GB Power Planer INSTRUCTION MANUAL
SI Močni obličNAVODILO ZA UPORABO
AL Makinë zdrukthimi elektrike MANUALI I PËRDORIMIT
BG Електрическо ренде
РЪКОВОДСТВО ЗА ЕКСПЛОАТАЦИЯ
HR Električna blanjalica PRIRUČNIK S UPUTAMA
MK Електричен апарат за рамнење
У
ПАТСТВО ЗА УПОТРЕБА
RO Rindea electricăMANUAL DE INSTRUCŢIUNI
RS Електрична рендисаљка
У
ПУТСТВО ЗА УПОТРЕБУ
RUS Рубанок
РУКОВОДСТВО ПО ЭКСПЛУАТАЦИИ
UA Електричний рубанок ІНСТРУКЦІЯ ЗЕКСПЛУАТАЦІЇ
1806B

2
1
1 002563
1
2 004880
1
2
3 004883
1
2
4 002560
1
2
3
4
5
5 002561
1
2
6 002562
1
2
7 004888
1
2
8 004893
12
9 002578
1
10 002591
1
2
34
5
11 002589 12 002592
1
13 001145
1
2
14 002595
1
2
15 002596

3
ENGLISH (Original instructions)
Explanation of general view
1-1. Knob
2-1. Switch trigger
3-1. Lock button / Lock-off button
3-2. Switch trigger
4-1. Hex wrench
4-2. Bolt
5-1. Adjusting screw
5-2. Planer blade
5-3. Notch in the blade
5-4. Drum cover
5-5. Drum
6-1. Triangular rule
6-2. Screwdriver
7-1. Nozzle
7-2. Screwdriver
8-1. Nozzle
8-2. Vacuum cleaner
9-1. End
9-2. Start
10-1. Sharpening holder
11-1. Wing nut
11-2. Blade (A)
11-3. Blade (B)
11-4. Side (D)
11-5. Side (C)
13-1. Limit mark
14-1. Chip cover
14-2. Screwdriver
15-1. Brush holder cap
15-2. Screwdriver
SPECIFICATIONS
Model 1806B
Planing width 170 mm
Planing depth 2 mm
No load speed (min-1) 15,000
Overall length 529 mm
Net weight 9.0 kg
Safety class /II
• Due to our continuing program of research and development, the specifications herein are subject to change without notice.
• Specifications may differ from country to country.
• Weight according to EPTA-Procedure 01/2003
ENE001-1
Intended use
The tool is intended for planing wood.
ENF002-2
Power supply
The tool should be connected only to a power supply of
the same voltage as indicated on the nameplate, and
can only be operated on single-phase AC supply. They
are double-insulated and can, therefore, also be used
from sockets without earth wire.
ENF100-1
For public low-voltage distribution systems of
between 220 V and 250 V.
Switching operations of electric apparatus cause voltage
fluctuations. The operation of this device under unfavorable
mains conditions can have adverse effects to the operation
of other equipment. With a mains impedance equal or less
than 0.41 Ohms it can be presumed that there will be no
negative effects. The mains socket used for this device must
be protected with a fuse or protective circuit breaker having
slow tripping characteristics.
ENG905-1
Noise
The typical A-weighted noise level determined
according to EN60745:
Sound pressure level (LpA) : 92 dB (A)
Sound power level (LWA) : 103 dB (A)
Uncertainty (K) : 3 dB (A)
Wear ear protection
ENG900-1
Vibration
The vibration total value (tri-axial vector sum)
determined according to EN60745:
Work mode : planing softwood
Vibration emission (ah) : 2.5 m/s2
Uncertainty (K) : 1.5 m/s2
ENG901-1
• The declared vibration emission value has been
measured in accordance with the standard test
method and may be used for comparing one tool
with another.
• The declared vibration emission value may also be
used in a preliminary assessment of exposure.
WARNING:
• The vibration emission during actual use of the
power tool can differ from the declared emission
value depending on the ways in which the tool is
used.
• Be sure to identify safety measures to protect the
operator that are based on an estimation of
exposure in the actual conditions of use (taking
account of all parts of the operating cycle such as
the times when the tool is switched off and when it
is running idle in addition to the trigger time).

4
ENH101-15
For European countries only
EC Declaration of Conformity
We Makita Corporation as the responsible
manufacturer declare that the following Makita
machine(s):
Designation of Machine:
Power Planer
Model No./ Type: 1806B
are of series production and
Conforms to the following European Directives:
2006/42/EC
And are manufactured in accordance with the following
standards or standardised documents:
EN60745
The technical documentation is kept by our authorised
representative in Europe who is:
Makita International Europe Ltd.
Michigan Drive, Tongwell,
Milton Keynes, Bucks MK15 8JD, England
30.1.2009
000230
Tomoyasu Kato
Director
Makita Corporation
3-11-8, Sumiyoshi-cho,
Anjo, Aichi, 446-8502, JAPAN
GEA010-1
General Power Tool Safety
Warnings
WARNING Read all safety warnings and all
instructions. Failure to follow the warnings and
instructions may result in electric shock, fire and/or
serious injury.
Save all warnings and instructions for
future reference.
GEB010-4
PLANER SAFETY WARNINGS
1. Wait for the cutter to stop before setting the
tool down. An exposed cutter may engage the
surface leading to possible loss of control and
serious injury.
2. Hold the power tool by insulated gripping
surfaces only, because the cutter may contact
its own cord. Cutting a "live" wire may make
exposed metal parts of the power tool "live" and
could give the operator an electric shock.
3. Use clamps or another practical way to secure
and support the workpiece to a stable
platform. Holding the work by hand or against
your body leaves it unstable and may lead to loss
of control.
4. Rags, cloth, cord, string and the like should
never be left around the work area.
5. Avoid cutting nails. Inspect for and remove all
nails from the workpiece before operation.
6. Use only sharp blades. Handle the blades very
carefully.
7. Be sure the blade installation bolts are
securely tightened before operation.
8. Hold the tool firmly with both hands.
9. Keep hands away from rotating parts.
10. Before using the tool on an actual workpiece,
let it run for a while. Watch for vibration or
wobbling that could indicate poor installation
or a poorly balanced blade.
11. Make sure the blade is not contacting the
workpiece before the switch is turned on.
12. Wait until the blade attains full speed before
cutting.
13. Always switch off and wait for the blades to
come to a complete stop before any adjusting.
14. Never stick your finger into the chip chute.
Chute may jam when cutting damp wood.
Clean out chips with a stick.
15. Do not leave the tool running. Operate the tool
only when hand-held.
16. Always change both blades or covers on the
drum, otherwise the resulting imbalance will
cause vibration and shorten tool life.
17. Use only Makita blades specified in this
manual.
18. Always use the correct dust mask/respirator
for the material and application you are
working with.
SAVE THESE INSTRUCTIONS.
WARNING:
DO NOT let comfort or familiarity with product
(gained from repeated use) replace strict adherence
to safety rules for the subject product.
MISUSE or failure to follow the safety rules stated in
this instruction manual may cause serious personal
injury.

5
FUNCTIONAL DESCRIPTION
CAUTION:
• Always be sure that the tool is switched off and
unplugged before adjusting or checking function
on the tool.
Adjusting depth of cut
Fig.1
Depth of cut may be adjusted by simply turning the knob
on the front of the tool.
Switch action
CAUTION:
• Before plugging in the tool, always check to see
that the switch trigger actuates properly and
returns to the "OFF" position when released.
For tool without lock button and lock-off button
Fig.2
To start the tool, simply pull the switch trigger. Release
the switch trigger to stop.
For tool with lock button
Fig.3
To start the tool, simply pull the switch trigger. Release
the switch trigger to stop.
For continuous operation, pull the switch trigger and
then push in the lock button.
To stop the tool from the locked position, pull the switch
trigger fully, then release it.
For tool with lock-off button
To prevent the switch trigger from being accidentally
pulled, a lock-off button is provided.
To start the tool, depress the lock-off button and pull the
switch trigger. Release the switch trigger to stop.
ASSEMBLY
CAUTION:
• Always be sure that the tool is switched off and
unplugged before carrying out any work on the tool.
Removing or installing planer blades
Fig.4
CAUTION:
• Tighten the blade installation bolts carefully when
attaching the blades to the tool. A loose installation
bolt can be dangerous. Always check to see they
are tightened securely.
• Handle the blades very carefully. Use gloves or
rags to protect your fingers or hands when
removing or installing the blades.
• Use only the Makita wrench provided to remove or
install the blades. Failure to do so may result in
overtightening or insufficient tightening of the
installation bolts. This could cause an injury.
To remove the blades on the drum, unscrew the five
installation bolts with the hex wrench. The drum cover
comes off together with the blades.
To install the blades, first clean out all chips or foreign
matter adhering to the drum or blades. Use blades of
the same dimensions and weight, or drum
oscillation/vibration will result, causing poor planing
action and, eventually, tool breakdown.
Fig.5
There are two adjusting screws for each blade. When
installing the blade, the notch in the blade should fit over
the head of the adjusting screw. Then fit on the drum
cover and secure all the installation bolts only finger-
tight.
Turn the drum until the blade edge is right in the middle
between the front and rear bases.
Place the triangular rule flat on the rear base and run it
out over and across the blade edge. Turn the two
adjusting screws to adjust the blade protrusion. The
blade setting should be made so that the protrusion will
be uniform all the way across. Thus the triangular rule
should be flush with the entire width of the blade edge.
After adjusting both blades, tighten all the installation
bolts evenly and alternately with the wrench.
Fig.6
After tightening the bolts, secure the adjusting screws
fully.

6
For the correct planer blade setting
Your planing surface will end up rough and uneven,
unless the blade is set properly and securely. The blade
must be mounted so that the cutting edge is absolutely
level, that is, parallel to the surface of the rear base.
Refer to some examples below for proper and improper
settings.
(A) (B)
(B)
(A) (B)
(A)
(A) Front base (Movable shoe)
(B) Rear base (Stationary shoe)
Correct setting
Nicks in surface
Gouging at start
Gouging at end
Although this side view cannot
show it, the edges of the blades
run perfectly parallel to the rear
base surface.
Cause: One or both blades fails to
have edge parallel to rear
base line.
Cause: One or both blade edges
fails to protrude enough in
relation to rear base line.
Cause: One or both blade edges
protrudes too far in relation
to rear base line.
EN0004-1
Connecting a vacuum cleaner
Fig.7
For European countries and areas
When you wish to perform clean planing operation,
connect a Makita vacuum cleaner to your tool. Install
the nozzle on the tool using the screws. Then connect a
hose of the vacuum cleaner to the nozzle as shown in
the figures.
For other countries and areas
A nozzle and joint (optional accessories) are necessary
to connect a Makita vacuum cleaner to your tool.
Consult a Makita catalogue or representative on the
nozzle and joint.
Fig.8
OPERATION
Planing operation
Fig.9
First, rest the tool front base flat upon the workpiece
surface without the blades making any contact. Switch
on and wait until the blades attain full speed. Then
move the tool gently forward. Apply pressure on the
front of tool at the start of planing, and at the back at the
end of planing. Planing will be easier if you incline the
workpiece in stationary fashion, so that you can plane
somewhat downhill.
The speed and depth of cut determine the kind of finish.
The power planer keeps cutting at a speed that will not
result in jamming by chips. For rough cutting, the depth
of cut can be increased, while for a good finish you
should reduce the depth of cut and advance the tool
more slowly.

7
MAINTENANCE
CAUTION:
• Always be sure that the tool is switched off and
unplugged before attempting to perform inspection
or maintenance.
• Never use gasoline, benzine, thinner, alcohol or the
like. Discoloration, deformation or cracks may result.
Sharpening the planer blades
Always keep your blades sharp for the best
performance possible. Use the sharpening holder to
remove nicks and produce a fine edge.
Fig.10
First, loosen the two wing nuts on the holder and insert
the blades (A) and (B), so that they contact the sides
(C) and (D). Then tighten the wing nuts.
Fig.11
Immerse the dressing stone in water for 2 or 3 minutes
before sharpening. Hold the holder so that the both
blades contact the dressing stone for simultaneous
sharpening at the same angle.
Fig.12
Replacing carbon brushes
Fig.13
Remove and check the carbon brushes regularly.
Replace when they wear down to the limit mark. Keep
the carbon brushes clean and free to slip in the holders.
Both carbon brushes should be replaced at the same
time. Use only identical carbon brushes.
Use a screwdriver to remove the chip cover.
Fig.14
Use a screwdriver to remove the brush holder caps.
Take out the worn carbon brushes, insert the new ones
and secure the brush holder caps.
Fig.15
To maintain product SAFETY and RELIABILITY, repairs,
any other maintenance or adjustment should be
performed by Makita Authorized Service Centers,
always using Makita replacement parts.
OPTIONAL ACCESSORIES
CAUTION:
• These accessories or attachments are recommended
for use with your Makita tool specified in this manual.
The use of any other accessories or attachments
might present a risk of injury to persons. Only use
accessory or attachment for its stated purpose.
If you need any assistance for more details regarding
these accessories, ask your local Makita Service Center.
• High-speed steel Planer blade
• Sharpening holder assembly
• Blade gauge
• Edge fence (Guide rule)
• Extension guide set
• Dressing stone
• Nozzle assembly
• Hex wrench
NOTE:
• Some items in the list may be included in the tool
package as standard accessories. They may differ
from country to country.

8
SLOVENŠČINA (izvirna navodila)
Razlaga splošnega pogleda
1-1. Ročica
2-1. Sprožilno stikalo
3-1. Gumb za zaklep / gumb za odklep
3-2. Sprožilno stikalo
4-1. Inbus ključ
4-2. Vijak
5-1. Nastavitveni vijak
5-2. Rezilo obliča
5-3. Zareza v rezilu
5-4. Pokrov bobna
5-5. Boben
6-1. Trikotno merilo
6-2. Izvijač
7-1. Šoba
7-2. Izvijač
8-1. Šoba
8-2. Sesalnik za prah
9-1. Konec
9-2. Zagon
10-1. Držalo za brušenje
11-1. Krilna matica
11-2. Rezilo (A)
11-3. Rezilo (B)
11-4. Stranica (D)
11-5. Stranica (C)
13-1. Meja obrabljenosti
14-1. Ščitnik za odrezke
14-2. Izvijač
15-1. Pokrov krtačke
15-2. Izvijač
TEHNIČNI PODATKI
Model 1806B
Širina oblanja 170 mm
Globina oblanja 2 mm
Hitrost brez obremenitve (min-1) 15.000
Celotna dolžina 529 mm
Neto teža 9,0 kg
Varnostni razred /II
• Zaradi našega nenehnega programa raziskav in razvoja si pridržujemo pravico do spremembe tehničnih podatkov brez obvestila.
• Tehnični podatki se lahko razlikujejo od države do države.
• Teža je v skladu z EPTA-postopkom 01/2003
ENE001-1
Namenska uporaba
Orodje je namenjeno za oblanje lesa.
ENF002-2
Priključitev na električno omrežje
Napetost električnega omrežja se mora ujemati s
podatki na tipski ploščici. Stroj deluje samo z enofazno
izmenično napetostjo. Stroj je po evropskih smernicah
dvojno zaščitno izoliran, zato se ga lahko priključi tudi
na vtičnice brez ozemljitvenega voda.
ENF100-1
Za javna nizkonapetostna električna omrežja z
napetostjo med 220 V in 250 V.
Vklopi in izklopi električnih aparatov povzročajo nihanje
električne napetosti. Delovanje te naprave v neugodnih
omrežnih pogojih ima lahko neugodne učinke na delovanje
drugih priključenih naprav. Pri impedanci omrežja do 0,41
Ohma je možno predpostaviti, da ne bo negativnih učinkov.
Omrežna vtičnica, na katero bo priključena ta naprava, mora
biti zaščitena z varovalko ali s tokovnim zaščitnim stikalom s
počasno karakteristiko proženja.
ENG905-1
Hrup
Tipični, z A ocenjeni vrednosti hrupa glede na EN60745:
Raven zvočnega tlaka (LpA) : 92 dB (A)
Raven zvočne moči (LWA) : 103 dB (A)
Odstopanje (K): 3 dB (A)
Uporabljajte zaščito za sluh
ENG900-1
Vibracije
Skupne vrednosti vibracij (vektorska vsota treh osi) po
EN60745:
Delovni način : oblanje mehkega lesa
Oddajanje tresljajev (ah): 2,5 m/s2
Odstopanje (K): 1,5 m/s2
ENG901-1
• Navedena vrednost oddajanja vibracij je bila
izmerjena v skladu s standardnimi metodami
testiranja in se lahko uporablja za primerjavo
orodij.
• Navedena vrednost oddajanja vibracij se lahko
uporablja tudi pri predhodni oceni izpostavljenosti.
OPOZORILO:
• Oddajanje vibracij med dejansko uporabo
električnega orodja se lahko razlikuje od navedene
vrednosti oddajanja, odvisno od načina uporabe
orodja.
• Upravljavec mora za lastno zaščito poznati
varnostne ukrepe, ki temeljijo na oceni
izpostavljenosti v dejanskih pogojih uporabe
(upoštevajočceloten delovni proces v trenutkih, ko
je orodje izključeno in ko deluje v prostem teku z
dodatkom časa sprožitve).

9
ENH101-15
Samo za evropske države
ES Izjava o skladnosti
Makita Corporation kot odgovorni proizvajalec
izjavlja, da je naslednji stroj Makita:
Oznaka stroja:
Močni oblič
Št. modela / tip: 1806B
del serijske proizvodnje in
Je skladen z naslednjimi evropskimi direktivami:
2006/42/ES
In je izdelan v skladu z naslednjimi standardi ali
standardiziranimi dokumenti:
EN60745
Tehnično dokumentacijo hrani naš pooblaščeni
predstavnik za Evropo.
Makita International Europe Ltd.
Michigan Drive, Tongwell,
Milton Keynes, Bucks MK15 8JD, England
30.1.2009
000230
Tomoyasu Kato
Direktor
Makita Corporation
3-11-8, Sumiyoshi-cho,
Anjo, Aichi, 446-8502, JAPAN
GEA010-1
Splošna varnostna opozorila za
električno orodje
OPOZORILO Preberite vsa varnostna opozorila
in navodila. Neupoštevanje opozoril in navodil lahko
vodi do električnega udara, požara, in/ali hudih telesnih
poškodb.
Shranite vsa opozorila in navodila za
kasnejšo uporabo.
GEB010-4
VARNOSTNA OPOZORILA PRI
UPORABI OBLIČA
1. Preden odložite orodje, počakajte, da se
rezalnik ustavi. Izpostavljeni rezalnik se lahko
zatakne v površini, kar lahko povzroči morebitno
izgubo nadzora in hude telesne poškodbe.
2. Držite električno orodje na izoliranih držalnih
površinah, saj se lahko rezalnik dotakne
lastnega kabla. Ob stiku z vodniki pod
napetostjo dobijo napetost vsi neizolirani kovinski
deli električnega orodja, zaradi česar lahko
uporabnik utrpi električni udar.
3. Uporabljajte sponke ali druge praktične
načine za pritrditev in podporo obdelovanca
na stabilno podlago. Če držite obdelovanca z
roko ali ga naslanjate na telo, je nestabilen in
lahko povzroči izgubo nadzora.
4. Krpe, kabel, vrvice in podobno je treba vedno
odstraniti iz delovnega območja.
5. Izogibajte se rezanju žebljev. Pred delom
poiščite in odstranite vse žeblje iz
obdelovanca.
6. Uporabljajte samo ostra rezila. Z rezili ravnajte
zelo previdno.
7. Pred delom se prepričajte, ali so vijaki za
pritrditev rezila trdno pritrjeni.
8. Orodje trdno držite z obema rokama.
9. Ne približujte rok vrtečim se delom.
10. Orodje naj nekaj časa deluje, preden ga
uporabite na dejanskem obdelovancu. Pazite
na tresljaje ali majanje, ki bi lahko nakazovali
slabo namestitev ali slabo uravnoteženo rezilo.
11. Preden vklopite stikalo, se prepričajte, ali se
rezilo ne dotika obdelovanca.
12. Pred rezanjem počakajte, da rezilo doseže
polno hitrost.
13. Pred vsako prilagoditvijo orodje vedno
izključite in počakajte, da se rezila popolnoma
ustavijo.
14. Nikoli ne vtikajte prstov v žleb za ostružke.
Med rezanjem vlažnega lesa se lahko žleb
zamaši. Ostružke očistite s palico.
15. Orodja ne pustite delovati brez nadzora.
Dovoljeno ga je uporabljati samo ročno.
16. Vedno zamenjajte obe rezili ali pokrova na
bobnu. V nasprotnem primeru bo posledična
neuravnoteženost povzročila vibriranje in
skrajšala življenjsko dobo orodja.
17. Uporabljajte samo rezila Makita, določena v
tem priročniku.
18. Vedno uporabite pravilno protiprašno
masko/respirator za material in uporabo.
SHRANITE TA NAVODILA.
OPOZORILO:
NE dopustite si, da bi zaradi udobnejšega dela ali
poznavanja izdelka (pridobljenega z večkratno
uporabo) opustili strogo upoštevanje varnostnih
pravil pri pravilni uporabi stroja.
ZLORABA ali neupoštevanje varnostnih pravil v teh
navodilih za uporabo lahko povzroči hude telesne
poškodbe.

10
OPIS DELOVANJA
POZOR:
• Pred vsako nastavitvijo ali pregledom nastavitev
stroja se prepričajte, da je le to izključeno in
ločeno od električnega omrežja.
Nastavljanje globine rezanja
Sl.1
Globino reza lahko prilagodite z vrtenjem gumba na
sprednjem delu orodja.
Delovanje stikala
POZOR:
• Pred priključitvijo orodja na električno omrežje se
vedno prepričajte, da je stikalo brezhibno in da se
vrača v položaj za izklop (OFF), ko ga spustite.
Za orodje brez gumba za zaporo vklopa in
sprostilnega gumba
Sl.2
Za zagon orodja povlecite sprožilno stikalo. Za izklop
orodja spustite sprožilno stikalo.
Za orodje z gumbom za zaporo vklopa
Sl.3
Za zagon stroja preprosto pritisnite stikalo za vklop. Za
izklop stroja spustite stikalo za vklop.
Za neprekinjeno delovanje pritisnite stikalo za vklop in
nato zaporni gumb.
Za izklop neprekinjenega delovanja stikalo za vklop
pritisnite do konca in ga spet spustite.
Za orodje s sprostilnim gumbom
Za zaščito pred nehotenim vklopom je stikalo
opremljeno s sprostilnim gumbom.
Za zagon orodja hkrati pritisnite na sprostilni gumb in
sprožilno stikalo. Za izklop orodja spustite sprožilno
stikalo.
MONTAŽA
POZOR:
• Pred vsakim posegom v orodje se prepričajte, da
je le to izključeno in ločeno od električnega
omrežja.
Odstranjevanje ali nameščanje rezil obliča
Sl.4
POZOR:
• Ko pritrjujete rezila na orodje, previdno privijte
vijake za namestitev rezila. Ohlapna namestitev
vijakov je lahko nevarna. Vedno preverite, ali so
dovolj trdno priviti.
• Z rezili ravnajte zelo previdno. Uporabljajte
rokavice ali krpo za zaščito prstov ali rok pri
odstranjevanju ali nameščanju rezil.
• Za odstranjevanje ali namestitev rezila uporabite
samo priloženi ključMakita. V nasprotnem primeru
je lahko posledica čezmerno ali nezadostno
privitje montažnih vijakov. To lahko povzroči
poškodbe.
Za odstranjevanje rezil na bobnu odvijte pet montažnih
vijakov z inbus ključem. Pokrov bobna se sname skupaj
z rezili.
Za namestitev rezil najprej očistite vse odrezke in tujke
z bobna ali rezil. Uporabite rezila z istimi merami in težo.
V nasprotnem primeru bo prišlo do oscilacije/vibriranja
bobna, zaradi česar se bo zmanjšala zmogljivost
oblanja in možne bodo poškodbe orodja.
Sl.5
Na obeh rezilih se nahajata prilagoditvena vijaka. Pri
nameščanju rezila se mora zareza na rezilu prilegati
glavi prilagoditvenega vijaka. Nato ga namestite na
pokrov bobna in pritrdite vse montažne vijake samo
ročno.
Obračajte boben, dokler ni rob rezila natančno na
sredini med sprednjo in zadnjo osnovno ploščo.
Namestite trikotno merilo plosko na zadnjo osnovno
ploščo in ga potisnite prek in nad rob rezila. Obrnite dva
prilagoditvena vijaka, da prilagodite izboklino rezila.
Nastavitev rezila je treba izvesti tako, da bodo izbokline
po vsej površini poravnane. Na ta način mora biti
trikotno merilo poravnano s celotno širino roba rezila.
Po prilagoditvi obeh rezil vse montažne vijake
enakomerno izmenično zategnite s ključem.
Sl.6
Po zategovanju vijakov močno zategnite prilagoditveni
vijak.
