Meteor Stem Dext 2.0 Series User manual

Secure half ball with stem.
Step 1
Attach swivel crossbar to junction box (by others).
Make electric connection in junction box. (See below)
Step 2
Feed the safety cable and power cord through the stem and
insert half ball joint into slot on swivel crossbar. Align the slot
on ball joint with the tab on the swivel crossbar.
Step 3
Step 4
Install canopy cover by aligning the tabs on crossbar with
slots in the cover.
Step 5
12
JUNCTION BOX
IMPORTANT SAFETY INFORMATION.
READ AND FOLLOW ALL SAFETY INSTRUCTIONS
!
IMPORTANT SAFETY INFORMATION. READ AND FOLLOW ALL SAFETY INSTRUCTIONS. Before wiring to power
supply and during servicing or relamping, turn off power at fuse or circuit breaker. All servicing or relamping
must be performed by qualified service personnel. Product must be grounded to avoid potential electric shock
or other potential hazard. Product must be at locations and at heights and in a manner consistent with its
intended use, and in compliance with Electrical Code and local codes.
SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.
3
CORD
TAB
4
5
Installation Instructions
Dext 2.0 Series - Stem
ADVANCED HIGH CEILING
METEOR LIGHTING P: 213.255.2060 F: 213.596.3704 www.meteor-lighting.com
*METEOR LIGHTING reserves the right to make changes to this product at any time without prior notice and such modification shall be effective immediately.
2019 V1.0 | Page 1 of 3

Loop the aircraft cable through the mounting corners and tighten the
clamp by adjusting the screw. Ensure that the height is adjusted
before tigtening the clamp.
Step 8
Clasp the hook onto the allocated bolt on the fixture mount.
Step 7
Clasp the hook through the aircraft cable loophole created.
Step 6
Length
adjuster
*Cable length
provided is 1.7X of
ordered stem length.
Installation Instructions
Dext 2.0 Series - Stem
ADVANCED HIGH CEILING
METEOR LIGHTING P: 213.255.2060 F: 213.596.3704 www.meteor-lighting.com
*METEOR LIGHTING reserves the right to make changes to this product at any time without prior notice and such modification shall be effective immediately.
2019 V1.0 | Page 2 of 3

Wiring Diagram
0-10V / Superior 0-10V
Black(Line)
Green(Ground)
White(Neutral)
Black(Line)
Green(Ground)
White(Neutral)
Violet(Positive)
Gray(Negative)
Violet(Positive)
Gray(Negative)
0-10V Dimming
SPD
Black(Line)
Green(Ground)
White(Neutral)
Black(Line)
Green(Ground)
White(Neutral)
LED
FixtureAC
LED
Fixture
SPD
Installation Instructions
Dext 2.0 Series - Stem
ADVANCED HIGH CEILING
METEOR LIGHTING P: 213.255.2060 F: 213.596.3704 www.meteor-lighting.com
*METEOR LIGHTING reserves the right to make changes to this product at any time without prior notice and such modification shall be effective immediately.
2019 V1.0 | Page 3 of 3
