Matrix AURA STRENGTH G3-S45 User manual

AURA STRENGTH
G3-S45 TRICEPS EXTENSION
MATRIX FITNESS |1600 LANDMARK DRIVE COTTAGE GROVE WI 53527 USA
Toll Free 866.693.4863 matrixfitness.com Fax [phone]
PART # 0000000000
REV. 1.7
ACTION FREQUENCY
Clean Upholstery Daily
Inspect Cables Daily
Clean Guide Rods Monthly
Inspect Hardware Monthly
Inspect Frame Bi-Annually
Clean Machine As Needed
Clean Grips As Needed
Lubricate Guide Rods As Needed
Upholstery & Grips should be cleaned with a non-ammonia based cleaner (like Simple Green) or a mild soap and water.
Guide rods should be lubricated with Teflon based lubricant. Apply the lubricant to a cotton cloth and then apply up and
down the guide rods.
MAINTENANCE CHECKLIST
PRODUCT SPECIFICATIONS
TECH SPECS
Overall dimensions 48”L X 43”W x 59”H (122 cm x 109 cm x 150 cm)
Weight 491 lbs (223 kg)
Shipping weight 521 lbs (236 kg)
WARRANTY (Valid in USA only)
Frame (not coatings) 10 years
Structural parts 10 years
Weight stacks 5 years
Pulleys 5 years
Pivot bearings 5 years
Any items not specified 3 years
Labor (excluding upholstery/cables/grips) 3 years
Upholstery/cables/grips/springs 1 year
IMPORTANT SAFETY INFORMATION
It is the sole responsibility of the purchaser of MATRIX Fitness Systems products to instruct all individuals, whether they
are the end user or supervising personnel on proper usage of the equipment.
It is recommended that all users of MATRIX Fitness Systems exercise equipment be informed of the following information
prior to its use.
PROPER USAGE
Do not use any equipment in any way other than designed or intended by the manufacturer. It is imperative that MATRIX
Fitness Systems equipment be used properly to avoid injury.
Keep hands and feet clear at all times from moving parts to avoid injury.
CHECK FOR DAMAGED PARTS
1. DO NOT use any equipment that is damaged and or has worn or broken parts. Use only replacement parts supplied by
your country’s local MATRIX Fitness Systems dealer.
2. MAINTAIN LABELS AND NAMEPLATES: Do not remove labels for any reason. They contain important information.
If unreadable or missing, contact your MATRIX Fitness Systems dealer for a replacement.
3. SECURING EQUIPMENT: All equipment MUST be secured to the floor to stabilize and eliminate rocking or tipping over.
This must be performed by a licensed contractor.
4. MAINTAIN ALL EQUIPMENT: Preventative maintenance is the key to smooth operating equipment as well as keeping
your liability to a minimum. Equipment needs to be inspected at regular intervals.
5. Ensure that any person(s) making adjustments or performing maintenance or repair of any kind is qualified to do so.
MATRIX Fitness Systems dealers will provide service and maintenance training at our corporate facility upon request.
WARNING: SERIOUS INJURY CAN OCCUR ON THIS EQUIPMENT. FOLLOW THESE PRECAUTIONS TO
AVOID INJURY!
1. Never allow children on freeweight or bench equipment. Teenagers must be supervised at all times while using
this equipment.
2. All warnings and instructions should be read and proper instruction obtained prior to use.
3. Cease exercise if you feel faint or dizzy. Obtain a medical exam before beginning an exercise program
4. Keep body, hair, clothing and fitness accessories free and clear of all moving parts.
5. Inspect the machine before use. DO NOT use machine if it appears damaged or inoperable.
6. This equipment should only be used in supervised areas where access and control are regulated by the owner.
IMAGE SHOWN MAY NOT REPRESENT FINAL PRODUCT
G3S45_AURA_triceps_extension_r1.7.indd 1 5/3/13 3:15 PM

AURA (G3-S45) TRICEPS EXTENSION
UNPACKING AURA (G3-S45) TRICEPS EXTENSION
Thank you for purchasing a MATRIX Fitness product. This machine is an EN957-1 and EN957-2 complaint Class S product. Your
MATRIX AURA (G3-S45) TRICEPS EXTENSION is inspected before it is packaged. It is shipped in multiple pieces to facilitate the
compact packaging of the machine. Prior to assembly, confirm all the components by matching them with the exploded diagrams.
Carefully unpack the unit from this box and dispose of the packing materials in accordance with your local laws.
CAUTION
The weight of the AURA (G3-S45) TRICEPS EXTENSION is 491 lbs. (223 kg). To avoid injury to yourself and prevent damage to
the frame components, be sure to have proper assistance removing the frame pieces from this box. Please be sure to install the
equipment on a stable base, properly level the machine and leave at least two feet of clearence to enter and exit the machine.
Maximum user weight for this machine is 300 lbs. (136 kg).
INCLUDED TOOLS REQUIRED FOR ASSEMBLY
17MM Open-End Wrench
3MM L-Shaped Allen Wrench
4MM L-Shaped Allen Wrench
5MM L-Shaped Allen Wrench
6MM L-Shaped Allen Wrench
8MM L-Shaped Allen Wrench
10MM L-Shaped Allen Wrench
If any items are missing please contact your country’s local MATRIX dealer for assistance.
0mm 10 20 30 40 50 60 70 80 90 100 1
10 120 130 140 150 160
Step 1
Frame Detail
Arc-at Washer
Screw
Lock Washer
Screw
Flat Washer
Lock Washer
Screw
Item
Screw
G14
G13
G15
G15
D32
D32
G13
G14
G15
Qty
12
6
18
12
Description
Lock Washer(M10)
Arc-at Washer(M10)
Flat Washer(M10)
Screw(M10x25L)
Step 2
Input Detail
F18
H33
Q07
H32
H32
Item Description Qty
E07
F18
Q07
H32
Pad Label
Flange Bushing
1
1
1
2
H33
1
1
G12 Screw(M10X25L)
E08
Screw(M12X25L)
2
Wavy Washer(M20)
E08
E07
Lock Washer(M12)
Flat Washer(M12)
G12
Step 5
Accessory and Belt
Routing Detail
Qty
1
6
6
Mectrol belt
Description
Item
F19
B51
B43 Screw(M4X12L)
Flat Washer(M4)
4
4
F15
F60
2
6
6
Upper CoverQ02
Q05
Q06
Rubber Shield Spacer
Rubber Tip Weight Shield Bolt
Nut(M5)
Screw(M5X35L) 4
2
4
F24
F23
Belt Fixer
F11
Lock Washer(M5)
Flat Washer(M5)
Q02
B43
B51
Q02
B43
B51
F19
F23 F24
F60
F15
F24
F23
F11
F60
B43
B51
B43
B51
B51
B43
B43
B51
Q06
Q06
Q06
Q05
Q05
Q05
Q01
Q06
Q06
Q06
Step 3
Upholstery Detail
C83
C86
C87
G12
G12
G12
Item Description Qty
G12 7
C86
C87
C83
1
1
1Screw(M8X20L)
Screw(M10X25L)
Washer(M8)
Lock Washer(M8) G12
G12
Step 4
Weight Stack Detail
Guide Rod
Top Weight
Selector Pin
Screw
Guide Sleeve
Knurled Belt Securing Insert
10
Knurled Belt Securing Insert
Rubber Stack Cushions
L14
L13
E-Clipper
K13
F23
K05
K07
4
4
4
1
2
4
Description
Item
B29
Qty
2
Guide Rod
K09 2
Screw(M8X30L)
Flat Washer(M5)
Lock Washer(M5)
Screw(M5)
200
170
190
180
150
160
110
140
120
130
70
100
90
60
K13
F23
L13
L14
1010
B29
K05
K07
K09 K19 Spring Pin(φ11x70L,in second weight plate) 1
K12
B29
