INSTRUCTION MANUAL
BEFORE USE ....
Thank you for choosing M-System. Before use, please check
contents of the package you received as outlined below.
If you have any problems or questions with the product,
please contact M-System’s Sales Office or representatives.
■PACKAGE INCLUDES:
Surge protector....................................................................(1)
Single mount DIN rail ........................................................(1)
(Only for option code ‘/DR’ selected)
■MODEL NO.
Confirm Model No. marking on the product to be exactly
what you ordered.
■INSTRUCTION MANUAL
This manual describes necessary points of caution when
you use this product, including installation, connection and
basic maintenance procedures.
LIMITATION APPLICABLE TO M-RESTER
The M-RESTER will protect electronics equipment from
damage caused by lightning by absorbing most of the
surge voltages.
However, M-RESTER may not be effective against cer-
tain extremely high voltages caused by a direct or almost
direct hit by lightning.
M-RESTER must be installed according to this installa-
tion / instruction manual.
POINTS OF CAUTION
■ENVIRONMENT
• Indoor use. Install the unit on a place where the check
button and indicator LEDs can be easily visible and ac-
cessible.
• DANGER!
DO NOT perform an installation, wiring and mainte-
nance of the MDCAT-SPE-A duting thunder storms.
• When heavy dust or metal particles are present in the
air, install the surge protector inside proper housing with
sufficient ventilation.
• Do not install the surge protector where it is subjected to
continuous vibration. Do not subject the unit to physical
impact.
• Environmental temperature must be within -10 to +55°C
(14 to 131°F) with relative humidity within 10 to 95% RH
in order to ensure adequate life span and operation.
• This unit can be earthed via a DIN rail. Oxide film on the
surface of an aluminum rail may lower the electric con-
ductivity between this module and the ground. When this
unit is earthed via a DIN rail, use a steel or copper rail.
• Steel rails may be coated with thin oxide film. Discharg-
ing surge current may produce sparks with the film.
However, this does not affect the surge protection. If you
need to avoid sparks, prior to mounting on the DIN rail,
remove the film by a wire brush.
• Single mount DIN rail for option code ‘/DR’ is made of alu-
minum. Connect to ground with ground terminal when
this DIN rail is used.
■AND ....
• We recommend that you keep spare surge protectors so
that you can replace them when necessary.
• Lightning surge can enter not only through signal lines
but also through power supply lines. We recommend that
you also use the surge protectors for power line for suf-
ficient protection.
COMPONENT IDENTIFICATION
321
CBA
SURGE SIDE
CONNECTOR
ALM Indicator LED
BAT Indicator LED
PROTECTED SIDE
CONNECTOR
CHK Check Button
Specifications (side)
■FRONT VIEW
SHIELD TERMINAL (SHLD)
■REAR VIEW
EARTH TERMINAL (G)
SHORTCIRCUIT BAR
LIGHTNING SURGE PROTECTOR FOR SINGLE PAIR ETHERNET
(PoDL, life monitor)
MODEL
MDCAT-SPE-A

MDCAT-SPE-A
5-2-55, Minamitsumori, Nishinari-ku, Osaka 557-0063 JAPAN
Phone: [phone] Fax: [phone] E-mail: [e-mail]
EM-8197 P. 2 / 3
INSTALLATION
Mount the unit on a DIN rail. Once installed, do not move it to another DIN rail.
■MOUNTING THE UNIT ON A DIN RAIL
A)Hang the upper hook of the DIN rail mounting adaptor at
the rear side of unit, on the DIN rail.
B)Push in the lower in keeping pressing the unit to the DIN
rail.
ADIN rail
B
■REMOVING THE UNIT
A)Pull down the DIN rail adaptor utilizing a minus screw-
driver.
B)Pull out the lower part of the unit.
C)Detach the upper part from the DIN rail.
CB
A
Slider
TERMINAL CONNECTIONS
Connect the unit as in the diagram below.
■EXTERNAL DIMENSIONS unit: mm [inch]
321
CBA
• When mounting, no extra space is needed between units.
38 [1.50]
90 [3.54]
10 [.39] 10 [.39]
DIN RAIL
(35mm wide)
(3 [.12])
40 [1.57]
SURGE SIDE
CONNECTOR
PROTECTED SIDE
CONNECTOR
SHIELD TERMINAL (SHLD)
EARTH TERMINAL (G)
35 [1.38]
6 [.24] (4.5 [.18] deep)
SHORTCIRCUIT BAR
■UNIT
11
[.43]
50 [1.97]
4.2 [.17]
35 [1.38]
7.3 [.29]
■DIN RAIL

MDCAT-SPE-A
5-2-55, Minamitsumori, Nishinari-ku, Osaka 557-0063 JAPAN
Phone: [phone] Fax: [phone] E-mail: [e-mail]
EM-8197 P. 3 / 3
■CONNECTION DIAGRAM
1
2
3
A
B
C
G
SHLD
+
–
SHLD
FG
Protected sideSurge Side
MDCAT-SPE-A
*1*2
*3, *4
*1. Use shortcircuit bar to ground the shield.
*2. If the protected device has an FG terminal, connect to the G terminal of the MDCAT-SPE.
*3. Use a DIN rail made of steel or copper when connecting to ground via the DIN rail.
*4. Single mount DIN rail for option code ‘/DR’ is made of aluminum.
Connect to ground with ground terminal when this DIN rail is used.
Shielded Cable
Protected Device
■WIRING INSTRUCTIONS
Applicable wire size range for euro type connector terminal
of communication is as shown below.
• Applicable wire size
Solid: 0.2 to 2.5 mm2(0.55 to 1.75 dia.)
Stranded: 0.2 to 2.5 mm2
Tinning wire ends may cause contact failure
and therefore is not recommended.
Ferruled: 0.2 to 1.5 mm2(0.55 to 1.35 dia.)
The following Phoenix Contact terminals are recommended:
AI 0.25-8YE 0.2 to 0.25 mm2
AI 0.34-8TQ 0.25 to 0.34 mm2
AI 0.5-8WH 0.34 to 0.5 mm2
AI 0.75-8GY 0.5 to 0.75 mm2
AI 1.0-8RD 0.75 to 1.0 mm2
AI 1.5-8BK 1.0 to 1.5 mm2
• Expose wire conductors by 8 mm (0.31”).
8 mm 8 mm
4 mm dia. max. 4 mm dia. max.
Wire exposure Recommended
ferruled wire
STATUS INDICATION
Press check button to indicate the status of internal dis-
charge element.
■INDICATORS
Activated by CHK (Check) button, see the status table
shown below.
BAT: Green LED
ALM: Red LED
CHK button: Push button; momentary
BAT ALM BATTERY DISCHARGE
ELEMENT
REPLACEMENT
ON OFF Normal No Need
ON ON Normal Near End Near
OFF ON Normal End of Life Immediately
Required
OFF OFF Discharged Unable to Judge
CHECKING
■WIRING
• Make sure that wiring is done as instructed in the con-
nection diagram.
• Make sure that the Earth terminal is connected to the
metallic housing of protected device.
• Make sure that the Earth terminal is connected to earth.
MAINTENANCE
Even lightning in remote locations could induce surges
without our knowledge. Regular checking of the surge
protector is important to find degradations in early stage,
before and after the storm seasons, and whenever you ex-
perience a strong lightning storm. Checking procedure is
explained in the following:
■CHECKING EXTERIOR
If discoloration or deformation is observed, replace with a
new one immediately.
■CHECKING
COMMUNICATION
Check the communication status is improved or not by re-
moving the device when the communication is unstable or
stopping. Replace with a new one if the device is not recov-
ered.
DISCHARGE ELEMENT
For testing, press CHK (Check) button on the front and
LEDs turn on or off according to the surge protector’s condi-
tion. When replacement is required, replace the module to
a new one immediately. Refer to the table for judgement.
