MedaCure TR500 Installation and operating instructions

1
MEDACURE
BARIATRIC FREE STANDING TRAPEZE
ASSEMBLYAND OPERATION MANUAL
MODEL # TR500
1. Trapeze installation as per Figure # 1
DISASSEMBLY
Grab Bar
Middle frame
Base frame
Caster
Rivet
Washer
Lock pin
Offset Bar

2
ASSEMBLY
Figure # 1
2. Using the Trapeze
2.1Moving the Trapeze
There are 2 casters on thebase of the frame to assist in moving the Trapeze. Slightly incline the
Trapeze to ensure thecasters touch the ground, gently push/pull tomove as per Figure # 2.

3
Figure # 2
2.2 Adjusting the position of the Grab Bar
There are 6 location bars on the top tube for adjusting the position as per Figure # 3
Figure # 3
The chain has 8 links to allow you to adjust the height of the Grab Bar as per Figure # 4

4
The lock position of the link The open position of the link
Figure # 4
WARNING
THE TRAPEZE WILL ASSIST AN INDIVIDUAL WEIGHING UP TO 500 LBS.THE TRAPEZE IS DESIGNED TO
PROVIDE SUPPORT,INCREASE STABILITY AND ASSIST THE USER WHEN REPOSITIONING IN BED. IT IS NOT
DESIGNED TO SUPPORT THE TOTAL BODY WEIGHT OF THE PATIENT. THIS DEVICE IS NOT DESIGNED TO
MOVE A PATIENT OR RESIDENT IN AND OUTOF BED. THIS DEVICE SHOULD BE USEDFOR ASSISTANCE ONLY.
WARNING
NO PART OR COMPONENT OF THE TR500 MEDACURE TRAPEZE SHOULD BE USED WITH NON-MEDACURE
BEDS, LIFTS OR TRAPEZES.
WARNING
AFTER ASSEMBLY AND BEFORE USE, MAKE SURE ALL HARDWARE IS SECURELY TIGHTENED.
Release the link to adjust the
height of the Grab Bar
Twist the nut to open
or lock the link
