MasterCraft 068-1224-2 User manual

model no. 068-1224-2
Please read this manual carefully before installing this
cabinet and save it for reference.
BASE CABINET
size:210x285mm

3
7
15
16
SAFETY GUIDELINES
PARTS LIST
ASSEMBLY INSTRUCTIONS
MASTERCRAFT LINE
WARRANTY

5
PARTS LIST
No. Description Qty. No. Description Qty.
1 Solid Hardwood Top 1
11D Large Drawer Back Panel 2
2 Front Frame 1
11E Large Drawer Base Panel 2
3 Back Frame 1
12 Wheel With Brake 2
4 Left Side Panel 1
13 Wheel W/O Brake 2
5 Right Side Panel 1
14 M8 x 18L Screw 4
6 Middle Shelf 1
15 M8 Washer 4
7 Base Panel 1
16 M4 x 8L Screw 61
8 Middle Panel 1
17 M4 x 8L Screw 78
9 Door 1
18 Back Corner Protector 2
10A Small Drawer Front Panel 2
19 Right Side Push Bar 1
20 Left Side Push Bar 1
10E Small Drawer Case 2
21 Screwdriver 1
11A Large Drawer Front Panel 2
22 Key 2
11B Large Drawer Left Panel 2
24 Drawer Mat 4
11C Large Drawer Right Panel 2
25 Wrench 1
26 Magnet 2
42 M4 x 30L Screw 16
57 Bumper 4
1
14 M8
M4 x 8L
M8 x 18L
M4 x 8L
M4 x 30L
16
42
15
17

6
model no. 068-1224-2 contact us 1-866-221-8146
17
16
18
5
57
42
13
3
2
4
20
24
10
11
8
19
1
15
6
26
9
7
14
12
11A
17
11B
11D
11C
11E
Small Drawer (10) Large Drawer (11)
10E
10A
17

7
1
14
15
25
3
5
Fig A
Fig B
Open both boxes, locate and remove the
cardboard box containing the Solid Hardwood
Top (1). Set the other parts to the side.
When assembling this item, place the Solid
Hardwood Top upside down on the cardboard to
avoid scratching the top surface (see Fig A).
[Use the Wrench (25) for this step.]
Place the Back Frame (3) as the
left picture shows and use 2 pcs
Screw (14) and Washers (15) to
fasten. Attach the "Top" of the
Back Frame (3), as indicated by
the attached sticker, to the Solid
Hardwood Top (1) (The Solid
Hardwood Top has no set front or
back end) (see Fig B).
Note: Ensure the back and side
are flush with the Solid Hardwood
Top. When assembling a part, do
not tighten any screws completely
until all screws for that part have been partially screwed in.
Step 1:
Step 2: Install Back Frame (3) to Solid
Hardwood Top (1).

8
model no. 068-1224-2 contact us 1-866-221-8146
16
5
8
16
Fig C
Fig D
Attach Right Side Panel (5) to Back Frame (3),
making sure the "Top" of Right Side Panel (5) is
on the Solid Hardwood Top (1). Use 3 pcs of Screw
(16) and Screwdriver (21) to fasten (see Fig C).
Step 3: Install Right Side Panel (5).
Attach the Middle Panel (8) to the Back Frame (3)
and Solid Hardwood Top (1) as the left picture
shows, making sure the "Top" of Middle Panel (8)
is attached on the Solid Hardwood Top (1). Again,
the “Top” is indicated by a sticker on one of the
vertical columns. Use 3 pcs of Screw (16) and
Screwdriver (21) to fasten (see Fig D).
Step 4: Install Middle Panel (8).

9
4
16
2
15
14
16
Fig E
Fig F
Attach Left Side Panel (4) to Back Frame (3),
making sure the "Top" of Left Side Panel (4) is
on the Solid Hardwood Top (1). Use 3 pcs of
Screw (16) and Screwdriver (21) to fasten
(see Fig E).
Step 5: Install Left Side Panel (4).
A: Attach the "Top" of the Front Frame
(2) to the Solid Hardwood Top (1).
The other screw holes will align with
the Left and Right Side Panels (4 and
5) and Middle Panel (8).
B: Use 9 pcs of Screw (16) and
Screwdriver (21) to fasten the Front
Frame (2) on the Left and Right Side
Panels (4 and 5) and Middle Panel (8).
C: Make sure the four edges of the
Cabinet are aligned, then fasten the
Front Frame (2) on the Solid
Hardwood Top (1) by using 2 pcs of
Washer (15) and Screw (14) with
Wrench (25) (see Fig F).
Step 6: Install The Front Frame (2).

10
model no. 068-1224-2 contact us 1-866-221-8146
57
42
Fig H
Fig G
A: Fit the Bottom Panel (7) between the
Back Frame (3) and Front Frame (2) as
shown ins Fig G, line up the screw holes
and use Screw (16) to tighten it.
B: Attach Wheels (12 and 13) using the
Wrench (25) to tighten. Make sure that
the Wheels w/o Brakes (13) are on the
Back Frame (3), and Wheels with Brakes
(12) are on the Front Frame (2) (see Fig G).
Attach Bumpers (57) to the bottom four
corners of the Cabinet. Use 16 pcs of
Screw (42) to fasten. Then, rotate/
stand the Cabinet upright (see Fig H).
Step 7: Install the Base Panel (7) & Wheel (12)
and (13).
Step 8: Install the Bumper (57).
12
13
16
73
2

10E 17
11
18
16
19
26
20
10E
Fig I
Fig J
Fig K Fig L
A: Attach the Back Corner Protector (18)
to the left and right side of the Back
Frame (3), and use 12 pcs Screw (16)
and Screwdriver (21) to tighten.
B: Attach the Left Push Bar (20) to left
side of the Front Frame (2), and attach
the Right Push Bar (19) to right side of
the Front Frame (2), and use 14 pcs
Screw (16) to tighten.
C: Use 4 pcs of Screw (16) to fasten
the Magnet (26) on the Front Frame
(2) (see Fig I).
A: Fold up all three panels of the Small Drawer Body
(10E) and use Screw (17) to tighten the back panel
to the Left and Right Side Panels (see Fig J and Fig K).
B: Insert the Small Drawer Body (10E) into the Small
Drawer Front Panel (10A) and use Screw (17) to tighten (see Fig L).
C: Repeat A and B to install another small drawer.
Step 9: Install the Back Corner
Protector (18) and Left & Right Push
Bar (20 &19) and Magnet (26).
Step 10: Install the Small Drawer (10).
17
10A

11
11
13
17
24
Fig P
Fig Q
Fig R
Note: Pull out the ball
bearing track completely
before you attach drawer.
The oval hole at the front of the slider allows for the gaps
between the drawers to be adjusted. Make the adjustments
once all the drawers are installed.
A: Pull out the sliders completely, then attach the
drawer to the sliders. Make sure the square holes
on the drawer side panels are lined up, and the
drawer is hooked onto the sliders completely
(see Fig P and Fig Q).
B: Use 4 pcs Screw (17) to tighten the drawer,
and put the Drawer Mat (24) into the drawer
(see Fig R).
Repeat above steps to place other drawers.
Note: Do not tighten any screws completely
until all the drawers are adjusted well.
Step 14: Place the Drawers.

14
model no. 068-1224-2 contact us 1-866-221-8146
9
16
Fig S
Fig T
Place the Middle Shelf (6) in the unit at
the desired height and ensure that all
four corners are secured on the hooks
on the Front and Back Frame (see Fig S).
Step 15: Install the Middle Shelf (6).
Attach the Door (9) to the right side of
the Cabinet. Use 5 pcs Screw (16) to fasten
(see Fig T).
Step 16: Install the Door (9).
6
Stainless Steel Maintenance:
These parts are given a fingerprint-resistant finish. Do not use traditional stainless steel cleaners on this
unit. Lightly wipe off once a month with clean warm water and a soft cloth (preferably a micro fibre cloth).
This is the safest formula to prevent new stains from appearing over time and manage unwanted
fingerprints or grease marks. Remember to always wipe in the direction of the surface grain (NEVER
ACROSS) and always use a lint-free cloth. Once the surface is clean, thoroughly wipe dry with a soft
absorbent cloth.
FINGERPRINT RESISTANT SURFACES AND INCREASED DURABILITY

15
Model no. 068-0667-4
MC TALL STORAGE CABINET
Model no. 068-0558-4
MC BASE CABINET
Model no. 068-1221-8
MC STORAGE CABINET
Model no. 068-6099-0
MC WORKBENCH
Model no. 068-7305-4
MC ROLLING CABINET
Model no. 068-1226-8
MC WALL CABINET
Model no. 068-7306-2
MC 36" WALL CABINET
Model no. 068-7430-4
MC 4-DRAWER STORAGE CHEST
Model no. 068-7428-2
MC WORK CENTRE
MASTERCRAFT LINE

16
model no. 068-1224-2 contact us 1-866-221-8146
Made in China
Imported by
Mastercraft Canada Toronto, Canada M4S 2B8
This Mastercraft product carries a three (3) year replacement warranty against defects in
workmanship and materials. Mastercraft Canada agrees to replace the defective product
free of charge within the stated warranty period, when returned by the original purchaser
with proof of purchase. This product is not guaranteed against wear or breakage due to
misuse and/or abuse.

4
5
7
15
16
CONSIGNES DE SÉCURITÉ
LISTE DES PIÈCES
CONSIGNES D’ASSEMBLAGE
GAMME MASTERCRAFT
GARANTIE

Communiquez avec nous au : 1-866-221-8146
Le présent guide contient des renseignements relatifs à la SÉCURITÉ ET À LA PRÉVENTION DES
PROBLÈMES AVEC LE MATÉRIAL. Il est très important de lire attentivement et de bien comprendre
ce guide avant d’utiliser le produit. Les symboles ci-dessous servent à indiquer cette information.
ATTENTION!
Danger potentiel qui peut provoquer des
Remarque : Le terme « Remarque » est utilisé
pour communiquer au lecteur un renseignement
essentiel sur le produit.
blessures moyennement graves ou des
dommages à l’équipement.
Ces mises en garde servent à assurer la sécurité de l'utilisateur et des gens qui l'aident. Le non-respect
de ces consignes peut entraîner une perte de vision permanente, des blessures graves ou même
mortelles, des dommages matériels ou causés à l'outil. Veuillez prendre le temps de les lire et de bien
les comprendre.
Danger potentiel qui peut provoquer des blessures moyennement graves
ou des dommages à l’équipement.
• L'armoire doit être placée sur une surface plane.
• Elle est destinée à être utilisée à l'intérieur uniquement.
• Vérifiez périodiquement que tous les écrous et boulons sont serrés.
• Utilisez un chiffon doux humide pour nettoyer l'armoire.
• Ne montez pas sur l'armoire et ne l'utilisez pas comme échafaudage.
• Ne dépassez pas la limite de poids indiquée pour cette armoire.
• L'assemblage et l'entretien de cette armoire ne doivent être effectués que par des adultes.
• Faites équipe avec quelqu'un pour assembler et déplacer l'armoire.
• N’excédez pas les limites de poids suivantes pour ce produit :
Charge maximale du plan de travail en bois : 430 lb (195,4 kg)
Charge maximale du panneau inférieur : 90 lb (40 kg)
Charge maximale de la tablette centrale : 70 lb (31,8 kg)
Charge maximale du tiroir : 40 lb (18,1 kg)
Charge maximale de l'armoire : 750 lb (340 kg)
068-1224-2
