MasterCraft 068-0004-2 User manual

model no. 068-0004-2
Stainless Steel Top
Base Cabinet
IMPORTANT
Please read this manual carefully before assembling and
using this product, and save it for reference.
INSTRUCTION
MANUAL
Due to continuing improvements,
the actual product may differ slightly
from the product described herein.

2
TABLE OF CONTENTS
3
3
5
10
11
TABLE OF CONTENTS
SAVE THESE INSTRUCTIONS
This manual contains important safety and
instructions and follow them carefully with use of this product.
operating instructions. Read all
NOTE:
If any parts are missing or damaged, or if you have any questions, please call our toll-free
helpline at: 1-800-689-9928. Have the product number, cash register receipt and the date
of purchase available when you call. DO NOT SHIP YOUR PRODUCT BACK TO THE STORE,
UNLESS WE SEND YOU WRITTEN INSTRUCTIONS FOR RETURN.
MAINTENANCE
COORDINATING PRODUCTS
WARRANTY
SAFETY
ASSEMBLY INSTRUCTIONS
model no. I contact us 1-800-689-9928068-0004-2
4
EXPLODED VIEW / PARTS LIST

To reduce the risk of serious injury, read and follow the safety instructions below before assembling
and using this product.
SAFETY
3
SAFETY / MAINTENANCE
Before assembling and using this product, carefully read this instruction manual and all of the labels
affixed to the product. Failure to follow all warnings and instructions may result in product damage or
personal injury.
Save all warnings and instructions for future reference.
-Maximum load: 400 lb (181 kg)
-Maximum load for shelf: 100 lb (45 kg)
-Maximum load for bottom panel: 150 lb (68 kg)
-Maximum load for stainless steel top: 150 lb (68 kg)
Keep the product on level surfaces. The product could become unstable and
stored or moved on an uneven surface, which may cause personal injury, death or product damage.
it may tip over if
This product is intended for indoor use only.
Any assembly or maintenance of the product must be carried out by adults only.
Use at least two people to move, assemble or install this cabinet. Failure to do so can result in
personal injury or product damage.
Check all nuts and bolts periodically for tightness. When required, tighten them.
Close and lock the doors before moving this cabinet.
DO NOT alter this product in any manner. For example, do not weld external bar locks or attach
electrical equipment. This may cause product damage or personal injury.
DO NOT leave children unattended near this product. Cabinets may tip over if improperly opened.
DO NOT stand or lean on the product.
DO NOT exceed the following weight limits for this product.
Periodically clean the surfaces with a soft rag and water.
Grease and oil can be removed with most standard cleaning fluids.
For safety, use a nonflammable cleaning fluid.
MAINTENANCE
This product is not designed for commercial nor industrial usage.

EXPLODED VIEW / PARTS LIST
Description
No. Qty. No.
2
2Back panel
Shelf bracket 4
3
14 Shelf
1
4
5
7
Right side panel
Back top beam 1
1
Description Qty.
No. Description No. Qty.
13
14
15
16
18
2
4
1
2
1
EXPLODED VIEW / PARTS LIST
1
6
17
19
Rubber ring
Pin
Left door
Magnet
Door stopper
M6x16 hex socket head screw
50
4
model no. I contact us 1-800-689-9928068-0004-2
NOTE:
be required.
Give information for spare parts: part number and quantity required.
Replacement keys may be ordered. Call our toll-free number. The code which appears on the lock will
Bottom panel
9
Adjustable foot
Lock
1
8Right door
2
10 Key
121
Left side panel
1
20
Front top beam
2
22 Stainless steel top
1
18 23
14
13
11 Door handle 2
Hex wrench
1
1
NOTE: Extra M6 x 16
hex socket head screw(s)
is (are) provided.
16
*
*
1
2
5
6
3
21
19
17
18
4
15
14 7
16
13
12
8
9
20
10
11
22
21
23 1
M6 x 40 hex tapping bolt
1
12 Locking hook

ASSEMBLY INSTRUCTIONS
5
STEP 1 INSTALL THE ADJUSTABLE FEET
Install the adjustable feet (7) to the bottom panel (6). Make sure the sides A of the adjustable feet (7)
are facing either towards the back or the front of the cabinet. Tighten securely with sixteen M6 x 16
hex socket head screws (18).
NOTE:
A
being scratched during assembly.
ssemble on a flat surface. A piece of cardboard is recommended to keep the product from
View from under
the cabinet
Front
Back
B
C
D
A
B
C
D
A
STEP 2 ATTACH THE SIDE AND BOTTOM PANELS
Attach the side panels (5 and 20) to the bottom panel (6) with eight M6 x 16 hex socket head screws (18).
18
7
18
5
20
6
ASSEMBLY INSTRUCTIONS
TOOLS REQUIRED FOR ASSEMBLY
• Hex wrench (23)
• Power drill (not included)
6

6
model no. I contact us 1-800-689-9928068-0004-2
ASSEMBLY INSTRUCTIONS
STEP 4 ATTACH THE TOP BEAMS
18
19
1
Attach the front top beam (19) to the side panels (5 and 20) with six M6 x 16 hex socket head screws (18).
Insert the screws by hand. DO NOT tighten.
•
Attach the back top beam (1) to the side panels with two M6 x 16 hex socket head screws (18).
Insert the screws by hand. DO NOT tighten.
(5 and 20)
•
View from inside of cabinet
5
20
1 2 3
STEP 3 ATTACH THE DOOR STOPPER
First press the two trapezoidal taps at the centre of the front top beam (19) inwards by 90 degrees.
•
Insert the door stopper (17) onto the two taps
top beam and face toward the front of the cabinet.
. Make sure the magnets (16) are outside of the front
•
Finally, bend the two trapezoidal taps of the front top beam (19) outwards until they are against the
door stopper (17).
•
19
17
16

ASSEMBLY INSTRUCTIONS
7
STEP 6 ATTACH THE STAINLESS STEEL TOP
Attach the stainless steel top (22) to the cabinet
top by inserting four M6 x 16 hex socket head
screws (18) through the pre-drilled holes in the
top beams (1 and 19) to the stainless steel top (22).
Tighten securely.
22
18
1
19
STEP 5 ATTACH THE BACK PANELS
Insert the top edge of top back
panel under the back top beam.
Lay the cabinet on its face.
•
Attach the back panels (2) to the back of the cabinet with fourteen M6 x 16 hex socket head
screws (18). Insert the screws by hand. DO NOT tighten.
•
Make sure your floor is free of debris or the cabinet
face is protected before laying the cabinet on its face.
The top edge of the top back panel should be inserted
under the back of the back top beam.
2
18

8
model no. I contact us 1-800-689-9928068-0004-2
ASSEMBLY INSTRUCTIONS
STEP 7 ATTACH THE DOORS
12 3
45
•Lay down the left door (15) on its face with a soft mat underneath. Pull the bottom locking tab at the
right bottom corner of the door outwards. Insert a pin (14) through the hole at the door’s bottom
corner and put a rubber ring (13) into the pin’s vertical end.
•Repeat the same procedure to install the right door (8).
When push the locking tab back to its place, make sure the
end of the pin's horizontal part inserted into the hole of the
locking tab to make the pin well locked.
14
6
8
15
View from door bottom
View from door top
locking tab
•Push back the bottom locking tab to its place. Insert the horizontal end of the pin (14) into the hole at
the locking tab at the same time.
•Take up the left door (15) and insert the pin (14) into the hole at the left bottom corner of the bottom
panel (6).
•Pull the upper locking tab at the right top corner of the door outwards. Insert a pin (14) through the
hole at door’s right top corner into the hole at the left top corner of the cabinet.
•Push back the upper locking tab to its place. Insert the horizontal end of the pin (14) into the hole at
the locking tab at the same time.
•Close the doors to see if the doors can touch the magnets (16) completely. If not, adjust the cabinet’s
top and side panels to make sure the shape of the cabinet is square and flush. Until the doors can
catch the magnets (16) completely, tighten the top and back panels’ screws.
13

9
ASSEMBLY INSTRUCTIONS
STEP 9 INSTALL THE SHELF
Insert four shelf brackets (3) into the slots on the side panels (5 and 20) at the desired height.
Make sure the four brackets (3) are at the same height. Place the shelf (4) over the shelf
brackets (3), and push it down onto the shelf brackets (3). Make sure the shelf (4) is properly
and safely locked by the upright hooks of the shelf brackets (3).
Shelf locked by shelf
bracket after installation
Slots on the inner back
side of side panel
Slots on the inner front
side of side panel
3
4
STEP 8 INSTALL THE LOCKING HOOK
NOTE:
To use the locking mechanism, the shelf must be placed in the centre position.
20
5
9
3
2
4
This section must be
inserted into the
square hole.
1
12
Install the lock (9) per Step 1, ensuring the lock code stays on top of the lock face. Release the
nut from the lock (9) back and attach the locking hook (12) per Step 3. Tighten the hook (12)
securely with the nut previously removed from the lock (9) back as shown in Step 4.

10
ASSEMBLY INSTRUCTIONS / OPERATION / MAINTENANCE
model no. I contact us 1-800-689-9928068-0004-2
COORDINATING PRODUCTS / ASSEMBLY INSTRUCTIONS
COORDINATING PRODUCTS
This product coordinates well with the units below to offer a best storage solution. They can be
combined into various combinations to meet different storage requirements.
Tall Cabinet
068-0006-8
Wall Cabinet
068-0005-0
Stainless Steel Top
Base Cabinet
068-0004-2
Place the cabinet on a flat floor against a wall. Use a power drill to attach the cabinet to the
wall with two M6 x 40 hex tapping screws (21) through the holes at the back top beam (1).
Tighten securely. For safety, the screws shall be drilled into the studs of the wall. The cabinet
is ready for use.
21
1
STEP 10 SECURE THE CABINET TO WALL

11
KNOW YOUR CABINET
WARRANTY
LIMITED WARRANTY
This product is guaranteed for 1 year from the date of original retail purchase against defects in
materials and workmanship.
Subject to the conditions and limitations described below, this product, if returned to us with a proof
of purchase within the stated warranty period and if covered under this warranty, will be repaired or
replaced (with the same model, or one of equal value or specification), at our option. We will bear
the cost of any repair or replacement and any costs of labour relating thereto.
This warranty is subject to the following conditions and limitations:
A sales receipt that indicates the date of purchase must be provided;
This warranty will not apply to any product or part thereof which is worn or broken or which
has become inoperative due to abuse, misuse, accidental damage, neglect or lack of proper
installation, operation or maintenance (as outlined in the applicable owner's manual or
operating instructions) or which is being used for industrial, professional, commercial or
rental purposes;
This warranty will not apply to normal wear and tear or to expendable parts or accessories
that may be supplied with the product that are expected to become inoperative or unusable
after a reasonable period of use;
This warranty will not apply to routine maintenance and consumable items such as, but not
limited to, fuel, lubricants, vacuum bags, blades, belts, sandpaper, bits, fluids, tune-ups or
adjustments;
(i.e. persons not authorized by the manufacturer);
T reconditioned or refurbished his warranty will not apply to any product that was sold as a
product (unless otherwise specified in writing);
This warranty will not apply to any product or part thereof if any part from another
manufacturer is installed therein or any repairs or alterations have been made or attempted
by unauthorized persons;
This warranty will not apply to normal deterioration of the exterior finish, such as, but not
limited to, scratches, dents, paint chips, or to any corrosion or discolouring by heat, abrasive
and chemical cleaners;
This warranty will not apply to component parts sold by and identified as the product of
another company, which shall be covered under the product manufacturer's warranty, if any.
Additional Limitations
This warranty applies only to the original purchaser and may not be transferred. Neither the retailer
nor the manufacturer shall be liable for any other expense, loss or damage, including, without
limitation, any indirect, incidental, consequential or exemplary damages arising in connection with
the sale, use or inability to use this product.
Notice to Consumer
This product is not guaranteed if used for industrial or commercial purposes.
This warranty gives you specific legal rights, and you may have other rights, which may vary from
province to province. The provisions contained in this warranty are not intended to limit, modify,
take away from, disclaim or exclude any statutory warranties set forth in any applicable provincial
or federal legislation.
Made in China.
Imported by Mastercraft Canada Toronto, Canada M4S 2B8
a)
b)
c)
d)
e)
f)
g)
h)
ti)
This warranty will not apply if damage is caused by repairs made or attempted by others
