METHVEN MINIMALIST MK2 User manual

Methven warrants this product against manufacturing defects and that it is suitable for use
under the general operating conditions specified in this instruction sheet. However, regional
regulations apply and may affect your warranty. Please refer to www.methven.com or call
customer service for full details.
New Zealand
0800 804 222
Australia
13 14 16
UK
0800 195 1602
www.methven.com
Never use abrasives or abrasive cleaning agents to clean this product. Clean regularly with
contamination free warm soapy water and a damp soft cloth.
Care and Cleaning:
IS  ISSUE A
MINIMALIST MK
SHOWER MIXER/DIVERTER TRIM KIT
Installation Guide
Technical Specifications:
Operating Pressure:
Min: 150kPa/1.5bar
Max: 1000kPa/10bar*
Optimum: 150kPa/1.5bar - 500kPa/5bar
Operating Temperature:
Hot: Max 80°C*
Cold: Min 5°C
Inlet Connections:
All ½" BSP
* Regional specific regulations apply.
Please refer to your warranty statement at
www.methven.com

mm
Step 1
Pre-assemble the faceplate seal to the internal
diameter of the faceplate.
IMPORTANT: Before you begin, turn off the water supply.
•
•
•
Step 3
Remove plastic cover from mixer/diverter body.
Lubricate O-ring on mixer/diverter body and fit trim
kit sleeve.
Apply silicon to rear of faceplate sub-assembly to
create a seal with the finished wall surface. Press
faceplate onto sleeve and press up against wall
surface ensuring the logo is orientated correctly.
Fit the dome cover by screwing it onto the nut until
it contacts the sleeve.
Fit the handle body to the cartridge spindle and
secure with the short grub screw.
Fit handle pin sub-assembly to the handle body and
hand tighten.
•
•
•
•
•
Step 2
Pre-assemble the long grub screw to the handle
pin leaving 7mm of thread protruding.
Fit small O-ring to protruding grub screw.
•
Handle Body
Faceplate Seal
Sleeve
Short Grub Screw
O-ring
O-ring
Long Grub Screw
Handle Pin
Faceplate
Dome Cover
•
•
IMPORTANT: Please read all of the instructions before installation.
General:
Methven recommends this product is installed by a licensed plumber in compliance with all
relevant regional regulations.
It is the responsibility of the installer to ensure a waterproof seal is achieved between the
product and mounting surface. If in doubt about the quality of the seal, remove the product and
reinstall using silicone to ensure a seal is achieved.
