LUCCI Air Airfusion Akmani Series Guide

Akmani fan-V2.0-2014-08-15
LUCCI
AIRFUSION AKMANI
DC CEILING FAN
INSTALLATION
OPERATION
MAINTENANCE
WARRANTY INFORMATION
CAUTION
READ INSTRUCTIONS CAREFULLY FOR SAFE
INSTALLATION AND FAN OPERATION.

Airfusion Akmani Installation Instructions
1 | P a g e
CONTENTS
GB
Installation Instruction Manual .......................................................................................... 2
D
Installationsanleitung ........................................................................................................11
F
Guide d’installation............................................................................................................18
E
Manual de instrucciones de instalación.............................................................................26
I
Manuale delle istruzioni di installazione............................................................................34
NL
Installatiehandleiding.........................................................................................................42

Airfusion Akmani Installation Instructions
2 | P a g e
CONGRATULATIONS ON YOUR PURCHASE
Congratulations on purchasing the latest in energy saving ceiling fans. This fan runs on DC (direct current) power which
gives it the benefit of being super energy efficient whilst still maintaining high volume air-movement and silent operation.
Energy Saving - The DC motor is the latest technology in fan design. Its highly efficient motor saves up to 65% more
energy than ceiling fans with traditional AC motors.
Silent operation –this DC fan motor is programmed with a stabilized current which efficiently reduces motor noise.
Low operating temperature –The DC power is managed effectively which brings down the motor operating temperature
to less than 50degs. This results in a much cooler motor than a standard AC fan and increases the longevity of the motor.
6 speed remote control, regular AC ceiling fans usually come with only 3 speeds, this DC fan comes complete with a 6
speed remote, which gives greater choice of comfort levels.
SAFETY PRECAUTIONS
1) Europe: This appliance can be used by children aged from 8 years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe way and understand the hazards involved. Cleaning and
maintenance shall not be undertaken by children without supervision.
2) Australia: This appliance is not intended for use by young children or infirm persons unless they have been
adequately supervised by a responsible person to ensure that they can use the appliance safely.
3) Children should be supervised to ensure that they do not play with the appliance.
4) An all-pole disconnection switch must be incorporated in the fixed wiring in accordance with the wiring rules.
5) Do not dispose of electrical appliances as unsorted municipal waste, use separate collection facilities.
Contact your local government for information regarding the collection systems available. If electrical appliances
are disposed of in landfills or dumps, hazardous substances can leak into the groundwater and get into the food
chain, damaging your health and well-being.
6) The structure to which the fan is to be mounted must be capable of supporting a weight of 40kg.
7) The fan should be mounted so that the blades are at least 2.3 metres above the floor for Europe.
8) The fan should be mounted so that the blades are at least 2.1 metres above the floor for Australia.
9) This fan is suitable for indoor use only. Mounting the fan in a situation where it is subject to water or moisture is
dangerous.
10) Only an authorized electrician should execute the installation.

Airfusion Akmani Installation Instructions
3 | P a g e
BEFORE INSTALLATION
Unpack your fan and check contents. You should have the following:
1.
Mounting bracket x 1
7.
Flat washers x 2
2.
Fan assembly with hanger cover, down rod,
canopy cover and canopy x 1
8.
Spring washers x 2
3.
Blades x 3
9.
Wall plugs for screws x 2
4.
Blade kits x 3
10.
Balance kits x 1 set
5.
Bottom cover x 1
11.
Motor screws for blade x 7
6.
Wooden screws x 2
12.
Light kit adaptor x 1
13.
Remote hand set x 1 set
Fig. 1

Airfusion Akmani Installation Instructions
4 | P a g e
INSTALLING THE FAN
TOOLS REQUIRED:
- Phillips / flat head screwdriver
- Pair of pliers
- Adjustable spanner
- Step ladder
- Wire cutter
- Wiring, supply cable as required by local provincial and national wiring codes and regulations.
INSTALLING THE MOUNTING BRACKET
The ceiling fan must be installed in a location so that the blades are 300mm spacing from the tip of the blade to the
nearest objects or walls.
Secure the hanging bracket to the ceiling joist or structure that is capable of carrying a load of at least 40kg, with two
long screws provided. Ensure at least 30mm of the screw is threaded into the support.
NOTE: The bracket screws provided are for use with wooden structures only. For structures other than wood,
the appropriate screw type MUST be used.
ANGLED CEILING INSTALLATION
This fan hanging system supports a maximum 20 degree angled
ceiling installation.
Fig. 2
Fig. 3

Airfusion Akmani Installation Instructions
5 | P a g e
HANGING THE FAN MOTOR ASSEMBLY
Lift the fan assembly onto the mounting bracket. Fig. 4
Ensure the notch of the ball joint is positioned on the stopper of the mounting bracket to prevent the fan from
rotating when in operation. Fig. 5
PREPARE AND COMPLETE THE ELECTRICAL WIRING --- WIRING DIAGRAM (FIG. 6)
WARNING: FOR YOUR SAFETY ALL ELECTRICAL CONNECTIONS MUST BE UNDERTAKEN BY A LICENSED
ELECTRICIAN.
NOTE: AN ADDITIONAL ALL POLE DISCONNECTION SWITCH MUST BE INCLUDED IN THE FIXED WIRING.
PLEASE MAKE SURE THE MAIN SWITCH HAS BEEN TURNED OFF BEFORE CONNECTING.
NOTE: IF THERE ARE TWO OR MORE DC CEILING FANS INSTALLED IN THE ONE LOCATION, AN ISOLATION
SWITCH IS REQUIRED FOR EACH CEILING FAN. THIS IS REQUIRED WHEN PROGRAMMING THE REMOTE AND
RECEIVER TO PAIR TOGETHER.
Fig. 6
Fig. 4
Fig. 5

Airfusion Akmani Installation Instructions
6 | P a g e
INSTALL CANOPY COVER
Loosen the 2 screws from the bottom of the mounting bracket. Fig. 7
Slide the canopy up to the mounting bracket and place the key hole on the canopy over the screw on the
mounting bracket, turn the canopy until it locks in place at the narrow section of the key holes and secure it by
tightening the two set screws. Avoid damaging the electrical wiring prepared previously.
BLADE INSTALLATION
Insert the blade screws through the blade kit and blade then secure the blade to the motor by tightening the 2
screws. Fig.8
Repeat this process to install the other blades to the motor.
Finally install the bottom cover to the light kit housing by rotating it clockwise. Fig. 9
LIGHT KIT INSTALLATION:(Optional, light kit not included)
Before installing the light kit to the fan, you need to do the following:
Do not install the bottom cover.
Remove the bottom cover adaptor (2) from the light kit housing (1) by loosening the 3 screws (3). Fig.10
Install the light kit adaptor (4) to light kit housing (1) by using the 3 screws (3). Fig.10
Install the light kit to the light kit adaptor using the light kit user guide instruction.
Fig. 7
Fig. 8
Fig. 9

Airfusion Akmani Installation Instructions
7 | P a g e
USING YOUR CEILING FAN
Pairing Transmitter and Receiver –when 2 or more DC ceiling fans are installed in one location
When two or more fans are located near each other, you may want to have the receiver/transmitter for each fan set to a
different code, so that the operation of one fan does not affect the operation of the other fan/s.
The DIP switches for the transmitter (remote hand piece) are located in the battery compartment of the transmitter.
Configuring the DIP switches will allow a unique transmission code assigned to each ceiling fan.
NOTE: Ensure that you have installed an all - pole disconnection switch in the fixed wiring for each fan, when using DIP
code function.
NOTE: Ensure power to the Receiver is ON prior to pairing the transmitter with the receiver.
Transmitter/Receiver pairing for ceiling fan 1:
Turn off both ceiling fans 1 and 2 via the mains supply to the receiver.
Slide the cover of the battery compartment of the transmitter to access the DIP switches. This will be transmitter
1.
Change the position of the DIP switches in the remote transmitter 1, so that it will be different to transmitter 2.
Fig. 11
Install the 12VDC battery in the compartment. Please make sure the polarity of the battery is correct.
Turn on the power to receiver 1. Keep the power OFF to receiver 2. (Each ceiling fan must have its own isolation
switch, so that only the ceiling fan that needs to be paired with the transmitter will be ON).
Press and hold the “ ” button on transmitter 1 for 5 seconds within 30 seconds of switching the power to the
receiver of ceiling fan 1.
Once the transmitter is paired with the receiver of ceiling fan 1, it will make a beep sound twice. Turn ON/OFF or
change the speed of the ceiling fan 1 by the transmitter to check the operation.
Fig. 10

Airfusion Akmani Installation Instructions
8 | P a g e
Setting DC Ceiling fan 2:
Turn off both ceiling fans 1 and 2 via the mains supply to the receiver.
Slide the cover of the battery compartment of the transmitter to access the DIP switches. This will be transmitter
2.
Change the position of the DIP switches in the remote transmitter 2, so that it will be different to transmitter 1.
Fig. 11
Install the 12VDC battery in the compartment. Please make sure the polarity of the battery is correct.
Turn on the power to receiver 2. Keep the power OFF to receiver 1. (Each ceiling fan must have its own isolation
switch, so that only the ceiling fan that needs to be paired with the transmitter will be ON).
Press and hold the “ ” button on transmitter 2 for 5 seconds within 30 seconds of switching the power to the
receiver of ceiling fan 2.
Once the transmitter is paired with the receiver of ceiling fan 1, it will make a beep sound twice. Turn ON/OFF or
change the speed of ceiling fan 1 by the transmitter to check the operation.
Note: The pairing of Transmitter and Receiver is not required if only one ceiling fan is installed. When more than
two ceiling fans are installed near each other, please refer to the instruction above.
Remote Control Buttons
: FAN ON/OFF BUTTON: Press the button to turn the fan on/off.
: SPEED INCREASE BUTTON: Press the button to increase the fan speed. The LED
indicator will indicate the fan speed (1-6 speed) accordingly.
: SPEED DECREASE BUTTON: Press the button to decrease the fan speed. The LED
indicator will indicate the fan speed (1-6 speed) accordingly.
: REVERSE FUNCTION BUTTON: Press the button to activate the reverse running
function. The fan must be operating to activate the reverse function.
Fig. 11
Fig. 12

Airfusion Akmani Installation Instructions
9 | P a g e
: NATURAL FLOW BUTTON: Press the button to set the fan running at changing speed automatically. If the fan is
working at speed 1, 2, 3, then press this button to let the fan run at a lower changing speed. If the fan is working at
speed 4,5,6, then press this button to let the fan run at a higher changing speed.
: LIGHT CONTROL BUTTON: Press the button to turn on/off the light.
When pressing the remote button, the LED indictator 1( )will be on. If the LED indicator 1 is off, then you need to
replace the battery with a new 12VDC battery.
When pressing the remote button, if the receiver receives the signal well, it will make a beep sound.
REPAIRING THE FAN RECEIVER & REMOTE PAIRING
Should the remote and receiver lose control after installation or during use, the pairing of the remote and the receiver
must be repaired. Below are the operating symptoms and method to repair the pairing of the DC ceiling fan remote and
receiver.
Issues:
Loss of control - Fan is only running at high speed after installation
Loss of control - No reverse function after installation
Loss of control - Remote cannot communicate with the receiver
Solution:
Switch off the main power to ceiling fan.
Press and hold the “ ” button on transmitter for 5 seconds within 30 seconds of switching the power to the
receiver of the ceiling fan.
Once the transmitter is paired with the receiver of the ceiling fan, it will make a beep sound twice. Turn ON/OFF
or change the speed of the ceiling fan by the transmitter to check the operation.
AFTER INSTALLATION
WOBBLE:
Note: Ceiling fans tend to move during operation due to the fact that they are mounted on a rubber grommet. If the fan
was mounted rigidly to the ceiling it would cause excessive vibration. Movement of a few centimeters is quite acceptable
and does not suggest any problem.
TO REDUCE THE FAN WOBBLE: Please check that all screws which fix the mounting bracket and down rod are
secure.
BALANCING KIT: A balancing kit is provided to balance the ceiling fan on initial installation. Please refer to the
instruction on how to use the balancing kit. The balancing kit can be used to assist re-balancing should the ceiling fan
