Liko SCALUP-V4-160KG User manual

The Scal’Up scale is a convenient, easy-to-use scale that is intended for weighing paents in Liko mobile or staonary lis.
Together with Liko’s lis and liing accessories, the Scal’Up scale enables safe and easy weighing.
The weight is shown on the scale’s digital display in kg.
The Scal’Up scale is cered according to the European direcve NAWI 2014/31/EU (Non Automac Weighing Instruments).
The scale should only be used in combinaon with approved lis and accessories in accordance with the instrucons in this
guide.
* This user guide is a complement to the complete documentaon issued by the manufacturer of the scale.
The intenon with this document is to make it easier for our customers to use the Scal’Up scale in combinaon with Liko’s
products. For detailed informaon regarding the scale we refer to the manufacturer’s instrucon guide (aached).
The Scal’Up scale can be used with the following Liko lis:
Likorall™ overhead li (all models)
Mulrall™overhead li
Viking™mobile li (S, M, L, XL)
Uno™ mobile li (all models)
Golvo™mobile li (all models)
The Scal’Up scale cannot be used with Standard SlingBar.
Balea Scal’Up®
Scale
User Guide*
Scal’Up 160 kg Prod. No. SCALUP-V4-160KG
Scal’Up 175 kg Prod. No. SCALUP-V4-175KG
Scal’Up 200 kg Prod. No. SCALUP-V4-200KG
Scal’Up 230 kg Prod. No. SCALUP-V4-230KG
Scal’Up 250 kg Prod. No. SCALUP-V4-250KG
Scal’Up 300 kg Prod. No. SCALUP-V4-300KG
7EN161114 Rev. 2
ENGLISH

Balea Scal’Up®scale • 7EN161114 Rev 2 2www.hill-rom.com I www.liko.com
Before assembly, make sure you have the following:
• 2 screws, 2 locking nuts • Instrucon Guide from manufacturer
• Baery • Declaraon of Conformity
• User Guide from Liko • Metrological notebook
The Scal’Up scale s is delivered with a 9 V baery. For installing/replacing of baery, see manufacturer’s instrucon guide.
NOTE! Old baeries should be le at the nearest recycling staon.
Assembly Instrucons
Installing/replacing the baery
Follow the assembly instrucons for the appropriate li, aachment point, and sling bar.
Viking™ mobile li, Uno™ mobile li: Quick-release assembly
Liko lis equipped with (Q-Link) quick fastener require Quick-Release Hook Universal Prod. No. 3156508,
Adapter 8 mm Prod. No. 2016502 and Adapter 22 Prod. No. 3156505.
1. Remove the liing accessory from the li.
2. Mount the Quick-Release Hook Universal and Adapter 8 mm,
in accordance with the assembly instrucons, on to the scale’s
upper aachment point.
3. Mount the Adapter 22 to the scale’s lower aachment point,
using bolt and nut provided.
4. Aach the scale on to the li.
5. Aach the liing accessory under the scale.
The Balea Scal’Up scale is not recommended to be used with
xed assembly on Viking™ mobile li and Uno™ mobile li.
Likorall™ overhead li, Golvo™ mobile li: Fixed assembly
1. Remove the liing accessory from the li.
2. Mount the liing accessory to the scale’s lower aachment point,
using bolt and locking nut provided.
3. Mount the scale on to the li, using bolt and locking nut provided.

Balea Scal’Up®scale • 7EN161114 Rev 2 3www.hill-rom.com I www.liko.com
The normal range for operaon of the Scal’Up scale is a temperature between +10°C and +40°C at a relave humidity not
exceeding 80 %.
The scale must not be stored at temperatures below -10°C or above +40°C.
Before weighing, ensure the scale has been installed in accordance with the Assembly Instrucons on pages 2-3.
Before liing, check that the liing accessory is hanging vercally and can move freely.
Operaon
Mulrall™ overhead li, Likorall™ overhead li, Golvo™ mobile li: Quick-release assembly
Liko lis equipped with (Q-Link) quick fastener require Quick-Release Hook Universal Prod. No. 3156508,
Adapter 8 mm Prod. No. 2016502 and Adapter 22 Prod. No. 3156505.
1. Remove the liing accessory from the li
2. Mount the Quick-Release Hook Universal and Adapter 8 mm,
in accordance with the assembly instrucons, on to the scale’s
upper aachment point.
3. Mount the Adapter 22 to the scale’s lower aachment point,
using bolt and nut provided.
4. Aach the scale on to the li.
5. Aach the liing accessory under the scale.
Weighing with the Balea Scal’Up scale
The scale can be reset to zero with or without the sling. If the scale is reset to zero without the sling aached to the sling bar,
the weight of the paent will include the weight of the sling. Therefore the weight of the sling must be subtracted to obtain
the correct weight of the paent.
Reseng the scale with the sling is described below:
1. Connect the sling to the sling bar.
2. Start the scale by pressing the buon.
3. Reset the scale by pressing the 0/T buon.
4. Remove the sling from the sling bar and apply the sling to the paent in accordance with the instrucon guide for the sling
and li. Connect the sling to the sling bar.
5. Raise the sling bar so the paent rises slightly. Never li a paent higher than necessary.
6. When the liing moon has stabilized you can read the paent’s weight on the display.
7. Lower the paent carefully and remove the sling from the sling bar.
8. Press the buon a few seconds to turn o the scale. The scale turns o automacally aer 5 minutes of inacvity.
Calibraon
For calibraon, see manufacturer’s instrucon guide or contact Hill-Rom.

© Copyright Liko R&D AB 2017
Distributor:
Liko AB
Nedre vägen 100
SE-975 92 Luleå, Sweden
Manufacturer:
Balea
8, avenue du Grand Chene
F-34270 Saint-Mathieu-de-Tréviers, France
www.hill-rom.com I www.liko.com
Maximum Load
The Scal’Up® scale must have a maximum capacity less than or equal to the li unit’s maximum capacity.
Example:
A li unit that is approved for 200 kg must be used together with a scale that is approved for at most a maximum load of 200 kg.
A li unit that is approved for 205 kg must be used together with a scale that is approved for at most a maximum load of 200 kg.
For the assembled li unit, including accessories, the maximum load is always the lowest maximum load rang for any of the
components.
Study the markings on the li and liing accessories or contact your Hill-Rom representave if you have any quesons.
Technical Data
Accuracy class: Class III according to the requirements of the NAWI 2014/31/EU Direcve.
Readout: Sensive to 0.1 kg
Tolerance: 2-50 kg ± 0.05 kg
50-200 kg ± 0.1 kg
200-300 kg ± 0.15 kg
Max. load: 160 kg/175 kg/200 kg/230 kg/250 kg/300 kg
Min. load: 2 kg
Reset: One buon reset ( 0/T )
Power supply: Baery 9 V
Baery: 9 V Alkaline (PP3, MN1604, 6LR61, E-block).
Baery life: 6 months
Display: Digital, liquid crystal (LCD)
Size: 173 x 60 x 100 mm (L x W x H)
Weight: 0.9 kg
Temperature range: +10o C to +40o C
Humidity range: 0 % - 80 %
