Memphis Shades MEM-9917 User manual

MEM-9917
MEMPHIS FATS/SLIMS MOUNTING KIT FOR
POLARIS VICTORY V92C 98-99
TOOLS REQUIRED: 3/16” Allen wrench (provided)
7/16” (or 11mm) wrench
1. Loosely install the two mounting plates on the windshield, using the bottom and third bolt up, leaving off the
nylon washers. The small tab goes at the bottom, large tab at the top. (See Figure 1)
NOTE: Tabs should point in towards the center of the shield.
2. Loosely install the four fork clamps on the forks, approximately two inches apart.
(See Figure 2)
3. Loosen the four bolts that are to hold the windshield to the fork clamps, and slide the mounting plates onto the
fork clamps. (See Figure 3)
4. Adjust the height, angle and alignment of the shield and tighten down the bolts that hold the windshield to the
plates, then the bolts that hold the plates to the fork clamps, then the clamps themselves.
WARNING: This is a quick disconnect kit. Be sure to tighten down all mounting bolts after removal or
installation, every time.
Fig. 1 Mounting plate to w/s Fig. 2 Fork clamps Fig. 3 narrow plate to forks
Care and Cleaning Instructions
To clean your windshield, use only warm water and a mild non-abrasive, dishwashing liquid. Use
a soft cloth, such as a T-shirt or flannel cloth. To protect your windshield, please use Novus #2 to
remove minor scratches, or use a polish like Memphis Shades Shinola which is specially designed
for plastic windshields; glass cleansing agents will cause severe damage to your windshield and
will void your warranty.
Never use any glass products, petroleum based chemicals, or cleaning agents with ammonia, bleach
or any harsh chemicals. This includes Rain-X, brake fluid, acetone, and gasoline.

MEM-9917 MOUNTING KIT
MEMPHIS FATS 9’ HDLT 45MM FORKS 98-01 VICTORY CRUISER
PART #
DESCRIPTION QTY.
M917 Mounting Instructions/Parts List 1
M609 Left Mounting Plate Fats/Slims 1
M610 Right Mounting Plate Fats/Slims 1
M577 Medium Inner Adjustable Fork Clamp Half 4
M578 Medium Outer Adjustable Fork Clamp Half 4
M302 1/4”-20 x 1/2” SS Socket Head Cap Screw 4
M306 1/4”-20 x 5/8” SS Socket Head Cap Screw 4
M501 Beveled Socket Washer 4
M314 3/16” T-Handle Allen Wrench 1
M310 3/16” Short Arm Allen Wrench 1
M337 3/16” T-Handle Wrench Cover 1
M313 3/16” Short Arm Allen Wrench Cover 1
M559 1/8” x 3/4” Beveled Spacer Washer 4
MEM9917 03-31-08
Memphis Shades warrants all product components, metal and plastic,
against defects in materials and workmanship for 24 months.
FOR PARTS AND WARRANTY HELP, CONTACT:
MEMPHIS SHADES
P.O. Box 429
Rossville, TN 38066
[phone]
Visit us on the web at www.memphisshades.com or
you can also reach us at
[e-mail]
