LOCKLY GUARD DEFENDER SLIDE EDITION User manual

DEFENDER
INSTALLATION
GUIDE
WWW.LOCKLYPRO.COM
PGD238F
FOR COMMERCIAL USE & PROFESSIONAL INSTALLATION
SLIDE EDITION (238SL)

3
Prepare door: remove existing deadbolt or use provided template to bore new holes.
Preparation
Ø1-11/32"(34mm)
Door Handle Hole
Baseline approximately 1
meter from the ground
Installation template

4
DETERMINE DOOR OPENING DIRECTION
Step 1
There are 4 common door-opening directions, the lockset configuration as shown on
each diagram below corresponds to the respective door-opening direction.
This lock is designed for 35-65mm Wooden or Aluminium Door or Aluminium
Thermal Barrier Door. If your door is outside the range of the list above please
contact our Customer hotline: [phone]
Before installing the exterior assembly, make sure you have already adjusted
your door handle (Step 2) and identified the latch throw orientation
according to door opening direction.
IMPORTANT
LEFT OUT-SWING DOOR
Inside
Outside
Make sure the latch throw is
correctly oriented as shown
to fit your left out-swing door
LEFT IN-SWING DOOR
Inside
Outside
Make sure the latch throw is
correctly oriented as shown
to fit your left in-swing door
RIGHT OUT-SWING DOOR
Inside
Outside
Make sure the latch throw is
correctly oriented as shown
to fit your right out-swing door
RIGHT IN-SWING DOOR
Inside
Outside
Make sure the latch throw is
correctly oriented as shown
to fit your right in-swing door

5
CHANGING HANDLE FOR RIGHT OR LEFT SWING DOORS
Step 2
The diagram below shows how to shift the door handle from right to left direction.
The default setting of the handle is for right handed door. You do not need to
change direction if you have a right handed door.
Use an Allen wrench to
tighen
two screws by
turning counterclock-
wise until completely
flushed
Take out the handle, then
rotate 180° to shift handle
to the left
Use allen wrench to loosen screws on both sides on the handle base.
Change the handle direction of the Exterior Assembly
3
1
2
Turn clockwise
to loosen

6
Make sure your door is prepared for installation. If you need to drill new holes, please
use the supplied template for drilling holes. Before installing the Lockset , confirm the
door opening direction (Step 1) and ensure latch throw is on correctly oriented to the
door’s opening direction.
INSTALLING THE LOCKSET
Step 3
Insert Lockset onto door hole and secure with screws (top and bottom) .
Lockset adapter is included with your
interior door handle.
The adapter is
installed according to the left or right
door direction. Install the adapter
according
to the user manual of
your interior
handle.
The Lockset adapter must
be installed according to
the left or right door
opening direction. Install it
on the door exterior.
If you are installing for a left
door, use the lockset
adapter F. If you are
installing for a right door,
lockset adapter F1.
Ø1-11/32"(34mm)
Door Handle Hole
Baseline approximately 1
meter from the ground
Installation template

7
Tighten screw clockwise and
ensure it sits on the V-shaped
groove of the lockset
assembly.
Exterior
Ensure the hole for spindle
stays in this position during
installation.
1
2
INSTALLING THE LOCKSET
Step 3 continued

8
Interior
Tighten screw clockwise and ensure it sits on the
V-shaped groove of the lockset assembly.
Note: Lockset adapter is a part included with your
interior door handle.
Check interior door handle
installation instructions and install accordingly.
Install faceplate S and secure with
screws.
1
2
INSTALLING THE LOCKSET
Step 3 continued

K
INSTALLING THE EXTERIOR AND INTERIOR ASSEMBLY
Step 4
9
Install top mounting block. Remove the
adhesive tape at the back of Bluetooth
receiver (L) and install under mounting
block. Mount the (K) on the groove of the
top block to secure the Bluetooth receiv-
er.
3
Install the exterior assembly onto the door. Make sure the spindle, cables and rods
are routed correctly through the holes in the door. Install top and bottom mount-
ing blocks and secure with scews.
1
Connect Bluetooth receiver
Rotate plugs to tighten cable
connection.
2
L
L

10
I
To complete installation, install
door interior handle according
to the user manual of your interior
door handle
FINAL CHECK AND BATTERY INSTALLATION
Step 5
Use a screwdriver to loosen the battery cover screw then open battery compart-
ment.
Unplug the terminals of the battery box and install the battery.
Reconnect the battery box to terminals, insert to compartment and return the
cover.
Tighten the battery screw Jto secure battery cover, then install Bottom Screw
Cover (I) to conceal bottom screws
1
2
3
3
4

Congratulations! You have completed the Lockly Guard physical lock installa-
tion. To complete your setup, download the LocklyPro app from the iOS or Google
Play app Store
and follow on-screen instructions.
Scan or visit
Locklypro.com/app
DOWNLOAD LOCKLYPRO APP
Step 6
PRO
11

FCC Warning：
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device
must accept
any interference received, including interference that may cause undesired operation.
NOTE 1: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protec-
tion against harmful interference in a residential installation. This
equipment generates, uses
and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more
of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
- Consult the dealer or an experienced radio/TV technician for help.
NOTE 2: Any changes or modifications to this unit not expressly approved by the party responsible
for compliance could void the user's authority to operate the equipment.
FCC Radiation Exposure Statement
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment. It should be installed and operated with minimum distance 20cm between the
radiator & your body.
IC WARNING
This device contains licence-exempt transmitter(s) that comply with Innovation, Science
and
Economic Development Canada’s licence-exempt RSS(s). Operation is subject to
the following
two conditions:
(1) This device may not cause interference.
(2) This device must accept any interference, including interference that may cause undesired
operation of the device.
L’émetteur/récepteur exempt de licence contenu dans le présent appareil est conforme aux
CNR d’Innovation, Sciences et Développement économique Canada applicables aux
appareils
radio exempts de licence. L’exploitation est autorisée aux deux conditions suivantes:
1. L’appareil ne doit pas produire de brouillage;
2. L’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est suscepti-
ble d’en compromettre le fonctionnement.
IC Radiation Exposure Statement
This equipment meets the exemption from the routine evaluation limits in section 2.5 of RSS-102. It
should be installed and operated with a minimum distance of 20cm between the radiator and
any part of your body.
Cet équipement est conforme à l'exemption des limites d'évaluation habituelle de la section 2.5
de la norme RSS-102. Il doit être installé et utilisé à une distance minimale de 20 cm entre le
radiateur et toute partie de votre corps
WARNING: This product can expose you to chemicals including Lead, which is known to the
State of California to cause cancer. For more information go to www.P65Warnings.ca.gov.

LOCKLYPRO.COM | HOTLINE: [phone] | EMAIL: [email protected]
ACC20220326
KEEP THIS CARD!
ACTIVATION CARD
LOCK SERIAL
ACTIVATION CODE
PGDxxxxxxxxxx
xxxxxxxx SCAN & SAVE
INSTALLATION OVERVIEW AND PARTS LIST
Parts List
Labeled As
F
E
A
B
C
D
Description
Lockset Adapter (Left)
F1 Lockset Adaptet (Right)
Battery Cover
Front Panel
Touchscreen Cover
Battery Box
Keys (x2)
G
H
J
K
Mounting Block (x2)
Mounting Screw
IBottom Screw Cover
Battery Cover Screw
Bluetooth Mounting Plate
LBluetooth Receiver
M
N
O
P
Q
R
RFID Card（x3）
Allen Wrench (x1)
Activation Card
Door Sensor Magnet
Door Sensor
Link Plus
E
G
H
IJ
K
LC
B
F1
A
D
O
M
N
0004001 1341652
P
Q
R
SFaceplate( not included ）
S

INSTALLATION OVERVIEW AND PARTS LIST
K
Bluetooth
Mounting Plate
(x1)
F
Lockset Adapter
Left (x1)
M
Allen Wrench (x1)
H
KM5x30mm (x4)
Escutcheon Screw
L
Bluetooth
Receiver (x1)
C
Key (x2)
F1
Lockset Adapter
Right (x1)
Bottom Screw
Cover (x1)
I
Mounting Block
(x2)
G

FOR COMMERCIAL USE & PROFESSIONAL INSTALLATION
MPGD23820220916
We’re here to help!
[email protected]
locklypro.com/support
