Matatakitoyo Torque Tools MOT2 User manual

Quick release button design.
Push the button to release socket.
PUSH
0
Insert square drive securely to the socket.
0
Quick Release
Ratchet Lever Tube
Main Scale Graduation Scale
Hand Force
Knob
Grip
1. Study this instruction before use.
2. This torque wrench as calibrated and tested before leaving the factory is certified to meet the current standard specification and has
an accuracy of C.W.±4% / C.C.W.±6%.
3. THIS TOOL IS A PRECISION MEASUREMENT AND DESIGNED FOR MANUAL TIGHTENING FASTERNERS ONLY.
DO NOT USE IT AS A NUT BREAKER OR FOR ANY OTHER PURPOSE.
4. Over torque will cause tool damage and personal injury.
5. Do not use this tool near rotating machinery.
6. Disassemble this tool or make any adjustments will result of losing accuracy and void the warranty.
7. Do not continuously apply force after hear click or feel shock.
8. Do not use any format of extension on the handle of the tool. This will not only damage the tool, also affect the accuracy.
9. Do not immerse grease inside ratchet head. It may cause unexpected damage.
10. Use special care at minimum torque setting.
11. Please wear gloves and goggles when working.
BEFORE STARTING
HOW TO USE CONTENTS
ManualSupplied in a plastic box.
Torque wrench
left right center
Position of ratchet lever for clockwise/counter clockwise tightening.
Manual
WARNING
Do not continuously apply force after hear click or feel shock.
STOP
CLICK
Choose quality socket
3/8” 3/4”1/2”
1-1/2”
1/4” 1”
TORQUE
MOT2
OPERATION MANUAL
Adjustable Torque Ｗｒｅｎｃｈ
Models covered

E-mail:[email protected]om
www.matatakitoyo.com Made in Taiwan
MATATAKITOYO TOOL CO., LTD.
No. 63, Ln. 493, Sec. 3, Zhongshan Rd., Tanzi Dist.,
Taichung City 42754, Taiwan
TEL : [phone]
Manufacturer
1. Please return torque value to just below lowest reading when not in use. Do not turn below lowest reading. (see D)
2. If this tool has not been used for a period of time, it shall be preloaded several times at its maximum torque setting.
This will allow internal lubricant to recoat.
3. Clean this tool by wiping with a clean cloth after operation and storage in a dry environment.
Do not dip any type of liquid in this tool. This may damage the internal of this tool.
4. This tool should be recalibrated a period of 12 months, or 5,000 cycles,
whichever occurs first. To contact with local vendor,
an authorized repair center for supporting.
MOT2-15N
MOT2-30N
MOT2-60N
MOT2-100N
MOT2-200N
MOT2-320N
MOT2-500N
MOT2-800N
MOT2-1000N
MOT2-1500N
MOT2-2000N
MOT2-3000N
0.4 Nm
0.2 Nm
0.5 Nm
0.5 Nm
1 Nm
2 Nm
4 Nm
5 Nm
5 Nm
10 Nm
10 Nm
20 Nm
3-15 Nm
6-30 Nm
10-60 Nm
20-100 Nm
40-200 Nm
60-320 Nm
100-500 Nm
100-800 Nm
200-1000 Nm
300-1500 Nm
400-2000 Nm
600-3000 Nm
1/4”
1/4”
3/8”
3/8”
1/2”
1/2”
3/4”
3/4”
3/4”
1”
3/4”
1”
1”
1-1/2”
ØD
26.2
26.2
40.0
40.0
40.0
40.0
40.0
40.0
40.0
40.0
40.0
40.0
H
24.0
24.0
32.3
32.3
40.3
40.3
55.0
55.0
54.0
60.4
57.0
66.8
66.8
107.9
W
28.5
28.5
36.9
36.9
43.9
43.9
64.4
64.4
64.4
65.8
79.7
79.7
68.2
0.27
0.30
1.07
1.14
1.36
1.69
3.65
5.48
6.30
11.87
13.78
23.00
KG
A
MOT2-150i
MOT2-250i
MOT2-45F
MOT2-75F
MOT2-150F
MOT2-230F
MOT2-300F
MOT2-600F
MOT2-700F
MOT2-1000F
MOT2-1500F
MOT2-2000F
2 in.lb
5 in.lb
0.5 ft.lb
0.5 ft.lb
1 ft.lb
2 ft.lb
2.5 ft.lb
5 ft.lb
5 ft.lb
10 ft.lb
20 ft.lb
20 ft.lb
30-150 in.lb
50-250 in.lb
10-45 ft.lb
15-75 ft.lb
30-150 ft.lb
50-230 ft.lb
50-300 ft.lb
100-600 ft.lb
100-700 ft.lb
200-1000 ft.lb
300-1500 ft.lb
400-2000 ft.lb
1/4”
1/4”
3/8”
3/8”
1/2”
1/2”
3/4”
3/4”
3/4”
1”
3/4”
1”
1”
1-1/2”
ØD
L
202
235
420
460
515
585
820
1110
1334
1704
2160
3700
26.2
26.2
40.0
40.0
40.0
40.0
40.0
40.0
40.0
40.0
40.0
40.0
24.0
24.0
32.3
32.3
40.3
40.3
55.0
55.0
54.0
60.4
57.0
66.8
66.8
107.9
202
235
420
460
515
585
820
1110
1334
1704
2160
3700
LHW
28.5
28.5
36.9
36.9
43.9
43.9
64.4
64.4
64.4
65.8
79.7
79.7
68.2
0.27
0.30
1.07
1.14
1.36
1.69
3.65
5.48
6.30
11.87
13.78
23.00
KG
A
Metric SAE
ITEM NO. Range ITEM NO. Range
D
A B C
120140
Nm
Nm
5
120
140
Nm
Nm
5
Nm
5
40 Nm
Nm
0
40 Nm
Nm
TORQUE CONVERSION FACTORS
MAINTENCE AND STORAGE
HOW TO SET TORQUE VALUE
1 Years
5000 Times
L
W
ØD
H
A
0
For example : ITEM NO. MOT2-200N
To set torque to 135 Nm. Red line of main scale reach 130 Nm (see A) and
adjust graduation scale to 5 Nm (see B). Then 130+5=135Nm (see C)
1. Push down the lock ring to unlocked.
2. Turn the adjustable handle Clockwise or
Anti-clockwise (Right or left) to set the desired torque.
3. Pull upper the lock ring to set finished.
1 2 3
Unlock
開
Lock
關
Set
設定
Unit : mm
Accuracy : cw± 4% / ccw± 6%
SPECIFICATION
Units to be
converted
1 mN.m
1 cN.m
1 N.m
1 ozf.in
1 lbf.in
1 lbf.ft
1 gf.cm
1 kgf.cm(kp.cm)
1 kgf.m(kp.m)
1
10
1000
7.062
113
1356
0.098
98.07
9807
0.1
1
100
0.706
11.3
135.6
0.01
9.807
980.7
0.001
0.01
1
0.007
0.113
1.356
0.0001
0.098
9.807
0.142
1.416
141.6
1
16
192
0.014
13.89
1389
0.009
0.088
8.851
0.0625
1
12
0.0009
0.868
86.8
0.0007
0.007
0.738
0.005
0.083
1
0.00007
0.072
7.233
10.2
102
10197
72
1152.1
13826
1
1000
100000
0.01
0.102
10.2
0.072
1.152
13.83
0.001
1
100
0.0001
0.001
0.102
0.0007
0.0115
0.138
0.00001
0.01
1
=mN.m =cN.m =N.m =ozf.in =lbf.in =lbf.ft =gf.cm =kgf.cm
(kp.cm)
=kgf.m
(kp.m)
Corresponding unit
Conversion-formula :
Units to be converted × Factor = Corresponding unit
Example : Convert 5 lbf.ft into cN.m
Solution : 5 × 135.6 = 678 cN.m
MAY 2020
02
Edition
