Markant Matrix Pro Combi User manual

TOOLS & MANPOWER
OPTION 2: Allen Key x1OPTION 1: Power Tool x1
MAIN COMPONENTS
A
B
C
Mallet x1
Component B (x2) Component C (x2)Component A (x2) Component E (x2)
JCH Screw
*only for table top
Leveler
Matrix Pro Combi installation manual
(frame)
*leveler
*leveler
*leveler
*leveler
Manpower x2

1 2
3 4
5 6
Finally, secure the lock plate under the C with screw using Allen key.
Repeat this step to the other part of the leg.
Attach C to A by using mallet. Repeat this step on the other side of
the leg.
Adjust the table length and secure the pre-installed screw using
Allen key.
Attach B to A and secure the screw using Allen key.
Repeat this step on the other side of the leg.
The frame (B) is pre-assembled. Do not remove the carton box
until the leg is flip up. This is to prevent any further damages.
Raise the legs, slide the frame outwards to fit desired size and fix it
with the bolts that are already mounted in the frame. Repeat this
step for the other leg.
B
A
C
A
*pre-installed screw
C
carton block carton block
ip up the leg ip up the leg
B
*mallet
Installation for 1200mm frame only: Remove the screws (A)x4 on each side of
the frame to slide in the frame deeper. When the frame is in the correct
position, fit in the screw (A)x4 again.
A

Matrix Pro Combi installation manual
(cable gutter)
Place the Main Gutter in between the C. Prior to that, the Main Gutter need to be install with its Side Covers to make sure it is placed properly on the C
brackets. This can be done by hammer it using rubber hammer (i.e Mallet) to secure its position.
Make sure the cutout of the Side Covers is positioned at the center with the holes of the C brackets.
C
*side cover
Finally, place the lid on top of the Main Gutter.
C

Matrix Pro Combi installation manual
(table top)
E
The installation of the table top is completed. This installation is only applicable for 1200L, 1400L, 1500L, 1600L,
and 1800L worktop size only.
Attach table top on the frame and secure it using (E) screw.
The installation of the table top is completed. This installation is only applicable for 2000L worktop size only.
2000L
*overhang table top

Matrix Pro Combi installation manual
(Elbow & Front gutter)
TOOLS & MANPOWER
Manpower x1 Allen Key x5
Power Tool x1
MAIN COMPONENTS
[A] Elbow (x2) [B] Smart Gutter (x2)
A
B

A
A
B
1 2
4
Attach A by slotting it’s bottom adapter into the Main Gutter
holes.
Then attach top part A to bottom B.
3
Next, self tapped the B under the table top. The installation of the elbow and front gutter is completed.
A
B

Matrix Pro Combi installation manual
(Frameless-Screen)
TOOLS & MANPOWER
Manpower x2 Power Tool x2 Allen Key x2
MAIN COMPONENTS
[A] Component A (x2) [B] Component B (x2) [C] Component C (x1)
A
B
C

Slot in A into the bridge’s holes. Secure it’s position by tighten it to B with washers and screws as provided.
1
2
3
The C can now be slotted inside the B.
The installation for frameless screen is completed.
B
A
*bridge
*washer & screw
B
C

Matrix Pro Combi installation manual
(accesories)
TOOLS & MANPOWER
Manpower x1 Allen Key x5
Power Tool x1
MAIN COMPONENTS
(A) Handset (B) Media Hub (C) Monitor Arm (E) Multi Drawer
B
C
A
D

*top part Multi Drawer
E*bottom part
Multi Drawer
B
*screw
*screw
B
A
A
E
1 2
4
Attach (A) Handset below the table top using a screw. The installation for (A) Handset is completed.
3
Attach (B) Media Hub on the table top. Tighten the screw on top of (B) Media Hub. The installation for
Media Hub is completed.
65
Attach (C) Monitor Arm on the table top. Tighten the screw at the bottom. The installation for (C) Monitor
Arm is completed.
87
Attach the top part of (E) Muli Drawer below the table top using
screw.
Slot in the bottom part of the (E) Multi Drawer and the installation
is completed.
C

Matrix Pro Combi installation manual
(control box)
MAIN COMPONENTS
[A] Control Box [B] Power Plug
A
B
Please refer handset manual
instruction that is provided.
TOOLS & MANPOWER
Manpower x1 Allen Key x5
Power Tool x1 Self Tap Screw

A
(A) Handset (B) Actuator (C) Control Box (F) Wall Socket(D) Power Extension A (E) Power Extension B
B
C
D E F
STEP 1: Attach (C) control box below the table top using self-tap screw.
STEP 2: Plug in the main plug to the power extension inside the trunk towards the power extension inside the front gutter.

1
Cable line from (C) control box to the (A) handset.
Cable line from the (C) control box to the (B) actuator.
Cable line from the (D) power extension A inside the
trunk to the (E) power extension B inside the front
gutter.
1
2
3
Cable line from the (E) power extension B inside the
front gutter to the Media Hub.
Cable line from the (E) power extension B to the
monitor arm.
Cable line from the (E) power extension B to the
C (control box).
4
5
6
Cable line from the (F) wall socket to the
(D) power extension A.
7
2
3
4
5 6 7
(A) Handset (B) Actuator (C) Control Box (F) Wall Socket(D) Power Extension A (E) Power Extension B
STEP 3: Attach the cable point to the rest of the accesories.
STEP 4: Reset procedure to follow before use: Hold up- and down button until desk is in lowest position and then slightly goes up.
