Mercia Garden Products 03BRN0705-V3 Instruction manual

N/A
Overlap
Cladding
Shiplap
Cladding
Solid Sheet
Roof
T&G Roof
Solid Sheet
Floor
T&G Floor
Fixed
Windows
Opening
Windows
No
Windows
For Assistance Please
Contact Customer Care on
01636 880514
2mm Drill bit
x2
Winter = High Moisture = Expansion
Summer = Low Moisture = Contraction
All building’s should be erected by two
adults
For ease of assembly, it is advisable to
pilot drill all screw holes and ensure
all screw heads are countersunk.
BEFORE YOU START PLEASE READ INSTRUCTIONS CAREFULLY
- Check the pack and make sure you have all the parts listed.
- When you are ready to start, make sure you have the right tools at hand
(not supplied) including a Phillips screwdriver, Stanley knife, wood saw,
step ladder and drill with 2mm bit.
- Ensure there is plenty of space and a clean dry area for assembly.
TIMBER
conditions. For the duration of heavy or extended periods of rain, swelling of the
wood panels may occur. Warping of the wood may also occur during excessive
dry spells due to an interior moisture loss. Unfortunately, these processes cannot
be avoided but can be helped. It is suggested that the outdoor building is
sprayed with water during extended periods of warm sunshine and sheltered as
much as possible during rain or snow.
Our buildings are pre treated with a water based treatment**; this only helps to
protect the product during transit and for upto 3 months against mould. To
validate your guarantee and ensure longevity of the product, it is ESSENTIAL the
assembly and thereafter in accordance with the manufactures recommenda-
tions. Care must be taken to ensure the product is placed on a suitable base.
BUILDING A BASE
When thinking about where the building and base is going to be constructed:
Ensure that there will be access to all sides for maintenance work and annual
treatment.
Whilst all products manufactured are made to the
highest standards of Safety and in the case of childrens
products independently tested to EN71 level,we cannot
accept responsibility for your safety whilst erecting or
using this product.
Mercia Garden Products Limited, Sutton On Trent, Newark, Nottinghamshire, NG23 6QN
www.merciagardenproducts.co.uk
CAUTION
manufacturing process to eliminate the
prospect of splinters on rough surfaces
of the timber. You are strongly advised
to wear gloves when working with or
handling rough sawn timer.
**Protim Fentex E5**
Biocidal Product Regulation (EU 528/2012) Article 58 Information
Protim Fentex E2 preserved wood is a “treated article”which incorporates biocidal products.
Wood correctly preserved with Protim Fentex E2 is protected against mould in storage.
Contains: IPBC (3-iodo-2-propynyl-N-butyl carbamate) and propiconazole.
Wear gloves when handling freshly treated wood.
Avoid breathing dust when cutting treated or untreated wood.
to diagrams for the base dimensions, The base should be slightly smaller than
the external measurement of the building, i.e. The cladding should overlap the
TYPES OF BASE
- Concrete 75mm laid on top of 75mm hard-core.
- Slabs laid on 50mm of sharp sand.
Please retain product label and instructions for future reference
P 1
General Instructions
03BRN0705-V3
7x5 Summerhouse
03BRN0707-V3
7x7 Summerhouse
03BRN0807-V3
8x7 Summerhouse
14/01/2014
8

Step 1
P 2
03BRN0705-V3
Please retain product label and instructions for future reference
Before assembly
please make sure you have a
suitable base ready to erect your
building
MADE IN GREAT BRITAIN
Overall Dimensions:
Length = 1481mm
Width = 2127mm
Height = 2199mm
Building content
123456
Remove transportation
blocks from the bottom
of each panel before
beginning assembly. Each
Panel should have two
Pre Assembly
2
Nail Bag
Door Gable Plain Gable Plain Side
QTY 2
Floor
Roof QTY 2
6
7
8
9
10
11
Eaves Frame 1720mm QTY 2
Ridge Bar 1457mm
Fascia 1240mm QTY 4
Finial QTY 2
Angle Fascia Block
Fascia Block QTY 2
13
12
Press Lock
Chrome Handle QTY 2
14 L Bracket QTY 2
50mm Barrel Bolt
15
16
Black Turn Button QTY 2
17
Felt
30mm Screw x32
50mm Screw x30
40mm Screw x25
Felt Tacks x75
16mm Black Screw x7
35mm Bolt x5
10mm Screw x15
25mm Screw x36
Fix the hinge to the door and door
gable using 25mm screws
ensuring that the screws go
through to the framing.
Place the oor on a rm and
level base, ensure base has
suitable drainage free from
areas where standing water
can collect. (See front page
on base requirements).
18
Butt Hinge QTY 6
234
5
12
36x25mm Screws
Pre drill
hole
25mm
screw
17

P 3
Step 2
9x50mm Screws
50mm
screw
Step 3
Fix door gable and Left panel
using the same method shown
in step 3.
Step 4
Fix the roof eaves to the
edge of the roof OSB with
30mm Screws.
Step 5
Pre drill
hole
50mm
screw
2
3
Do not secure the building
to the oor until the roof is
tted. Fix the panels onto
the oor using 50mm
screws in alignment with the
oor joists
Fix the corners with 50mm
screws as shown in diagram.
Position the panels so there is equal spacing
between the floor and cladding on all 4 sides
3x50mm Screws
Pre drill
hole
50mm
screw
7
14
Fix the ridge bar between
the apex of the two gable,
using a L bracket at each
end secured using 30mm
screws.
8x30mm Screws
Pre drill
hole
30mm
screw
8x30mm Screws
Pre drill
hole
30mm
screw
6
5

Step 6
Step 7
Once the roof is xed in
place, secure the building
to the oor using
16x50mm screws.
Step 8
Step 9
Fix the roof panels on
either side as shown in
diagram.
Fix panels into position
using 30mm screws
from the top of the
panel, straight into the
framing and ridge bar.
Pre drill holes before
hand.
Ensure the larger over
hang on both panels are
facing each other at the
top point.
16x30mm Screws
Pre drill
hole
30mm
screw
16x50mm Screws
Pre drill
hole
50mm
screw
Fix the rectangular fascia
xing block half way along
the front edge of the roof
using 40mm screws.
Fix the angled fascia xing
block to the apex of the
roofs, aligned at the front
and xed with 40mm screws.
Pre-drill to avoid splitting.
6x40mm Screws
Pre drill
hole
40mm
screw
Cut felt into 3 sheets and lay onto
roof as shown in diagram ensuring
there is a 50mm overhang around
the sides.
Fix using felt tacks at 100mm
intervals
75xFelt Tacks
11
11
10

Step 10
Step 11
To x the door handles rstly pre
drill hole approximately 3mm in
the middle of the door framing,
then screw the handle in as
shown using the 35mm bolt
from behind the door.
Pre drill
hole
35mm
bolt
Use 40mm Screws to x
each fascia and the nial
in place.
14x40mm Screws
Pre drill
hole
40mm
screw
4x35mm Bolt
Step 13
Step 14
Fix the black press lock to
the rear of the left hand
door (from the inside of the
building). Ensuring that the
hole in the door lines up
with the key hole in the
lock allowing it to turn fully.
Fix with 30mm black
screws.
4x16mm Black Screws
1
13
Align the tower bolt onto
the top of the door framing
(opposite door to which the
door clocks where xed)
and x with 10mm screws.
18
4x16mm Black Screws
16mm
screw
Pre drill
hole
8x10mm Screws
Pre drill
hole
10mm
screw

Slave Door
Locking Door
Step 15
Fix the turn buttons into
place at the top and
bottom of door as shown in
the diagram.
The turn buttons help to
keep the doors alligned
during high and low levels
of moisture.
2x16mm Black Screws
16mm
screw
Pre drill
hole
It is ESSENTIAL that you apply wood
treatment immediately after the building
has been assembled.
AFTER TREATMENT:
score around protective
cover on glazing and
carefuly peel
covering back
