MasterCraft 068-0014-8 User manual

continuation tabs
IMPORTANT:
Please read this manual carefully before assembling
and using this cabinet and save it for reference.
INSTRUCTION
MANUAL
WIDE CABINET
Model no. 068-0014-8

headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings

TABLE OF CONTENTS
2
3
4
7
Safety
Parts List
Assembly Instructions
Mounting Instructions
Warranty 9
NOTE:
If any parts are missing or damaged, or if you have any questions,
please call our toll-free helpline at 1-800-689-9928.
1
TABLE OF CONTENTS
SAVE THESE INSTRUCTIONS
This manual contains important safety and operating instructions.
Read all instructions and follow them with use of this product.

SAVE THESE INSTRUCTIONS
This manual contains important safety and operating instructions.
Read all instructions and follow them with use of this product.
2
SAFETY
headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
model no. 062-3582-8 | contact us 1-800-689-9928
headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
model no. 068-0014-8 | contact us 1-800-689-9928
• To reduce the risk of serious injury, read the following safety
instructions before assembling and using the cabinet.
• This cabinet is intended for domestic, indoor use only.
• The cabinet should be positioned on a level surface.
• Any assembly or maintenance of the cabinet must be carried
out by adults only.
• Arrange for necessary manpower when assembling and moving
the cabinet.
• Check all the nuts and bolts periodically for tightness.
When required, tighten them again.
• Use a slightly damp, soft cloth to clean the cabinet.
• Do not stand on the cabinet and do not use it as a scsffold.
• Do not exceed the weight limit specified for this cabinet.
Maximum middle shelves load: 80 lb (36 kg).
Maximum bottom panel load: 140 lb (64 kg).
Maximum cabinet load: 300 lb (136 kg).

3
PARTS LIST
No.
1
2
3
4
5
6
7
8
9
10
11
Description
Bottom panel
Left side panel
Right side panel
Bottom back panel
Upper back panel
Top panel
Middle shelf
Left door panel
Right door panel
Wall-hanging bracket
Screw A (M4x8)
Qty.
1
1
1
1
1
1
2
1
1
2
36
PARTS LIST
11
M4x8
13
M6x60
12 M4x8
14 M6
#6
#2
#12
#9
#8
#15
#1 #3
#4
#11
#16
#7 #10
#5
No.
12
13
14
15
16
17
18
Description
Screw B (M4x8)
Screw C (M6x60)
Plastic anchor
Magnet
Hook
Screwdriver
Key (attached at the door handle)
Qty.
10
8
8
2
8
1
2

headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
model no. 062-3582-8 | contact us 1-800-689-9928
4
ASSEMBLY INSTRUCTIONS
headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
model no. 068-0014-8 | contact us 1-800-689-9928
ASSEMBLY INSTRUCTIONS
• Begin the assembly of this cabinet on a clean, level surface.
• Remove all items from the box and ensure that all parts listed on page 3 are
present.
• When installing parts that have more than one screw, tighten all screws by
hand before finishing tightening them with the provided screwdriver (17).
STEP 1
Attach the right side panel (3) to the
top panel (6). Line up screw holes of
both the panels. Use the screwdriver
(17) and three M4x8 screws A (11) to
secure.
STEP 2
Attach the left side panel (2) to the top
panel (6). Line up screw holes and use
the screwdriver (17) and three M4x8
screws A (11) to secure.
STEP 3
Attach bottom panel (1) between the
left side panel and right side panel (2
and 3) as the figure to the right shows.
Line up screw holes and secure
together using the screwdriver (17)
and three M4x8 screws A (11) on each
side of bottom panel.
#3
#11 #17
#6
Front
Back
#6
#11
#2
Back
Front
#1
#11

5
ASSEMBLY INSTRUCTIONS
STEP 4
Attach the bottom back panel and the
upper back panel (4 and 5) to the cabinet
frame. Line up screw holes and use the
screwdriver (17) and twenty M4x8 screws
A (11) to secure.
STEP 5
Attach the magnet (15) to the top panel
and bottom panel (6 and 1), using the
screwdriver (17) and four M4x8 screws A
(11) to secure.
STEP 6
Decide a height for each middle shelf (7)
and insert the hooks (16) into the hook
slots at the desired height. Then, place
the middle shelf (7) into the cabinet and
push it down onto the hooks (16). Follow
the same procedure for the second
middle shelf (7).
#5
#4
#11
Top
Bottom
#11
#15
#2
#3
#7
#16

headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
model no. 062-3582-8 | contact us 1-800-689-9928
6
ASSEMBLY INSTRUCTIONS
headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
model no. 068-0014-8 | contact us 1-800-689-9928
STEP 7
Attach the left door panel (8) to the
cabinet, and line up screw holes. Use
the screwdriver (17) with five M4X8
screws B (12) to secure.
STEP 8
Attach the right door panel (9) to the
unit. Line up screw holes and use the
screwdriver (17) with five M4x8
screw B (12) to secure.
STEP 9
Use key (18) to lock the doors.
Now your cabinet is ready to be
mounted on the wall.
#8
#12
#12
#9

7
MOUNTING INSTRUCTIONS
MOUNTING INSTRUCTIONS
STEP 1
Choose a location for the wall cabinet. The recommended height from the floor to the
bottom of the cabinet is 63" (160 cm). Start from one side of the desired location to
find the first screw location for the wall-hanging brackets (10). Use a pencil to mark
the centre of the screw. Then, locate the second screw 16" (40.6 cm) from either
side of the first screw. The distance between the two screws is 16" (40.6 cm) (from
centre to centre).
STEP 2
Drill a small hole (Ø1/8”) at both screw
locations. Use the provided drawing to find the
rest of the screw holes to fasten the wall-hang-
ing brackets (10). Place the drawing on the wall
and align the holes in the drawing with those
already drilled on the wall. Then, drill a small
hole at each of the eight hole locations.
Note: The shop drawing shows the actual size of the wall
cabinet (28 x 28" / 71.1 x 71.1 cm) and indicates the
locations of the holes on the wall-hanging brackets.
You may also want to temporarily tape the drawing to the
wall for marking the locations of the screws. Use a small
nail to penetrate the shop drawing and mark the eight
points to fasten the wall-hanging brackets.
After marking locations, pre-drill a small hole (1/4"
diameter) at each of the eight hole locations.
FLOOR
DOOR
63" (160 cm) 63" (160 cm) 28" (71.1 cm)
16" (40.6 cm)
1 2

headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
model no. 062-3582-8 | contact us 1-800-689-9928
8
MOUNTING INSTRUCTIONS
headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
model no. 068-0014-8 | contact us 1-800-689-9928
STEP 3
Insert the plastic anchors (14) into the holes
in the wall. Then, attach the wall-hanging
brackets (10) to the wall, securing each one
of them with four M6x60 screws (13).
Finally, hang the cabinet on the wall-hang-
ing brackets (10) as shown in the illustration
to the side. Now, your cabinet is ready for
use. Use the keys (18) to lock the cabinet
doors, if desired.
Back panel view of wall cabinet shows
6 flat hooks that allow the cabinet to
hang on two wall-hanging brackets.
Close-up view of how the wall-hanging
brackets fit with the 6 flat hooks on the back
of the cabinet.
13
10

9
WARRANTY
Close-up view of how the wall-hanging
brackets fit with the 6 flat hooks on the back
of the cabinet.
This Mastercraft® product carries a one (1) year warranty from the date of the original
retail purchase, against defects in material and workmanship. Subject to the condi-
tions and limitations described below, this product, if returned to us with proof of
purchase within the stated warranty period and if covered under this warranty, will be
repaired or replaced (with the same model, or one of equal value or specification), at
our discretion. We will bear the cost of any repair or replacement and any costs of
labour relating thereto.
These warranties are subject to the following conditions and limitations:
a. a bill of sale verifying the purchase and purchase date must be provided;
b. this warranty will not apply to any product or part thereof which is worn or broken
or which has become inoperative due to abuse, misuse, accidental damage, neglect or
lack of proper installation, operation or maintenance (as outlined in the applicable
owner's manual or operating instructions) or which is being used for industrial, profes-
sional, commercial or rental purposes;
c. this warranty will not apply to normal wear and tear or to expendable parts or acces-
sories that may be supplied with the product which are expected to become inopera-
tive or unusable after a reasonable period of use;
d. this warranty will not apply to routine maintenance and consumable items such as,
but not limited to, fuel, lubricants, vacuum bags, blades, belts, sandpaper, bits, fluids,
tune-ups or adjustments;
e. this warranty will not apply where damage is caused by repairs made or attempted
by others (i.e., persons not authorized by the manufacturer);
f. this warranty will not apply to any product that was sold to the original purchaser as
a reconditioned or refurbished product (unless otherwise specified in writing);
g. this warranty will not apply to any product or part thereof if any part from another
manufacturer is installed therein or any repairs or alterations have been made or
attempted by unauthorized persons;
h. this warranty will not apply to normal deterioration of the exterior finish, such as, but
not limited to, scratches, dents, paint chips, or to any corrosion or discolouring by heat,
abrasive and chemical cleaners; and
i. this warranty will not apply to component parts sold by and identified as the product
of another compay, which shall be covered under the product manufacturer's warran-
ty, if any.

headline bars
continuation tabs
notes
warnings
Additional Limitations
This warranty applies only to the original purchaser and may not be
transferred. Neither the retailer not the manufacturer shall be liable for
any other expense, loss or damage, including, without limitation, any
indirect, incidental, consequential or exemplary damages arising in
connection with the sale, use or inability to use this product.
Notice to Consumer
This warranty gives you specific legal rights, and you may have other
rights, which may vary from province to province. The provisions
contained in this warranty are not intended to limit, modify, take away
from, disclaim or exclude any statutory warranties set forth in any applica-
ble provincial or federal legislation.
Made in China
Imported by
Mastercraft Canada Toronto, Canada M4S 2B8

continuation tabs
GUIDE
D’UTILISATION
IMPORTANT :
Veuillez lire attentivement ce guide avant d’assembler
et d’utiliser cette armoire large et le conserver à titre de référence.
ARMOIRE LARGE
Modèle nº 068-0014-8

headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings

TABLE DES MATIÈRES
2
3
4
7
Sécurité
Liste des pièces
Instructions d’assemblage
Instructions de montage
Garantie 9
1
TABLE DES MATIÈRES
CONSERVEZ CES INSTRUCTIONS
Le présent guide d’utilisation contient un mode d’emploi et des
consignes de sécurité importants. Lisez et respectez toutes les
instructions lorsque vous utilisez cet article.
REMARQUE :
Si des pièces sont manquantes ou endommagées, ou si vous avez des questions,
veuillez contacter notre service de soutien téléphonique sans frais au 1 800 689-9928.

2
SÉCURITÉ
headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
model no. 062-3582-8 | contact us 1-800-689-9928
headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
Modèle n° 068-0014-8 | Contactez-nous au 1 800 689-9928
• Pour réduire les risques de blessures graves, lisez les consignes de
sécurité suivantes avant d’assembler et d’utiliser l’armoire.
• Cette armoire est conçue pour un usage domestique, à l’intérieur
seulement.
• L’armoire doit être placée sur une surface plane.
• Tout assemblage ou entretien de l’armoire doit être effectué par des
adultes seulement.
• Demandez à d’autres personnes de vous aider à assembler et
déplacer l'armoire.
• Vérifiez périodiquement le serrage de tous les écrous et boulons.
Au besoin, resserrez-les.
• Utilisez un chiffon doux légèrement humide pour nettoyer l’armoire.
• Ne vous tenez pas debout sur l’armoire et ne l’utilisez pas comme
échafaudage.
• Ne dépassez pas la limite de poids spécifiée pour cette armoire.
Charge maximale des tablettes du milieu : 80 lb (36 kg).
Charge maximale du panneau inférieur : 140 lb (64 kg).
Charge maximale de l’armoire : 300 lb (136 kg).
CONSERVEZ CES INSTRUCTIONS
Le présent guide d’utilisation contient un mode d’emploi et des
consignes de sécurité importants. Lisez et respectez toutes les
instructions lorsque vous utilisez cet article.

3
LISTE DES PIÈCES
Nº 1
1
2
3
4
5
6
7
8
9
10
11
Description
Panneau inférieur
Panneau latéral gauche
Panneau latéral droit
Panneau arrière inférieur
Panneau supérieur arrière
Panneau supérieur
Tablette centrale
Panneau de porte gauche
Panneau de porte droite
Support mural
Vis A (M4x8)
Qté
1
1
1
1
1
1
2
1
1
2
36
LISTE DES PIÈCES
11
M4x8
13
M6x60
12 M4x8
14 M6
#6
#2
#12
#9
#8
#15
#1 #3
#4
#11
#16
#7 #10
#5
Nº
12
13
14
15
16
17
18
Description
Vis B (M4x8)
Vis C (M6x60)
Cheville en plastique
Aimant
Crochet
Tournevis
Clé (attaché à la poignée de porte)
Qté
10
8
8
2
8
1
2

headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
model no. 062-3582-8 | contact us 1-800-689-9928
4
INSTRUCTIONS D’ASSEMBLAGE
headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
Modèle n° 068-0014-8 | Contactez-nous au 1 800 689-9928
INSTRUCTIONS D’ASSEMBLAGE
• Commencez l’assemblage de cette armoire sur une surface propre et plane.
• Retirez tous les articles de la boîte et assurez-vous que toutes les pièces
énumérées à la page 3 sont présentes.
• Lors de l’installation de pièces ayant plus d’une vis, serrer toutes les vis à la
main avant de les serrer à l’aide du tournevis (17) fourni.
ÉTAPE 1
Fixez le panneau latéral droit (3) au
panneau supérieur (6). Alignez les
trous de vis des deux panneaux et
utilisez le tournevis (17) et trois vis M4
x 8 (11) pour fixer.
ÉTAPE 2
Fixez le panneau latéral gauche (2) au
panneau supérieur (6). Alignez les
trous de vis et utilisez le tournevis (17)
et trois vis M4 x 8 (11) pour fixer.
ÉTAPE 3
Fixez le panneau inférieur (1) entre le
panneau latéral gauche et le panneau
latéral droit (2 et 3) comme le montre
l'illustration du côté droit. Alignez les
trous de vis et serrez les trois vis A M4
x 8 (11) de chaque côté du panneau
inférieur à l'aide du tournevis (17).
#3
#11 #17
#6
Avant
Arrière
#6
#11
#2
Arrière
Avant
#1
#11

5
INSTRUCTIONS D’ASSEMBLAGE
ÉTAPE 4
Fixez le panneau arrière inférieur et le
panneau arrière supérieur (4 et 5) au
cadre de l'armoire. Alignez les trous de
vis et utilisez le tournevis (17) et vingt vis
M4x8 A (11) pour serrer.
ÉTAPE 5
Attachez l'aimant (15) au panneau
supérieur et au panneau inférieur (6 et 1)
à l'aide du tournevis (17) et de quatre vis
M4x8 A (11) pour fixer.
ÉTAPE 6
Choisissez une hauteur pour chaque
tablette du milieu (7) et insérez les
crochets (16) dans les fentes du crochet à
la hauteur désirée. Ensuite, placez la
tablette du milieu (7) dans l’armoire et
poussez-la vers le bas sur les crochets
(16). Suivez la même procédure pour la
deuxième tablette du milieu (7).
#5
#4
#11
Dessus
Panneau inférieur
#11
#15
#2
#3
#7
#16

headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
model no. 062-3582-8 | contact us 1-800-689-9928
6
INSTRUCTIONS D’ASSEMBLAGE
headline bars
continuation tabs
notes
warnings
headline bars
continuation tabs
notes
warnings
Modèle n° 068-0014-8 | Contactez-nous au 1 800 689-9928
ÉTAPE 7
Alignez les trous de vis et, à l’aide du
tournevis (17) avec cinq vis B M4 x 8
(12), fixez le panneau de porte
gauche (8) à l’armoire.
ÉTAPE 8
Placez le panneau de porte droite (9)
sur l’armoire. Alignez les trous de vis
et à l’aide du tournevis (17) avec
cinq vis B M4 x 8 (12) fixez-le.
ÉTAPE 9
Utilisez la clé (18) pour verrouiller les
portes.
Votre armoire est maintenant prête à
être montée sur le mur.
#8
#12
#12
#9
