MELINERA 291041 Technical specifications

LED SOLAR LIGHT
IAN 291041
LED-SOLARLEUCHTE
Montage-, Bedienungs- und Sicherheitshinweise
LED SOLÁRNY LAMPÁŠ
Pokyny pre montáž, obsluhu a bezpečnostné pokyny
LED SOLÁRNÍ SVÍTIDLO
Pokyny k montáži, obsluze a bezpečnostní pokyny
LED SOLAR LIGHT
Assembly, operating and safety instructions
NAPELEMES LED LÁMPA
Szerelési, használati és biztonsági tudnivalók

GB Assembly, operating and safety instructions Page 5
HU Szerelési, használati és biztonsági tudnivalók Oldal 23
CZ Pokyny k montáži, obsluze a bezpečnostní pokyny Strana 40
SK Pokyny pre montáž, obsluhu a bezpečnostné pokyny Strana 57
DE/AT/CH Montage-, Bedienungs- und Sicherheitshinweise Seite 75

HG03597A/
HG03597B
HG03597C
OFF ON
OFF ON
A
5
4
6
7
5
16
2
1
3
3
4
2
HG03597A/
HG03597B HG03597C

B
6
9
10 5
8
7
8
9
HG03597A/
HG03597B
HG03597C
9
710 5

5GB
Introduction.............................................................................. Page 6
Proper use.................................................................................... Page 6
Description of parts and features ............................................... Page 6
Scope of delivery......................................................................... Page 7
Technical data ............................................................................. Page 7
Safety instructions................................................................ Page 8
Product-specific safety instructions.............................................. Page 9
Safety instructions for batteries/ rechargeable batteries.......... Page 10
Functioning................................................................................ Page 12
Preparing for use.................................................................. Page 13
Assembling of the product .......................................................... Page 13
Setting up the product................................................................. Page 14
Replacing the rechargeable battery........................................... Page 14
Charging the rechargeable battery............................................ Page 17
Maintenance and care....................................................... Page 17
Troubleshooting..................................................................... Page 18
Disposal....................................................................................... Page 19
Warranty.................................................................................... Page 21

6 GB
LED Solar Light
Introduction
We congratulate you on the purchase of your new product. You
have chosen a high quality product. The instructions for use are
part of the product. They contain important information concern-
ing safety, use and disposal. Before using the product, please fa-
miliarise yourself with all of the safety information and instructions
for use. Only use the product as described and for the specified
applications. If you pass the product on to anyone else, please
ensure that you also pass on all the documentation with it.
Proper use
The product is intended for outdoor use. The product is suitable for
use in private household and is not intended for commercial use or
for use in other applications.
Description of parts and features
1Solar cell housing 2Glass jar

7GB
3LED light chain
4Handle
5ON/ OFF switch
6Solar cell
7Battery compartment
8Battery compartment cover
9Screws
10 Rechargeable battery
Scope of delivery
1 LED solar light and rechargeable battery
1 Assembly, operating and safety instructions
Technical data
Operating voltage: 1.2V (direct current)
Rechargeable battery: 1 x Ni-MH rechargeable battery/AAA /
1.2V (direct current)/300 mAh
LED: 10 x Micro LED
Rated power LED: approx. 0.06W per LED
Protection type: IP44 (splash proof)
Solar cell: approx. Ø 58 mm (HG03597A/
HG03597B)
approx. 40 x 40 mm (HG03597C)

8 GB
Lighting time
(with full charge): approx. 6 hours
Safety instructions
PLEASE READ THE INSTRUCTIONS FOR USE PRIOR TO USE!
PLEASE KEEP THE INSTRUCTIONS IN A SAFE PLACE! IF PASS-
ING THIS PRODUCT ON TO A THIRD PARTY ALSO INCLUDE
ALL DOCUMENTS.
This product can be used by children aged from 8 years and
above and persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have
been given supervision or instruction concerning use of the
product in a safe way and understand the hazards involved.
Children shall not play with the product. Cleaning and user
maintenance shall not be made by children without supervision.
Do not use the product if you detect any kind of damage.

9GB
Always switch off the product, when storing it in dark environ-
ment, in order not to discharge the rechargeable battery.
The LEDs are not replaceable.
If the LEDs fail at the end of their lives, the entire product must
be replaced.
The product does not contain any parts that can be serviced
by the user.
Never plug in the LED light chain 3directly into a 230V~
(alternating current) directly.
The product is not a toy and should not be player by children.
Children are not able to understand the danges that can
occur when handling the product.
The product can never be used as a container.
Product-specific safety instructions
Make sure that the solar cell is free of dirt and free of snow
and ice in winter. Otherwise the performance of the solar cell
will diminish.

10 GB
Safety instructions for batteries/
rechargeable batteries
DANGER TO LIFE! Keep batteries/rechargeable batteries
out of reach of children. If accidentally swallowed seek
immediate medical attention.
DANGER OF EXPLOSION! Never recharge
non-rechargeable batteries. Do not short-circuit bat-
teries/rechargeable batteries and/or open them.
Overheating, fire or bursting can be the result.
Never throw batteries/rechargeable batteries into fire or water.
Do not exert mechanical loads to batteries/rechargeable
batteries.
Risk of battery leakage
Avoid extreme environmental conditions and temperatures,
which could affect batteries/rechargeable batteries, e.g.
radiators/direct sunlight.
If batteries /rechargeable batteries have leaked, avoid
contact with skin, eyes and mucous membranes with the

11GB
chemicals! Flush immediately the affected areas with fresh
water and seek medical attention!
WEAR PROTECTIVE GLOVES! Leaked or dam-
aged batteries/rechargeable batteries can cause
burns on contact with the skin. Wear suitable pro-
tective gloves at all times if such an event occurs.
In the event of a battery leak, immediately remove it from the
product to prevent damage.
Only use the same type of batteries/rechargeable batteries.
Do not mix used and new batteries/rechargeable batteries.
Remove the batteries/rechargeable batteries if the product
will not be used for a longer period.
Risk of damage of the product
Only use the specified type of battery/rechargeable battery!
When inserting ensure the correct polarity! This is shown
inside the battery compartment!
Clean the contacts on the battery and in the battery compart-
ment before inserting!

12 GB
Remove exhausted batteries/rechargeable batteries from the
product immediately.
Functioning
The solar cell installed in the product converts sunlight into electri-
cal energy and stores it in 1Ni-MH rechargeable battery. Switch
on the product with the ON/ OFF switch 5. The product will au-
tomatically light on as it begins to get dark. The LEDs are a very
long-life and energy-saving light source. The light duration depends
on the amount of sunlight, the angle of light on the solar cell and
the temperature (the battery capacity is temperature-dependent).
A vertical angle of light at temperatures above the freezing point
is ideal. The rechargeable battery does not achieve maximum ca-
pacity until after several charge and discharge cycles.
In summer a completely drained rechargeable battery takes about
2 to 4 days to fully recharge in constant sunlight

13GB
Preparing for use
Note: Remove the protective film from the solar cell before use.
Assembling of the product (see Fig. A)
HG03597A/ HG03597B:
1. Rotate the solar cell housing 1anti-clockwise out of the
glass jar 2.
Note: Take care not to damage the LED light chain 3.
2. Move the ON/OFF switch 5to the ON position to enable
the product switching on during darkness.
3. Insert the solar cell housing 1into the glass jar 2and
tighten it by turning it clockwise.
4. Your product is ready for use.
HG03597C:
1. Take out the solar cell housing 1from the glass jar 2.
Note: Take care not to damage the LED light chain 3.
2. Move the ON/OFF switch 5to the ON position to enable
the product switching on during darkness.

14 GB
3. Put back the solar cell housing 1to the glass jar 2.
4. Your product is ready for use.
Setting up the product
In order to achieve the best result, set the product up in a
place where the solar cell will get direct sunlight for as long as
possible.
Make sure that the solar cell is not influenced by any other
source of light such as yard or street lighting as otherwise the
product will not come on in twilight.
The product automatically switches on in twilight conditions
and off again when normal outdoor lighting conditions return.
Replacing the rechargeable battery
(see Fig. B)
The battery should be replaced every 12 months to ensure
optimum performance.

15GB
HG03597A/ HG03597B:
1. Rotate the solar cell housing 1anti-clockwise out of the glass
jar 2. Move the ON/OFF switch 5to the OFF position to
switch off the product.
2. Screw out the screws 9from the battery compartment 7.
Separate the battery compartment cover 8from the battery
compartment 7. Take care not to damage the cables, cable
connections and the LED light chain 3.
3. Exchange the old rechargeable battery 10 to a new one,
ensure that you do not damage the wiring. Take care of the
correct polarity, when inserting the new rechargeable battery.
The polarity is indicated in the battery compartment 7. The
new rechargeable battery has to have the same technical
data like the old one.
4. Now attach the battery compartment cover 8to the battery
compartment 7by screwing up the screws 9. Move the
ON/ OFF switch 5to ON position to enable the product
switching on during darkness.
5. Insert the solar cell housing 1into the glass jar 2and
tighten it by turning it clockwise.

16 GB
HG03597C:
1. Separate the solar cell housing 1from the glass jar 2.
Move the ON/OFF switch 5to the OFF position to switch
off the product.
2. Rotate the battery compartment 7by moving it clockwise
and then lever out the battery compartment 7. Take care not
to damage the cables, cable connections and the LED light
chain 3.
3. Exchange the old rechargeable battery 10 to a new one, en-
sure that you do not damage the wiring. Take care of the cor-
rect polarity, when inserting the new rechargeable battery 10 .
The polarity is indicated in the battery compartment 7. The
new rechargeable battery 10 has to have the same technical
data like the old one.
4. Now insert the battery compartment 7into the solar cell
housing 1by moving it anti-clockwise. Move the ON/OFF
switch 5to ON position to enable the product switching on
during darkness.
5. Put back the solar cell housing 1to the glass jar 2.

17GB
Charging the rechargeable battery
Note that the product must be switched on when the battery is
charging.
The charging time of the battery when the solar cell is used depends
on the intensity of the sunlight and the angle of incidence of the light
on the solar cell 6. Place the solar cell as perpendicular as possi-
ble to the angle of incidence of the light. In this way you will
receive the highest light levels.
Maintenance and care
The light-emitting diodes cannot be replaced.
The product is maintenance-free, except for any necessary change of
battery.
Clean the product regularly with a dry, lint-free cloth. Use a
slightly dampened cloth to remove more stubborn dirt.

18 GB
Troubleshooting
Note: This product has delicate electronic components. This
means that if it is placed near an object that transmits radio
signals, it could cause interference. If you notice that the product
is malfunctioning, remove any sources of interference from the
area of the product.
Note: Electrostatic discharges may cause product to malfunction.
In the event of such malfunctions, remove the rechargeable battery
briefly and reinsert it.
Error Cause Solution
The light will not
switch on even
though the sun
shone on the
product all day.
Artificial sources of
light, e.g. street light-
ing, are interfering
with the product.
Mount the product in
a place where it can-
not be disturbed by
other sources of light.

19GB
Error Cause Solution
The light does not
come on or
comes on only
briefly.
The rechargeable bat-
tery is broken or there
was not enough day-
light.
Replace the re-
chargeable battery
or mount the product
in a place where it
can receive more
sunlight.
Disposal
The packaging is made entirely of recyclable materials, which you
may dispose of at local recycling facilities.
b
a
Observe the marking of the packaging materials for
waste separation, which are marked with abbreviations
(a) and numbers (b) with following meaning: 1–7:
plastics/ 20–22: paper and fibreboard/80–98:
composite materials.

20 GB
The product and packaging materials are recyclable,
dispose of it separately for better waste treatment. The
Triman logo is valid in France only.
Contact your local refuse disposal authority for more
details of how to dispose of your worn-out product.
To help protect the environment, please dispose of the
product properly when it has reached the end of its use-
ful life and not in the household waste. Information on
collection points and their opening hours can be
obtained from your local authority.
Faulty or used batteries /rechargeable batteries must be recycled
in accordance with Directive 2006/66/EC and its amendments.
Please return the batteries/ rechargeable batteries and/ or the
product to the available collection points.
