Metra Electronics 99-7337B User manual

Dash Disassembly
-KIA Soul 2010-11 . .............................................. .1
Kit Assembly
- ISO Head Unit Provision.................................... . ...... 2
Final Assembly ..........................................3
TABLE OF CONTENTS
99-7337B
*Note:
Refer also to the instructions included with the aftermarket radio.
K NOWLEDGE IS P OWER
Enhance your installation and fabrication skills by
enrolling in the most recognized and respected
mobile electronics school in our industry.
Log onto www.installerinstitute.com or call
800-354-6782 for more information and take steps
toward a better tomorrow.
Metra recommends MECP certified
technicians.

99-7337B DASH DISASSEMBLY
KIA SOUL 2010-11
1
Disconnect the negative battery ter-
minal to prevent an accidental short
circuit.
1
Unclip and remove the radio/climate
control trim panel. (Figure A)
2
Remove (4) Phillips screws securing
the climate control. (Figure B)
3
Remove (4) Phillips screws securing
the radio. (Figure C)
4
Continue to kit assembly.
A
B
C

2
99-7337B KIT ASSEMBLY
B
A
ISO HEAD UNIT PROVISION
Slide the head unit into the bracket /
radio housing assembly and secure
using the ISO screws supplied with
the radio.
(Figure B)
2
Locate the factory wiring harness in
the dash. Metra recommends using
the proper mating adapter from
Metraor AXXESS.Re-connect the
negative battery terminal and test
the unit for proper operation.
3
Reassemble dash in reverse order of
disassembly.
4
Continue to final assembly.
*Note: Refer also to the instructions included with the aftermarket radio.
Attach the ISO brackets to the radio
housing. (Figure A)
1

99-7337B FINAL ASSEMBLY
FINAL ASSEMBLY
(A) Strip wire ends back 1/2"
B) Twist ends together
C) Solder
D) Tape
A
B
C
D
Locate the factory wiring harness in the dash. Metra recommends using the
proper mating adapter and making connections as shown. (Isolate and individ-
ually tape off the ends of any unused wires to prevent electrical short circuit.)
Re-connect the negative batteryterminal and test the unit for proper operation.
Reassemble radio and dash assemblies in reverse order of disassembly.
1
2
3
3
FINAL WIRING CONNECTIONS
Make wiring connections using the EIA color code chart shown belowand the instructions included with the
head unit. Metra recommends making connections as shown below; Strip, Splice, Solder, Tape. Isolate and
individually tape off ends of anyunused wires to prevent electrical short circuit.
METRA / EIA WIRING CODE
12V Ignition / Acc. . . . . . . . . . Red
12V Batt / Memory. . . . . . . . . Yellow
Ground. . . . . . . . . . . . . . . . . . Black*
Power Antenna. . . . . . . . . . . . Blue
Amp Turn-On . . . . . . . . . . . . . Blue / White
Amp Ground. . . . . . . . . . . . . . Black / White
Illumination . . . . . . . . . . . . . . Orange
Dimmer.................Orange / White
Right Front (+) . . . . . . . . . . . . Gray
Right Front (-). . . . . . . . . . . . . Gray/ Black
Left Front (+) . . . . . . . . . . . . . White
Left Front (-). . . . . . . . . . . . . . White / Black
Right Rear (+) . . . . . . . . . . . . Violet
Right Rear (-) . . . . . . . . . . . . . Violet / Black
Left Rear (+) . . . . . . . . . . . . . Green
Left Rear (-) . . . . . . . . . . . . . . Green / Black
*NOTE: When a Black wire is not present, ground radio to vehicle chassis.
All colors may not be present on all leads due to manufacturer’s specifications.

99-7337B
NOTES
4

99-7337B
NOTES
5

99-7337B INSTRUCTIONS
1-800-221-0932
REV. 09/01/10 © COPYRIGHT 2004-2010 METRA ELECTRONICS CORPORATION INST99-7337B
www.metraonline.com
