Mastercare Master Turner Royal-L User manual

(UK) User Manual
Article no.
MC 001-1735
MC 001-2535
HMI no.
128452
131086
Name - Size
Master Turner Royal - L
Master Turner Royal - L Inco
UDI-DI/GTIN
5744001973936
5744001973974
19_20221019 UK
The Original Master Turner System
Master Turner Royal - L
Regulation MDR 2017/745 for medical devices class 1
ISO 12 31 03 21
The Original Nordic
Human Handling Concept

Thank you for choosing a product from master care A/S.
We recommend reading the user manual thoroughly before using the
product (-s).
The information in this user manual applies to the shown products
provided that the products have not been modied or customized
and that the products have been used as recommended in this user
manual.
If the costumer changes, repairs or uses the product in other combi-
nations than recommended by master care A/S the CE-approval no
longer applies and the guarantee becomes void.
In case of doubt, contact master care A/S or our distributor in your
area.
MDR (EU) 2017/745:
Products in this user manual is CE-approved and follows the harmo-
nized standards. This means that the products are in compliance with
the essential health and safety directives. The product(-s) comply with
the standards in the Medical Device Regulation MDR (EU) 2017/745 –
Class 1.
The intended use of the product/-s:
The intended use for the product is to reduce friction between the
user and the mattress to make it easier for the helper and gentler for
the user whilst turning, moving up/downwards, and moving to sitting
position on the edge of the bed. This product should always be used in
combination with a Mattress Cover from master care a/s.
Correct use of the product:
The combination of the Master Turner and the Mattress Cover from
master care A/S constitutes a turning system, which can be used for
users with a decrease in function where transfers in bed and between
beds can be difcult.
Risk assessment:
Always make a risk assessment and a functional assessment of the
user prior to using the product. This way using the product for trans-
ferring or moving a user, is ergonomic and legally sound.
Knowledge of the product/transferring:
It is important that the user of the product has been properly instruc-
ted in the use of the product and has read the user manual thoroughly
prior to using the product.
master care A/S and our distributors provide education in the use of
products and on our website all user manuals can be found.
Life span:
The expected life span of products with nylon sliding material with
daily wear and tear and washing averagely is 1-3 years. The products
life span depends on the use, users load, washing and drying tempera-
tures and how often it is washed and dried.
Products with insufcient friction reduction, defect seams, broken
material or other deciencies must be discarded. This way you will
always keep a sound and healthy work environment for both helper
and user.
Make visual inspections frequently and preferably before every use.
Guarantee:
master care A/S provide a 2-year guarantee covering material defects
and manufacturing defects if the product has been used correctly.
Unintended events and injuries when misusing the products:
Unintended events must always be reported to the appropriate Na-
tional Authority and to master care A/S or the distributor in the current
country.
master care A/S and our distributors take no responsibility for per-
sonal injuries or product damages if the product(-s) have been used
in contravention of the by the manufacturer recommended intended
purpose or proper use of the product.
master-care.dk

User Manual - Master Turner Royal - L
Table of Contents
Mounting Mattress Cover and Master Turner Royal - L ......................... page 4
Turning in bed manually – slightly dependent patient (1 helper) ......................... page 4
Turning in bed manually – more dependent patient (1 helper) ......................... page 4
Turning in bed with hoist - dependent patient (1 helper) ......................... page 5
Transferring between 2 beds (1-2 helpers) ......................... page 5
Avoid sliding downwards in bed by using cushions and wedges (1 helper) ......................... page 5
Retaining the Master Turner Royal - L by using Locking Straps - MC 001-1950 ......................... page 6
Higher up in bed with Master Turner Royal - L (1-2 helpers) ......................... page 6
Higher up in bed on top of the Master Turner Royal - L with a sliding material (1-2 helpers) ......................... page 6
Into a sitting position on the edge of the bed with a hoist (1-2 helpers) ......................... page 7
Placing a sling sheet under the Master Turner and lifting (2 helpers) ......................... page 7
Master Turner Royal Inco ......................... page 8
Technical Specikations ......................... page 10
master-care.dk

User Manual - Master Turner Royal - L
Mounting Mattress Cover and Master Turner Royal - L:
2. Place the Master Turner Royal – L with
the nylon side towards the Mattress Cover
and the label ”This side up” visible.
1. Mount the Mattress Cover - L on the
mattress.
3. To protect the Master Turner and to avoid
unnecessary washing an incontinence sheet
e.g., MC 001-1810 can be placed on top of
the Master Turner.
Turning in bed manually – slightly dependent patient (1 helper):
Turning in bed manually – more dependent patient (1 helper):
side 2
5. The patient begins the turn by pushing
the pelvis backwards and turning the upper
body. The helper grabs the Master Turner
close to the patient´s pelvis and supports
the turning.
4. Bend one or both of patient´s knees. The
patient grabs the bed rail to participate as
much as possible.
6. To increase stability and comfort in
side lying, the Master Comfort Positioning
Wedge - S MC 001-8035 can be placed in
front of the patient´s stomach before turn-
ing. Also, it increases the patient´s sense of
security, it keeps the stomach in place and
maintains alignment of the spine in the side
lying position.
8. Place a Positioning Wedge - S close
to the stomach before the turn. Grab the
Master Turner on both sides of the hips and
turn the patient to side lying. This way you
maintain vital tactile information from the
patient´s back.
7. Transfer the patient to the side of the bed
by moving respectively hips, upper body and
legs using small tugs. Avoid transferring the
whole patient at once. Bend the patient´s
closest leg, elevate the bed rail and walk
to the opposite side of the bed. Bend the
other leg.
9. After turning to side lying a Back Wedge
- Short MC 001-8070 can be placed behind
the patient if necessary. If a Positioning
Cushion - S with bilayered Nylon Master
was placed next to the legs before the turn
it is now easy to slide the upper leg in
position and remove the Nylon Master.
Avoid lifting the leg.
master-care.dk

User Manual - Master Turner Royal - L
Turning in bed with hoist - dependent patient (1 helper):
11. Elevate the hoist. When the shoulder
and one side of the hip is free of the mat-
tress slide the patient backwards by moving
respectively hips, upper body and legs using
small tugs. Elevate the hoist and repeat
until the patient is in side lying position.
10. Place patient´s hand on the stomach,
connect the hoist, elevate the bed rail,
and walk to the opposite side of the bed.
Slide the pillow to the side and place the
closest hand on the pillow. Place Position-
ing Wedge – S next to the stomach and a
Positioning Cushion – S next to the legs.
12. Slide the upper leg forwards towards
the Positioning Wedge. Adjust the position
by using the sliding material under the pa-
tient e.g., rotate the hip. If necessary, place
a Back Wedge - Long MC 001-8075 behind
the user before lowering the hoist.
Transferring between 2 beds (1-2 helpers):
Avoid sliding downwards in bed by using cushions and wedges (1 helper):
side 3
14. Place some sliding material over the
non-skid-edge of the Mattress Cover. The
sliding material must cover the surface the
Master Turner will travel during the transfer.
13. Place the two beds close together.
Activate breaks. Fill up the space between
the mattresses with e.g., Cylinder Cushions
MC 001-8030 and MC 001-8080. Pull Straps
MC 001-1947 can be mounted on the side
of the Master Turner Royal – L for a better
work position.
15. Calmly pull the Master Turner to transfer
the patient sideways. Make sure to move
respectively hips, upper body and legs
using small tugs to avoid pulling the whole
bodyweight at once.
17. Place two Positioning Wedges – S MC
001-8040 under the patient´s thighs under
the Master Turner – with the non-skid-side
facing downwards. Place a Positioning
Cushion between the feet and the footboard
– keep 5 cm space between them.
16. Position the patient´s pelvis correct in
the bed by sliding the Master Turner. Check
the position by fully elevating the knee-rest
of the bed.
18. Elevate the knee-rest and the back rest.
If the patient´s upper body slides to one
side place a Positioning Wedge – M MC
001-8050 on each side to create stability,
comfort and to give the patient clear tactile
information.
master-care.dk

User Manual - Master Turner Royal - L
Retaining the Master Turner Royal - L by using Locking Straps - MC 001-1950:
20. Lead the xed end of the Locking Strap
through the top strap of the Master Turner.
Close the buckle. Do this on both sides.
19. Remove the footboard and pull the mat-
tress a bit downwards. Fix the two Locking
Straps to the underside of the head rest
with the long adjustable end of the straps.
21. The locking Straps keeps the Master
Turner in place when the head rest is eleva-
ted. Note: Be aware of the risk of shear.
Higher up in bed with Master Turner Royal - L (1-2 helpers):
Higher up in bed on top of the Master Turner Royal - L with a sliding material (1-2 helpers):
side 4
23. Alternatively: Elevate the foot of the
bed and lower the back rest or activate the
Trendelenburg. Helper stands at the end of
the bed and removes the footboard. Places
the hands under the ancles and pushes
the patient from here. If the patient bends
the knees place the hands on the shines
instead.
22. Elevate the foot of the bed and lower
the back rest. If the patient has the use
of the legs place the feet on a non-skid
surface e.g., remove the ap on the cover.
The helper/-s grabs the Master Turner and
pulls upwards using weight transfer and a
calm pace.
24. Alternatively use the hoist. Mount the
hoist around the patient´s pelvis and elevate
slightly to barely lift the pelvis of the mat-
tress. The helper pushes the patient´s feet or
pulls the Master Turner to make the transfer
higher up in bed.
26. Place two pieces of sliding material
under the whole body. Place them by turning
the patient to side lying position or with the
folding technique.
25. Remove the aps of the cover under the
patient´s upper body if the cover has aps.
27. Pull up the patient on top of the Master
Turner by using e.g., a Mini Master or a
sheet under the pelvis.
master-care.dk

User Manual - Master Turner Royal - L
Into a sitting position on the edge of the bed with a hoist (1-2 helpers):
29. Fold the Master Turner around the
patient´s legs and slide them over the edge
of the bed without lifting.
28. Do not use Master Turner Royal Inco
for this! Elevate the bed rail behind the
patient. Elevate the knee rest and then the
back rest. Attach the top straps to the hoist.
Elevate until it ts snugly behind the pa-
tient´s back. Adjustment Straps can be used
to increase the patient´s safety, comfort,
and stability.
30. You can use the Master Turner´s nylon
sliding surfaces if necessary to help the
patient´s pelvis move forwards when sitting
on the edge of the bed. The Adjustment
Straps MC 001-1948 can be regulated again
when sitting.
Placing a sling sheet under the Master Turner and lifting (2 helpers):
side 5
32. Lower the hoist and attach it to the
opposite side. Elevate and straighten out
the sling sheet under the patient and the
Master Turner. Postion the sling sheet using
the sliding surfaces between the Master
Turner and the Mattress Cover.
31. Attach the Master Turner to the hoist
and turn the patient to side lying position.
Fold and place the sling sheet between the
Master Turner and the Mattress Cover.
33. For patients with nausea or tactile
issues: Place a Positioning Cushion – S
between the feet and the foot board. The
helpers grab the leg straps of the sling
sheet and places them between the Master
Turner and the Mattress Cover and slides
the sling sheet down to the correct position.
35. Elevate the knee rest and elevate the
back rest. Attach the sling sheet and lift the
patient off the bed with the Master Turner
between the patient´s back and the sling
sheet.
34. Move the leg straps to the sides and to
the upper side of the Master Turner. Place
them under the legs preferably using the
Sling Sock Basic MC 003-903. This reduces
the risk of shear during lifting and eases
placing the leg straps without lifting the
heavy legs.
36. Fold the Master Turner backward and up
on the outer side of the sling sheet before
lowering the patient into the chair. The
Master Turner is now placed in a ”U”-shape
around the sling sheet.
master-care.dk

User Manual - Master Turner Royal - L
Placing a sling sheet under the Master Turner and lifting (2 helpers): - continued
38. Slide the leg straps out of the Sling
Socks and slide the sling sheet upwards
between the two ends of the Master Turner.
You can also use the hoist to remove the
sling sheet. This way the patient does not
need to lean forward or lift the legs to
remove the sling sheet.
37. Lower the hoist and place the patient in
the chair. The patient is NOT sitting on the
loose part of the Master Turner.
39. The helper grabs the lower corners of
the Master Turner and slides the Master
Turner out manually. The backmost part
slides on the front part of the Master Turner.
It can be an advantage to slide diagonally.
Some Master Turners can also be attached
to the hoist for this part.
Master Turner Royal Inco:
side 6
41. Alternatively, a separate incontinence
sheet can be used on top of the Master
Turner e.g., Inco Master - S MC 001-1801.
This will lower the frequency of washing
thus prolonging the durability of the sliding
material and therefore the life of the Master
Turner.
40. Master Turner Royal Inco – L has an
integrated incontinence membrane. This
means the Mattress Cover does not get wet
if the Master Turner Inco gets soaked.
master-care.dk

Product Quality - Care Quality - Quality of Life
master-care.dk side 7

User Manual - Master Turner Royal - L
Technical Specikations
Materials
Cotton, polyester, nylon.
For Master Turner Royal Inco - L: Cotton, polyester, polyuretane, nylon.
MC 001-1735 Master Turner Royal - L L 210 x B 150 cm 24 200 kg
MC 001-2535 Master Turner Royal Inco - L L 210 x B 150 cm 24 200 kg
User Weight
Recommended max. max user weight: 200 kg.
Ingen strygning symbol
Ironing:
Do not iron.
Washing:
This product can be washed in a washing
machine at max 85 ºC.
Gentle washing and dry tumbling signicantly
prolongs the durability.
Dry cleaning:
Do not dry clean.
Detergents pH level:
This product tolerates detergents / disinfec-
tants with a pH level between 5-9.
Bleach:
Do not bleach.
Fabric softener:
Never use fabric softener as this will reduce
the sliding properties signicantly.
Maintenance:
Make visual inspections frequently and
preferably before every use. Pay attention to
torn fabric, seams and straps. Products with
high friction or other deciencies must be
discarded.
Dry Tumbling:
This product may only be dry tumbled gently
and at max. 40 ºC.
Airdrying prolongs the durability signicantly.
User Manual:
Always read the User Manual thoroughly
before using the product.
Surface cleaning:
The surface of this product can be cleaned
with a wet cloth and soap.
Disposal:
Always make sure to follow local guidelines
when disposing or discarding the product.
Disinfectants:
This product tolerates alcoholic disinfectants
with a pH level between 5-9.
Size:
Number of
handles:
WARNINGS
Never leave the user on
the product when lying on the
edge of the bed.
Never leave the product
on the oor.
Always make sure that the
user is not caught in the straps.
Never leave the user lying on the
product whilst connected to a hoist.
Do not use as a sling sheet. Can
be combined with a hoist for e.g.
repositioning in bed.
Make sure that all relevant brakes
are activated before transferring
the user.
CE-certication:
This product is CE-approved and
follows the harmonized standards.
This means that the products are
in compliance with the essential
health and safety directives.
The product(-s) comply with the
standards in the Medical Device
Regulation (EU) 2017/745 – class 1.
For more information, videos
Quick Guide etc., visit
www.master-care.dk
ISO certications:
ISO 12952-1:2015
Textiles – Assessing the ignitability of all bedding
items, when subject to a smouldering cigarette.
Article no. - Product Name: Max. User Weight
HUMAN HANDLING CONCEPT
We support the Sustainable Development Goals Reservations are made for printing errors.
Find us on:
master-care.dk
master care A/S, Soenlystvej 3, DK 8340 Malling, Danmark
Tel. [phone], E-mail: [email protected]
