MG R5-RS1A User manual

MG CO., LTD. www.mgco.jp
5-2-55 Minamitsumori, Nishinari-ku, Osaka 557-0063 JAPAN
BEFORE USE ....
Thank you for choosing us. Before use, please check con-
tents of the package you received as outlined below.
If you have any problems or questions with the product,
please contact our sales office or representatives.
■PACKAGE INCLUDES:
RTD input module...............................................................(1)
■MODEL NO.
Confirm Model No. marking on the product to be exactly
what you ordered.
■INSTRUCTION MANUAL
This manual describes necessary points of caution when
you use this product, including installation, connection and
basic maintenance procedures.
POINTS OF CAUTION
■CONFORMITY WITH EU DIRECTIVES
• The equipment must be mounted inside the instrument
panel of a metal enclosure.
• Insert noise filters for the signal I/O connected to the
unit. COSEL Model NAC-06-472 or equivalent is recom-
mended.
• The actual installation environments such as panel con-
figurations, connected devices, connected wires, may af-
fect the protection level of this unit when it is integrated
in a panel system. The user may have to review the CE
requirements in regard to the whole system and employ
additional protective measures to ensure the CE conform-
ity.
■HOT SWAPPABLE MODULES
• Replacing the module does not affect other modules on
the same base. Thus, the module can be replaced while
the power is ON. However, replacing multiple modules
at once may greatly change live voltage levels. We highly
recommend to replace them one by one.
■GENERAL PRECAUTIONS
• DO NOT set the switches while the power is supplied.
The switches are used only for maintenance without the
power.
■ENVIRONMENT
• Indoor use.
• When heavy dust or metal particles are present in the
air, install the unit inside proper housing with sufficient
ventilation.
• Do not install the unit where it is subjected to continuous
vibration. Do not subject the unit to physical impact.
• Environmental temperature must be within -10 to +55°C
(14 to 131°F) with relative humidity within 30 to 90% RH
in order to ensure adequate life span and operation.
■WIRING
• Do not install cables close to noise sources (relay drive
cable, high frequency line, etc.).
• Do not bind these cables together with those in which
noises are present. Do not install them in the same duct.
■AND ....
• The unit is designed to function as soon as power is sup-
plied, however, a warm up for 10 minutes is required for
satisfying complete performance described in the data
sheet.
INSTALLATION
Use the Installation Base (model: R5-BS).
RTD INPUT MODULE
(re-transmitted output) MODEL R5-RS1A
EM-7558 Rev.4 P. 1 / 4
INSTRUCTION MANUAL

MG CO., LTD. www.mgco.jp
5-2-55 Minamitsumori, Nishinari-ku, Osaka 557-0063 JAPAN
COMPONENT IDENTIFICATION
RUN LED
ON
12345678 Zero/Span Adj.
Mode Selector
5
4
3
2
1
0
9
8
7
6
456
123
RUN
UP
DOWN
UP Button
DOWN Button
RTD Burnout
Temp. Unit
Function
■ SIDE VIEW ■FRONT VIEW
Euro Type
Connector Terminal
■SIDE DIP SW
(*) Factory setting
RTD type, temperature unit and burnout are selectable
with the side DIP switches.
• RTD: SW1, 2, 3, 4
SW RTD
1234
ON OFF ON OFF Cu 10 @ 25°C
OFF OFF OFF OFF Cu 50
OFF OFF OFF ON JPt 100 (JIS ’89)
ON OFF OFF OFF Pt 100 (JIS ’89)
OFF ON OFF OFF Pt 100 (JIS ’97, IEC) (*)
OFF ON ON OFF Pt 1000
ON ON OFF OFF Pt 50 Ω (JIS ’81)
OFF OFF ON OFF Ni 100
ON ON ON OFF Ni 508.4 Ω
• Temperature Unit: SW5, 6
SW TEMP.
UNIT
5 6
OFF OFF °C (*)
ON OFF °F
ON ON K
• Burnout: SW7
SW BURNOUT
7
OFF Downscale
ON Upscale (*)
Note: Be sure to set unused SW8 to OFF.
R5-RS1A
EM-7558 Rev.4 P. 2 / 4

MG CO., LTD. www.mgco.jp
5-2-55 Minamitsumori, Nishinari-ku, Osaka 557-0063 JAPAN
■ZERO/SPAN ADJ. MODE SELECTOR ROTARY SW
SW MODE *1FUNCTION RUN LED *1
0 (*) Monitor Output % proportional to the Input % Red/Green ON *2
1
2
3
Output 0% adjustment Increments by 1
Increments by 5
Increments by 10
Red Blinking
4
5
6
Output 100% adjustment Increments by 1
Increments by 5
Increments by 10
Green Blinking
7
8
9
Simulated output Simulates output 0%
Simulates output 50%
Simulates output 100%
Orange Blinking
(*) Factory setting
*1. When switching Monitor mode to another, set the rotary switch to a desired SW position and then press UP/DOWN button, so
that the mode is switched. Along with mode switching, RUN LED turns to blinking as shown in the table. Setting the rotary
switch to 0, the mode is automatically switched to Monitor mode in a few seconds.
*2. Red when the bus A operates normally;
Green when the bus B operates normally;
Amber when both buses operate normally.
• Zero/Span Adjustment Modes
Monitor Mode
Re-transmits the input signal as output in proportion.
Output 0% Adjustment Mode
Adjusts the 0% output signal using the front UP/DOWN
buttons, in monitoring the output value with a multimeter.
SW1 through SW3 switch the internal increments by 1, 5
and 10.
Output 100% Adjustment Mode
Adjusts the 100% output signal using the front UP/DOWN
buttons, in monitoring the output value with a multimeter.
SW4 through SW6 switch the internal increments by 1, 5
and 10.
Simulated Output Mode
Outputs the simulated signals of 0%, 50% and 100%.
• How to Operate
1) Start up in Monitor Mode (SW position = 0) and wait for
2 or 3 seconds.
2) Switch to another mode and go through the adjustments.
3) Reset the switch to the position ‘0’ so that the new setting
is stored in the internal memory.
PC CONFIGURATOR
With configurator software, settings shown below are available.
Refer to the software manual of R5CON for detailed operation.
■CHANNEL INDIVIDUAL SETTING
PARAMETER AVAILABLE RANGE DEFAULT SETTING
Zero Scale -32000 to +32000 0
Full Scale -32000 to [phone]
Bias [Zero Adj.] -320.00 to +320.00 0.00
Gain [Span Adj.] -32000 to +32000 1.0000
Zero Base Depends on sensor type 0.00
Full Base Depends on sensor type 0.00
■CHANNEL BATCH SETTING
PARAMETER AVAILABLE RANGE DEFAULT SETTING
Limit No check mark: Limits to the scaling values equivalent to -15 % to
+115 %.
Check-marked: Limits within Zero Scale to Full Scale.
No check mark
R5-RS1A
EM-7558 Rev.4 P. 3 / 4

MG CO., LTD. www.mgco.jp
5-2-55 Minamitsumori, Nishinari-ku, Osaka 557-0063 JAPAN
TERMINAL CONNECTIONS
Connect the unit as in the diagrams below.
■EXTERNAL DIMENSIONS unit: mm (inch)
456
123
6.5
(.26)
90 (3.54) LOCKING CLAMP
90 (3.54) 5.6
(.22)
18 (.71)
POSITIONING GUIDE
■CONNECTION DIAGRAM
4
5–
+
BUS CONNECTOR
INTERNAL POWER
INTERNAL BUS A
INTERNAL BUS B*
*For dual redundant communication.
OUTPUT
1
2
A
B
B
RTD
3
WIRING INSTRUCTIONS
■EURO TYPE CONNECTOR TERMINAL
Applicable Wire size: 0.2 – 2.5 mm2
Stripped length: 7 mm
R5-RS1A
EM-7558 Rev.4 P. 4 / 4
