METHVEN 01-8345 User manual

Methven Australia Pty Ltd
ABN 15 104 813 390
Melbourne, Australia
www.methven.com
Note: It is the responsibility of the installer to ensure a water proof seal is
achieved between the faceplate and the finished surface of the wall. If in any
doubt about the quality of the seal, the faceplate should be removed and
then reinstalled using silicone to ensure a seal is achieved.
WMKA21005
IMPORTANT
Please read all of the instructions before installation
MA018345
Waipori 3 Hole Wall Mounted
Bath Set
01-8345
Use of this product is recommended for domestic and commercial applications.
Domestic and commercial warranty terms and conditions vary. Please refer to the Methven website
for full warranty terms and conditions - www.methven.com
All pipework must be thoroughly flushed prior to the installation of the mixer.
Inline filter washers must be installed on both hot and cold supplies to prevent foreign particles
damaging the ceramic head works.
Do not remove the ceramic head works from the mixer when installing.
Damage caused by hydrostatic testing is not covered by Methven’s warranty.
Methven recommends a licensed plumber carry out all installations in compliance with
the requirements of AS/NZS 3500. This product complies with AS/NZS 3718 regulations.
April 2012
Installation Guide
Installation
1. Screw the breech set (1) into the
mounting stud. Refer to
illustration 1. for minimum and
maximum tolerances. Plumb the
breech set (1) into system.
2. A hole diameter of 35mm will
be required for correct head
works (2) installation and a
hole diameter of 25mm will be
required for correct spout (10)
installation.
3. Screw head works (2) into
breech (1).
4. Trim brass nipple (3) to length
with a max 15mm protruding
from wall lining.
5. Insert O-ring (4) into the groove
in the bottom of the base ring
(8) and place over spindle/head
works.
6. Screw locking nut (7) over
spindle/ head works (2).
7. Place handle (9) onto spindle/
head works (2) and fasten with
a 2.5mm hex key (11).
8. Fit inlet connector (6) to brass
nipple (3) and place spout (10)
over inlet connector (6).
9. Tighten with a 2.5mm hex key
(11). 2.5mm hex key
Trim to 15mm
Ø 35mm
Ø 25mm
Ø 35mm
1.
2.
3.
4.
5.
Distance from mounting stud to
front of wall lining:
Std - 54-64mm
Ext - 64-76mm
Hot
Cold
Apply appropriate thread
sealant material
Do not discard screws
For deeper installations,
remove short threaded
headworks collars, replace
with long threaded headworks
collars and spindle extensions.
www.methven.com
Customer Care Hotline: 1300 METHVEN (638 483)
Email: [email protected].com

3
10
2
4
6
5
9
1
8
12
7
Cold handle
Grub screws
Locking nut
Base ring
Faceplate
Headworks
O-ring - base ring
Push fit
inlet connector
Breech set
(250mm ctrs)
Brass nipple
Foam seal
Hot handle
Spout
04-9905
Hot 04-9752
Standard Spindle &
Handle Assembly Set Up
Spindle Handle
Extension 04-9837
Spindle Flange M x F
Extension 04-9875
SPARE PARTS
(NOT INCLUDED)
(NOT INCLUDED)
(NOT INCLUDED)
Cold 04-9769
Product Components
Please check every component in accordance
with the table below
No. Item description Qty supplied
1 Breech Set 1
2 Headworks 2
3 Brass nipple 1
4 O-ring - base ring 2
5 Faceplate 1
6 Push fit inlet connector 1
7 Locking nut 2
8 Base ring 2
9 Handle with grub screw 2
10 Spout with grub screw 1
11 2.5mm hex key 1
12 Foam seal 1
THE METHVEN GUARANTEE
The warranty statement shall apply to all tapware & showers supplied by Methven
For more information visit www.methven.com
THIS WARRANTY ISSUED BY: Methven Australia Pty Ltd, Melbourne Australia
Technical Specification
Inlet Connections: All 1/2" BSP
Operating Pressure: 150kPa - 500kPa
For optimum performance hot and cold water pressures should be equal.
AS/NZS 3500 stipulates a 500kPa maximum operating pressure at any outlet
within a building. Where normal pressure exceeds 500kPa, a pressure limiting
valve must be installed.
Operating Temperature: Recommended hot water supply 50°C, maximum 70°C. AS/NZS 3500 requires all
hot water supplies to any sanitary fitting to be tempered to 50°C.
Ceramic cartridges: Warranty claims will be void where the ceramic head works has malfunctioned due
to the presence of the following within the water supply:
Copper tube pieces
Plastic pieces
Sand, dirt or stones
Thread tape
Other objects not normally present in the potable water supplies
Handle Parts / Assembly
www.methven.com
Customer Care Hotline: 1300 METHVEN (638 483)
Email: [email protected].com
Care and Cleaning
Never use abrasives to clean this
product. Clean regularly with
contamination free warm soapy
water and a damp soft cloth.
Damage caused by using unsuitable
cleaning agents is not covered by
warranty.
11
2.5 Hex key
