Merrithew Spring Wall User manual

Please review this important assembly, safety and warranty information about your new
Merrithew™equipment and keep it handy for future reference.
OWNER’S MANUAL
Spring Wall™

Spring Wall™Owner’s Manual2
SPRING WALL OWNER’S MANUAL
Care and Cleaning
Wipe surfaces using warm water with mild soap and clear
water rinses for day-to-day cleaning. Ensure soap does not
leave an oily residue, or make surfaces slippery.
If handles require cleaning, use a mild solution of soapy
water and rinse well.
CAUTION: We do not recommend using chemical-
basedproducts.
User Guidelines
Pilates equipment when used effectively can faciliate many
Pilatesexercises safely and effectively. However, care and
caution must be taken as there are some inherent dangers
when usingany exercise equipment — especially when spring
resistanceisinvolved.
For inexperienced or first-time users, this equipment
should only be used under the supervision of a
trainedprofessional.
Please ensure that you and your clients/patients have
receivedproper instruction regarding the correct and safe
useofthis equipment.
Many exercises performed on the Spring Wall are part of
the Cadillacrepertoire. Full instructions are provided in
STOTTPILATESCadillac manuals.
This manual includes general guidelines for setup and usage.
To get the most out of this equipment, Merrithew offers
instructional DVDs and manuals. Personalized training is offered
through our Corporate, Licensed and Host Training Centers.
Visit merrithew.com for more information.
Mechanical
Safety Check
Proper maintenance and timely replacement of your
equipment or component parts is your responsibility
as it helps reduce the risk of injury. Conduct a regular
inspection of the following:
Daily: Clean all wooden surfaces areas after each use
as per Careand Cleaning instructions.
Weekly: Check all springs and spring clips for wear
and damageand replace as needed.
Monthly: Ensure all nuts, bolts, screws and eyehooks
aresecurely fastened.
Yearly: Replace all spring clips
Every Two Years: Replace all springs
FAILURE TO PERFORM RECOMMENDED SAFETY CHECKS,
OR USING THE MACHINE WITH IMPROPERLY ADJUSTED,
BROKEN OR WORN PARTS, COULD RESULT IN SERIOUS
BODILY INJURY.
IMPORTANT!
This manual contains important assembly, safety and
warranty information. Read the manual carefully
before using your new equipment and keep the
manual on hand for future reference.
UNSAFE OR IMPROPER USE OF THIS EQUIPMENT
BY FAILING TO READ AND COMPLYWITH ALL
REQUIREMENTS ANDWARNINGS COULD RESULT
INSERIOUSINJURY.
It is impossible to predict every situation and
conditionthat can occur while using this equipment.
Merrithew makes no representation about the
safe use of any exercise equipment that cannot
bepredicted or avoided.
PLEASE DO NOT ATTEMPT TO ASSEMBLE ON YOUR
OWN. SOME OF THESE STEPS REQUIRE TWO PEOPLE.
PLEASEREAD THESE INSTRUCTIONS COMPLETELY
BEFOREBEGINNING ASSEMBLY.
Merrithew recommends cautious assembly and
usage andwishesyou many hours of safe and
effectiveexercise.
CAUTION IMPROPER USE OF EXERCISE EQUIPMENT MAY CAUSE SERIOUS BODILY INJURY. TO REDUCE RISK, PLEASE READ THE FOLLOWING:
wBefore starting any exercise program, consult a physician.
wStop exercising if you experience chest pain, feel faint,
have difficulty breathing or experience musculoskeletal
discomfort.
wUse equipment only for intended exercises.
wDo not use if equipment appears worn, broken or damaged.
wDo not attempt to repair equipment yourself without
consulting Merrithew.
wDo not allow children to use or be around equipment
withoutadult supervision.
wKeep body, clothing and hair free from all moving parts.
wProper fitness apparel, including sticky socks is
recommended whileusing this equipment.
WARNING: As with any athletic activity, the use of
exercise equipment involves risk of injury, damage
and/or death.
By choosing to use Merrithew equipment, you and/or
your clients/patients assume responsibility for that risk,
not the people who sell, distribute and/or manufacture
thisequipment.

3
Spring Wall™
1Serial Number Sticker (top edge)
2Attachment Point Hole
3Spring Wall Back Board
4Roll-Down / Regular Arm Springs
with Spring Clips
5Roll-Down Bar
9Foam Grip Handles [fig. A]
6Leg Springs
7Padded Foot Straps
8Roll-Up Bar
A
PART IDENTIFICATION
Required Tools (not supplied)
Builder’s Level
Electric Drill
Hardware Required
not included QTY
Affixing to Drywall
Butterfly toggle or
slotted hex head wall anchors 8
Affixing to Brick Wall
Masonry fasteners 8
3
2
4
5
6
7
8
9
1

Spring Wall™Owner’s Manual4
Springs
ROLL-DOWN SPRINGS
Attach roll down springs to eyehooks
at desired height and ensure they are
securelyattached with spring clips.
LEG SPRINGS
Attach leg springs to eyehooks at
desiredheight. Ensure spring clips are
completely closed and secure.
LIGHT ARM SPRINGS
Attach light arm springs to eyehooks
atdesired height. Ensure spring clips are
completely closed and secure.
Roll-Down Bar
Attach roll-down springs to roll-down bar,
then to the fixed eyehooks on the board.
Both springs must be attached.
To increase resistance, substitute
withtheleg springs.
CAUTION: The roll-down bar can
release at high velocity due tothe
spring tension. Ensure a secure grip
at alltimes. Grippermats can be
used. Alwaysensurespring clips are
completelyclosed and secure.
ASSEMBLY INSTRUCTIONS
Assembling the Spring Wall
PLEASE DO NOT ATTEMPT TO ASSEMBLE ON YOUR OWN.
Installation of this product requires a minimum of two people. We highly recommend that you have this product installed by
a professional contractor. Read instructions completely beforebeginning assembly. Improper installation voids equipment
warranty. Merrithew will not be responsible for any injuryor damage resulting from improper installation.
wPlace all parts from the box in a cleared area and position
themon the floor in front of you.
wRemove all packing material from your area and place
themback into the box. Do not dispose of the packing
materials until assembly iscompleted.
wTo prevent unsafe or improper use, please read each
stepcarefully before beginning.
1. Find support studs in wall (typically 16"/ 40.64 cm apart)
and mark off location.
2. Position the back board [3] 3-1/2"/8.9 cm above the
mat surface. Use a builder’s level or set square to ensure
SpringWall’s length is perpendicular to the floor.
3. Mark attachment point holes [2] against the wall over the
underlying support studs.
4. Remove back board [3] and drill appropriately sized holes
through wall
5. Position the back board [3] and screw it firmly against the wall.
There are eight (8) attachment point [2] screw holes.
On a standard drywall surface, when only one support stud
can be found, affix the remaining holes to the wall using
butterfly toggle anchors, slotted hex head wall anchors
or other appropriate heavy-duty drywall anchor fasteners.
Brickwalls require four masonry fasteners.
6. Attach springs to back board using spring clips. Test stability
and solidness of the board to the wall before use.
Spring Clips
SPRING CLIP LOCKING SPRING CLIP
Used to connect springs to equipment.
Two types available. Locking spring clips
are required for the push-thru bar with
springs from below.
Always ensure spring clips are closed
completely. It may otherwise come
undone and detach with high force.
Safety Cautions
Improper use of exercise equipment may cause serious injury. To reduce risk, please observe the following:
wThe Spring Wall should only be used by one person at a time,
not weighing over350 lbs / 159 kgs.
wAlways choose the workout which best fits your physical
strength and flexibility level. Know your limits and train within
them. Always use common sense when exercising.
wDo not wear loose clothing while using the Spring Wall.
wEnsure a secure grip when holding the roll-down bar.
wWhen springs are used ensure the spring clips at both ends
ofeach spring are closed completely.
If a spring clip is only half closed, it may come undone
and detach with highforce
wIf you are watching someone perform an exercise, never put
your face (or any other body part) above the roll-down bars
orextended springs.
If the bar or spring handles are released suddenly
theycouldfly upward and cause injury.
SAFETY & USAGE

5
Leg Springs – Green
Shown here with padded foot (long spine)
straps attached.
Light Arm Springs – Yellow
Shown here with foam grip
handles attached.
Roll-Down Springs – Black
with Roll-Down Bar
Can also function as regular arm springs.
Shown with roll-down bar attached
(sold separately).
Non-Locking Spring Clip
Used to connect springs to equipment.
Padded Footstraps –
Long Spine Straps
Also available without padding.
Foam Grip Handles
Cushioned and rounded, these provide
extracomfort.
Platform Mat
Features dense foam padding and a
supportive surface that provides
faithful proprioceptive feedback.
Footstrapincluded.
Also available as a Split Raised Mat
foreasierstorage.
Gripper Mat
Non-slip rubber mats are handy to
increase traction and prevent slipping.
A gripper mat can be wrapped around
push-thru bar, roll-down bar, uprights
or placed on upholstered bed.
Extension Straps
Assists alignment of the knee joint.
Available in two lengths: The standard 24"
and 26" recommended for those with
athletic thighs.
Optional Items
Replacement Parts
For more information and to place an order, visit merrithew.com/replacementparts or email [e-mail]
MAINTENANCE & REPLACEMENT PARTS
ACCESSORIES

Spring Wall™Owner’s Manual6
THE FINE PRINT
Warranty
Merrithew™warrants that all new equipment is free of manufacturing defects in workmanship and materials, subject to the terms below.
Thiswarranty becomes effective at the invoice date of the original purchase. Parts repaired or replaced under the terms of this warranty
willbe warranted for the remainder of the original warranty period.
It is the purchaser’s responsibility to notify the Company of any change of contact information. This ensures, that in the unlikely event
ofareplacement or safety notice, we are able to contact you immediately.
This warranty applies to equipment only:
wWhile it remains in the possession of the original purchaser
and proof of purchase is demonstrated
wIf claims are made within the part-specific warranty period
wIf upgrades are made as required by Merrithew
This warranty shall be null and void if:
wEquipment failure is a result of improper assembly,
installationormaintenance
wThe equipment is used for any other purpose other than
asintended, or is stored or used outdoors, or in environments
without adequate climate/humidity controls
wEquipment has been subjected to accident, misuse, abuse,improper
service, or any modification not authorizedbyMerrithew
This warranty does not cover damage to the finish of any equipment
nor shipping charges, customs clearance fees (if applicable), or any costs
incurred in installing repaired or replacement parts shipped under the
provisions of this warranty.
Failure to change springs every two (2) years may void warranty.
Two (2) Year Limited Warranty
Merrithew will, at its option, repair or replace all other components other
than upholstery, that fail for any reason, provided such failure is reported
to Merrithew within a period of two years from the invoice date of the
originalpurchase.
One (1) Year Limited Warranty
Merrithew will, at its option, repair or replace any of the parts listed below,
provided that the part(s) fail due to a defect in workmanship ormaterials:
wStraps
wHandles
wSpring clips
We recommend spring clips be changed annually.
Disclaimer of Implied Warranties and LimitationofRemedies
Repair or replacement of defective parts is your exclusive remedy under
the terms of this limited warranty. In the event of parts availability issues,
Merrithew will not be responsible for any consequential or incidental
damages arising from the breach of either this limited warranty or any
applicable implied warranty, or for failure or damage resulting from acts
ofnature, improper care and maintenance, accident, alteration, replacement
of parts by anyone other than Merrithew, misuse, transportation, abuse,
hostile environments (inclement weather, acts of nature), improper
installation or installation not in accordance with local codes or
printedinstructions.
This limited warranty is the sole express warranty given by
Merrithew. No product performance, specification or description
wherever appearing is warranted by Merrithewexcept to the extent
set forth in this limited warranty. Any implied warranty protection
arising under the laws of any state, provinceor territory including
implied warranty of merchantability or fitness for a particular
purpose, oruse, is hereby limited in duration to the duration of this
limited warranty.
Neither distributors, dealers, web resellers, nor the retailers selling this
product have any authority to make any additional warranties or to
promise remedies in addition to, or inconsistent with those stated above.
Merrithew’s maximum liability, in any event, shall not exceed the purchase
price of the product paid by the originalpurchaser.
IMPORTANT
Please keep this manual in a safe place.
If you have questions, issues or are missing parts:
Do NOT return this unit to your local retailer,
please contact the manufacturer directly.
[e-mail]
416.482.4050 |1.800.910.0001 |0800.328.5676 UK |ext. 0907

Take Advantage of our Training Tools
Make the Most of Merrithew™Equipment
As Leaders in Mindful Movement™, Merrithew is committed to developing unique, top-quality fitness programs
based on the latest in exercise science and research. Our signature STOTT PILATES®education is unparalleled,
and we bring the same expertise and passion to our full range of branded programs, including CORE™Athletic
Conditioning and Performance Training™, ZEN·GA®, Total Barre™and Halo®Training. Join our global community
of elite fitness professionals. Merrithew courses and workshops are offered worldwide.
Find courses and workshops near you at merrithew.com/education/training
Contact Us 416.482.4050 | 1.800.910.0001 | 0800.328.5676 UK | ext. 300
Training Manuals: Two fully illustrated manuals, developed
forour Instructor Training Program, offer step-by-step
instruction to the complete Cadillac repertoire.
Wall Charts: Full-size posters, measuring 27"x 39",
depictexercises featured in the STOTTPILATES®Cadillac
repertoire. Each exercise is described with name, equipment
accessories, one photo, as well as suggested repetitions.
Instructional DVDs: We offer almost limitless
exercise challenges in our clear and detailed
repertoire of cutting edge titles. For a full
listing visitmerrithew.com/shop/dvds

P00209 PM-ST01052-4 SEPT17 ™/® Trademark or registered trademark of Merrithew Corporation, used under license. Printed in Canada. All rights reserved.
Please keep this manual in a safe place.
IMPORTANT
This is your Spring Wall Serial Number:
Go to merrithew.com/warranty
to activate your warranty!
Get the benefits:
wEnsure that you’ll be able to repair it under warranty should you encounter a problem.
wMake warranty service fast and efficient by having your information in our records.
wIn the unlikely event of a replacement or safety notice, we’ll be able to contact you immediately.
wProof of purchase for insurance purposes in the event of a loss due to fire, flood or theft.
wStay informed of any product updates.
Can’t get online?
Please fill out the warranty card enclosed with this product, and return to us.
2200 Yonge Street, Suite 500, Toronto, Ontario, Canada M4S 2C6
416.482.4050 | 1.800.910.0001 | 0800.328.5676 UK | ext. 0907
[email protected]om | merrithew.com
