MasterCraft 058-6551-6 User manual

model no. 058-6551-6
058-6552-4
52” Chest and Cabinet

headline bars
continuation tabs
notes
warnings

4
6
8
10
9
9
headline bars
continuation tabs
notes
warnings
PARTS LIST
ASSEMBLY INSTRUCTIONS
OPERATING INSTRUCTIONS
MAINTENANCE
WARRANTY
SAFETY
3

4
This manual contains information that relates to PROTECTING PERSONAL SAFETY
and PREVENTING EQUIPMENT PROBLEMS. It is very important to read this manual
carefully and understand it thoroughly before using the tool chest and cabinet.
• The maximum weight for each drawer should be no more than 77 lb (35 kg).
DO NOT OVERLOAD DRAWERS.
• The maximum product weight, including contents, should be no more than
1000 lb (454 kg) for roller cabinets.
• DO NOT attempt to lift the chest using chains, ropes or other lifting devices if
two persons cannot lift the chest by the side handles. Use a forklift placed
under the bottom of the chest if this situation occurs. The side handles may
fail, which may cause personal injury or damage to the product.
• DO NOT stand on this product. You may fall, which may cause personal injury.
• WEAR SAFETY GLASSES when removing or repositioning the slides.
• When moving this product, do not pull it. Push the product to prevent personal
injury.
• Handle and swivel castors must be attached on the same side of the product.
• USE THE BRAKES when not moving this product. This will prevent the product
from rolling, which may cause personal injury or product damage.
• DO NOT open more than one drawer at a time. The product may become
unstable and tip, which may cause personal injury or product damage.
• DO NOT mount this product on a truck bed or any other moving object. This may
cause personal injury or product damage.
• Secure this product properly before moving it with a forklift.
• DO NOT tow with other power equipment. The product could tip, which may
cause personal injury or product damage.
• DO NOT alter this product in any manner. For example, do not weld external
lock bars or attach other electrical equipment. This may cause product damage
or personal injury.
• Keep the product on level surfaces. The product may become unstable and tip
if stored or moved on an uneven surface, which may cause personal injury or
product damage.
• When the cover is open, be sure the gas lifts are in good condition. This will
prevent accidental closure and personal injury.
model no. 058-6551-6, 058-6552-4 I contact us 1-800-689-9928
headline bars
continuation tabs
notes
warnings

• BE CAREFUL when closing the cover. Remove hands before the cover closes
completely to prevent personal injury.
• Close the cover and lock the drawers before moving this product. The drawers
could come open and make the product unstable and tip, which may cause
personal injury or product damage.
• Remove the worktop from the roller cabinet, if necessary, before installing the
chest. Otherwise, the chest could slip, be damaged and cause injuries.
• When locking a chest, close the drawers before closing the cover for lock bars to
work properly.
• IMPORTANT: Do not attach or mount this product to a vehicle. Mounting this
product to any vehicle in any manner will void warranty.
headline bars
continuation tabs
notes
warnings
5

6
headline bars
continuation tabs
notes
warnings
Top liner
Slide (L)
Drawer liner
Slide (R)
Handle
Gas lift
Lock assembly (601-610)
Magnetic backing
Power bar with USB outlets 02-470002
02-470001
02-460901
02-460422
02-460311-11
02-100102A-4
02-100102A-3
02-6016703-01
02-6016703-02
2
1
1
1
2
2
6
6
6
TOOL CHEST 058-6551-6
PARTS LIST
model no. 058-6551-6, 058-6552-4 I contact us 1-800-689-9928

Big drawer liner
Handle 02-460311-07
M6x12 screw
Slide (R)
Slide (L)
Swivel castors
M8x20 hex bolts
Drawer liner
Rigid castors
Top liner
Lock assembly (601-610)
02-471605
02-100102A-4
02-100102A-3
02-460904
02-200112-1
02-200112-3
02-471105
02-6016709-03
02-6016709-01
02-6016709-02
1
4
11
11
2
2
1
1
1
8
16
TOOL CABINET 058-6552-4
PARTS LIST
headline bars
continuation tabs
notes
warnings
The keys are taped to the top of the castor carton, which is placed in the
bottom drawer of the cabinet.
7

NOTE: You may require the assistance of
another person for this step.
Carefully lay down the cabinet on its back with
a soft mat underneath to protect the finish.
Position the two rigid castors (7) on the
bottom of the cabinet on the left side. Insert the
M8 x 20 hex bolts (5) through the the castors
and into the bottom of the cabinet.
Tighten securely.
Repeat for the two swivel castors (4) on the
other side. The handle must be mounted on
the same side of the cabinet as the swivel castors.
Wrench tighten all screws. Return the cabinet to
its upright position.
8
headline bars
continuation tabs
notes
warnings
model no. 058-6551-6, 058-6552-4 I contact us 1-800-689-9928
NOTE: The holes in the cabinet are tapped and
therefore require no nuts for installation.
Position the cabinet handle (1) over the
holes and attach with the M6 x 12 bolts (2).
Tighten securely.

headline bars
continuation tabs
notes
warnings
9
Extend the drawer slides from the
tool chest. Insert the brackets on
each side of the drawer into the
slots in the slide and ensure that
they are properly in position. Once
properly inserted, completely close
the drawer to set the slides in their
proper positions.

10
headline bars
continuation tabs
notes
warnings
model no. 058-6551-6, 058-6552-4 I contact us 1-800-689-9928
This Mastercraft product is guaranteed for a period of one (1) year from the date of
original retail purchase against defects in materials and workmanship.
This warranty is subject to the following conditions and limitations:

11
