MedaCure GC500 User manual

500
Bariatric 3 Position
Geri-Chair Recliner
Model # GC500
Maximum weight capacity: 500lbs. | Casters should be in the locked position during patient transfer.
Extra Wide Seat: 25” W
Weight Capacity: 500 lbs.
Durable 5” Castors

To place chair in reclining position: To place chair in the locked position:
DIRECTIONS FOR USE
BY USER:
Place hands on armrests and push against seat back.
Legrest will automatically adjust to each position.
NOTE: The table can only be used in the upright sitting
position. Patient should be transported in reclined
position with recliner lock set.
BY NURSE OR AID:
1. Ensure recliner lock bar is in the stored position. See
Fig. 1.
2. Position yourself at either side of the recliner.
3. Grasp armrest with one hand, and PVC push bar (J)
with the other hand.
4. Push down on the push bar to recline the back to
the rst reclining position. For the second reclining
position, push on push bar again.
5. To raise upright, pull forward on push bar.
6. Set recliner Lock Bar (F).
TO LOCK RECLINER:
1. Place recliner into desired position.
2. Pull out Lock-Release Pull Button (G) to release Lock
bar (F) from stored position.
3. Rotate recliner Lock Bar (F) down until notches are fully
engaged over Locking Pins (H).
TO UNLOCK RECLINER:
1. Lift recliner Lock Bar (F) up to disengage from Locking
Pins.
2. While holding Lock-Release Pull Button (G) out, rotate
recline Lock Bar (F) all the way up until completely
against seat back.
3. Release Lock-Release Pull Button (G) to hold recliner
Lock Bar in stored position.
WARNING: Do not attempt to change the position of
the chair with the recliner lock bar engaged. This could
cause damage to the mechanism and will void the
warranty.
ASSEMBLY INSTRUCTIONS
1. Remove back assembly (C) from
unassembled chair.
2. Slide the 1 piece back assembly (C) into
the square tubes on the lower frame
assembly (B) so that the holes in the
back rest line up with the holes located
on the horizontal brace of the lower
frame assembly.
3. Raise the recliner lock bar (F) adjust
position of back assembly (C) until
the lock release button (G) positively
engages middle slot lock bar link when
chair is in the storage position.
4. Insert included screws through the holes
of the horizontal brace and tighten all
screws with a screwdriver
NOTE: Make sure that the top screw on
both sides of the square tubing of the
back assembly are secure before using the
recliner.

DIRECTIONS FOR USE
MAINTENANCE & CLEANING
HEADREST
Headrest can be adjusted to desired
position by pulling forward or pushing back.
TABLE TOP
To Operate:
1. Underneath each arm, pull down and
hold pull button (Fig. 2 A&B) and slide
lockout keys forward on both sides (D).
2. Pick up the tabletop by circular table
arm and slide into receiving lubes in
front of each arm.
3. Tabletop can slide on and off by
keeping lock/lockout key forward.
4. The tabletop can be locked into one of
5 positions. Pull down the pull button,
hold the pull button and slide the key
backwards. Proceed to the other arm
and move that key backwards. Tabletop
is now locked.
TABLE TOP STORAGE
The tabletop is stored in the small round
tube underneath the left armrest, leaving the
tabletop facing out.
THE FOLLOWING PARTS SHOULD BE CHECKED AND INSPECTED PERIODICALLY:
Check and Clean Casters | Tighten Nuts | Check Brakes on Casters | Check and Clean Lock Recline Mechanism
UPHOLSTERY CARE AND MAINTENANCE/STAIN REMOVAL:
Ordinary Dirt: Wash with warm water and a mild soap or detergent.
Stubborn Dirt: Using a soft bristle brush, follow directions above.
Ground-in Dirt: Scrub with powdered cleanser or similar detergent.
Chewing Gum: Scrape carefully, remove with kerosene or naphtha.
Nail Polish and Remover: Blot immediately to prevent damage.
Tars, Asphalt, Creosote: Remove to prevent staining. Clean area with kerosene or naphtha.
Warning: When using kerosene or naphtha, do so in a well ventilated area and keep away from re and ame.
Paint, Shoe Polish, Heel Marks: Remove immediately. Use a white cloth dampened in kerosene naphtha or turpentine. Do not use
paint remover or liquid brush cleaners.
Ball Point Pen: Blot immediately with a white cloth dampened in water or mineral oil.
Wax and Renishing: Improver wearability. Use any quality paste wax.
A diluted solution of 10% (or less) of bleach or clorox may be used when cleaning the reclining chair.
CAUTION:
DO NOT USE FORCE OR PRESSURE TO THE LEGREST TO
OPERATE THE RECLINER . DO NOT PLACE HANDS OR LEGS
IN CREASES NEAR RECLINER MECHANISM.
