects (N1) and ingress of water (N2).
Manufacturer.
Date of manufacture.
Cauon! consult instrucons for use.
Consult instrucons for use for more informaon.
Baery.
,
Pb
,
All baeries in this product must be recycled separately.
- Pb underneath the symbol indicate baeries containing lead
- Single Black line underneath the symbol indicate this product have been placed on the market aer 2005.
UL Recognized Component Mark for Canada and the United States.
EFUP, Environmental Friendly Usage Period (years).
Environmentally-friendly product which can be recycled and reused.
The Australian Safety/EMC.
PSE Mark (Japan).
Product Idener.
Serial Number.
Medical Device.
Recyclable.
The safety and essenal performance of medical electrical equipment.
Proof of Product compliance to North American safety standards.
Non-ionizing electromagnec radiaon.
X%
Y% ≤Tmin
Duty cycle for non-connuous operaon.
The maximum acve operaon me X% of any given me unit, followed by a deacvaon me, Y%.
The acve operaon me shall not exceed the specied me in minutes, T.
(01) 0100887761997127
(11) Y Y M M DD
(21) 012345678910
GS1 Data Matrix Barcode that may contain following informaon
(01) Global Trade Item Number
(11) Producon Date
(21) Serial Number

4
7EN120115 Rev. 11 • 2020 www.hillrom.com
Safety Instrucons
Intended Use
This product is not intended to be used by the paent alone. Liing and transferring a paent shall always be performed with
the assistance of at least one caregiver. This product is used as a means to perform the li but is not in contact with the paent;
therefore we do not go into the various paent condions in this manual. Contact your Hill-Rom representave for support and
advice.
Installaon of Likorall overhead li to carriages shall be made by personnel authorized by Hill-Rom in accordance with the
installaon instrucons and recommendaons for the current li system.
Before use, make sure that:
• the liing accessory is properly aached to the li
• the baeries have been charged for at least 8 hours
• you have read the instrucons for use for the li and liing accessories
• personnel using the li are informed of the correct operaon and use of the li
Before liing, always make sure that:
• the liing accessory is selected appropriately, in terms of type, size, material and design with regard to the paent’s needs.
• the li strap is not twisted or worn and can move in and out of the li freely
• the liing accessories are not damaged
• the liing accessory is correctly and safely applied to the paent in order to prevent injuries
• the liing accessory is properly aached to the li
• the liing accessory hang vercally and can move freely
• the latches are intact; missing or damaged latches must always be replaced
• the sling’s strap loops are correctly connected to the sling bar hooks when the sling straps are extended upwards, but before
the paent is lied from the underlying surface.
Incorrect aachment of sling to slingbar may cause Severe injury to the paent.
If the Likorall is installed in the S65 carriage with single hook, make sure it is resng securely at the boom of the hook
and is not lted.
Never leave a paent unaended during a liing situaon!
Likorall is tested by an accredited tesng instute.
No modicaon of this product is allowed.
Portable RF communicaons equipment (including peripherals such as antenna cables and external antennas) should be
used no closer than 30 cm (12 inches) to any part of the li, including cables specied by the manufacturer. Otherwise,
degradaon of the performance of this equipment could result.
Use of the product adjacent to other equipment should be avoided because it could result in improper operaon. If such
use is necessary, observe and verify that the other equipment is operang normally.
Electromagnec disturbance may aect the liing performance of the product. Modicaon using other parts than original
spare parts (cables, etc.) may aect the electromagnec compability of the product. Parcular care must be observed when
using strong sources of electromagnec disturbance, such as diathermy, etc, so that diathermy cables are not posioned on or
near the li.
If you have quesons, please consult the responsible assisve-device technician or the supplier.
The product may not be used in areas where ammable mixtures may occur, for example in areas where ammable goods are
stored.

5www.hillrom.com
7EN120115 Rev. 11 • 2020
Technical Data
Emergency lowering
device:
Mechanical: Likorall 242
Electrical: Likorall 242 R2R
Likorall 243
Likorall 250
Intermient
operaon:
Int. Op 10/90, acve operaon
max 30 Sec.
Sound level: 49 dB
Protecon class: IP 43
Protecon class
hand control:
IP 43
Operang forces
of controls:
5 N
Ambient
temperature:
Min. + 10°C - Max. + 50°C
(Min. 50° F - Max. 122° F)
Maximum
load:
LikorallTM 242: 200 kg (440 lbs)
LikorallTM 243: 230 kg (507 lbs)
LikorallTM 250: 250 kg (550 lbs)
Baeries: 2 x 12 V (2.4 Ah - 2.6 Ah). Valve-regulated lead-
acid gel-type baeries. New baeries
are provided by the supplier.
Baery
charger:
SMP CC-10-43-24; 100-240 V AC,
40-60 Hz, max 600 mA
IRC (In-Rail Charging): CH01 FW7218M/24;
100-240 V AC, 50-60 Hz, max 500 mA
Liing
speed:
50 mm/s (2 inch./s)
Liing
interval:
2050 mm (80.7 inch.)
(242 vercally adjustable)
Electrical
data:
24 V, 12 A
Li motor
weight:
Likorall 242 13.0 kg (28.6 lbs)
Likorall 242 R2R 13.2 kg (29 lbs)
Likorall 243 12.6 kg (27.7 lbs)
Likorall 250 12.6 kg (27.7 lbs)
The LikorallTM overhead li is equipped with a SFS (Single Fault Safety) safety drum. This patented safety design provides protecon
against uncontrolled lowering. The li strap has a tenfold safety.
Intended for indoor use.
Type B, in accordance with the
electrical shock protecon class.
Denions
1. Connecon: hand control
2. Indicaon: charging
3. End cover
4. Emergency stop
5. Emergency stop cord
6. Emergency lowering/raising (electrical)
7. Outlet for transfer motor/contact rail (exclusively: ES)
8. IR receiver (exclusively: ES)
9. SSP Limit Switch
10. Strap stop (exclusively: LikorallTM 242)
11. Movable strap stop (exclusively: LikorallTM 242)
12. Hang-up, HandControl Hanger
13. Mechanical emergency lowering (exclusively: Likorall 242)
14. Latches
15. Hand control with wire
16. Q-Link (not at LikorallTM 242)
17. Q-Link II
10
11
9
13
12
7
2
4
3
1
8
5
6
14
Likorall
16
15
17

6
7EN120115 Rev. 11 • 2020 www.hillrom.com
Guidance and manufacturer’s declaraon – electromagnec emissions
This product is intended for use in the electromagnecenvironment specied below. The customer or the user of this product
should assure that it is used in such an environment.
Emissions test Compliance Electromagnec environment - guidance
RF emissions
CISPR 11
Group 1 The product uses RF energy only for its internal
funcon
Therefore, its RF emissions are very low and are
not likely to cause any interference in nearby
eletronic equipment.
RF emissions
CISPR 11
Class B
The product is suitable for use in all establishments
other than domesc and those directly connected
to the public low-voltage power supply network
that supplies buildings used for domesc purposes.
Harmonic emissions
IEC 61000-3-2
Class A
Voltage uctuaons/ icker emissions
IEC 61000-3-3
Complies
EMC Table
Overhead view
Lateral view
C
A
B
H** D*
Ceiling
L***
CSP (Central Suspension Point)
* Minimum distance from ceiling to CSP at maximum liing height with the standard carriage.
** Built-in dimension: the distance between the aachment point for the li unit on the carriage and the CSP at maximum liing
height.
*** Liing interval: the distance between maximum liing height and minimum liing height measured in CSP.
Measurements in mm.
Measurements
Measurements in inch.
A B C D* H** L***
165 340 250 304 221
(models: 242 R2R, 243, 250)
346
(models: 242)
2050
A B C D* H** L***
6.5 13.4 9.8 12.0 8.7
(models: 242 R2R, 243, 250)
13.6
(models: 242)
80.7

7www.hillrom.com
7EN120115 Rev. 11 • 2020
Guidance and manufacturer’s declaraon – electromagnec immunity
The product is intended for use in the electromagnec environment specied below. The customer or the user of this product
should assure that it is used in such an environment.
Immunity test IEC 60601 test level Compliance level Electromagnec environment - guidance
Electrostac discharge
(ESD)
IEC 61000-4-2
+/- 6 kV contact
+/- 8 kV air
+/- 6 kV contact
+/- 8 kV air
Electrical fast transient
/ Burst
IEC 61000-4-4
+/- 2 kV for power supply
lines
+/- 1 kV for input/output
lines
+/- 2 kV for power supply
lines
n/a. for input/output
lines
Mains power quality should be that of a typical
commercial or hospital environment.
Surgew
IEC 61000-4-5
+/- 1 kV dierenal mode
+/- 2 kV common mode
+/- 1 kV dierenal mode
n/a. for common mode
Mains power quality should be that of a typical
commercial or hospital environment.
Voltage dips, short
interrupons and
voltage variaons
on power supply
input lines
IEC 61000-4-11
<5 % UT
(>95 % dip in UT)
for 0,5 cycle
40 % UT
(60 % dip in UT)
for 5 cycles
70 % UT
(30 % dip in UT)
for 25 cycles
<5 % UT
(>95 % dip in UT))
for 5 sec
Power frequency
(50/60 Hz) magnec
eld
IEC 61000-4-8
3 A/m 3 A/m Power frequency magnec elds should be at
levels characterisc of a typical locaon in a
typical commercial or hospital environment
Conducted RF
IEC 61000-4-6
3 Vrms
150 kHz to 80 MHz
3 Vrms
150 kHz to 80 MHz
Radiated RF
IEC 61000-4-3
10 V/m
80MHz to 2,5GHz
10 V/m
80MHz to 2,5GHz
NOTE UT is the a.c. mains voltage prior to applicaon of the test level.

8
7EN120115 Rev. 11 • 2020 www.hillrom.com
Guidance and manufacturer’s declaraon – electromagnec immunity
The product is intended for use in the electromagnetic environment specied below. The customer or the user of
this product should assure that it is used in such an environment.
Immunity test IEC 60601 test level Compliance
level
Electromagnec environment - guidance
Portable and mobile RF communicaons equipment should be
used no closer to any part of the product, including cables, than
the recommended separaon distance calculated from the
equaon applicable to the frequency of the transmier.
Conducted RF
IEC 61000-4-6
3 Vrms
150 kHz to 80 MHz
Recommended separaon distance
d P=035,
Radiated RF
IEC 61000-4-3
10 V/m
80MHz to 2,5GHz
d P=029,
80 MHz to 800 MHz
d P=058,
800 MHz to 2,5 GHz
where P is the maximum output power rang of the transmier
in was (W) according to the transmier manufacturer and d is
the recommended separaon distance in meters (m).
Field strengths from xed RF transmiers, as determined by an
electromagnec site survey, a should be less than the compliance
level in each frequency range. b
Interference may occur in the vicinity of equipment marked with
the following symbol.
NOTE 1 At 80MHz and 800MHz, the higher frequency range applies.
NOTE 2 These guidelines may not apply in all situaons. Electromagnec propagaon is aected by absorpon and reect-
ed from structures, objects and people.
a Field strengths from xed transmiers, such as base staons for radio (cellular/cordless) telephones and land mobile radios,
amateur radio, AM and FM radio broadcast and TV broadcast cannot be predicted theorecally with accuracy. To assess the
electromagnec environment due to xed RF transmiers, an electromagnec site survey should be considered. If the measured
eld strength in the locaon in which the product is used exceeds the applicable RF compliance level above, the product should be
observed to verify normal operaon. If abnormal performance is observed, addional measures may be necessary, such as
reorienng or relocang the product.
b Over the frequency range 150 kHz to 80 MHz, eld strengths should be less than 10 V/m.

9www.hillrom.com
7EN120115 Rev. 11 • 2020
Operaon
Hand Control LikorallTM Overhead Li
LikorallTM overhead li is operated with a light push on the buons of the hand control. The arrow direcons should be the
same as the direcon shown in the illustraon. The movement ceases when the buon is released. For the LikorallTM ES
overhead li, there is a number of hand controls to choose from, depending on how the li and rail system are equipped, and
an IR hand control for wireless operaon.
If needed, the liing moon can also be controlled without hand control via the buons and respecvely, on the end
cover of the li, see illustraon below.
Liing accessory with quick-release hook (Likorall: 242 R2R, 243 ES, 250 ES)
Push down the catch and connect the quick-release hook to the Q-Link II or Q-Link. Release
and check that the catch locks in order to prevent involuntary unhooking from the Q-Link II
or Q-Link. Read more about the Liko
TM
Quick-release Hook system in chapter "Recommended
Liing Accessories".
Emergency stop
For emergency stop: pull the red emergency stop cord.
To reset: turn the buon in the direcon of the arrows.
The red cord on the li motor´s end cover is intended for use if an emergency situaon occurs.
Before liing check that the
Quick-release Hook is correctly
aached to the Q-Link II or
Q-Link, see illustraon above.
Liing movement: Up/Down
Movement direcon: Transfer motor
Control: Switch system
Buon funcons:
HandControl
Remote IR
Fits Likorall: All (ES) (ES) (ES) (ES)
Reset:
Acvate:
Quick
Release Hook
Q-Link II or Q-Link

10
7EN120115 Rev. 11 • 2020 www.hillrom.com
Mechanical emergency lowering (LikorallTM 242 S/
ES)
1) Move the emergency lowering handle up and
down unl the paent has been lowered and the
li strap is completely slack. Always ensure that
the emergency lowering is made to a bed, wheel-
chair or other suitable locaon.
2) Aer mechanical emergency lowering has been
performed, reseng/adjustment of the liing
height is required:
- Lower the sling bar so that the li strap is
completely slack.
- Hold down the emergency lowering handle
halfway. Simultaneously, ghten the li strap by
turning the black wheel counter clockwise with
the other hand. Repeat unl the desired height
has been achieved.
Li correctly!
Before each li, make sure that:
– the Sling loops at opposite sides of the Sling are at the same height
– all the Sling loops are fastened securely in to the Slingbar hooks
– the Slingbar is level during the li, see Figure 1.
If Slingbar is not level (see Figure 2) or if the sling loop(s) is(are)
wrongly aached to the slingbar (see Figure 3) lower the user to a
rm surface and adjust according to the Instrucons for use of Sling
in use.
An improper li can be uncomfortable for the user and cause
damage to the li equipment! (see Figure 2 and gure 3).
Carriages with adjustable fricon brake
The amount of drag along the rail can be
adjusted on carriages equipped with a fricon
brake. Turn the brake clockwise for increased
resistance and counter clockwise to reduce
resistance.
The following carriages have a fricon brake:
prod. no. 3126011 and 3126015.
Hang-up HandControl Hanger
When not in use, the hand
control can be hung on the
Hang-up Hand control hanger.
Electrical emergency lowering
Emergency lower by pushing in the
buon on the end cover of the li.
Always ensure that the emergency
lowering is made to
a bed, wheelchair or other suitable
locaon.
Figure 1. Figure 2. Figure 3.
1. 2.
