LIVARNO LUX 298829 User manual

LED SENSOR LIGHT
IAN 298829
LED-SENSORLEUCHTE
Bedienungs- und Sicherheitshinweise
LED SENZOROVÉ SVIETIDLO
Pokyny pre obsluhu a bezpečnostné pokyny
LED-SVETILKA S SENZORJEM
Navodila za upravljanje in
varnostna opozorila
LED SENZOROVÉ SVÍTIDLO
Pokyny pro obsluhu a bezpečnostní pokyny
LED SENSOR LIGHT
Operation and Safety Notes
SZENZOROS LED LÁMPA
Kezelési és biztonsági utalások

GB Operation and Safety Notes Page 5
HU Kezelési és biztonsági utalások Oldal 17
SI Navodila za upravljanje in varnostna opozorila Stran 29
CZ Pokyny pro obsluhu a bezpečnostní pokyny Strana 42
SK Pokyny pre obsluhu a bezpečnostné pokyny Strana 53
DE/AT/CH Bedienungs- und Sicherheitshinweise Seite 65

A
4
4
1
3
1
3
2
2
2

B
1514
17
16
12 13
C
1514
12
13
17
7

5GB
List of pictograms used.............................. Page 6
Introduction......................................................... Page 6
Intended use.............................................................. Page 7
Description of parts................................................... Page 7
Scope of delivery...................................................... Page 8
Technical data........................................................... Page 8
General safety instructions.................... Page 8
Safety instructions for batteries/
rechargeable batteries.............................................. Page 9
Before use............................................................. Page 11
Inserting/ changing batteries ................................... Page 11
Install the ground spike bracket ............................... Page 12
Install the wall bracket.............................................. Page 12
Mounting the product............................................... Page 13
Setting up the product............................................... Page 13
Start of operation .......................................... Page 14
Cleaning and care.......................................... Page 14
Disposal.................................................................. Page 14
Warranty............................................................... Page 15

6 GB
List of pictograms used
Direct current (Type of current and voltage)
splashproof
Detection angle: 80°–100°
Detection range: approx. 3m
Battery
LED sensor light
Introduction
We congratulate you on the purchase of your new product.
You have chosen a high quality product. The instructions for
use are part of the product. They contain important information
concerning safety, use and disposal. Before using the product,
please familiarise yourself with all of the safety information
and instructions for use. Only use the product as described
and for the specified applications. If you pass the product on
to anyone else, please ensure that you also pass on all the
documentation with it.

7GB
Intended use
The product is only intended for use in private households.
This product is designed for indoor and outdoor use. The
product is not intended for commercial use or for use in other
applications.
Not suitable for household room illumination.
This product is suitable for extreme temperature
up to -21°C.
Description of parts
1Battery compartment cover
2Screws
3Batteries
4Battery compartment
5Mounting screws
6Dowels (Ø 6mm)
7Wall bracket
8Caps
9Light
10 Sensor
11 Ground spike
12 Screw
13 Teeth washer
14 Washer
15 Nuts
16 Ground spike bracket
17 Bracket holder

8 GB
Scope of delivery
1 LED Sensor light
6 Batteries, 1.5V AAA
2 Dowels (Ø 6mm)
2 Mounting screws
2 Caps
1 Ground spike
1 Instructions for assembly and use
Technical data
Illuminant: 6 LEDs, max. 0.06W per LED
Detection range: approx. 3m
Detection angle: approx. 80°–100°
Light on time: approx. 45s
Battery: 6 x 1.5V , AAA
Protection class: IP54 (splashproof)
LED lifespan: 20,000 hours
General safety instructions
KEEP ALL THE SAFETY ADVICE AND INSTRUCTIONS IN
A SAFE PLACE FOR FUTURE REFERENCE!
This is not a toy.
This product can be used by children aged from
8 years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience and

9GB
knowledge if they have been given supervision or instruction
concerning use of the product in a safe way and under-
stand the hazards involved. Children shall not play with
the product. Cleaning and user maintenance shall not be
made by children without supervision.
Electrostatic discharges may cause malfunctions. In the
event of such malfunctions, remove the batteries briefly
and reinsert them.
CAUTION! RISK OF INJURY! Please do not use this
product if you find that it is damaged in any way.
Never cover the product when it is in operation.
This product does not contain any parts that need to be
maintained by the user. The LED cannot be replaced.
The LEDs are not replaceable.
If the LEDs fail at the end of their lives, the product must
be replaced.
Never open one of the products of electrical equipment or
insert any objects into them.
For garden use:
When the product is not in use, the ground spike 11
should also be removed to avoid any risk, for example,
stumbling.
Safety instructions for batteries/
rechargeable batteries
DANGER TO LIFE! Keep batteries/rechargeable bat-
teries out of reach of children. If accidentally swallowed
seek immediate medical attention.

10 GB
DANGER OF EXPLOSION! Never recharge
non-rechargeable batteries. Do not short-circuit
batteries/rechargeable batteries and/or open
them. Overheating, fire or bursting can be the result.
Never throw batteries/rechargeable batteries into fire or
water.
Do not exert mechanical loads to batteries / rechargeable
batteries.
Risk of leakage of batteries/rechargeable batteries
Avoid extreme environmental conditions and temperatures,
which could affect batteries/rechargeable batteries, e.g.
radiators/direct sunlight.
If batteries/rechargeable batteries have leaked, avoid
contact with skin, eyes and mucous membranes with the
chemicals! Flush immediately the affected areas with fresh
water and seek medical attention!
WEAR PROTECTIVE GLOVES! Leaked or
damaged batteries/rechargeable batteries
can cause burns on contact with the skin. Wear
suitable protective gloves at all times if such an event occurs.
In the event of a leakage of batteries/rechargeable bat-
teries, immediately remove them from the product to prevent
damage.
Only use the same type of batteries/rechargeable batteries.
Do not mix used and new batteries/rechargeable batteries.
Remove batteries/ rechargeable batteries if the product
will not be used for a longer period.

11GB
Risk of damage of the product
Only use the specified type of battery/rechargeable battery!
Insert batteries/ rechargeable batteries according to po-
larity marks (+) and (-) on the battery/ rechargeable bat-
tery and the product.
Clean the contacts on the battery/rechargeable battery
and in the battery compartment before inserting!
Remove exhausted batteries/ rechargeable batteries from
the product immediately.
Before use
Note: Remove all packaging materials from the product.
Inserting/changing batteries
(see Fig. A)
Open the battery compartment 4on the back side of
the product by loosening the screws 2anti-clockwise
with a cross type screw driver.
Open the battery compartment cover 1.
Insert the batteries 3. Only use batteries of the specified
type (see “Technical data”).
Note: When inserting the batteries 3ensure the correct
polarity! This is indicated in the battery compartment 4.
Close the battery compartment 4again with the battery
compartment cover 1.
Make sure the narrow of symbol and marked on
cover and enclosure face to each other, which means
cover is place at a correct position.

12 GB
Fix the cover by screwing the screws 2tightly in clock-
wise direction.
Install the ground spike bracket
Screw-out the screw 12 (see Fig. C)
Take out the teeth washer 13 , washer 14 , nuts 15 and wall
bracket 7(see Fig. C)
Insert the teeth washer
13
to the bracket holder
17
(see Fig. B)
Place the ground spike bracket 16 to bracket holder 17
(see Fig. B)
Place the washer 14 between the ground spike bracket 16
and bracket holder 17 (see Fig. B)
Place the nuts 15 to the bracket holder 17 (see Fig. B)
Screw-in the screw 12 to the bracket holder 17 (see Fig. B)
Install the wall bracket
Screw-out the screw 12 (see Fig. B)
Take out the teeth washer 13 , washer 14 , nuts 15 , ground
spike bracket 16 (see Fig. B) and ground spike 11 (see Fig. D)
Insert the teeth washer 13 to the bracket holder 17 (see
Fig. C)
Place the wall bracket 7to bracket holder 17 (see Fig. C)
Place the washer 14 between the wall bracket 7and bra-
cket holder 17 (see Fig. C)
Place the nuts 15 to the bracket holder 17 (see Fig. C)
Screw-in the screw 12 to the bracket holder 17 (see Fig. C)

13GB
Mounting the product
For wall mount use (see Fig. D):
Note: You will need an electric drill to install the product.
CAUTION! RISK OF INJURY! Refer to the operating
instructions for your electric drill.
CAUTION! Ensure that you do not damage any cables in the
wall.
Use the round holes of the wall bracket 7intended for
the mounting screws 5to mark the holes for drilling.
Now drill the mounting holes.
Insert the dowels 6into the drilled holes.
Fix the wall bracket
7
using the included mounting screws
5
.
Press the caps 8on the screws.
Your product is now ready for use.
Setting up the product
For garden use (see Fig. D):
Insert the ground spike 11 to the light 9. Ensure the
product is correctly seated.
Your product is now ready for use.
Insert the product far enough into the ground (lawn,
flower bed) for it to be stable.
Make sure you keep proper footing and balance at all
times. Do not use any force when assembling or setting-up
the product, e.g. hammer blows. This will damage the
product.

14 GB
Start of operation
The product will automatically switch on when motion is
detected in a dark environment.
The product will automatically switch off when motion is
no longer detected for a period of time.
Cleaning and care
Clean the product regularly with a dry, lint-free cloth.
Use a slightly dampened cloth to remove more stubborn
dirt.
Disposal
The packaging is made entirely of recyclable materials, which
you may dispose of at local recycling facilities.
b
a
Observe the marking of the packaging materials
for waste separation, which are marked with abbre-
viations (a) and numbers (b) with following meaning:
1–7: plastics/ 20–22: paper and fibreboard/
80–98: composite materials.
The product and packaging materials are recycla-
ble, dispose of it separately for better waste treat-
ment. The Triman logo is valid in France only.
Contact your local refuse disposal authority for
more details of how to dispose of your worn-out
product.

15GB
To help protect the environment, please dispose of
the product properly when it has reached the end
of its useful life and not in the household waste.
Information on collection points and their opening
hours can be obtained from your local authority.
Faulty or used batteries must be recycled in accordance with
Directive 2006/66/EC and its amendments. Please return the
batteries and/or the product to the available collection points.
Environmental damage through incorrect
disposal of the batteries!
Batteries may not be disposed of with the usual domestic waste.
They may contain toxic heavy metals and are subject to
hazardous waste treatment rules and regulations. The chemical
symbols for heavy metals are as follows: Cd = cadmium,
Hg = mercury, Pb = lead. That is why you should dispose of
used batteries at a local collection point.
Warranty
The product has been manufactured to strict quality guidelines
and meticulously examined before delivery. In the event of
product defects you have legal rights against the retailer of
this product. Your legal rights are not limited in any way by
our warranty detailed below.
The warranty for this product is 3 years from the date of
purchase. Should this product show any fault in materials or
manufacture within 3 years from the date of purchase, we will
repair or replace it – at our choice – free of charge to you.

16 GB
The warranty period begins on the date of purchase. Please
keep the original sales receipt in a safe location. This docu-
ment is required as your proof of purchase. This warranty be-
comes void if the product has been damaged, or used or
maintained improperly.
The warranty applies to defects in material or manufacture.
This warranty does not cover product parts subject to normal
wear, thus possibly considered consumables (e.g. batteries) or
for damage to fragile parts, e.g. switches, rechargeable batte-
ries or glass parts.

17HU
Az alkalmazott piktogramok
jelmagyarázata..............................................Oldal 18
Bevezető...............................................................Oldal 18
Rendeltetésszerű használat .....................................Oldal 19
Alkatrészleírás..........................................................Oldal 19
A csomag tartalma...................................................Oldal 20
Műszaki adatok .......................................................Oldal 20
Általános biztonsági utasítások.......Oldal 20
Az elemekre/akkukra vonatkozó
biztonsági tudnivalók...............................................Oldal 21
Az üzembe helyezés előtt......................Oldal 23
Elemek behelyezése/ cseréje..................................Oldal 23
A talajnyárstartó összeszerelése.............................Oldal 24
A falitartó felszerelése .............................................Oldal 24
A termék rögzítése...................................................Oldal 24
A termék felállítása ..................................................Oldal 25
Üzembe helyezés..........................................Oldal 25
Tisztítás és ápolás.........................................Oldal 26
Mentesítés ...........................................................Oldal 26
Garancia...............................................................Oldal 27

18 HU
Az alkalmazott piktogramok jelmagyarázata
Egyenáram (áram- és feszültségnem)
Fröccsenő víztől védett
Hatószög: 80°–100°
Hatóterület: kb. 3m
Elem
Szenzoros LED lámpa
Bevezető
Gratulálunk új termékének vásárlása alkalmából. Ezzel a
döntésével vállalatunk értékes terméke mellett döntött. A hasz-
nálati utasítás ezen termék része. A biztonságra, a használa-
tára és a megsemmisítésre vonatkozó fontos tudnivalókat
tartalmazza. A termék használata előtt ismerje meg az összes
használati és biztonsági tudnivalót. A terméket csak a leírtak
szerint és a megadott felhasználási területeken alkalmazza.
A termék harmadik személy számára való továbbadása ese-
tén kézbesítse vele annak a teljes dokumentációját is.

19HU
Rendeltetésszerű használat
A termék csak magánháztartásokban való használatra
készült. A termék bel- és külterületeken történő alkalmazásra
készült. A terméket nem közületi felhasználásra, vagy egyéb
alkalmazásra szánták.
Ez a termék nem alkalmas arra, hogy háztartá-
sok központi fényforrásaként szolgáljon.
Ez a termék -21°C-ig extrém hőmrséklethez is megfelelő.
Alkatrészleírás
1Elemrekesz-fedél
2Csavarok
3Elemek
4Elemrekesz
5Rögzítőcsavarok
6Tipli (Ø 6mm)
7Fali rögzítés
8Zárókupakok
9Lámpa
10 Érzékelő
11 Talajnyárs
12 Csavar
13 Fogastárcsa
14 Alátétlemez
15 Anya
16 Talajnyárstartó
17 Tartó

20 HU
A csomag tartalma
1 szenzoros LED lámpa
6 elem, 1,5V AAA
2 tipli (Ø 6mm)
2 rögzítőcsavar
2 zárókupak
1 talajnyárs
1 szerelési és kezelési útmutató
Műszaki adatok
Izzó: 6 LED, max. 0,06W LED-enként
Érzékelési tartomány: kb. 3m
Érzékelési szög: kb. 80°–100°
Világítási időtartam: kb. 45 mp
Elem: 6 x 1,5V AAA
Védelmi jelleg: IP54 (fröccsenő vízzel szemben védett)
LED-élettartam: 20.000 óra
Általános biztonsági utasítások
ŐRIZZEN MEG MINDEN BIZTONSÁGI TUDNIVALÓT ÉS
UTASÍTÁST A JÖVŐBENI FELHASZNÁLÁS CÉLJÁBÓL!
A termék nem játékszer.
A terméket 8 éves kor feletti gyermekek, valamint korlátozott
fizikai, érzékszervi vagy szellemi képességgel élő vagy
nem megfelelő tapasztalattal és tudással rendelkező
