Malta Dynamics A6205 Guide

OPERATION AND INSTRUCTION MANUAL
WIRE ANCHOR SLINGS
Model: A6205, A6206
V2.4-B
WARNING: ALL PERSONS USING THIS EQUIPMENT MUST
READ AND UNDERSTAND ALL INSTRUCTIONS. FAILURE TO DO
SO MAY RESULT IN SERIOUS INJURY OR DEATH. USERS SHOULD
BE FAMILIAR WITH PERTINENT REGULATIONS GOVERNING THIS
EQUIPMENT. ALL INDIVIDUALS WHO USE THIS PRODUCT MUST
BE PROPERLY INSTRUCTED ON HOW TO USE THE DEVICE. AVOID
CONTACT WITH PHYSICAL HAZARDS (THERMAL, CHEMICAL,
ELECTRICAL, ETC.). MAKE ONLY COMPATIBLE CONNECTIONS.

User Instructions must always be available to the user and are not to be removed except by the user of this equipment. For proper
use, see supervisor, User Instructions, or contact the manufacturer.
Compliant fall protection and emergency rescue systems help prevent serious injury during fall arrest. Users and purchasers of
this equipment must read and understand the User Instructions provided for correct use and care of this product. All users of this
equipment must understand the instructions, operation, limitations and consequences of improper use of this equipment and be
properly trained prior to use per OSHA 29 CFR 1910.66 and 1926.503 or applicable local standards.
Misuse or failure to follow warnings and instructions may result in serious personal injury or death.
PURPOSE
The A6205 and A6206 are anchorage connectors designed to function as an interface between the anchorage and a fall protection,
work positioning, rope access, or rescue system for the purpose of coupling the system to the anchorage. Any references to
“anchorage connector” in this manual include, and apply to, the A6205 and A6206.
USE INSTRUCTIONS
1. A user must be of sound mind and body to properly and safely use this equipment in normal and emergency
situations. Users must have a physician ensure they are clear of any medical conditions that may aect the proper
and safe use of this equipment in normal and emergency situations.
2. Before using a personal fall arrest system, user must be trained in accordance with the requirements of OSHA 29
CFR 1910.66 in the safe use of the system and its components.
3. Use only with ANSI/OSHA compliant personal fall arrest or restraint systems. The anchorage must have the
strength capable of supporting a static load, applied in the directions permitted by the system, of at least 5,000-lbf
(22kN) in the absence of certication.
4. The user shall be equipped with a means of limiting the maximum dynamic forces exerted on the user during the
arrest of a fall to a maximum of 8 kN (1800-lbf).
5. Use of this product must be approved by an engineer or other qualied person to be compatible with any and
all structural & operational characteristics of the selected installation location and system to be connected to this
anchorage connector.
6. The anchorage connector must be inspected prior to each use for wear, damage, and other deterioration. If
defective components are found the anchorage connector must be immediately removed from service in
accordance with the requirements of OSHA 29 CFR 1910.66 and 1926.502.
7. The anchorage connector should be positioned in such a way that minimizes the potential for falls and the
potential fall distance during use. The complete fall protection system must be planned (including all components,
calculating fall clearance, and swing fall) before using.
8. A rescue plan, and the means at hand to implement it, must be in place that provides the prompt rescue of users
in the event of a fall, or assures that users are able to rescue themselves.
9. After a fall occurs the anchorage connector must be removed from service and destroyed immediately.
USE LIMITATIONS: The anchorage connector shall not be used outside its limitations, or for any purpose other than that
for which it is intended.
1. The anchorage connector is designed for single user, with a capacity up to 310 lbs (140 kg) including
clothing, tools, etc.
2. The anchorage connector may only be loaded as shown under CONFIGURATIONS.
3. The anchorage connector is designed to be used in temperatures ranging from -40°F to +130°F (-40°C to +54°C).
4. Do not expose the anchorage connector to chemicals or harsh solutions which may have a harmful eect.
5. Do not alter or modify this product in anyway.
6. Caution must be taken when using any component of a fall protection, work positioning, rope access, or rescue
system near moving machinery, electrical hazards, sharp edges, or abrasive surfaces, as contact may cause
equipment failure, personal injury, or death.
7. Do not use/install equipment without proper training by a“competent person” as defined by OSHA 29
CFR 1926.32(f).
8. Do not remove the labeling from this product.
9. Additional requirements and limitations may apply depending on anchorage type and fastening option utilized
for installation. All placements must be approved by an engineer or other qualied person.
10. This anchorage connector should not be used as part of a horizontal lifeline system that has not been designed
and/or approved to be used with 5,000-lbf anchorage connectors.
11. The anchorage connector should only be used for personal fall protection and not for lifting equipment.
COMPATIBILITY LIMITATIONS
Anchorage connector must only be coupled to compatible connectors. OSHA 29 CFR 1926.502 prohibits snaphooks from being
engaged to certain objects unless two requirements are met: it must be a locking type snaphook, and it must be “designed for”
making such a connection. “Designed for” means that the manufacturer of the snaphook specically designed the snaphook to be
used to connect to the equipment listed. The following connections must be avoided, because they can result in rollout* when a
nonlocking snaphook is used:
• Direct connection of a snaphook to horizontal lifeline.
• Two (or more) snaphooks connected to one D-ring.
• Two snaphooks connected to each other.
• A snaphook connected back on its integral lanyard.
• A snaphook connected to a webbing loop or webbing lanyard.
• Improper dimensions of the D-ring, rebar, or other connection point in relation to the snaphook dimensions that
would allow the snaphook keeper to be depressed by a turning motion of the snaphook.
*Rollout: A process by which a snaphook or carabiner unintentionally disengages from another connector or object
to which it is coupled. (ANSI Z359.0-2007)
Read This Instruction Manual Carefully Before Using This Equipment.

Aircraft Cable
Max Capacity:
(1) person 310-lbs
,
Model: A6205 or A6206
Tubing .47” Ø
7 X 19 Aircraft Cable .25” Ø
1.25”
X”
2”
Tensile Strength (UTS): 5,000-lbf (22kN)
Working load (WLL): 1,000-lbs (454kg)
Max Capacity: 310-lbs (140kg)
Length: Variable
Materials: Aircraft Cable, Polyurethane,
Zinc Plated Copper, Zinc Plated Steel
Regulatory Compliance: Meets or exceeds
ANSI Z359.18 Type A, ANSI Z359.7(11),
OSHA 1910.66, OSHA 1926.502
Model: A6205 or A6206
1(800) 494-1840

BASKET ANCHOR
CONFIGURATION:
VERTICAL
CONFIGURATION:
CONFIGURATIONS
“STRUCTURAL”
ANCHOR POINT
,
WARNING: Do not loop around sharp edges or structural members
that could lessen structural integrity of the anchorage connector.
Only make compatible connections!
Due to the risk of improper loading,
wire sling terminations must not be
connected to each other by a single
carabiner or snaphook. Only OSHA
compatible connections, such as a
Y-lanyard, are permitted.

(ANCHOR POINT)
*The structure
the anchorage is
attached to must
be able to support
5,000-lbf (22kN).
Installation only
under the supervision
RIDTXDOL¿HGSHUVRQ
*The user shall be equipped with a means of
limiting the maximum dynamic forces exerted
on the user during the arrest of a fall to a
maximum of 8 kN (1800-lbf).
WARNING!!! SWING FALLS MAY OCCUR WHEN THE WORKER IS NOT DIRECTLY UNDER ANCHOR POINT.
MINIMUM CLEARANCE 3ft (1m)
DECK/FLOOR/GROUND LEVEL
*All products subjected to fall
arresting forces should be
removed from service immediately!
WORK SURFACE
WORK SURFACE
(

Part Number Comments Inspector Name Date
Inspection:
Ocial periodic inspection must be made at least annually. The inspection must be performed by a
qualied person other than the intended user. If severe weather or conditions exist then inspections
must be carried out more frequently. All inspection results must be logged in the space provided above.
1. Make sure all labeling is axed to the unit.
2. Inspect anchoring system for signs of damage or wear.
3. Record inspection results in the space provided above.
*If any damage that could aect the strength or operation of the device, or unsafe conditions are
found, proper disposal is required. The anchorage connector must be rendered unusable and then
properly discarded.
INSPECTION AND MAINTENANCE LOG
MAINTENANCE, CLEANING AND STORAGE
Cleaning periodically will prolong the life and proper functioning of the product. The frequency of
cleaning should be determined by inspection and by severity of the environment. Clean with com-
pressed air and/or a sti brush using plain water or a mild soap and water solution. Do not use any
corrosive chemicals that could damage the product. Wipe all surfaces with a clean, dry cloth and
hang to dry, or use compressed air. When not in use, store anchorage connector in a cool, dry, clean
environment, out of direct sunlight and free of corrosive or other degrading elements.
MODEL NUMBER:
DATE OF MANUFACTURE:

Notes

Malta Dynamics, LLC.
210 13th Street, Malta OH 43758
1(800) 494-1840 / www.maltadynamics.com
Product Warranty, Limited Remedy and Limitation of Liability
WARRANTY: THE FOLLOWING IS MADE IN LIEU OF ALL WARRANTIES OR
CONDITIONS, EXPRESS OR IMPLIED, INCLUDING THE IMPLIED WARRANTIES OR
CONDITIONS OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE.
Equipment oered by Malta Dynamics is warranted against factory defects in
workmanship and materials for a period of one year from date of purchase or rst use
by the original owner.
LIMITED REMEDY: Upon notice in writing, Malta Dynamics will repair or replace all
defective items at Malta Dynamics’s sole discretion. Malta Dynamics reserves the
right to require that the defective item be returned to its plant for inspection before
determining the appropriate course action. Warranty does not cover equipment
damage resulting from wear, abuse, damage in transit, failure to maintain the product
or other damage beyond the control of Malta Dynamics. Malta Dynamics shall be the
sole judge of product condition and warranty options. This warranty applies only to
original purchaser and is the only warranty applicable to this product. Please contact
Malta Dynamics technical service department for assistance.
LIMITATION OF LIABILITY: IN NO EVENT WILL MALTA DYNAMICS BE LIABLE FOR
ANY INDIRECT, INCIDENTAL, SPECIAL OR CONSEQUENTIAL DAMAGES INCLUDING,
BUT NOT LIMITED TO LOSS OF PROFITS, IN ANY WAY RELATED TO THE PRODUCTS
REGARDLESS OF THE LEGAL THEORY ASSERTED.
