MasterCraft 068-1554-6 User manual

IMPORTANT
Please read this manual carefully before assembling and
using this product, and save it for reference.
INSTRUCTION
MANUAL
Due to continuing improvements,
the actual product may differ slightly
from the product described herein.
model no. 068-1554-6
28" (71 cm) Base Cabinet

2
model no. 068-1554-6 I contact us 1-800-689-9928
TABLE OF CONTENTS
3
3
5
10
11
TABLE OF CONTENTS
SAVE THESE INSTRUCTIONS
This manual contains important safety and operating instructions. Read all
instructions and follow them carefully with use of this product.
NOTE:
If any parts are missing or damaged, or if you have any questions, please call our toll-free
helpline at: 1-800-689-9928. Have the product number, cash register receipt and the date
of purchase available when you call. DO NOT SHIP YOUR PRODUCT BACK TO THE STORE
UNLESS WE SEND YOU WRITTEN INSTRUCTIONS FOR RETURN.
MAINTENANCE
COORDINATING PRODUCTS
WARRANTY
SAFETY
ASSEMBLY INSTRUCTIONS
4
EXPLODED VIEW / PARTS LIST

3
SAFETY / MAINTENANCE
To reduce the risk of serious injury, read and follow the safety instructions below before assembling
and using this product.
SAFETY
Before assembling and using this product, carefully read this instruction manual and all of the labels
affixed to the product. Failure to follow all warnings and instructions may result in product damage or
personal injury.
Save all warnings and instructions for future reference.
-Maximum load: 400 lb (181 kg)
-Maximum load for shelf: 100 lb (45 kg)
-Maximum load for bottom panel: 150 lb (68 kg)
-Maximum load for rubber wood top: 150 lb (68 kg)
Keep the product on level surfaces. The product could become unstable and it may tip over if
stored or moved on an uneven surface, which may cause personal injury, death or product damage.
This product is intended for indoor use only.
Any assembly or maintenance of the product must be carried out by adults only.
Use at least two people to move, assemble or install this cabinet. Failure to do so can result in
personal injury or product damage.
Check all nuts and bolts periodically for tightness. When required, tighten them.
Close and lock the doors before moving this cabinet.
DO NOT alter this product in any manner. For example, do not weld external bar locks or attach
electrical equipment. This may cause product damage or personal injury.
DO NOT leave children unattended near this product. Cabinets may tip over if improperly opened.
DO NOT stand or lean on the product.
DO NOT exceed the following weight limits for this product.
Periodically clean the surfaces with a soft rag and water.
Grease and oil can be removed with most standard cleaning fluids.
For safety, use a nonflammable cleaning fluid.
MAINTENANCE
This product is not designed for commercial nor industrial usage.
It is always recommended to secure this product to the wall with the anti-tip hardware provided.

EXPLODED VIEW / PARTS LIST
No.
2
2Back panel
Shelf bracket 4
3
14 Shelf
1
4
5
7
Right side panel
Back top beam 1
1
Description Qty.
No. Description No. Qty.
13
14
15
16
18
2
4
1
2
1
EXPLODED VIEW / PARTS LIST
1
6
17
19
Rubber ring
Pin
Left door
Magnet
Door stopper
4
NOTE:
Replacement keys may be ordered. Call our toll-free number. The code which appears on the lock will
be required.
Give information for spare parts: part number and quantity required.
Bottom panel
9
Adjustable foot
Lock (001-010)
1
8Right door
2
10 Key (001-010)
1
21
Left side panel
1
20
Front top beam
2
22 Stainless steel top
1
11 Door handle 2
Hex wrench
1
1
M6x16 hex socket
head screw *
18 23
14
13
NOTE: Extra M6 x 16
hex socket head screw(s)
is (are) provided.
16
*
1
2
5
6
3
21
19
17
18
4
15
14 7
16
13
12
8
9
20
10
11
22
21
23 1
M6 x 40 hex tapping bolt
1
12 Locking hook
113539
226078
118218
117604
313066
234908
Part No.
117601
118124
304196
304236
306018
236397
237444
118123
312033
117680
314219
Part No.
320327
117605
320328
117603
118122
317023
50
model no. 068-1554-6 I contact us 1-800-689-9928
No.
4
2Shelf bracket
Shelf 1
3
14 Bottom panel
1
2
5
7
Front top beam
Right side panel 1
1
Description Qty.
No. Description No. Qty.
13
14
15
16
18
1
2
2
4
48
1
6
17
19
Left door
Key (001-010)
Door handle
Adjustable foot
M6 x 16 hex socket
head screw
Door stopper
9
Magnet
Lock (001-010)
1
8Right door
1
10 Locking hook
121
M6 x 40 hex tapping bolt
2
20
Back panel
1
22 Rubberwood top
2
11 Pin 41
23
12
NOTE: Extra pcs are provided.
17
11
7
*
1
2
5
8
3
22
19
20
7
18
10
17
12
13
21
16
20
Back top beam
2
12 Rubber ring
Part No. Part No.
1
4
11
15
9
14
Left side panel
2
1
2
6
7
3
21
18
19
5
17
9
16
11
12
20
15
4
10
14
8
13
6
23 Hex wrench 1
121609
203902
121659
121607
242910
236270
312033
118124
304236
236397
237444
314219
118123
306018
313066
320327
121608
113539
320328
242909
572161
317023
*
*
304196

ASSEMBLY INSTRUCTIONS
5
STEP 1 ATTACH THE SIDE AND BOTTOM PANELS
View from under
the cabinet
Front
Back
B
C
D
A
B
C
D
A
STEP 2 INSTALL THE ADJUSTABLE FEET
Install the adjustable feet to the bottom panel. Make sure the sides A of the adjustable feet are facing
either towards the back or the front of the cabinet.
Tighten securely with sixteen M6 x 16 hex socket head screws.
18
7
18
5
20
6
6
STEP 2 ATTACH THE SIDE AND BOTTOM PANELS
Attach the side panels to the bottom panel with six M6 x 16 hex socket head screws.
Back
STEP 1 ATTACH THE SIDE AND BOTTOM PANELS
ASSEMBLY INSTRUCTIONS
TOOLS REQUIRED FOR ASSEMBLY
• Hex Wrench (23)
• Power Drill (not included)
• Measuring Tape (not included)
Please wear gloves during the whole assembly process.
NOTE: Assemble on a flat surface. A piece of cardboard is recommended to keep the product
from being scratched during assembly.
•
6
1
17
16
Back
18
1
17
4
Lay the bottom panel (4) on its front and attach the side panels (1 & 18) to the bottom
panel (4) with two M6 x 16 hex socket head screws (17) through the holes on bottom left
and right corners. DO NOT tighten.
•Screw two M6 x 16 hex socket head screws (17) in the middle of the bottom. Tighten securely.

6
model no. 068-0004-2 I contact us 1-800-689-9928
ASSEMBLY INSTRUCTIONS
STEP 4 ATTACH THE TOP BEAMS
18
19
1
Attach the front top beam to the side panels with four M6 x 16 hex socket head screws.
Insert the screws by hand. DO NOT tighten.
•
View from inside of cabinet
5
20
1 2 3
STEP 3 ATTACH THE DOOR STOPPER
First press the two trapezoidal taps at the centre of the front top beam inwards by 90 degrees.
•
Insert the door stopper onto the two taps. Make sure the magnets are outside of the front
top beam and face toward the front of the cabinet.
•
Finally, bend the two trapezoidal taps of the front top beam outwards until they are against the
door stopper.
•
Attach the back top beam to the side panels with two M6 x 16 hex socket head screws.
Insert the screws by hand. DO NOT tighten.
•
Turn over.
•
Turn over
model no. 068-1554-6 I contact us 1-800-689-9928
STEP 2 ATTACH THE BACK TOP BEAM AND BACK PANELS
18 20
16
Insert the top edge of top back
panel under the back top beam.
Attach the back top beam (21) and back panels (19) to the back.
Insert sixteen M6 x 16 hex socket head screws (17) by hand.
DO NOT tighten.
The top edge of the top back panel (19) should be inserted under the back top
beam (21).
21
19
17
STEP 3 INSTALL THE ADJUSTABLE FEET
Install the adjustable feet (16) to the bottom panel (4). Tighten securely with
sixteen M6 x 16 hex socket head screws (17).
17
16
4

ASSEMBLY INSTRUCTIONS
7
STEP 6 ATTACH THE STAINLESS STEEL TOP
Attach the stainless steel top to the cabinet
top by inserting four M6 x 16 hex socket head
screws through the pre-drilled holes in the
top beams to the stainless steel top.
Tighten securely.
STEP 5 ATTACH THE BACK PANELS
Lay the cabinet on its face.
•
Attach the back panels to the back of the cabinet with fourteen M6 x 16 hex socket head
screws. Insert the screws by hand. DO NOT tighten.
•
Make sure your floor is free of debris or the cabinet
face is protected before laying the cabinet on its face.
The top edge of the top back panel should be inserted
under the back of the back top beam.
Insert the top edge of top back
panel under the back top beam.
22
18
1
19
STEP 4 ATTACH THE DOOR STOPPER AND THE FRONT TOP BEAM
Stand up the cabinet.
•
•
•
1
23
STEP 3 ATTACH THE DOOR STOPPER
First press the two trapezoidal tabs at the centre of the front top beam (5) inwards by 90 degrees.
•
Insert the door stopper (6) onto the two tabs. Make sure the magnets are outside of the front
top beam (5) and face toward the front of the cabinet.
•
Finally, bend the two trapezoidal tabs of the front top beam outwards until they are against the door
stopper.
•
STEP 4 ATTACH THE DOOR STOPPER AND FRONT TOP BEAM
Stand up the cabinet and tear off the protective film for front top beam (5).
Attach the front top beam (5) to the side panels (1 & 17) with four M6 x 16 hex socket
head screws (16). DO NOT tighten.
Screwing four M6 x 16 hex socket head screws (16) through the side panels (1 & 17) to
the bottom panel (6). DO NOT tighten.
•
•
•
16
1
5
6
17
5
5
17
4
1
18
STEP 5 ATTACH THE RUBBERWOOD TOP
Attach the rubberwood top (22) to the cabinet top by inserting
four M6 x 16 hex socket head screws (17) through the
pre-drilled holes underneath. Tighten securely.
•
•
At the same time, square up the cabinet and make sure
the inner diagonal lines are equal with the help of a
measuring tape. Tighten all screws on front and back.
17
20
22
6
Stand up the cabinet.
Attach the front top beam (5) to the side panels (1 & 18) with four M6 x 16 hex socket head screws (17).
DO NOT tighten.
Screwing four M6 x 16 hex socket head screws (17) through the side panels (1 & 18) to
the bottom panel (4). DO NOT tighten.
Attach the front top beam (5) to the side panels (1 & 18) with four M6 x 16 hex socket head screws (17).
DO NOT tighten.
Screw four M6 x 16 hex socket head screws (17) through the side panels (1 & 18) into
the bottom panel (4). DO NOT tighten.

8
ASSEMBLY INSTRUCTIONS
STEP 6 ATTACH THE DOORS
12 3
45
•Lay down the left door on its face with a soft mat underneath. Pull the bottom locking tab at the
right bottom corner of the door outwards. Insert a pin through the hole at the door’s bottom
corner and put a rubber ring into the pin’s vertical end.
•Repeat the same procedure to install the right door.
When push the locking tab back to its place, make sure the
end of the pin's horizontal part is inserted into the hole of the
locking tab to ensure the pin is well secured.
View from door bottom
View from door top
locking tab
•Push back the bottom locking tab to its place. Insert the horizontal end of the pin into the hole at
the locking tab at the same time.
•Take up the left door and insert the pin into the hole at the left bottom corner of the bottom
panel.
•Pull the upper locking tab at the right top corner of the door outwards. Insert a pin through the
hole at door’s right top corner into the hole at the left top corner of the cabinet.
•Push back the upper locking tab to its place. Insert the horizontal end of the pin into the hole at
the locking tab at the same time.
•Close the doors to see if the doors can touch the magnets completely. If not, adjust the cabinet’s
top and side panels to make sure the shape of the cabinet is square and flush. Until the doors can
catch the magnets completely, tighten the top and back panels’ screws.
12 3
45
14
6
8
15
View from door bottom
View from door top
locking tab
13
STEP 6 ATTACH THE DOORS
•Lay down the right door (8) on its face with a soft mat underneath. Pull the bottom locking tab at the
left bottom corner of the door outwards. Insert a pin (11) through the hole at the door’s bottom
corner and put a rubber ring (12) into the pin’s vertical end.
•Repeat the same procedure to install the left door (13).
•Push back the bottom locking tab to its place. Insert the horizontal end of the pin (11) into the hole at
the locking tab at the same time.
•Take up the right door (8) and insert the pin (11) into the hole at the right bottom corner of the bottom
panel (4).
•Pull the upper locking tab at the left top corner of the door outwards. Insert a pin (11) through the
hole at door’s left top corner into the hole at the right top corner of the cabinet.
•Push back the upper locking tab to its place. Insert the horizontal end of the pin (11) into the hole at
the locking tab at the same time.
1 2 3
4
View from door bottom
View from door top
locking tab
5
11
10
12
7
11
12
13
8
model no. 068-1554-6 I contact us 1-800-689-9928
•Lay down the left door (13) on its face with a soft mat underneath. Pull the bottom locking tab at the
right bottom corner of the door outwards. Insert a pin (11) through the hole at the door’s bottom
corner and put a rubber ring (12) onto the pin’s vertical end.
•Repeat the same procedure to install the right door (8).
•Push back the bottom locking tab to its place. Insert the horizontal end of the pin (11) into the hole at
the locking tab at the same time.
•Take up the left door (13) and insert the pin (11) into the hole at the left bottom corner of the bottom
panel (4).
•Pull the upper locking tab at the right top corner of the door outwards. Insert a pin (11) through the
hole at door’s right top corner into the hole at the left top corner of the cabinet.
•Push back the upper locking tab to its place. Insert the horizontal end of the pin (11) into the hole at
the locking tab at the same time.

9
ASSEMBLY INSTRUCTIONS
STEP 7 INSTALL THE LOCKING HOOK
9
3
2
4
This section must
be inserted into
the square hole.
1
Install the lock per Step 1, ensuring the lock code stays on top of the lock face. Release the
nut from the lock back and attach the locking hook per Step 3. Tighten the hook securely
with the nut previously removed from the lock back as shown in Step 4.
Shelf locked by shelf
bracket after installation
Slots on the inner back
side of side panel
Slots on the inner front
side of side panel
3
4
20
5
STEP 8 INSTALL THE SHELF
Insert four shelf brackets into the slots on the side panels at the desired height.
Make sure the four brackets are at the same height. Place the shelf over the shelf
brackets.
NOTE: To use the locking mechanism, the shelf must be placed in the
centre position.
•
Install the lock (9) as shown below, ensuring the lock code stays on top of the lock face. Release
the nut from the lock (9) back and attach the locking hook (10) as shown in illustration 3 below.
Tighten the hook (10) securely with the nut previously removed from the lock (9) back as shown
in illustration 4.
STEP 7 INSTALL THE LOCKING HOOK
8
3
2
4
This section must be
inserted into the
square hole.
1
9
9
10
STEP 8 INSTALL THE SHELF
Insert four shelf brackets (2) into the slots on the side panels (1 & 18) at the desired height.
Make sure the four brackets (2) are at the same height. Place the shelf (3) over the shelf
brackets (2).
2
3
2
3

10
ASSEMBLY INSTRUCTIONS / OPERATION / MAINTENANCE
COORDINATING PRODUCTS / ASSEMBLY INSTRUCTIONS
Place the cabinet on a flat floor against a wall. Use a power drill to attach the cabinet to the
wall with two M6 x 40 hex tapping screws through the holes at the back top beam.
Tighten securely. For safety, the screws shall be drilled into the studs of the wall. The cabinet
is ready for use.
STEP 9 SECURE THE CABINET TO WALL
model no. 068-1554-6 I contact us 1-800-689-9928
COORDINATING PRODUCTS
This product coordinates well with the units below to offer our best storage solutions.
They can be combined into various combinations to meet different storage requirements.
2-Door Tall Cabinet
068-0006-8
Wall Cabinet
068-0005-0
28" (71 cm)
Base Cabinet
068-1554-6
28" (71 cm) Base
Cabinet with Drawers
068-1575-6
54" (137 cm)
Workstation
068-1577-2
48 x 72" (122 x 183 cm)
Tall Cabinet
068-1576-4
STEP 9 SECURE THE CABINET TO WALL
Place the cabinet on a flat floor against a wall. Use a power drill to attach the cabinet to the
wall with two M6 x 40 hex tapping bolts (20) through the holes at the back top beam (21).
Tighten securely. For safety, the bolts should be drilled into the studs of the wall. The cabinet
is ready for use.
21
19
20

11
KNOW YOUR CABINET
WARRANTY
LIMITED WARRANTY
This product is guaranteed for 1 year from the date of original retail purchase against defects in
materials and workmanship.
Subject to the conditions and limitations described below, this product, if returned to us with a proof
of purchase within the stated warranty period and if covered under this warranty, will be repaired or
replaced (with the same model, or one of equal value or specification), at our option. We will bear
the cost of any repair or replacement and any costs of labour relating thereto.
This warranty is subject to the following conditions and limitations:
A sales receipt that indicates the date of purchase must be provided;
This warranty will not apply to any product or part thereof which is worn or broken or which
has become inoperative due to abuse, misuse, accidental damage, neglect or lack of proper
installation, operation or maintenance (as outlined in the applicable owner's manual or
operating instructions) or which is being used for industrial, professional, commercial or
rental purposes;
This warranty will not apply to normal wear and tear or to expendable parts or accessories
that may be supplied with the product that are expected to become inoperative or unusable
after a reasonable period of use;
This warranty will not apply to routine maintenance and consumable items such as, but not
limited to, fuel, lubricants, vacuum bags, blades, belts, sandpaper, bits, fluids, tune-ups or
adjustments;
(i.e., persons not authorized by the manufacturer);
This warranty will not apply to any product that was sold as a reconditioned or refurbished
product (unless otherwise specified in writing);
This warranty will not apply to any product or part thereof if any part from another
manufacturer is installed therein or any repairs or alterations have been made or attempted
by unauthorized persons;
This warranty will not apply to normal deterioration of the exterior finish, such as, but not
limited to, scratches, dents, paint chips, or to any corrosion or discolouring by heat, abrasive
and chemical cleaners; and
This warranty will not apply to component parts sold by and identified as the product of
another company, which shall be covered under the product manufacturer's warranty, if any.
Additional Limitations
This warranty applies only to the original purchaser and may not be transferred. Neither the retailer
nor the manufacturer shall be liable for any other expense, loss or damage, including, without
limitation, any indirect, incidental, consequential or exemplary damages arising in connection with
the sale, use or inability to use this product.
Notice to Consumer
This product is not guaranteed if used for industrial or commercial purposes.
This warranty gives you specific legal rights, and you may have other rights, which may vary from
province to province. The provisions contained in this warranty are not intended to limit, modify,
take away from, disclaim or exclude any statutory warranties set forth in any applicable provincial
or federal legislation.
Made in China.
Imported by Mastercraft Canada Toronto, Canada M4S 2B8
a)
b)
c)
d)
e)
f)
g)
h)
ti)
This warranty will not apply if damage is caused by repairs made or attempted by others
