Metra Electronics 99-4000 User manual

99-4000
INSTALLATION
INSTRUCTIONS
APPLICATIONS
GENERAL MOTORS 1982-02
VEHICLES EQUIPPED WITH J-2000 PANEL-STYLE
FACTORY HEAD UNIT PROVISIONS
(SEE INSIDE FOR SPECIFIC APPLICATIONS)
KIT COMPONENTS
TOOLS REQUIRED
Socket wrench
Phillips screwdriver
Bracket Set "A"
Bracket Set "B"
Bracket
Set "C"
(2) Keps Nuts
(2) Studs
(2) Carriage Bolts
(2) Tape Strips
(2) Pal Nuts
Radio Housing
KIT FEATURES
CD jewel case
pocket
1-800-221-0932 www.metraonline.com
© COPYRIGHT 2001 METRA ELECTRONICS CORPORATION
rev. 200202 1
Please call Metra's Technical
Support line for individual
dash disassemblies.
Mount Bracket Set "A" to the
Radio Housing with (2)
Studs and (2) Pal Nuts
supplied in the kit. Skip to the
Installation Instructions for
ALL VEHICLES on Page #3.
Blazer 1998-02 / Camaro 1997-99 / Caprice 1994-96 / Cavalier 1995-99
Corvette 1997-02 / Impala SS 1994-96 / Jimmy 1998-02
Lumina 1995-99 / Malibu 1997-99 / Montana 1999
Monte Carlo 1995-99 / S-10 Pickup 1998-02 Silhouette 1997-99
Sonoma Pickup 1998-02 / TransSport 1997-98 / Venture 1997-99
1
BUICK
Century 1982-96*
Electra 1984-94*
Estate wagon 1984-94*
LeSabre 1984-94*
Park Ave. 1984-94*
Reatta 1990-91*
Regal 1984-87*
Riviera 1983-85*
Riviera 1990-95*
Roadmaster 1991-94*
Skyhawk 1982-89*
Skylark 1983-85*
Skylark 1987-89*
Skylark 1990-95*
CADILLAC
Cimarron 1982-88*
DeVille 1985-93*
Eldorado 1984-91*
Escalade 1999-02
Fleetwood 1985-93*
Seville 1984-91*
CHEVROLET (cont.)
Camaro 1997-99
Caprice 1991-93*
Caprice 1994-96
Cavalier 1982-90*
Cavalier 1991-94*
Cavalier 1995-99
Celebrity 1982-83*
Celebrity 1984-87*
Citation II 1985*
Corsica 1991-96*
Corvette 1984-89*
Corvette 1997-02
El Camino 1985-88*
Express 1996-00
Impala SS 1994-96
Lumina 1990-94*
Lumina 1995-99
Lumina APV 1990-95*
Lumina APV 1996*
Malibu 1997-99
Monte Carlo 1985-88*
Monte Carlo 1995-99
Nova 1985-88*
Pickup 1995-02
S10 Blazer 1982-85*
S10 Blazer 1986-94*
S10 Pickup 1982-85*
S10 Pickup 1986-93*
S10 Pickup 1998-02
Silverado 1999-02
CHEVROLET
Astro 1985-89*
Astro 1990-95*
Astro 1996-02
Beretta 1991-96*
Blazer (full) 1989-91*
Blazer 1998-02
Camaro 1982-84*
Camaro 1985-92*
OLDSMOBILE (cont.)
Ninety Eight 1984-90*
Omega 1983-84*
Silhouette 1990-95*
Silhouette 1996*
Silhouette 1997-99
Toronado 1982-85*
PONTIAC
6000 1982-91*
Bonneville 1982-86*
Bonneville 1987-93*
Bonneville 1994-99
Fiero 1984-88*
Firebird 1982-84*
Firebird 1985-92*
Firebird 1993-02
Grand Am 1985-91*
Grand Am 1992-95*
Grand Am 1996-98
Grand Am 1999-00
Grand Prix 1985-87*
Grand Prix 1990-93*
Grand Prix 1994-96
Grand Prix 1997-00
Montana 1999
Sunbird J-2000 1982-88*
Sunfire 1995-99
TransSport 1990-95*
TransSport 1996*
TranSport 1997-98
SATURN
(all models) 1991-94*
CHEVROLET (cont.)
Suburban 1989-91*
Suburban 1995-02
Tahoe 1995-02
Van (full) 1988-95*
Venture 1997-99
GMC
Jimmy (full) 1989-91*
Jimmy 1998-02
S15 Jimmy 1982-85*
S15 Jimmy 1986-94*
S15 Pickup 1982-85*
S15 Pickup 1986-93*
Safari 1985-89*
Safari 1990-95*
Safari 1996-02
Savana 1996-00
Sierra 1995-02
Sonoma 1998-02
Suburban 1989-91*
Suburban 1995-99
Van (full) 1988-95*
Yukon 1995-02
OLDSMOBILE
Achieva 1992-95*
Bravada 1991-94*
Cutlass Calais 1984-91*
Cutlass Ciera 1982-96*
Cutlass Supr. 1984-88*
Delta 88 1986-88*
Firenza 1982-89*
APPLICATIONS
* THE FACTORY MOUNTING BRACKET(S) MUST BE RETAINED AND USED WITH THIS VEHICLE.
THIS KIT HAS BEEN SPECIALLY DESIGNED WITH SUPPORT RIBS TO INSURE
STRUCTURAL INTEGRITY DURING SHIPPING. PLEASE CUT AND REMOVE THESE
RIBS FROM THE RADIO OPENING BEFORE BEGINNING YOUR INSTALLATION.

DIN HEAD UNITS: Slide the DIN cage into the Radio Housing and secure by bending the
metal locking tabs down. Slide the aftermarket head unit into the cage until secure.
ALL VEHICLES
3 4
Locate the factory wiring harness in the
dash. Metra recommends using the
proper mating adaptor and making
connections as shown. (Isolate and
individually tape off the ends of any
unused wires to prevent electrical short
circuit).
Re-connect the battery terminal and test the unit
for proper operation. Depending on the vehicle
you have, snap the head unit/kit assembly into
the sub-dash OR mount the head unit/kit
assembly to the sub-dash with the (4) factory
screws previously removed.
A
B
C
D
A) Strip wire ends back ½"
B) Twist ends together
C) Solder
D) Tape
2
3
2
Please call Metra's Technical
Support line for individual
dash disassemblies.
Mount Bracket Set "B" to the
Radio Housing with (2) Studs
and (2) Pal Nuts supplied in
the kit. Skip to the Installation
Instructions for ALL
VEHICLES on Page #3.
Please call Metra's Technical
Support line for individual dash
disassemblies.
Peel off the supplied Tape Strips
and attach the strips to the lower
shelves of Bracket Set "C".
Mount the Brackets to the Radio
Housing with (2) Carriage
Bolts and (2) Keps Nuts
supplied in the kit. Skip to the
Installation Instructions for ALL
VEHICLES on Page #3.
Please call Metra's Technical
Support line for individual
dash disassemblies.
Mount Bracket Set "C" to the
Radio Housing with (2)
Carriage Bolts and (2) Keps
Nuts supplied in the kit. Skip
to the Installation Instructions
for ALL VEHICLES on Page
#3.
Bonneville 1994-99 / Firebird 1993-02 / Grand Am 1996-00
Grand Prix 1994-00 / Sunfire 1995-99
1
1
1
Pickup 1995-02 / Sierra 1995-02 / Silverado 1999-02
Suburban 1995-02 / Tahoe 1995-02 / Yukon 1995-02
Astro 1996-02 / Escalade 1999-02 / Express 1996-00
Safari 1996-02 / Savana 1996-00
