Markant Myoffice User manual

www.markantoffice.com

MYOFFICE RECTANGULAR & CORNER HI (ALLEN KEY) - STEEL & ALUMINIUM BEAM

INSTALLATION MANUAL

T-leg T-leg (Middle)

MYOFFICE LEGS BEAMS VERSIONS

1. Rectangular Frame 2. Corner Frame

Steel Beam HI version - via allen keyAluminium Beam

www.markantoffice.com

MYOFFICE RECTANGULAR & CORNER HI (ALLEN KEY) - STEEL & ALUMINIUM BEAM

INSTALLATION MANUAL

Adjust the end leg height using allen key.

Rectangular - Place worktop on frame. For Steel Beam, rectangular (view up-side-down) -

Attach frame and worktop with JCBC screws.

For Aluminium Beam, rectangular (bottom view) -

a. Attach worktop with JCBC screws from bottom of top

support, b. Adjust the length of the beam to t with

worktop, c. Fix cap screws with beam.

For Steel Beam, corner (view up-side-down) -

Attach worktops with stabiplates and top support.

For Aluminium Beam, corner (view up-side-down) -

Attach worktops with stabiplates and top support.

BASIC FRAME

1 2 2a

HI VERSION

11a

CORNER FRAME

CABLE MANAGEMNET

= Steel & Aluminium = Steel = Aluminium

WORKTOP

33a

Allen Key

For Steel Beam - Mount beam to endlegs with JCBC screws. For Aluminium Beam - Mount connector to endlegs with cap screws. For Aluminium Beam - Slide connector into beam.

For Steel Beam - Hook return beam on the main beam. For Aluminium Beam - Attach return beam on the main beam. For Aluminium Beam (view up-side-down) - Fix cap screws into

main beam.

View up-side-down - Press cable ngers into the rail depend on needs. Bottom view - Tidy up all the cables, slot it into the cable ngers

JCBC Screw

x 2

M8 x 16mm

M8 x 25mm

Cap Screw

x 2

M6 x 12mm

Cap Screw

x 4

JCBC Screw
