5ENGLISH
ENGLISH (Original instructions)
SPECIFICATIONS
Model: M2401
Wheel diameter 355 mm
Max. wheel thickness 3 mm
Hole diameter 25.4 mm
No load speed 3,900 min-1
Dimensions (L x W x H) 515 mm x 280 mm x 640 mm
Net weight 15.3 kg
Safety class /II
• Duetoourcontinuingprogramofresearchanddevelopment,thespecicationshereinaresubjecttochange
withoutnotice.
• Specicationsmaydifferfromcountrytocountry.
• WeightaccordingtoEPTA-Procedure01/2014
• Theshapeandweightvarydependingonthespecicationswhichdiffercountrytocountry.
Intended use
Thetoolisintendedforcuttinginferrousmaterialswithappro-
priateabrasivecut-offwheel.Followalllawsandregulations
regardingdustandworkareahealthandsafetyinyourcountry.
Power supply
Thetoolshouldbeconnectedonlytoapowersupplyof
thesamevoltageasindicatedonthenameplate,and
canonlybeoperatedonsingle-phaseACsupply.They
aredouble-insulatedandcan,therefore,alsobeused
fromsocketswithoutearthwire.
For public low-voltage distribution
systems of between 220 V and 250 V
Switchingoperationsofelectricapparatuscausevoltage
uctuations.Theoperationofthisdeviceunderunfavor-
ablemainsconditionscanhaveadverseeffectstothe
operationofotherequipment.Withamainsimpedance
equalorlessthan0.22Ohmsitcanbepresumedthat
therewillbenonegativeeffects.Themainssocketused
forthisdevicemustbeprotectedwithafuseorprotec-
tivecircuitbreakerhavingslowtrippingcharacteristics.
Noise
ThetypicalA-weightednoiseleveldeterminedaccord-
ingtoEN62841:
Soundpressurelevel(LpA):100dB(A)
Soundpowerlevel(LWA):111dB(A)
Uncertainty(K):3dB(A)
WARNING: Wear ear protection.
Vibration
Thevibrationtotalvalue(tri-axialvectorsum)deter-
minedaccordingtoEN62841:
Vibrationemission(ah):3.0m/s2
Uncertainty(K):1.5m/s2
NOTE: Thedeclaredvibrationemissionvaluehasbeen
measuredinaccordancewiththestandardtestmethod
andmaybeusedforcomparingonetoolwithanother.
NOTE: Thedeclaredvibrationemissionvaluemay
alsobeusedinapreliminaryassessmentofexposure.
WARNING: Thevibrationemissionduringactual
useofthepowertoolcandifferfromthedeclaredemission
valuedependingonthewaysinwhichthetoolisused.
WARNING:Besuretoidentifysafetymeasures
toprotecttheoperatorthatarebasedonanestima-
tionofexposureintheactualconditionsofuse(taking
accountofallpartsoftheoperatingcyclesuchas
the times when the tool is switched off and when it is
runningidleinadditiontothetriggertime).
EC Declaration of Conformity
For European countries only
TheECdeclarationofconformityisincludedasAnnexA
tothisinstructionmanual.
SAFETY WARNINGS
General power tool safety warnings
WARNING: Read all safety warnings, instruc-
tions, illustrations and specications provided
with this power tool.Failuretofollowallinstructions
listedbelowmayresultinelectricshock,reand/or
seriousinjury.
Save all warnings and instruc-
tions for future reference.
Theterm"powertool"inthewarningsreferstoyour
mains-operated(corded)powertoolorbattery-operated
(cordless) power tool.

6ENGLISH
Cut-off machine safety warnings
1. Position yourself and bystanders away from
the plane of the rotating wheel.Theguardhelps
toprotecttheoperatorfrombrokenwheelfrag-
ments and accidental contact with wheel.
2. Use only bonded reinforced cut-off wheels for
your power tool.Justbecauseanaccessorycan
beattachedtoyourpowertool,itdoesnotassure
safe operation.
3. The rated speed of the accessory must be at
least equal to the maximum speed marked on
the power tool.Accessoriesrunningfasterthan
theirratedspeedcanbreakandyapart.
4. Wheels must be used only for recommended
applications. For example: do not grind with
the side of a cut-off wheel.Abrasivecut-off
wheels are intended for peripheral grinding, side
forcesappliedtothesewheelsmaycausethemto
shatter.
5. Always use undamaged wheel anges that are
of correct diameter for your selected wheel.
Properwheelangessupportthewheelthus
reducingthepossibilityofwheelbreakage.
6. The outside diameter and the thickness of your
accessory must be within the capacity rating
of your power tool. Incorrectly sized accessories
cannotbeadequatelyguardedorcontrolled.
7. The arbour size of wheels and anges must
properly t the spindle of the power tool.
Wheelsandangeswitharbourholesthatdonot
matchthemountinghardwareofthepowertool
willrunoutofbalance,vibrateexcessivelyand
maycauselossofcontrol.
8. Do not use damaged wheels. Before each use,
inspect the wheels for chips and cracks. If the
power tool or wheel is dropped, inspect for
damage or install an undamaged wheel. After
inspecting and installing the wheel, position
yourself and bystanders away from the plane
of the rotating wheel and run the power tool
at maximum no load speed for one minute.
Damagedwheelswillnormallybreakapartduring
this test time.
9.
Wear personal protective equipment.
Depending on application, use face shield,
safety goggles or safety glasses. As appropri-
ate, wear dust mask, hearing protectors, gloves
and shop apron capable of stopping small
abrasive or workpiece fragments.Theeyepro-
tectionmustbecapableofstoppingyingdebris
generatedbyvariousoperations.Thedustmask
orrespiratormustbecapableofltratingparticles
generatedbyyouroperation.Prolongedexposure
tohighintensitynoisemaycausehearingloss.
10. Keep bystanders a safe distance away from
work area. Anyone entering the work area
must wear personal protective equipment.
Fragmentsofworkpieceorofabrokenwheelmay
yawayandcauseinjurybeyondimmediatearea
of operation.
11. Position the cord clear of the spinning acces-
sory.Ifyoulosecontrol,thecordmaybecutor
snaggedandyourhandorarmmaybepulledinto
the spinning wheel.
12. Regularly clean the power tool’s air vents.The
motor’sfancandrawthedustinsidethehousing
andexcessiveaccumulationofpowderedmetal
maycauseelectricalhazards.
13. Do not operate the power tool near ammable
materials. Do not operate the power tool while
placed on a combustible surface such as
wood.Sparkscouldignitethesematerials.
14. Do not use accessories that require liquid
coolants.Usingwaterorotherliquidcoolants
mayresultinelectrocutionorshock.
Kickback and related warnings
Kickbackisasuddenreactiontoapinchedorsnagged
rotatingwheel.Pinchingorsnaggingcausesrapid
stallingoftherotatingwheelwhichinturncausesthe
uncontrolledcuttingunittobeforcedupwardstoward
the operator.
Forexample,ifanabrasivewheelissnaggedor
pinchedbytheworkpiece,theedgeofthewheelthat
isenteringintothepinchpointcandigintothesurface
ofthematerialcausingthewheeltoclimboutorkick
out.Abrasivewheelsmayalsobreakunderthese
conditions.
Kickbackistheresultofpowertoolmisuseand/or
incorrectoperatingproceduresorconditionsandcanbe
avoidedbytakingproperprecautionsasgivenbelow.
1. Maintain a rm grip on the power tool and
position your body and arm to allow you to
resist kickback forces.Theoperatorcancontrol
upwardkickbackforces,ifproperprecautionsare
taken.
2. Do not position your body in line with the
rotating wheel.Ifkickbackoccurs,itwillpropel
thecuttingunitupwardstowardtheoperator.
3. Do not attach a saw chain, woodcarving blade,
segmented diamond wheel with a peripheral
gap greater than 10 mm or toothed saw blade.
Suchbladescreatefrequentkickbackandlossof
control.
4. Do not “jam” the wheel or apply excessive
pressure. Do not attempt to make an excessive
depth of cut.Overstressingthewheelincreases
theloadingandsusceptibilitytotwistingorbinding
ofthewheelinthecutandthepossibilityofkick-
backorwheelbreakage.
5. When the wheel is binding or when interrupt-
ing a cut for any reason, switch off the power
tool and hold the cutting unit motionless until
the wheel comes to a complete stop. Never
attempt to remove the wheel from the cut while
the wheel is in motion otherwise kickback may
occur.Investigateandtakecorrectiveactionto
eliminatethecauseofwheelbinding.
6. Do not restart the cutting operation in the
workpiece. Let the wheel reach full speed and
carefully re-enter the cut.Thewheelmaybind,
walkuporkickbackifthepowertoolisrestartedin
the workpiece.
7. Support any oversized workpiece to minimize
the risk of wheel pinching and kickback. Large
workpiecestendtosagundertheirownweight.
Supportsmustbeplacedundertheworkpiece
nearthelineofcutandneartheedgeofthework-
pieceonbothsidesofthewheel.

7ENGLISH
Additional safety warnings
1. Watch out for ying sparks when operating.
Theycancauseinjuryorignitecombustible
materials.
2. Secure work. Use clamps or a vise to hold
work when practical.It'ssaferthanusingyour
handanditfreesbothhandstooperatetool.
3. Secure the wheel carefully.
4. Be careful not to damage the spindle, anges
(especially the installing surface) or bolt, or
the wheel itself might break.
5. Keep guards in place and in working order.
6. Hold the handle rmly.
7. Keep hands away from rotating parts.
8. Make sure the wheel is not contacting the
work-piece before the switch is turned on.
9. Before each use, watch for utter or excessive
vibration that might be caused by poor instal-
lation or a poorly balanced wheel.
10. Remove material or debris from the area
that might be ignited by sparks. Be sure that
others are not in the path of the sparks. Keep
a proper, charged re extinguisher closely
available.
11. If the wheel stops during the operation, makes
an odd noise or begins to vibrate, switch off
the tool immediately.
12. Always switch off and wait for the wheel to
come to a complete stop before removing,
securing workpiece, working vise, changing
work position, angle or the wheel itself.
13. Do not touch the workpiece immediately after
operation; it is extremely hot and could burn
your skin.
14. Store wheels in a dry location only.
SAVE THESE INSTRUCTIONS.
INSTALLATION
WARNING: This tool produces spark when
cutting a workpiece. Do not install this tool in
the place in which ammable and/or explosive
materials might be ignited by the spark from the
tool. Also make sure that there is no such material
near the tool before starting the operation.
Securing the base
Thistoolshouldbeboltedwithtwoboltstoaleveland
stablesurfaceusingtheboltholesprovidedinthetool's
base.Thiswillhelppreventtippingoverandpossible
personalinjury.
►Fig.1: 1.Boltholes2.Base
FUNCTIONAL
DESCRIPTION
CAUTION: Always be sure that the tool is
switched off and unplugged before adjusting or
checking function on the tool.
Unlocking/locking tool head
Thetoolheadcanbelocked.
Whenusing,unhookthelockchainfromthehook.
Whennotinuseorcarrying,alwayshookthelockchain
to the hook.
►Fig.2: 1. Hook 2. Lock chain
Switch action
WARNING: Before plugging in the tool,
always check to see that the switch trigger actu-
ates properly and returns to the "OFF" position
when released.
►Fig.3: 1.Lockbutton/Lock-offbutton2. Switch
trigger
For tool with lock button
Tostartthetool,simplypulltheswitchtrigger.Release
theswitchtriggertostop.Forcontinuousoperation,
pulltheswitchtrigger,pushinthelockbuttonandthen
releasetheswitchtrigger.Tostopthetoolfromthe
lockedposition,pullthetriggerfully,thenreleaseit.
CAUTION: Switch can be locked in "ON" posi-
tion for ease of operator comfort during extended
use. Apply caution when locking tool in "ON"
position and maintain rm grasp on tool.
For tool with lock-off button
Topreventtheswitchtriggerfrombeingaccidentally
pulled,alock-offbuttonisprovided.Tostartthetool,
pressthelock-offbuttonandpulltheswitchtrigger.
Releasetheswitchtriggertostop.
WARNING: NEVER defeat the lock-off button
by taping down or some other means.Aswitchwith
anegatedlock-offbuttonmayresultinunintentional
operationandseriouspersonalinjury.
WARNING: NEVER use the tool if it runs when
you simply pull the switch trigger without press-
ing the lock-off button.Aswitchinneedofrepair
mayresultinunintentionaloperationandserious
personalinjury.ReturntooltoaMakitaservicecenter
forproperrepairsBEFOREfurtherusage.
NOTICE: Do not pull the switch trigger hard
without pressing in the lock-off button.Thiscan
causeswitchbreakage.

8ENGLISH
Interval between vise and guide
plate
CAUTION: After adjusting the interval
between the vise and the guide plate, make
sure that the guide plate is properly secured.
Insufcientxingmayresultinpersonalinjury.
CAUTION: Remember that narrow workpieces
may not be secured safely when using the two,
wider interval settings.
Thefollowingintervalsettingsoftheviseareavailable:
• 0-170mm(originalsetting)
• 35-205mm
• 70-240mm
Ifyourworkrequiresdifferentsetting,proceedasfol-
lowstochangethespacingorinterval.
Removethetwohexsocketboltsusingahexwrench.
Movetheguideplatetothedesiredpositionandsecure
itwiththehexsocketbolts.
►Fig.4: 1. Hex wrench 2.Guideplate3. Hex socket
bolts
Cutting angle adjustment
CAUTION: After adjusting the angle of the
guide plate, make sure that the guide plate is
properly secured.Insufcientxingmayresultin
personalinjury.
CAUTION: Do not operate the tool when
the material is not rmly secured with the vise
because of the cutting angle.
Loosenthetwohexsocketboltsusingahexwrench.
Turntheguideplatetothedesiredangleandsecureit
withthehexsocketbolts.Becarefulnottomovetheset
anglewhilesecuringthehexsocketbolts.
►Fig.5: 1.Guideplate2.Hexsocketbolts
NOTE:Thescaleontheguideplateisonlyarough
indication.Formoreaccurateangle,useaprotractor
ortriangleruler.Keepthehandledownsothatthe
cut-offwheelextendsintothebase.Atthesametime,
adjusttheanglebetweentheguideplateandthecut-
offwheelwithaprotractorortriangleruler.
Spark guard adjustment
►Fig.6: 1. Screw 2.Sparkguard
Thesparkguardisfactory-installedwithitsloweredge
contactingthebase.Operatingthetoolinthisposition
willcausemanysparkstoyaround.Loosenthescrew
andadjustthesparkguardtoapositionatwhichmini-
mumsparkswillyaround.
ASSEMBLY
CAUTION: Always be sure that the tool is
switched off and unplugged before carrying out
any work on the tool.
Removing or installing cut-off wheel
CAUTION: Be sure to tighten the hex socket
bolt securely.Insufcienttighteningmayresultin
severeinjury.Whentighteningthehexsocketbolt,
usethehexwrenchprovidedwiththetooltoassure
proper tightening.
CAUTION: Always use only the proper inner
and outer anges which are provided with the
tool.
CAUTION: Always lower the safety guard
after replacing the wheel.
CAUTION: Wear gloves when handling
wheels.
►Fig.7: 1.Innerange2.Ring3.O-ring4.Bonded
reinforcedcut-offwheel5.Outerange
6. Washer 7.Hexsocketbolt
Raisethesafetyguard.Turnthehexsocketboltcoun-
terclockwiseusingahexwrenchwhileholdingdownthe
shaftlock.Thenremovethehexsocketbolt,washer,
outerangeandwheel.
►Fig.8: 1. Shaft lock 2.Hexsocketbolt
Toinstallthewheel,followtheremovalproceduresin
reverse.Makesuretottheholeofcut-offwheeltothe
ringandreturnthesafetyguard.
Hex wrench storage
►Fig.9: 1. Hex wrench
Whennotinuse,storethehexwrenchasshowninthe
guretokeepitfrombeinglost.
OPERATION
CAUTION: Proper handle pressure during
cutting and maximum cutting efciency can
be determined by the amount of sparks that is
produced while cutting. Do not force the cut
by applying excessive pressure on the handle.
Reducedcuttingefciency,prematurewheelwear,as
wellas,possibledamagetothetool,cut-offwheelor
workpiecemayresult.
Holdthehandlermly.Switchonthetoolandwaituntil
thewheelattainsfullspeedbeforeloweringgently
intothecut.Whenthewheelcontactstheworkpiece,
graduallybeardownonthehandletoperformthecut.
Whenthecutiscompleted,switchoffthetoolandwait
until the wheel has come to a complete stop before
returningthehandletothefullyelevatedposition.

9ENGLISH
Cutting capacity
Maximumcuttingcapacityvariesdependingonthe
cuttingangleandworkpieceshape.
Max. cutting capacity with a brand-new cut-off
wheel
Cutting angle /
Workpiece shape
90° 45°
127 mm 127 mm
102 x 194 mm
70 x 233 mm
115 x 103 mm
119 x 119 mm 106 x 106 mm
137 x 137 x 10 mm 100 x 100 x 10 mm
Securing workpiece
CAUTION: Always place the thread holder on
the shaft threads when securing the workpiece.
Failuretodosomayresultininsufcientsecuringof
theworkpiece.Thiscouldcausetheworkpiecetobe
ejectedorcauseadangerousbreakageofthewheel.
Whilethethreadholderislifted,theviseplatecanbe
movedinandoutquickly.Togripaworkpiece,pushthe
handleuntiltheviseplatecontactstheworkpiecethen
returnthethreadholder.Turnthehandleclockwiseuntil
theworkpieceissecurelyretained.
►Fig.10: 1. Handle 2.Threadholder3. Vise plate
Whenthecut-offwheelhasworndownconsiderably,
placeaspacerblockbehindtheworkpieceasshown
inthegure.Youcanmoreefcientlyutilizetheworn
wheelbyusingthemidpointontheperipheryofthe
wheeltocuttheworkpiece.Useasturdyandnon-am-
mablematerialforaspacerblock.
►Fig.11: 1.Spacerblock
Whencuttingworkpiecesover85mmwideatanangle,
attachastraightpieceofwood(spacer)over190mm
longx45mmwidetotheguideplateasshowninthe
gure.Attachthisspacerwithscrewsthroughtheholes
intheguideplate.Makesurethatthecut-offwheeldoes
not contact the spacer when the tool head is depressed.
►Fig.12: 1.Guideplate2.Spacerblock(over190
mm long x45 mm wide) 3.Workpiece(over
85 mm wide) 4. Vise plate
►Fig.13
Whenthecut-offwheelhasworndown,raisethecutting
positionbyputtingaspacerblockwhichisslightlynar-
rowerthantheworkpieceasshowninthegure.This
willhelpyoutoutilizethewheeleconomically.
►Fig.14: 1. Vise plate 2. Workpiece diameter
3.Guideplate4.Spacerblockwidth
Longworkpiecesmustbesupportedbyblockson
eithersidesothatitwillbelevelwiththebasetop.Use
non-ammablematerialforsupportingblocks.
►Fig.15: 1.Supportingblock
Carrying tool
Folddownthetoolheadandlockit.Holdthehandle
when carrying.
►Fig.16
MAINTENANCE
CAUTION: Always be sure that the tool is
switched off and unplugged before attempting to
perform inspection or maintenance.
NOTICE: Never use gasoline, benzine, thinner,
alcohol or the like. Discoloration, deformation or
cracks may result.
Replacing carbon brushes
►Fig.17: 1. Limit mark
Checkthecarbonbrushesregularly.
Replacethemwhentheyweardowntothelimitmark.
Keepthecarbonbrushescleanandfreetoslipinthe
holders.Bothcarbonbrushesshouldbereplacedatthe
sametime.Useonlyidenticalcarbonbrushes.
1. Useascrewdrivertoremovethebrushholder
caps.
2. Takeouttheworncarbonbrushes,insertthenew
onesandsecurethebrushholdercaps.
►Fig.18: 1.Brushholdercap
TomaintainproductSAFETYandRELIABILITY,
repairs,anyothermaintenanceoradjustmentshould
beperformedbyMakitaAuthorizedorFactoryService
Centers,alwaysusingMakitareplacementparts.

10 SLOVENŠČINA
SLOVENŠČINA (Originalna navodila)
TEHNIČNI PODATKI
Model: M2401
Premerrezalneplošče 355 mm
Največjadebelinaplošče 3 mm
Premerodprtine 25,4 mm
Hitrostbrezobremenitve 3.900 min-1
Mere (D × Š × V) 515 mm x 280 mm x 640 mm
Netoteža 15,3 kg
Razredzaščite /II
• Kernenehnoopravljamoraziskaveinrazvijamosvojeizdelke,selahkotehničnipodatkivtemdokumentu
spremenijobrezobvestila.
• Tehničnipodatkiselahkorazlikujejooddržavedodržave.
• TežavskladuspostopkomEPTA01/2014
• Oblikaintežaserazlikujetagledenaspecikacije,kisorazličnegledenadržavo.
Predvidena uporaba
Orodjejenamenjenozarezanježeleznegamateriala
zustreznoabrazivnorezalnoploščo.Upoštevajtevse
nacionalnezakoneinpredpisegledeprahuinzdravja
tervarnostinadelovnemmestu.
Priključitev na električno omrežje
Napetostelektričnegaomrežjasemoraujematispodatkinatip-
skiploščici.Strojdelujesamozenofaznoizmeničnonapetostjo.
Strojjepoevropskihsmernicahdvojnozaščitnoizoliran,zato
segalahkopriključitudivvtičnicebrezozemljitvenegavoda.
Za javna nizkonapetostna električna
omrežja z napetostjo med 220 V in
250 V
Vklopiinizklopielektričnihaparatovpovzročajonihanjeelek-
tričnenapetosti.Delovanjetenapravevneugodnihomrežnih
pogojihimalahkoneželeneučinkenadelovanjedrugih
priključenihnaprav.Priimpedanciomrežja,kijeenakaali
manjšaod0,22ohma,jemožnopredpostaviti,danebo
negativnihučinkov.Omrežnavtičnica,nakaterobopriklju-
čenatanaprava,morabitizaščitenazvarovalkoalistokov-
nimzaščitnimstikalomspočasnokarakteristikoproženja.
Hrup
ObičajnaA-ovrednotenaravenhrupavskladuzEN62841:
Ravenzvočnegatlaka(LpA):100dB(A)
Ravenzvočnemoči(LWA):111dB(A)
Odstopanje(K):3dB(A)
OPOZORILO: Uporabljajte zaščito za sluh.
Vibracije
Skupnevrednostivibracij(vektorskavsotatrehosi)v
skladuzEN62841:
Emisijevibracij(ah):3,0m/s2
Odstopanje(K):1,5m/s2
OPOMBA:Navedenavrednostoddajanjavibracij
jebilaizmerjenavskladusstandardnimimetodami
testiranjainselahkouporabljazaprimerjavoorodij.
OPOMBA:Navedenavrednostoddajanjavibra-
cijselahkouporabljatudipripredhodnioceni
izpostavljenosti.
OPOZORILO:Oddajanjevibracijmeddejansko
uporaboelektričnegaorodjaselahkorazlikujeod
navedenevrednostioddajanja,odvisnoodnačina
uporabeorodja.
OPOZORILO:Upravljavecmorazalastnozaš-
čitopoznativarnostneukrepe,kitemeljijonaoceni
izpostavljenostivdejanskihpogojihuporabe(poleg
časaproženjajetrebaupoštevaticelotendelovni
cikel,vključnosčasom,kojeorodjeizklopljeno,in
časom,kodelujevprostemteku).
Izjava o skladnosti ES
Samo za evropske države
IzjavaESoskladnostijevključenavdodatkuA,kije
priložentemnavodilomzauporabo.
VARNOSTNA
OPOZORILA
Splošna varnostna opozorila za
električno orodje
OPOZORILO: Preberite vsa varnostna opo-
zorila in navodila s slikami in tehničnimi podatki,
ki so dobavljeni skupaj z električnim orodjem.
Obneupoštevanjuspodajnavedenihnavodilobstaja
nevarnostelektričnegaudara,požarain/alihudih
telesnihpoškodb.
