LUCCI Air FUTURA Series Installation guide

V2.2 EN-WS (07/2021)
FUTURA SERIES
CEILING FAN
⚫INSTALLATION
⚫OPERATION
⚫MAINTENANCE
⚫WARRANTY INFORMATION
CAUTION
READ INSTRUCTIONS CAREFULLY FOR SAFE
INSTALLATION AND FAN OPERATION.

Futura Installation Instructions
2 | P a g e
CONTENTS
GB
Installation instruction manual .......................................................................................... 3
D
Installationsanleitung ........................................................................................................ 12
F
Guide d’installation............................................................................................................ 22
E
Manual de instrucciones de instalación............................................................................. 32
I
Manuale delle istruzioni di installazione............................................................................ 42
NL
Installatiehandleiding......................................................................................................... 51
EL
Εγχειρίδιο οδηγιών εγκατάστασης ....................................................................................61
Contact:
Beacon International Ltd
Hong Kong Head Office: Room 05, 18/F, Kimberland Center, 55 Wing Hong Street, Cheung Sha Wan Kowloon, Hong Kong
Tel [phone] Fax [phone]
China showroom / Office: 11/Fl, Guzhen Lighting Building B, Mid Zhongxing Road, Guzhen, Zhongshan, GuangDong, China.
Tel: [phone] Fax: [phone]
[email protected]
www.beaconinternational.com
Beacon Lighting Europe GmbH
Campus Fichtenhain 42, 47807 Krefeld, Germany
TEL [phone] FAX [phone]
[email protected]
www.beaconlighting.eu

Futura Installation Instructions
3 | P a g e
THANK YOU FOR PURCHASING
Thank you for purchasing this quality Lucci product. To ensure correct function and safety, please read
and follow all instructions carefully before assembly, installation and use of this ceiling fan. Please keep
instructions for future reference.
SAFETY PRECAUTIONS
1. This appliance can be used by children aged from 8 years and above and persons with reduced
physical, sensory or mental capabilities or lack of experience and knowledge if they have been given
supervision or instruction concerning the use of the appliance in a safe way and understand the
hazards involved. Cleaning and maintenance shall not be undertaken by children without supervision.
2. Children should be supervised to ensure that they do not play with the appliance.
3. An all-pole disconnection switch must be incorporated into the fixed wiring, in accordance with local
wiring rules.
4. Do not dispose of electrical appliances as unsorted municipal waste, use separate collection
facilities. Contact your local government for information regarding the collection systems available. If
electrical appliances are disposed of in landfills or dumps, hazardous substances can leak into the
ground water and get into the food chain, damaging your health and well-being.
5. The structure to which the fan is to be mounted must be capable of supporting a weight of 30kg.
6. The fan should be mounted so that the blades are at least 2.3 m above the floor in Europe
7. This fan is suitable for indoor and alfresco areas where the fan is fully undercover with a minimum of
2 walls. This fan is not waterproof. When installed in an alfresco area, the ceiling fan must be
positioned in a location protected from water, wind, dust and salt. Exposure to these elements will
void the warranty. Mounting the fan in a situation where it is subject to water or moisture is dangerous
and may increase the risk of damage, injury or electrical shock and will void the warranty.
8. Must be assembled and installed by a licensed electrician.
9. WARNING: If unusual wobbling or oscillating movement is observed, immediately stop using the
ceiling fan and contact the manufacturer, its service agent or suitably qualified persons.
10. The replacement of parts of the safety suspension system device shall be performed by the
manufacturer, its service agent or suitably qualified persons.
11. The fixing means for attachment to the ceiling such as hooks or other devices shall be fixed with a
sufficient strength to withstand 4 times the weight of the ceiling fan; that the mounting of the
suspension system shall be performed by the manufacturer, its service agent or suitably qualified
persons.

Futura Installation Instructions
4 | P a g e
BEFORE INSTALLATION
•Unpack your ceiling fan carefully. Remove all parts and hardware.
•Lay out all the components on a smooth surface and make sure there are no components missing
before assembling. If parts are missing, return the complete product to the place of purchase for
inspection or replacement.
•Check whether the ceiling fan has been damaged during transport. Do not operate/install any product
which appears damaged in any way. Return the complete product to the place of purchase for
inspection, repair or replacement.
Examine all parts, you should have the following:
1
Mounting bracket x 1
2
Pre-assembled fan motor, down rod and canopy cover x 1
3
Bottom cover x 1
4
Blades x 4
5
Screw for mounting bracket x 2
6
Blade screws pre-mounted on the rotating member fan motor assembly x 12 (and 1 spare).
7
8
Balance kit x 1 set
Wall controller x 1 set
Fig. 1

Futura Installation Instructions
5 | P a g e
INSTALLING THE MOUNTING BRACKET
•The ceiling fan must be installed in a location so that the blades are a minimum 300mm spacing from
the tip of the blade to the nearest objects or walls.
•Install the hanging bracket to the ceiling joist or structure that is capable of carrying a load of at least
30kg, with the two long screws provided. Ensure at least 30mm of the screw is threaded into the
support.
NOTE: The bracket screws provided are for use with wooden structures only. For structures
other than wood, the appropriate screw type MUST be used. Ensure the screws used are
suitable for the mounting surface and the surrounding environment.
Angled Ceiling Installation
This fan hanging system supports a maximum 20
degree angled ceiling installation.
Fig. 2
Fig. 3

Futura Installation Instructions
6 | P a g e
HANGING THE FAN
Lift the fan assembly onto the mounting bracket. Ensure the key slot (A) of the hanger ball is positioned
on the key pin (B) of the mounting bracket (C) to prevent the fan from rotating when in operation. (Fig.4)
INSTALLING THE FAN
Blade attachment
1. Twist the cover plate to access the blade mounting screw holes.
2. Before installing the blades, remove the blade screws that are pre-installed on the fan motor
assembly. Fig.5
3. Insert the blade into the slot of rotating member of fan motor assembly and align the 3 mounting
holes on the blade to the 3 mounting holes on the rotating member of fan motor assembly and using
the 3 blade screws (removed in step 1) to secure the blade to the fan motor assembly, ensuring they
are tightened equally and evenly tighten. (Take care not to over tighten as this can damage blades).
Fig.6
4. Once completed, repeat the process on the remaining blades.
5. Reinstall the cover via turning it clockwise. Fig.7
Fig. 5
Fig. 6
Fig. 4
Fig. 7

Futura Installation Instructions
7 | P a g e
ELECTRICAL WIRING DIAGRAM
WARNING: FOR YOUR SAFETY ALL ELECTRICAL CONNECTIONS MUST BE UNDERTAKEN BY A
LICENSED ELECTRICIAN.
NOTE: AN ADDITIONAL ALL POLE DISCONNECTION SWITCH MUST BE INCLUDED IN THE FIXED
WIRING.
NOTE: Wiring diagram includes the light kit wiring. The light wiring diagram and switch is omitted
when no light kit is used with the ceiling fan.
USE WITH WALL SWITCH WIRING DIAGRAM:
(Fig. 8)
Fig. 8

Futura Installation Instructions
8 | P a g e
USE WITH REMOTE WIRING DIAGRAM: (REMOTE sold separately)
(Fig.9 and Fig.10)
1/ Remote without quick connectors (manual wiring)
2/ Remote with quick connectors (using quick connectors)
Fig. 9
Fig. 10

Futura Installation Instructions
9 | P a g e
COMPLETING THE INSTALLATION
•After completing the electrical connection at the mounting bracket terminal block, connect the ceiling
fan wiring via the quick connector plug.
•Ensure the earth wiring is secure and correct, by performing an earthing continuity test from the fan’s
accessible metal body back to the earth terminal at the terminal block on the mounting bracket.
•Cover the mounting bracket with the canopy. Ensure all electrical wiring is tucked inside the canopy
and that the wires are not damaged during this step. Secure the canopy to the hanger bracket using
the screws provided. (Fig. 11)
•Switch ON mains power supply to the fan. Test the fan operations or enjoy using the fan following
instructions the under “USING YOUR CEILING FAN” section of this instruction manual.
USING YOUR CEILING FAN
FAN WALL CONTROL
Turn on the power and check the operation of the fan.
• OFF Position – Fan off
• 3rd Position – Low fan speed
• 2nd Position – Medium fan speed
• 1st Position – High fan speed
Fig. 12
Fig. 11

Futura Installation Instructions
10 | P a g e
REVERSE FUNCTION
Your ceiling fan can operate in either summer or winter mode.
SUMMER Mode: The reverse switch should be in the “down” (SUMMER) position to rotate the fan in an
anticlockwise direction. The airflow will be directed downwards, for cooling in summer.
WINTER Mode: The reverse switch should be in the “up” (WINTER) position to rotate the fan in a
clockwise direction. The airflow will be directed upwards, for energy conservation in winter.
AFTER INSTALLATION
WOBBLE:
NOTE: ceiling fans tend to move during operation due to the fact that they are mounted on a rubber
grommet. If the fan was mounted rigidly to the ceiling it would cause excessive vibration. Movement of a
few centimetres is quite acceptable and DOES NOT suggest any problem.
TO REDUCE THE FAN WOBBLE: Please check that all screws which fix the mounting bracket and down
rod are secure.
NOTE: This fan has been precision balanced at the factory and will not need to be balanced again.
NOISE:
When it is quiet (especially at night) you may hear occasional small noises. Slight power fluctuations and
frequency signals superimposed in the electricity for off-peak hot water control, may cause a change in
fan motor noise. This is normal. Please allow a 24-hour “settling-in” period, most noises associated with
a new fan disappear during this time.
The manufacturer’s warranty covers actual faults that may develop and NOT minor complaints such as
hearing the motor run –All electric motors are audible to some extent.
Fig. 13
